James products SONIC 3D User manual

SONIC RANGE
USER GUIDE

INTRODUCTION 3
UNPACKING & IMPORTANT 3
SAFETY INSTRUCTIONS 3-4
SUGGESTED APPLICATIONS 5
SONIC - D SERIES 6
OPERATION INSTRUCTIONS 7-8
SONIC - MX SERIES 9
OPERATION INSTRUCTIONS 10-11
DIFFERENT CLEANING METHODS 12
1

2

3
INTRODUCTION
Ultrasonic cleaners function by producing sound waves that are transmitted into the tank and
cleaning solution. These waves create millions of microscopic bubbles, which collapse or ‘implode’,
releasing large amounts of energy, which scrub the surface clean. This process is called ‘Cavitation’.
These tiny bubbles create incredible cleaning results not only to the surface, but by penetrating
the ner detail and recesses in small and hard to get areas to restore them to their former glory.
UNPACKING AND IMPORTANT
Remove cleaner from its packaging and ensure it is correct for your local voltage supply. Never
operate without, or remove the safety ground (earth) from the A.C. power cord / mains lead.
SAFETY INSTRUCTIONS
KEEP AWAY FROM CHILDREN
This unit is not intended for use by individuals including children with restricted physical, sensory
or mental capacities or those with a lack of experience and / or knowledge, including children,
unless they are supervised by an individual who is responsible for their safety or have received
training in operating the unit.
Please store the ultrasonic cleaner where it is not reachable by children.
Danger to children!
Danger of death through suocation! Keep packaging material away from children.
TO PREVENT LIFE-THREATENING ELECTRICAL SHOCK, OBSERVE THE
FOLLOWING
Danger of electrical shock! Do not use while bathing. Never immerse the unit or the power cord in
water or any other liquid. Never touch the power plug with wet hands, especially when inserting or
removing the plug. If the unit has fallen into water during operation, do not touch the unit. Remove
the power plug from the socket rst.
• Never operate the unit unattended.
• Follow the manual to operate the unit.
• Do not use components unapproved by the manufacturer.
• When removing the power cord from the socket, grab the power plug not the cord.
• Do not position power cord anywhere near a trip hazard.
• If there is damage to the plug, cord, housing or other parts of the unit, do not use.
• Do not open the unit as this will void your warranty.
• Remove power plug from the socket: If malfunction occurs; Before cleaning the unit;
• If the unit is not going to be used for prolonged use and aer each use.

4
TO PREVENT FIRE HAZARDS, PLEASE OBSERVE THE FOLLOWING
Never block the vents on the unit. Keep the vents free from lint, hair and other materials.
Do not place the unit on a so surface, such as a bed or a sofa, where the vents could become
blocked.
OTHER OBSERVATIONS
• Do not operate the product without lling the tank with water. Running dry will damage the unit.
• Do not plug in the power cord before rst adding water to the tank.
• Do not over-ll the tank.
• Do not use solution containing abrasive substances or strong corrosive chemical solution not
recommended by the manufactures or the supplier.
• Place the unit on a dry and at surface for operation.
• When the unit is subjected to severe electromagnetic interference, it may malfunction, stop
operating or lose control functions. If this happens, unplug the power cord then reinsert it to
restart the unit.
NOT SUITABLE FOR ULTRASONIC CLEANING
Porous stones such as pearls etc should not be immersed.
Watches should be fully waterproof (30m or more).
Any unrm or inlaid item may become loose.
Items that are easy to be discoloured are not recommended for ultrasonic cleaning.
Welded or plated metal items
Glued items
Glass
Ceramics
Camera Filters
Spectacles (Check with your optician)
Blu-Ray discs

5
DOMESTIC
Jewellery: Necklaces, rings, bracelets, etc.
Watches: Waterproof wristwatches, watch
chains.
Toiletry Items: Electric toothbrush heads,
Electric shaver heads, Razor blades, Combs,
Toothbrushes, Dentures etc.
Oice Equipment: Printer heads, fountain pen
nibs, wax or rubber stamps etc.
Metal Items: Metal cutlery (knives/forks etc),
old coins, metal badges, valves, machine
nozzles, small metal parts etc.
SUGGESTED APPLICATIONS
COMMERCIAL/INDUSTRIAL
Airbrushes/ Spray-guns
Automotive/ Aviation components
Calligraphic pens/ nibs
Computer plotter pens/ nibs
Dental & surgical instruments
Fuel injectors
Geological & metallurgical specimens
Hypodermic needles
Ink jet printer cartridges
Jewellery manufacturing
Laboratory glassware & apparatus
Lenses & other optical components
Metal / bre lters
Metal / rubber seals
Microelectronic circuits & components
Moulding dies
Nozzles
Printed circuit board (PCBs)
Production line cleaning
Scientic & Industrial instruments
Spectacle frames & lenses
Watches & clockwork
Made from a unique formula containing natural products,
mixing carefully balanced quantities of seaweed, coconut oils
and fruit extracts to create a powerful cleaning solution.
SeaClean2 will expertly clean tarnished items and assist in
the removal of carbon, rust and dirt from most solid metals*,
precious stones* and ink jet cartridges to return them to a shiny condition.
Available in 500ml, 1L, 5L and 25L bottles.
* Refer to list of items not suitable for ultrasonic cleaning

Set:
Primes unit for adjusting
cleaning time. This is then
altered using + / – keys above.
SONIC D SERIES
+/– Keys:
Use for adjusting settings.
Degas:
Intermittent operation of
ultrasonic power for rapid
removal of entrained air
from liquids.
Power On/O:
Primes unit for adjusting cleaning time.
This is then altered using + / – buttons
above.
Start/Stop:
Starts and stops ultrasonic
cleaner.
6

7
OPERATION INSTRUCTIONS
1) Check the specication table for the correct operating requirements
(located on the rear of the unit).
2) Before connecting power, put the unit on a stable and at working surface.
Add water to tank, suicient to completely immerse the items being cleaned.
Using the stainless steel basket is highly recommended. Never operate the unit without
water in the cleaning tank. Always ll the unit above 2/3 marker line indicated on the inside
of the tank. Failing to do so, may cause damage to the unit.
3) Connect the power cable to the rear of the unit and ensure the wall supply is switched
ON. All the buttons are touch-sensitive, just lightly touch with your nger. Touch the
button on the front panel to turn on the machine. You are now ready to set the timer and
temperature.
4) Setting the Temperature- When the power is on, the LCD will display the actual
temperature of the solution within the tank. The temperature setting gure will ash once
the option is pressed to set temperature. It indicates that the temperature setting
function has been started. Then, press button to set the required temperature.
When the set temperature is higher than the actual temperature, the built-in heater will
initiate the heating function. The working status (OFF and ON) is visible through the LCD
display window. When the heater has reached the necessary temperature, the heating
function will stop automatically. When the set temperature is lower than the actual one,
heating will not start automatically. In this case, the uid will enter into the constant
temperature state. The heating function is not restricted by the ultrasonic cleaning timing
but can work for a long time (however, it is necessary to make sure there is enough
water inside the tank). To deactivate the heating function, input “00” in preset
temperature, then the Heater will be turned o.

8
5) Setting the timer– When power is on, the timing setting gure will ash once the
option button has been pressed. This indicates that a time setting is required. To set the
timer, press the button to set the required cleaning time (Minutes).
The ultrasonic’s cleaning function will instantly start once the button is pressed.
The LCD display window displays “U” which represents that the ultrasonic is working.
Cleaning will stop automatically when the cleaning time (seconds) and (minutes)
has counted down to “00” on both sides. The gure will resume the original setting
automatically. This is the “memory function”.
6) Memory Function and Pause Function (= Start/Pause). Every time the Green Button
is touched; the memory function will be activated to keep the “MIN” gure in the memory
(but not the “SEC”). When the timer stops automatically, the memorized “MIN” gure will
be remembered. It is convenient for frequent users who repeat with same cleaning time
cycle, as there is no need to reset again and again. The Green Button is also a PAUSE
function button allowing you to pause the unit whilst the ultrasonic timer is still running,
touch again to release the pause and continue the operation ( need to RESET
desired memorized setting gure again aer Pause function is used).
7) Use of degassing function: at the normal working state, the machine will start degassing
function once the button is pressed. Then, the LCD displays “D”. Degassing function
will stop once button is pressed again. Then, the LCD displays “U”.
8) Red Button- This is the power switch for the machine. When you have nished using
the machine, touch to make sure that all of the displays have turned o. Disconnect
the unit from the mains supply and remove the power cable.

9
SONIC MX SERIES
Temp Dial:
Adjusts thermostat
of ultrasonic heating
element.
Timer Dial:
Sets duration of
cleaning cycle.
Sweep:
Creates a wave amongst the cleaning
solution. Providing enhanced
cleaning of tubular items.
Degas:
Intermittent operation of ultrasonic
power for rapid removal of entrained
air from liquids.
Pulse:
Produces intense bursts of ultrasonic
power. Use to remove stubborn
contaminants or degas solution rapidly.
Power:
Adjusts the power rating of
the transducer.
Start/Stop:
Starts and stops ultrasonic cleaner.
Power On/O:
Primes unit for adjusting cleaning time.
This is then altered using + / – buttons above.

10
1) Check the specication table for the correct operating requirements
(located on the rear of the unit).
2) Before connecting power, put the unit on a stable and at working surface. Add water to
tank, suicient to completely immerse the items being cleaned. Using the stainless steel
basket is highly recommended. Never operate the unit without water in the cleaning tank.
Always ll the unit above 2/3 marker line indicated on the inside of the tank. Failing to do
so, may cause damage to the unit.
3) Connect the power cable to the rear of the unit and ensure the wall supply is switched on.
Touch the button on the front panel to turn on the machine. You are now ready to set the
timer and temperature.
4) To freely set the required heating temperature. When the set temperature is higher than
the actual temperature, the built-in heater will initiate the heating function immediately.
The working status (OFF and ON) is visible through the LCD display window. When the
heater has reached the required temperature, the heater will stop automatically. When the
temperature is lower than the set one, heating will also start automatically. In this case, the
uid will be maintained at the current set temperature.
5) Setting the timer. When the power is on, rotate the timing knob to set the cleaning
duration. Adjustments will be visible on the LCD display. At this time, the ultrasonic
cleaning function will start promptly once the button is pressed.
6) Start/stop button ( ) Pressing this will start the unit, press again to pause/stop
cleaning, this is useful to stop the unit mid cycle and inspect cleaning progress.
OPERATION INSTRUCTIONS

11
7) Use of degassing function: at the normal working state, once the button is pressed,
the machine will start the degassing function and the degas button indicator lamp will
be on. Once button is pressed again, degassing function will stop and degassing
button indicator lamp will be o.
8) Use of sweep function: at the normal work status, the sweep function will start and the
sweep button indicator lamp will be on once the button is pressed. If the button is
pressed again, the machine will stop the sweep function and the sweep button indicator
lamp will turn o.
9) Use of pulse function: at the normal working status, once the button is pressed,
the machine power will be increased to 120% and the pulse button indicator lamp will be
on. If the button is pressed again, the pulse function will stop, the pulse button
indicator lamp will be o and the power will resume the normal value.
10) Use of power regulating function: the power is 40% when the power is on normally. The
power range changes from 40% to 70% and 100%, which can be chosen freely by pressing
the function button. Then, the set value will be displayed in the LCD display
module.

1) General Cleaning: Only use plain warm water, about 50°C.
2) Enhanced Cleaning: Add a few drops of standard washing up liquid, liquid soap, or
detergent into the water, other non-acidic based cleaning agents can be also used.
3) Extensive Cleaning: Removing Tarnish, Carbon and Rust from non-plated metals, it is
recommended that you use a specialist cleaning solution such as SeaClean2 that has
been developed to work in an ultrasonic cleaner.
12
DIFFERENT WAYS OF CLEANING
Warning: Strong acid or alkaline cleaning solution will cause corrosion, rust and even
puncture a tank or machine body. This will void your warranty.
Model 3D 4D 6D 3MX 4.5MX 6MX
Volume Size 3 4 6 3 4.5 6
Tank Internal Dimension 238 x 138 x 100 302 x 152 x 100 302 x 152 x 100 238 x 138 x 100 238 x 138 x 150 302 x 152 x 150
Operation Frequency 40 40 40 37 37 37
Adjustable Power 3 3 3
Ultrasonic Power 120 120 180 160 160 240
Drainage Tap 3 3
Degas 3 3 3 3 3 3

13
Model Number
Date of Purchase
Invoice/Receipt Number
Supplier Name, address and
contact information
Serial Number
Remarks
USEFUL INFORMATION FOR GUARANTEE OR REPAIR PURPOSE
