JAI GO-5000M-PMCL-UV User manual

User Manual
Thank you for purchasing this product.
Be sure to read this manual before use.
This manual includes important safety precautions and instructions on how to operate the unit. Be sure to read
this manual to ensure proper operation.
The contents of this manual are subject to change without notice for the purpose of improvement.
© 2021 JAI
CMOS Digital Progressive Scan
Monochrome UV Camera
Document Version: 1.0
GO-5000M-PMCL-UV_Ver.1.0_Feb.2021
GO-5000M-PMCL-UV

Notice/Warranty/Certifications
3
Trigger Control
39
Usage Precautions
5
Normal continuous operation
40
Features
6
Timed mode
41
Parts Identifications
7
Trigger width mode
42
RCT mode
43
Preparation
9
Sequence Mode
45
Preparation Process
9
Multi ROI function
47
Step 1: Connecting Devices
10
Operation and function matrix
49
Step 2: Verifying Camera Operation
12
Black level control
50
Step 3: Verifying the Connection between
Gain control
50
the Camera and PC 12
LUT
52
Step 4: Changing the Camera Settings
13
Gamma
52
Step 5: Adjusting the Image Quality
14
Shading Correction
53
Step 6: Saving the Settings
15
Blemish compensation
54
ALC
54
Main Functions
17
HDR(High Dynamic Range)
55
Camera Link Interface
17
External appearance and dimensions
56
Digital IN/OUT interface
19
Spectral response
57
Pulse Generator
21
Specifications table
58
Sensor layout
24
Appendix
60
Camera ouput format(Tap Geometry)
24
User's Record
73
Output timing(Horizontal)
27
Output timing(Vertical)
32
ROI(Region Of Interest) setting
35
Digital ouput Bit allocation
35
Acquisition Control
36
Exposure setting
37
Contents
—2 —
GO-5000M-PMCL-UV

—3 —
Notice
The material contained in this manual consists of information that is proprietary to JAI Ltd.,
Japan and may only be used by the purchasers of the product. JAI Ltd., Japan makes no
warranty for the use of its product and assumes no responsibility for any errors which may
appear or for damages resulting from the use of the information contained herein. JAI Ltd.,
Japan reserves the right to make changes without notice.
Company and product names mentioned in this manual are trademarks or registered
trademarks of their respective owners.
Warranty
For information about the warranty, please contact your factory representative.
Certifications
CE compliance
As defined by the Directive 2004/108/EC of the European Parliament and of the Council, EMC
(Electromagnetic compatibility), JAI Ltd., Japan declares that GO-5000M-PMCL-UV comply with
the following provisions applying to their standards.
EN 61000-6-3 (Generic emission standard part 1)
EN 61000-6-2 (Generic immunity standard part 1)
FCC
This equipment has been tested and found to comply with the limits for a Class A digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Warning
Changes or modifications to this unit not expressly approved by the party responsible for FCC
compliance could void the user’s authority to operate the equipment.
GO-5000M-PMCL-UV

—4 —
Supplement
The following statement is related to the regulation on “Measures for the Administration
of the control of Pollution by Electronic Information Products“ ,known as “China RoHS“.
The table shows contained Hazardous Substances in this camera.
mark shows that the environment-friendly use period of contained Hazardous
Substances is 15 years.
GO-5000M-PMCL-UV

Usage Precautions
Notes on cable configurations
The presence of lighting equipment and television receivers nearby may result in
video noise. In such cases, change the cable configurations or placement.
Notes on attaching the lens
Avoiding dust particles
When attaching the lens to the camera, stray dust and other particles may adhere
to the sensor surface and rear surface of the lens. Be careful of the following
when attaching the lens.
• Work in a clean environment.
• Do not remove the caps from the camera and lens until immediately before
you attach the lens.
• To prevent dust from adhering to surfaces, point the camera and lens
downward and do not allow the lens surface to come into contact with your
hands or other objects.
•Always use a blower brush to remove any dust that adheres.
Never use your hands or cloth, blow with your mouth, or use other methods to
remove dust.
Phenomena specific to CMOS image sensors
The following phenomena are known to occur on cameras equipped with CMOS
image sensors. These do not indicate malfunctions.
• Aliasing
When shooting straight lines, stripes, and similar patterns, vertical aliasing
(zigzag distortion) may appear on the monitor.
• Blooming
When strong light enters the camera, some pixels on the CMOS image sensor
may receive much more light than they are designed to hold, causing the
accumulated signal charge to overflow into surrounding pixels.This
“blooming” phenomenon can be seen in the image, but does not affect the
operation of the camera.
• Fixed pattern noise
When shooting dark objects in high-temperature conditions, fixed pattern noise
may occur throughout the entire video monitor screen.
• Defective pixels
Defective pixels (white and black pixels) of the CMOS image sensor are
minimized at the factory according to shipping standards. However, as this
phenomenon can be affected by the ambient temperature, camera settings
(e.g., high sensitivity and long exposure), and other factors, be sure to operate
within the camera’s specified operating environment.
Notes on exportation
When exporting this product, please follow the export regulations of your country
or region.
—5 —
GO-5000M-PMCL-UV

Features
Connection example:
— 6 —
The GO-5000M-PMCL-UV is an industrial progressive scan camera equipped with a
1-inch global shutter CMOS image sensor with 5.2 effective megapixels (2560 ×2048).
This CMOS image sensor has sensitivity in the UV region.
The unit is compact and lightweight in design and is equipped with Mini Camera Link interface
Supporting a “Power over Camera Link” capability.
Compact and lightweight
The unit’s compact size (approx. 29 ×29 ×41.5 mm, excluding lens mount) and lightweight
design (approx. 46 g) allows for easy assembly and installation.
Feature overview
New small-in-size 1-inch CMOS 5-megapixel progressive scan camera
Utilizes two Mini Camera Link interfaces to support Base, Medium or Full configurations
Aspect ratio 5:4, 2560 (H) x 2048 (V) -5 million effective pixels
5 μm square pixels
S/N 55dB (Dark compression is used, traditional measurement method)
8-bit, 10-bit or 12-bit output for monochrome and Bayer
107.2 frames/second with full resolution in continuous operation for 8-tap, 63.6
frames/second for 4-tap, 47.8 frames/second for 3-tap, and 31.9 fps for 2-tap readout
Supports ROI (Region Of Interest) modes for faster frame rate
0dB to +24dB gain control
10 μs (1/100,000) to 8 seconds exposure control in 1 μs step
Auto exposure control
Timed and trigger width exposure control
RCT trigger mode for specific applications
ALC control with combined function of AGC and Auto Shutter
Various pre-processing circuits are provided
Programmable LUT
Gamma correction (3 steps: 0.45, 0.6 and 1.0)
Shading correction
Blemish compensation
HDR (High Dynamic Range) function
C-mount for lens mount
Accepts power over Mini Camera Link
GO-5000M-PMCL-UV

Parts Identification
①Lens mount（C-mount）
Mount a C-mount lens, microscope adapter, etc. here.
❖Before mounting a lens, be sure to refer to “Step 2:Connecting Devices” and confirm
the precautions for attaching a lens and the supported lens types.
—7 —
GO-5000M-PMCL-UV

②POWER/TRIG LED
Indicates the power and trigger input status.
LED status and camera status
LED Light Status
POWER/
TRIG LED
（Lit amber）Camera initializing.
（Lit green）Camera in operation.
（Blinking green）During operation in trigger mode, trigger signals are
being input.
❖The blinking interval is not related to the actual input interval of
the external trigger.
③Camera Link Connector 1
Connect a cable that is compatible with Mini Camera Link (SDR) connectors here.
④Camera Link Connector 2
Connect a cable that is compatible with Mini Camera Link (SDR) connectors here.
—8 —
GO-5000M-PMCL-UV
Pin No.
Input/Output
Signal Description
1, 26 Power Power
2(－), 15(＋) Out X_OUT0 Data out
3(－), 16(＋) Out X_OUT1 Data out
4(－), 17(＋) Out X_OUT2 Data out
5(－), 18(＋) Out X_Clk CL Clock
6(－), 19(＋) Out X_OUT3 Data out
7(＋), 20(－) In SerTC (RxD)
8(－), 21(＋) Out SerTFG (TxD)
9(－), 22(＋) In CC1 (Trigger) JAI standard trigger
10(＋), 23(－) In CC2 (Reserved)
11,24 N.C.
12,25 N.C.
13,14 Shield GND
LVDS Serial Control
Pin No. Input/Output Signal Description
1, 26 Power Power
2(－), 15(＋) Out Y_OUT0 Data out
3(－), 16(＋) Out Y_OUT1 Data out
4(－), 17(＋) Out Y_OUT2 Data out
5(－), 18(＋) Out Y_Clk CL Clock
6(－), 19(＋) Out Y_OUT3 Data out
8(－), 21(＋) Out Z_OUT0 Data out
9(－), 22(＋) Out Z_OUT1 Data out
10(＋), 23(－) Out Z_OUT2 Data out
11(－), 24(＋) Out Z_CLK CL Clock
12(＋), 25(－) Out Z_OUT3 Data out
13,14 Shield GND
⑤Camera locking screw holes（M3, 3mm depth）
Use these holes when attaching an MP-43 tripod adapter plate (optional) or
mounting the camera directly to a wall or other structural system.

Preparation
Preparation Process
— 9 —
GO-5000M-PMCL-UV
Step 1
Connecting Devices
Connect the lens, CameraLink cable, AC adapter, computer, and other devices.
Step 5
Adjusting the Image Quality
Refer to the procedures for adjusting the gain, white balance, and black level as
examples, and adjust the image quality.
Step 6
Saving the Settings
Save the current setting configurations in user memory.
Step 2
Verifying Camera Operation
Verify whether the camera is turned on and ready for use.
Step 3
Verifying the Connection between the Camera and PC
Verify whether the camera is properly recognized via Control Tool.
Step 4
Changing the Camera Settings
Refer to the procedure for changing the output format setting as an example, and
change various settings as necessary.
The most universal method for controlling a Camera Link camera such as the GO-5000M-
PMCL-UV is by the use of short ASCII commands sent via serial communications. All
Camera Link frame grabber boards support the use of these short ASCII commands.
SDKs that utilize these ASCII commands for developing machine vision applications are
typically available from the grabber manufacturer, as well as from third-party vendors.
This section describes how to configure various camera settings using serial
communication and specific short ASCII commands. A complete list of all available ASCII
commands for this camera can be found at the end of this manual.
Later sections of the manual refer to GenICam nomenclature for various
features/functions, and includes a complete list of all camera settings starting on Page 54.
The GO-5000M-PMCL-UV fully supports applications written using GenICam-based SDKs.
The advantage of this is that programs written using GenICam names can be applied with
little or no modification to control cameras with other GenICam-compliant interfaces and
even GenICam-compliant cameras from different vendors.
Short ASCII commands

Step 1: Connecting Devices
—10 —
GO-5000M-PMCL-UV
①Lens
Camera body ③Camera Link Cable
②Direct connection
(or MP-45 tripod adapter plate)
④Frame grabber board
or
①Lens
・C-mount lenses with lens mount protrusions of 10 mm or less can be attached.
Lens mount protrusion
Lens
10 mm or less
・To prevent vignetting and to obtain the optimal resolution, use a lens that will cover
the image sensor size.
・The maximum performance of the camera may not be realized depending on the lens.
・Attaching a lens with a mount protrusion of 10 mm or longer may damage the lens or
camera.
Caution
Model name
GO-5000M-PMCL-UV Mono 1 inch
12.8mm x 10.24mm (16.392mm diagonal)
Image Sensor
Note
The following formula can be used to estimate the focal length.
Focal length ＝WD /（1 ＋W/w）
WD ：Working distance （distance between lens and object）
W ：Width of object
w：Width of sensor

—11 —
②Direct connection（or MP-43 tripod adapter plate）
When mounting the camera directly to a wall or other device, use screws that match the
camera locking screw holes on the camera (M3, depth: 3 mm). Use the supplied screws to
attach the tripod adapter plate.
For heavy lenses, be sure to support the lens itself. Do not use configurations in which its weight
is supported by the camera.
Caution
③Camera Link cable
Connect the Camera Link cable to the Mini Camera Link connector.
•Use a cable that supports the Camera Link standard and is compatible with Mini Camera Link
(SDR) connectors.
•Refer to the specifications of the cable for details on its bend radius.
•For details on the cable, see “②Mini Camera Link connector”
④Frame grabber board
Refer to the operating instructions of the frame grabber board, and configure settings on
the computer as necessary.
GO-5000M-PMCL-UV
Secure the locking screws on the connector
manually, and do not use a driver. Do not secure
the screws too tightly. Doing so may wear down the
screw threads on the camera. (Tightening torque:
0.291±0.049 N·m or less) Secure manually.
Do not secure too tightly.
Caution

—12 —
Step 2: Verifying Camera Operation
When power is supplied to the camera while the necessary equipment is connected, the
POWER/TRIG LED at the rear of the camera lights amber, and initialization of the camera
starts.When initialization is complete, the POWER/TRIG LED lights green.
Verify whether power is being supplied to the camera by checking the rear LED.
When properly turned on
* For details on how to read the LEDs, see “LED status and camera status” in the “Parts
Identification” section.
GO-5000M-PMCL-UV
Lit green
Step 3: Verifying the Connection between the Camera
and PC
Use a short ASCII command to verify whether the GO-5000M-PMCL-UV is properly recognized
in your setup.
Please install terminal emulator software capable of serial communication to the PC connected
to the camera via the frame grabber board.
Then set the following serial communication.
Please enter the command DVN? <CR><LF> from the terminal emulator software.
If correctly connected, response DVN = JAI Corporation will be displayed.
Item Short ASCII command Description
DeviceVendorName DVN
Display the device vendor name.
"JAI Corporation"

Item Default value
ImageFormatControl Width 2560
Height 2048
OffsetX (horizontal position) 0
OffsetY (vertical position) 0
PixelFormat Mono8
—13 —
GO-5000M-PMCL-UV
1Example of changing the [Width] setting of [ImageFormatControl].
Use the Short ASCII command WTC.
You can check the current [Width] setting with WTC? <CR> <LF>.
To change the setting of [Width] to 2480, execute the following command.
WTC=2480<CR><LF>
To change the settings of other items, please use the Short ASCII command below.
2Example of changing the [PixelFormat] setting of［ImageFormatControl］.
Step 4: Changing the Camera Settings
This section explains how to change settings by describing the procedure for changing the
output format as an example.
Configuring the Output Format
Configure the size, position, and pixel format of the images to be acquired.
The factory settings are as follows. Change the settings as necessary.
Factory default values
* You can specify the image acquisition area. For details, see “ROI (Regional Scanning Function)”.
Use the Short ASCII command BA.
You can check the current [PixelFormat] setting with BA? <CR> <LF>.
To change the setting of [PixelFormat] to Mono10, execute the following command.
BA=1<CR><LF>
Width WTC
2～2560
2 pixels/step
Height HTL
1～2048
1 lines/step
OffsetX OFC
0～2558
2 pixels/step
OffsetY OFL
0～2047
1 lines/step
PixelFormat BA
0. Mono8
1. Mono10
2. Mono12

—14 —
GO-5000M-PMCL-UV
Step 5: Adjusting the Image Quality
Display the camera image and adjust the image quality.
Displaying the Image
Display the image captured by the camera.
Please display the image with the viewer on the frame grabber board application.
Item Short ASCII Command Description
GainRawDigitalAll FGA
It can be set in the range from 1 time to
16 times.
Please specify with a value between 100
and 1600.
AnalogBaseGainAll ABALL
It can be set in the range from 0 to 2.
(0:0dB, 1:6dB, 2:12dB)
GainAuto AGC
0:Off, 1:Continuous
Adjusting the Gain
Adjusting the Black Level
The gain control uses Analog Base Gain and Digital Gain.
Analog Base Gain can be set at 0dB, +6dB or +12dB.
The digital gain is used for the master gain setting.
For setting the gain,
1. Set analog gain (Select from 0dB, +6dB and +12dB)
2. Set digital gain
The master gain (DigitalAll) can be set x1 (0dB) to x16 (+24dB) against the analog
base gain. The resolution for gain setting is x0.01/step which is 0.05dB to 0.08dB,
depending on the setting value.
The black level can be set in the following range.
GO-5000M-PMCL-UV: DigitalAll：-256～+255
Item Short ASCII Command Description
BlackLevelRawAll BL
It can be set in the range from -256 to
255.

—15 —
Step 6: Saving the Settings
The setting values configured will be deleted when the camera is turned off. By saving
current setting values to user memory, you can load and recall them whenever necessary.
You can save up to three sets of user settings in the camera. (UserSet1 to UserSet3)
■To save user settings
1Stop image acquisition.
2Specify the storage location (UserSet1 -UserSet3) using the UserSetSave
command and save the current camera settings.
Note
The factory default setting values are stored in [Default] and cannot be overwritten.
Settings can only be saved when image acquisition on the camera is stopped.
Caution
eBUS SDK for
JAI (Player)
一時メモリ
UserSet1
UserSet2
UserSet3
DefaultSet
Working Set
Memory(Flash)
Memory(RAM)
GO-5000M-PMCL-UV
To save to UserSet1, execute the command SA=1<CR><LF>.
Item Short ASCII command Description
UserSetLoad LD
Set the specified user setting to the
camera.
0: Default
1: UserSet1
2: UserSet2
3: UserSet3
UserSetSave SA
Save the current camera settings in the
specified user setting area.
1: UserSet1
2: UserSet2
3: UserSet3

—16 —
GO-5000M-PMCL-UV
■To load user settings
1Stop image acquisition.
User settings can only be loaded when image capture on the camera is stopped.
2Specify the storage location (UserSet1 -UserSet3) using the UserSetLoad
command and read the settings of the camera.
To read the settings saved in UserSet 1, execute the command LD=1<CR><LF>.

—17 —
Main Functions
Camera Link Interface
GO-5000M-PMCL-UV

—18 —
GO-5000M-PMCL-UV
Note
1. In this table, not all tap geometry items are described. For instance, 1X4–1Y shows only 12-bit.
In case of 10-bit, upper 2 bits (D10 and D11) are not used and in case of 8-bit, upper 4 bits
(D8 through D11) are not used.
2. Please check whether the frame grabber complies with those formats if you use 80-bit
(8-tap/10-bit) camera configuration.
3. If you use 80-bit (8-tap/10-bit) camera configuration, DVAL and Exposure Active (JAI custom)
are not output through the Camera Link interface. FVAL is only output via Digital I/O-1
connector.
Camera Link pixel clock frequency
In the GO-5000M-PMCL-UV, the Camera Link pixel clock can be selected from 84.99 MHz, 72.85
MHz, 58.28 MHz, and 48.57 MHz. If the 48.57MHz clock is used, the transfer length through the
camera link cable will be extended to 10m for all tap geometries. On the other hand, the frame rate
will be reduced (see table). The default setting is 72.85 MHz.
Note: The maximum lengths shown in the above table are guidelines. Operating at these lengths
may generate bit noise, depending on the cable used.

—19 —
Digital IN/OUT interface
In the GO-5000M-PMCL-UV, the software control tool can assign the necessary signals used in
the system to digital inputs and outputs.
Line Selector
In the Line Selector, the following input and output signals can be assigned.
Line Source
Line source signal can be selected from the following table to connect it to the line item
which is selected in the line selector.
Line Mode
Indicates the status of the item selected in Line Selector. (INPUT or OUTPUT)
Line Inverter
Inverts the signal polarity for the item selected in Line Selector. (False=Positive, True=Negative)
Line Status
Indicates the status of the selected signal (input or output) (True=High, False=Low)
GO-5000M-PMCL-UV
Note)
As for LVAL, some line items cannot be connected. Refer to “GPIO matrix table”.
Line Format
Indicates the interface information of the input and output lines.
Not connected, TTL, LVDS or Opto-coupled
Note: In the GO-5000M-PMCL-UV, Opto-coupled interface is not available.

—20 —
GO-5000M-PMCL-UV
Basic block diagram
GPIO
GPIO is a general interface for input and output which controls the I/O for trigger signals and
other valid signals and pulse generators. By using this interface you can control an external light
source, make a delay function for an external trigger signal, or make a precise exposure setting
together with a PWC trigger.
GPIO IN/OUT Matrix
