Jameson 16-DT-2 Use and care manual

Directional Entry Tool
* Due to continuous improvement,
specications may change at any time.
Since 1956
OPERATION AND SAFETY
MANUAL
800.346.1956 WWW.JAMESONLLC.COM Clover, SC
Warranty
Jameson products carry a warranty against any defect in material and workmanship for a period of one year from date of
shipment unless failure is due to misuse or improper application. Jameson shall in no event be responsible or liable for modi-
cations, alterations, misapplications or repairs made to its products by purchaser or others. This warranty is limited to repair or
replacement of the product and does not include reimbursement for shipping or other expenses incurred. Jameson disclaims
any other express or implied warranty.
Part Number 16-DT-2
DID_MO4
Directional Entry Tool
with Hard Case
16-DT-2-C
Weight, Tool Only 21.5 lbs.
Weight In Case 50 lbs.
Tool Dimensions 40.5 x 11 x 9.5 in.
Case Dimensions 42 x 13 x 12 in.
Bag Dimensions 42 x 13 x 12 in.
Thread size 2” NPT
Pressure Rating 125 psi
From Jameson
Live Tracer
1/4” X 600’ Locating Rodder
For Gas Mains
Part # 16-14-600-GL

Accessories
* All Accessories Sold Separately
Tools Required For Example Shown
Item Manufacturer Part Number Description
1TD Williamson 09-0758-0000-00 Shortcut Valve, 2” NPT
2TD Williamson 05-0252-0000-00 Speed Tapper with hole saw arbor &
completion plug adapter
3TD Williamson 06-1002-0000-00 Valve Adapter for Speed Tapper, 2” NPT
4TD Williamson 05-0179-0002-00 Hole Saw for Speed Tapper, 1-7/8” dia.
5Continental 9964-99-0033-00 Mechanical Adapter Saddle for 2” IPS
pipe with completion plug and cap
6Continental 0000-33-6449-01 2” NPT Threaded Adapter for Mechani-
cal Saddle
7Jameson 16-DT-2-C Directional Entry Tool, 2” NPT, hard case
8Jameson 16-SB Stufng Box for 1/4” Live Tracer Rodder
9Jameson 16-14-600-GL “Live Tracer” 1/4” Gas Main Tracing
Rodder includes Stufng Box 16-SB
Compatible Saddles For Plastic Pipe (Available From Manufacturers Shown Below)
Continental 9964-99-0033-00 Saddle, Mechanical, 2” IPS, includes completion plug & cap. 0000-33-6449-01 adapter required.
Continental 9964-99-0034-00 Saddle, Mechanical, 4” IPS, includes completion plug & cap. 0000-33-6449-01 adapter required.
GF/Central Plastics 10008646 Saddle, Electrofusion, 2” IPS x 2” NPT, includes completion plug & cap
GF/Central Plastics 10008647 Saddle, Electrofusion, 3" IPS x 2" NPT, includes completion plug and cap
GF/Central Plastics 10007522 Saddle, Electrofusion, 4" IPS x 2" NPT, includes completion plug and cap
GF/Central Plastics 10007523 Saddle, Electrofusion, 6" IPS x 2" NPT, includes completion plug and cap
Example Application: 2” IPS Pipe
Dimensions Shown With Tool Fully Retracted
Other Congurations Can Be Implemented. Always
Conrm Compatibility Of Accessories In A Lab
Environment.
Several Accessories Are Required To Use Jameson’s
Directional Entry Tool.
Please Review Charts Below For Compatible Accessories.
Contact The Manufacturer Listed For Pricing And Availability.
WWW.JAMESONLLC.COM 800.346.1956

Accessories For Camera Inspection (Available From Manufacturers Shown Below)
Manufacturer Part Number Description
Tellus Underground TCL-4201 Stufng Box with split head for camera insertion, 2” NPT,
includes gasket set of your choice.
Tellus Underground CLK 4212 10 mm Gasket Set for TCL-4201
Tellus Underground CLK 4211 8 mm Gasket Set for TCL-4201
Tellus Underground CLK 4210 7 mm Gasket Set for TCL-4201
Radiodection GatorCam4 Inspection Camera, compatible with 16-DT-2-B/C
Hathorn Corp. 70105-400 Inspection Camera, compatible with 16-DT-2-B/C
Vivax Metrotech D18-MX Inspection Camera, compatible with 16-DT-2-B/C
Fittings For Steel Pipe (Available From Manufacturers Shown Below)
Continental CD-548 Mechanical Bolt-On Fitting 2” IPS X 2” NPT
Continental CD-548-1 Mechanical Bolt-On Fitting 4” IPS X 2” NPT
Various Weld-On Stopper Nipples
Accessories
WWW.JAMESONLLC.COM 800.346.1956

1. Identify pipe to be traced. Remove surrounding soil to expose pipe around
the entire circumference approximately 2 feet (minimum) in length. It may
be necessary to install supports under the pipe to prevent buckling once work
begins.
2. Install entry saddle per manufacturer instructions and follow your com-
pany’s procedures. Remove Completion Plug from saddle and store in clean,
safe place.
3. Install necessary adapter ttings (if any) to enable installation of valve in
Step 4. Follow company procedures to ensure proper seal is achieved.
4. Install TD Williamson 2” NPT Shortcut Valve (09-0758-0000-00) to the saddle top
works (sold separately.) Follow company procedures to ensure proper seal is
achieved. Close the valve.
5. Install TD Williamson 2” NPT Speed Tapper Assembly (05-0252-0000-00 & 06-
1002-0000-00) equipped with 1-7/8” Hole Saw (05-0179-0002-00.) All parts sold
separately. Follow company procedures to purge gas and ensure proper seal
is achieved.
6. Open the valve and follow Speed Tapper procedures to tap a hole into the
pipe.
7. Retract Hole Saw and close Shortcut Valve. Remove Speed Tapper.
The following instructions describe an example set-up using a mechanical saddle. Other types of saddles
may be used, however the basic process will be similar. Always follow your company procedures.
8. Measure the distance between top of Shortcut Valve and lower wall of pipe to be inspected.
9. If the Tool carriage does not move freely, try adjusting both Lock Handles so clamps tighten on Guide Rods
very slightly. This will help square-up Carriage so it moves freely.
10. Move the Tool to a clean, dry place. Verify Tool is clean and lubricated. Apply grease to Gear Rack and
Gear as necessary. Wipe Guide Rods clean and lubricate with company approved spray lubricant as needed.
11. Be certain Shoe is secured tightly to launch tube of the Tool.
12. Turn Hand Wheel so Carriage retracts completely to top and compresses the Spring. Verify lower edge of
Shoe would not interfere with closing the Shortcut Valve.
13. If adjustment is required to allow Shoe to retract further, loosen Lock
Collar located inside Lock Collar Housing. The Lock Collar screws are
accessible through slots in the Lock Collar Housing. Slide Launch Tube to
retract the Shoe to desired position then tighten Lock Collar screws.
14. Turn Hand Wheel to lower Launch Tube the approximate distance
obtained in Step 8. Use a permanent marker to mark position on Launch
Tube. This will provide a visual indication when Launch Tube is inserted
completely into pipe.
15. Use Hand Wheel to fully retract Carriage.
16. Lock Carriage using the two Lock Handles. ***IMPORTANT***
When pressure is applied to tool from gas main, carriage raises suddenly if not locked in place.
Tapping The Pipe
Before Installing Directional Entry Tool (“The Tool”)
Instructions For Directional Entry Tool

16. Install Threaded End of the Tool onto the 2” NPT hole of the Shortcut Valve. Follow your company
approved sealing methods to ensure proper seal is achieved.
17. Install camera or traceable rod into Stufng Box (sold separately.) Secure Stufng Box to Upper End
of Launch Tube. Follow your company procedures to ensure proper seal is achieved.
18. With a permanent marker, make a mark on camera rod or traceable rod where it enters Stufng Box.
19. Orient Aiming Handle so it is pointed in the direction of pipe you intend to trace or inspect.
20. Open Shortcut Valve.
21. Follow your company procedures to verify there are no leaks.
Installing The Tool
800.346.1956 WWW.JAMESONLLC.COM Clover, SC

22. Loosen the Lock Handles.
23. Turn Hand Wheel to lower Carriage. This inserts Shoe into pipe. There will be resistance due to internal pres-
sure of pipe.
24. When visible mark applied in Step 13 is approached, feel for resistance in Hand Wheel to indicate Shoe is
bottomed out inside pipe.
25. Securely tighten both Lock Handles.
26. If available, use a C-clamp or other mechanical means to hold Carriage in locked position as a redundant
lock mechanism.
27. Insert camera or traceable rod following your company procedures.
Inserting Camera or Traceable Rod
Removing Camera or Traceable Rod
28. Remove camera or traceable rod until it is out of pipe and completely inside Launch Tube. Stop removal
once the mark from Step 18 is observed exiting Stufng Box.
29. Verify security of both Lock Handles.
30. Remove C-clamp from Step 26, if necessary.
31. Grasp Hand Wheel rmly and slowly release tension of Lock Handles. CAUTION: Maintain rm grip on Hand
Wheel, as internal pressure will force Carriage upward abruptly.
32. Allow Carriage to retract to fully raised position.
33. Tighten both Lock Handles.
34. Close Shortcut Valve.
35. Purge gas and remove Tool per your company procedures.
800.346.1956 WWW.JAMESONLLC.COM Clover, SC
Changing Direction
- When inspection or tracing is complete in rst direction, retract camera or tracing rod until completely out of
pipe and inside launch tube.
- Remove c-clamp from Step 26, if necessary.
- Grasp hand wheel rmly and unlock the two lock handles. Use caution as pressure will cause carriage to raise
suddenly.
- Raise shoe approximately 1/2” and turn aiming handle 180° to opposite direction.
- Lower shoe using hand wheel until it bottoms out in pipe.
- Securely tighten the two lock handles.
- Insert camera or traceable rod to run in opposite direction.

36. Remove Hole Saw and arbor from Speed Tapper.
37. Install Completion Plug adapter to end of Speed Tapper.
38. Install Completion Plug onto end of Speed Tapper.
39. Install Speed Tapper onto Shortcut Valve as in Step 5.
40. Ensure Speed Tapper is in fully raised position and locked in place.
41. Open Shortcut Valve. Check for leaks per your company procedure.
42. Insert Speed Tapper with Completion Plug and install into Mechanical Saddle per manufacturer’s
instructions.
43. Raise Speed Tapper and close Shortcut Valve.
44. Purge gas and remove Speed Tapper per company procedures.
45. Replace Cap of Saddle and tighten per manufacturer’s instructions.
Installation of Completion Plug
