Jam Aqualarm LeakSense 2 Manual instruction

Tel:
+44
(0)191 490 1547
Fax: [phone]
Email: [e-mail]
Website: www.heattracing.co.uk
www.thorneanderrick.co.uk

CONTENTS
Section Page No.
A INSTALLATION
1. Control Panel 3
2. Leader / Jumper cable 3
3. Detecting cable 3
B TESTING
1. Installed Cables 4
C CONTROL PANEL
1. Start-Up Procedure 5
2. Set-Up Time & Date 6
3. Mapping Procedure 6
D CONTROL PANEL OUTPUTS
1. Relay Outputs 7
2. RS-232 8
3. RS-485 8
E CONTROL PANEL FUNCTIONS
1. Test / Mute / Reset Keys 9
2. View 100 Event Record Log 10
3. What to do if an Alarm Sounds 10
F MAINTENANCE & CABLE CARE
1. Maintenance 14
2. Cable Care 15
G EQUIPMENT
1. Control Panel Terminals 16
2. Ancillary Equipment 16
3. Spares 17
4. Mapping Results Sheets 18
5. Certificates 20
6. Control Panel Facia / CE Mark 23
READ IMPORTANT INSTRUCTIONS 24
- 2 -

Section A
Installation
1. Control Panel
i. The LeakSense 2i Control Panel should be sited in a position
where the ‘Alarm Horn’ can be heard and at a height where the
LCD Screen can be seen. SEE PAGE 20 BEFORE INSTALLING.
ii. A 220/240 volt 50 Hz single phase power supply via a non-
switched fused spur should be made available adjacent to the
Control Panel prior to the start of the installation and should be
connected to the Control Panel by a competent qualified person.
DO NOT CONNECT POWER TO THE CONTROL PANEL OR
THE BATTERIES YET . (SEE PAGE 15 FOR CONNECTIONS.)
2. Leader / Jumper cables
NOTE: Only J.A.M. Ltd. Leader & Jumper Cables must be used.
i. The Leader cable (LS-LC) should be installed first. The bare
end of the Leader cable, consisting of 2 cores, should be installed
ready to connect into the Control Panel via the knockout provided
and with a suitable cable gland to the terminals marked ‘CD-X’.
ii. The cores can be connected to either terminal as there is no
polarity. DO NOT CONNECT TO THE CONTROL PANEL YET.
iii. The connectorized end of the Leader cable (female) is to be
connected to the first piece of Detecting cable (CD-x).
iv. Detecting cables (CD-x) & Jumper cables (LS-JC) are
connectorized at both ends (one end female the other end male, the
female end should always be at the furthest end of the piece of cable
you have just installed). The Jumper cable (LS-JC) is to be used
where it is required to connect Detecting cables (CD-x) installed in
different areas.
v. Ensure all cables are installed Securely.
3. Detecting cable
i. Detecting cable (CD-x) should be installed using the following
methods:-
a. Clip to the underside of pipe-work using nylon type cable ties at
300 mm centres..
b. Clip to the floor slab or other flat surface using ‘aqualarm’
floor clips (CL-1) hot melt glued or screwed to the surface at
500 mm centres. (Do not rely on sticky back pads only)
- 3 -

Section A …… cont
ii. IMPORTANT NOTES;-
a. Do not use metal ties or straps as they can damage the
Detecting cable.
b. Do not over tighten the cable ties.
c. Detecting cable should never be installed between pipe-
work and its insulation. It must be installed on the outside
of any insulation finish.
d. ‘aqualarm’ WARNING LABELS (WL-1) should be fitted at
5m intervals along the entire length of all cables installed.
Where cables go through walls etc. the WL-1 should be
fitted either side of the wall.
Section B
1. Testing Installed Cables
i. When all your Leader / Detecting / Jumper cables have been
installed, the total length should be Tested as follows :-
ii Ensure that all the cables are connected together BUT DO NOT
CONNECT the Leader cable to the Control Panel AT THIS STAGE.
iii. Connect the End of line resistive plug (EOL-2) to the end of the
last length of cable installed.
iv. Carry out the following ‘TEST’ using a Multimeter to ensure the
integrity of the installed cables.
v. Set Multimeter to read a resistance above 100 ohms. Connect
the Multimeter leads to the bare cores of the Leader Cable. The
following should be noted:-
CONDITION POSSIBLE FAULT
No resistance a. EOL-2 not fitted at end (Open
Circuit)
b. Cable disconnected along the
installed length.
Resistance reading
below 45 ohms a. Cable is damaged (Short Circuit)
b. Cable is wet (Rectify)
Resistance reading
above 50 ohms. a. All cables are correct. System is
ready to connect to Control Panel.
- 4 -

Section C
Control Panel.
1. Start-Up Procedure.
i. On completion of the Installation of all Leader / Detecting &
Jumper cables, the following procedure should be used to Start-Up
the system :-
ii Ensure that all the cables are connected together and that the
End of Line resistive plug (EOL-2) has been connected at the end of
the last length of cable installed & that they have been tested as
described in Section ‘B’.
iii. Connect the Leader cable (LS-LC) to the Control Panel Terminals
marked ‘CD-x’ via a suitable cable entry gland.
iv. Cause a competent qualified person to connect the Battery
Back-Up leads to the correct terminals of the sealed Lead Acid
Batteries and the Control Panel to the Mains Power supply as
described in Section ‘A’.
(See also page 15, Control Panel Terminals.)
v. Close & Lock the Control Panel door & Switch on the Mains
Power supply.
vi. The Control Panel will Automatically recognise the characteristics
& length of the cables connected to the system.
vii. The LCD screen will now DISPLAY the following:-
viii. The Heart will pulse to show that the Power Supply is connected.
- 5 -
aqualarm Environmental Monitoring System
SET
TIME TIME DATE
SYSTEM CLEAR
VIEW
LOGS
SHOW
CABLE
TEST
Screen ‘A’

Section C …… cont
ix. Press the button corresponding to the ‘SHOW CABLE’ key.
x. The LCD screen will DISPLAY the following:-
xi. The cable Characteristics of your system should look similar to
that displayed.
xii. Press the button corresponding to the ‘SHOW TEXT’ key, the
screen will revert back to Screen ’A’.
2. Set-Up Time & Date.
i. Press the button corresponding to the ‘SET TIME’ key.
ii. The LCD screen will DISPLAY the following:-
iii. The Hours will be highlighted. Using the buttons corresponding
to the + / - keys, set the hours.
iv. Continue using the buttons corresponding to the ARROW keys,
to highlight the Minutes, then the date. Use the + / - keys to set the
Minutes then the Date. When this has been done,
v. Press the button corresponding to the ‘SAVE’ key. This will save
the set time & date and the screen will revert back to Screen ’A’.
The system is now ready for Mapping. (see Sect. C.3. )
- 6 -
VIEW
LOGS
SHOW
TEXT
TEST
OPEN CIRCUIT
LEAK DETECT
SET REAL TIME CLOCK
Hrs : Mins Date
+
_
SAVE

Section C …… cont
3. Mapping Procedure
(SEE PAGES 18 & 19 for MAPPING RESULTS SHEET)
i. Using the Mapping Tool provided, carry out the following:-
ii. Starting at the first joint between the leader cable LS/LC & the
first piece of detecting cable (CD-x), open the joint. The ‘Alarm Horn’
will sound and the LCD screen will DISPLAY the following:-
Note this Reading on your Mapping Results Sheet.
iii. Connect the Mapping Tool lead into the Leader cable and the
Detecting cable into the other end of the Mapping Tool. Press the
button corresponding to the ‘Reset ‘ key, the LCD screen will now
revert to Screen ‘A’ .
iv. Press & hold down the Button on the top of the Mapping Tool
until the ’Alarm Horn’ sounds. The LCD screen will now display the
following:-
Note this Reading on your Mapping Results Sheet..
v. Disconnect the Mapping Tool & re-instate the joint. Press the
button corresponding to the ‘Reset‘ key, the LCD screen will now
revert to Screen ‘A’ . – Go to the next joint.
- 7 -
VIEW
LOGS
SHOW
CABLE
TEST
TIME DATE
Open Circuit at
…….. Metres
RESET
VIEW
LOGS
SHOW
CABLE
TEST
TIME DATE
Water Detected at
…….. Metres
RESET

Section C…… cont
vi. Disconnect this joint & CONTINUE MAPPING EACH JOINT
AS DESCRIBED IN the Paragraphs above UNTIL ALL JOINTS HAVE
BEEN MAPPED & RECORDED (including the EOL joint). The figures
recorded will form the basis for preparing the ‘System Map’.
viii. THE SYSTEM IS NOW READY FOR USE.
Section D.
Control Panel Outputs.
1. Relays.
The Control Panel has the following dedicated relay outputs
each with a set of ‘Clean Contacts’ for remote signalling:-
OUTPUT TERMINALS MARKED
Water Detected Alarm ‘Alarm’ - N.C. / C / N.O.
Open Circuit Alarm ‘Network Fail’ - N.C. / C / N.O.
Mains Failure Alarm ‘Mains Fail’ - N.C. / C / N.O.
Battery Failure Alarm ‘Batt Fail’ - N.C. / C / N.O.
Service Alarm ‘Service’ - N.C. / C / N.O.
N.C = Normally Closed. – C = Common. – N.O= Normally Open
All the above outputs are via a ‘Clean Set’ of Contacts with a
Maximum rating of 200 mA at 24 volts.
OUTPUT TERMINALS MARKED
Remote Sounder ‘Sounder’ - V+ / V-
Remote Beacon ‘Beacon’ - V+ / V-
For connection to J.A.M. Sounder & Beacon only.
Beacon output can also be used for J.A.M. Repeater Panel.
2. RS 232 RS 232 - RX / TX / 0 v
RS 232 Settings.
Baud = 9600
Data Bits = 8
Parity = None
StopBit = 1
Flow Control = None
3. RS 485 RS 485 - A / B / E
- 8 -

Section E.
Control Panel Functions.
1. TEST / MUTE / RESET.
i. ‘TEST’ is used to Test the operation of the Control Panel only.
Press the button corresponding to the ‘TEST’ key, the alarm Horn will
sound & the LCD screen will DISPLAY the following:-
ii. Press the button corresponding to the ‘MUTE’ key, the alarm horn
will cease to sound. This should be used on all occasions to ‘MUTE’
the sounder.
iii. Press the button corresponding to the ‘RESET’ key. This should
always be used to ’RESET’ the System following the clearance of an alarm
condition or Panel ‘TEST’. The LCD screen will now revert to Screen ‘A’.
iv. In ‘TEST’ mode if you Press the key corresponding to the ‘SHOW
CABLE’ sign, the LCD screen will now DISPLAY the following:-
v. Press the button corresponding to the ‘SHOW TEXT’ key, then
Press the button corresponding to the ‘RESET’ key. The LCD screen will
now revert to Screen ‘A’.
- 9 -
VIEW
LOGS
SHOW
TEXT
TEST
Leak at 1 METRES
OPEN CIRCUIT
LEAK DETECT
VIEW
LOGS
SHOW
CABLE
TEST
RESET
TIME DATE
PANEL TEST OK

Section E …… cont
2. View 100 Event Record Log.
i. Press the button corresponding to the ‘VIEW LOGS’ key. The
LCD screen will now DISPLAY the following:-
ii. Scroll through the Events using the buttons corresponding to the
+ / - keys. The cable characteristics of the alarm event can also be
seen by pressing the button corresponding to the ‘SHOW CABLE’ key.
iii. Press the button corresponding to the ‘EXIT’ key to return to
Screen ‘A’
iv. To remove all LOGS, Press the button corresponding to the
‘CLEAR LOGS’ key. Then Press the button corresponding to the
‘EXIT’ Sign to return to Screen ’A’
3. What to do if an Alarm sounds.
a. Water Detected.
i. On detecting the presence of water the ‘Water Detected’ alarm is
activated. The LCD Screen will change to the following:-
and the ‘Alarm Horn‘ will sound.
ii Press the button corresponding to the ‘MUTE’ key, take NOTE of
the LOCATION READING displayed.
- 10 -
VIEW
LOGS
SHOW
CABLE
TEST
TIME DATE
Water Detected at
…….. Metres
RESET
Details of Event
DATE - TIME
Log Event Number
+
_
EXIT
SHOW
CABLE
CLEAR
LOGS

Section E …… cont
3. What to do if an Alarm sounds. …… cont
iii. Check this reading against the ‘System Map’ to locate the water
contact.
iv. Attend to the reason giving rise to the Alarm.
v. If you press the button corresponding to the ‘Show Cable’ key,
The LCD Screen will change to the following & you will be able to view
the cable characteristics of the alarm:-
vi. Press the button corresponding to ‘Show Text’ to return to the
previous screen.
vii. After attending to the reason for the alarm, reset the system by
pressing the ‘RESET’ button. The LCD Screen will revert to Screen ‘A’
and the system will return to Normal Operation.
viii. Should the system re-alarm within 30 seconds & display the
same or similar Location Reading, this will indicate that the Detecting
cable has not dried or that the water is still present.
ix. If a vastly different Location Reading is displayed this will
indicate that a further water contact has been made.
x. Carry out the above procedures again until the LCD Screen
reverts to Screen ‘A’.
# NOTE – Following a Water Leak, the Detecting Cable should
be dried using a Clean Dry cloth. If the Detecting Cable is left to
dry of its own accord, ensure that an adequate air flow is
available to dry it. This could take up to 24 hours (depending on
the air flow available, temperature & extent of the water leak).
Contamination of Detecting Cable may occur after a water leak
(especially if it is allowed to dry of its own accord) if the floor area
- 11 -
VIEW
LOGS
SHOW
TEXT
TEST
OPEN CIRCUIT
LEAK DETECT
Leak at ……. METRES

Section E …… cont
where it is installed is dirty or dusty. This may cause the cable to
short circuit because of a ‘Trace Path‘ of congealed dust particles
or dirt. This will stop the system from being ‘RESET’
b. Open Circuit.
i. Should damage occur or a joint between Leader, Detecting or
Jumper cables become parted, an ‘Open Circuit’ alarm is activated.
Ii. The LCD Screen will change to the following:-
iii. The ‘Alarm Horn’ will sound.
iv. Press the button corresponding to the ‘MUTE’ key, take NOTE of
the LOCATION READING displayed, check this against the ‘System
Map’ to locate the ‘Open Circuit’.
v. Attend to the reason giving rise to the Alarm.
vi. If you press the button corresponding to the ‘Show Cable’ key,
the LCD Screen will change to the following & you will be able to view
the cable characteristics of the alarm:-
- 12 -
VIEW
LOGS
SHOW
CABLE
TEST
TIME DATE
Open Circuit at
…….. Metres
RESET
VIEW
LOGS
SHOW
TEXT
TEST
OPEN CIRCUIT
LEAK DETECT
O / C at ……. METRES

Section E …… cont
vi. Press the button corresponding to the ‘Show Text’ key to return
to the previous screen.
vii. After attending to the reason for the alarm, press the button
corresponding to the ‘RESET’ key. The LCD Screen will revert to
Screen ’A’ and the system will return to Normal Operation.
viii. Should the system re-alarm within 30 seconds & display the same
or similar Location Reading, this will indicate that the ‘Open Circuit’ is
still present.
ix. If a vastly different Location Reading is displayed this will indicate
that a further ‘Open Circuit’ has been found.
x. Carry out the above procedures again until the LCD Screen
reverts to Screen ‘A’.
# NOTE – The most common cause of an ‘Open Circuit’
alarm is caused by Engineers who are working in the area of the
alarm. They may have caused damage to the detecting cable or
opened a joint whilst carrying out other duties or works.
Always be aware of any works being carried out in the vicinity of
your Water Leak detection System
c. Mains Fail.
i. Should the Mains Power fail, the LCD Screen will change to the
following:-
ii. This will also cause the ’Mains Fail’ relay to energise and the
system will switch automatically to Battery Back Up. The LCD Screen
will display a pulsing plug & show the percentage Life State of the
Batteries. When the Life State of the Batteries are Zero the Battery Fail
relay will de-energise & the System will Shut Down.
iii. On re-instating the Mains Power, Press the button corresponding
to the ‘Reset’ key, the LCD Screen will revert to Screen ’A’ & the System
will return to Normal operation.
- 13 -
SET
TIME TIME DATE
SYSTEM CLEAR
VIEW
LOGS
SHOW
CABLE
TEST
RESET MAINS FAILURE
Battery 100%

Section E
What to do if an Alarm sounds
4. Battery Fail.
i. Should the Batteries Fail or become disconnected the LCD Screen
will display the following:-
ii. This will also cause the ’Battery Fail’ relay to energise. The LCD
Screen will display a pulsing battery with a CROSS through it and a
beep will be heard every 75 secs. whilst the batteries are in a ‘Battery
Fail’ state. After a short period of time the LCD screen will change to the
General Screen. It will continue to display the ‘BATTERY FAIL’ symbol.
iii. When the cause of the ’Alarm’ has been dealt with PRESS the
button corresponding to the ‘RESET’ button. The LCD screen will revert
to the General Screen and the system will return to normal operation.
Section F
Maintenance, & Cable Care
1. Maintenance.
i. Although the system is relatively maintenance free, it is
recommended that it should be checked fully at least ONCE each
year. Should an alarm occur which you cannot clear by the method
described in this Manual or you are unsure of the operation of any part
of the system, please contact your local ’aqualarm’ ‘LeakSense’ Agent
or direct to J.A.M. Limited who will be pleased to give you advice &
assistance.
ii. J.A.M. Limited & their authorised Agents are able to offer you a
comprehensive Maintenance Contract to look after your ’LeakSense’
system on a 1, 2, or 4 visit programme each year. For information
please contact the Authorised Agent listed on the back of this booklet
or directly to J.A.M. Limited
iii. Your system is fitted with a ‘Mains Fail’ Battery Back-Up system
in the form of automatic re-chargeable Batteries They should give you a
trouble free life of between 3 & 5 years (dependant on use).
- 14 -
TIME DATE
BATTERY FAILURE
RESET

Section F
Maintenance, & Cable Care
1. Maintenance. ……… (cont)
iv. When Maintenance is due the following screen will be displayed:-
v. The ‘Spanner’ will pulse and a ‘Bleep’ sound will be heard.
Telephone the number displayed for Service.
2. Cable Care
The Detecting Cable is one of the most important parts of the
system. For the system to work, water must be able to penetrate the
Cables. The following list of substances (although not exhaustive) will
have a detrimental effect on the cables & will cause un-reliable readings.
Fizzy Soda, (coca-cola etc) Coffee, Tea & Chocolate Drinks,
Chemical Cleaning Agents both Wet or Dry, Photocopier, Printer
Toners, Mastics & Sealants, Plumbing, Heating & A.C. lubricants,
Glycol, Builders Rubble & Dust.
All the above substances will cause an ’Alarm’ state. If allowed to dry
without attendance a Trace Path (contamination) may occur & the ‘Alarm’
state will not be able to be cleared or the system reset. Contamination may
also cause un-reliable alarm readings. Contaminated cable should be
removed, cleaned & allowed to dry before replacing back into service. If
after cleaning the cable the system will not reset, the cable must be
replaced. Damaged cable should always be replaced.
# NOTE – Following a Water Leak, the Detecting Cable should
be dried using a Clean Dry cloth. If the Detecting Cable is left to dry of
its own accord, ensure that an adequate air flow is available to dry it.
This could take up to 24 hours (depending on the air flow available,
temperature & extent of the water leak).
-15-
TIME DATE
SYSTEM CLEAR
SERVICE REQUIRED
01268 777222
SET
TIME
VIEW
LOGS
SHOW
CABLE
TEST
RESET

Section F
Maintenance, & Cable Care ……… (cont)
2. Cable Care ……… (cont)
Contamination of Detecting Cable may occur after a water leak
(especially if it is allowed to dry of its own accord) if the floor area
where it is installed is dirty or dusty. This may cause the cable to short
circuit because of a ‘Trace Path‘ of congealed dust particles or dirt.
This will stop the system from being ‘RESET’
Section G
1. Control Panel Terminals
2. Ancillary Equipment
i. The following ‘aqualarm’ equipment is available to be connected
directly to the ‘LeakSense’ 2i system:-
- Repeater Panel (RP-1)
- Beacon & Sounder (B+S-1)
- Touch Screen system (‘aqualarm One Touch’)
- Auto-dialler (SD-1)
- Automatic Voice Alarm (AVA-1)
- 16 -
N
L
L
N
E
E
PSU
MAINS
IN
DOOR
SWITCH
RS-232
Tx Rx 0
v
RS-485
A B E Alarm
N
c C N
o
Network
Fail
N
c C N
o
BeaconSounde
r
V+ V- V+ V- Service
NcC N
o
Bat1 Bat2 PSU
+ - + - + -
CD-x
MainsFail BatFail
Nc C No Nc C No
PCB
BATTERY No 1 MUST BE CONNECTED
TO THE TERMINALS MARKED BAT 1.
ENSURE BOTHPOSITIVE & NEGATIVE
ARE CONNECTED CORRECTLY.
BATTERY No 2 MUST BE CONNECTED
TO THE TERMINALS MARKED BAT 2.
ENSURE BOTHPOSITIVE & NEGATIVE
ARE CONNECTED CORRECTLY.

Section G …… cont
Spares
-17-
EOL-2
End of Line
Resistor
LS-LC Leader Cable
(Can be cut to Length)
CD-x Detecting Cable
1m, 2m, 5m & 10m
WARNING
WATER LEAK DETECTION
CABLE
WL-1/10Packof 10
WL-1/100 Pack of 100
Warning Labels
LS-MBi
Mapping Box
LS-JC Jumper Cable
(Please Specify Length)
Floor Clip
CL-1/10 Packof 10
CL-1/100 Pack of 100

MAPPING RESULTS SHEET
Project Name ………………………………..Date……….
When all Readings have been recorded, the information should
be used to prepare a ‘System Map’
-18 -
Position
Log No.
Cable
Length
& Type
Alarm
Reading
Open
Circuit
Reading
Position
Log No.
Cable
Length
& Type
Alarm
Reading
Open
Circuit
Reading

MAPPING RESULTS SHEET
Project Name ………………………………..Date……….
(You should also photcopy pages 18 & 19 for your records)
-19 -
Position
Log No.
Cable
Length
& Type
Alarm
Reading
Open
Circuit
Reading
Position
Log No.
Cable
Length
& Type
Alarm
Reading
Open
Circuit
Reading

- 20 -
