J&W JW-A780LM-D3 User manual

JW-A780LM-D3 V2.0
Socket AM3 Processor Mainboard
User’s Manual
Rev: 1.0, July 2011
Motherboard

Disclaimer
The intellectual property of this manual belongs to our company. The ownership of all of the
products, including accessories and software etc. belong to our company. No one is permitted to
copy, change, or translate without our written permission.
We compiled this manual based on our careful attitude, but we can not guarantee the accuracy
of the contents. This manual is purely technical documentation, without any hint or other
meanings, and we won't commit users' misunderstanding of the typesetting error.
Our products are in continuous improvement and updating, Therefore, we retain the right that
we won't give notice to the users in future.
Copyright
All of the trademark in this manual belong to their own registered company.
All of the products name is only for identication, its title belongs to its manufacturer or brand
owner.

Table of Contents
Chapter 1 Introduction ........................................................................................... 3
1.1 Package Checklist ...............................................................................................................
3
1.2 Specications ...................................................................................................................... 4
1.3 Mainboard Layout ...............................................................................................................
5
1.4 Connecting Rear Panel I/O Devices ............................................................................. 6
Chapter 2 Hardware Setup ...................................................................................... 7
2.1 Choosing a Computer Chassis .............................................................................................. 7
2.2 Installing Mainboard ............................................................................................................ 7
2.3 Installation of the CPU and CPU Cooler.................................................................................. 8
2.3.1 Installation of the CPU ............................................................................................................. 8
2.3.2 Installation of the CPU Cooler ................................................................................................... 9
2.4 Installation of Memory Modules ............................................................................................
9
2.5 Connecting Peripheral Devices............................................................................................. 10
2.5.1 Serial ATA Connectors ............................................................................................................. 10
2.5.2 PCI and PCI Express slots ........................................................................................................ 10
Chapter 3 Jumpers & Headers Setup .................................................................... 11
3.1 Checking Jumper Settings ..................................................................................................
11
3.2 CMOS Memory Clearing Header .......................................................................................... 11
3.3 Keyboard Power Function(JKB) ........................................................................................... 11
3.4 FAN Power Connectors ....................................................................................................... 12
3.5 Front Panel Switches & SPEAKER Headers ........................................................................... . 12
3.6 Additional USB Port Headers ............................................................................................... . 13
3.7 Front Panel Audio & Internal Audio Connectors .................................................................... . 13
3.8 Serial Port Header(JCOM1) ................................................................................................. 14
3.9 S/PDIF out connection Header............................................................................................. . 14
3.10 Power Connectors ........................................................................................................... . 15
Chapter 4 BIOS Setup Utility ................................................................................. 16
4.1 About BIOS Setup .............................................................................................................. 16
4.2 To Run BIOS Setup ............................................................................................................ 16
4.3 About CMOS....................................................................................................................... 16
4.4 The POST (Power On Self Test)............................................................................................ 16
4.5 BIOS Setup — CMOS Setup Utility...................................................................................... .. 17
4.5.1 CMOS Setup Utility .............................................................................................................. . .. 17
4.5.2 Control Keys ......................................................................................................................... 17
4.5.3 Main Setting ......................................................................................................................... 18
4.5.4 Advanced Setting .................................................................................................................. 20
4.5.5 Boot Setting........................................................................................................................... 25
4.5.6 Security Setting...................................................................................................................... 26
4.5.7 Power Setting........................................................................................................................ . 26
4.5.8 JUSTw00t!(Overclock) Setting................................................................................................ ... 29
4.5.9 Exit Options........................................................................................................................... . 31
Chapter 5 Driver Installation ................................................................................ 34
APPENDIX 1 (AMIBIOS easy code list only for your reference)...........................
36

- 3 -
JW-A780LM-D3 V2.0 User's Manual
Chapter 1 Introduction
1.1 Package Checklist
Thank you for choosing our product.
Please check the following packing and accessories, if there is any broken or part missing,
please contact with your franchiser.
• Rear I/O Panel X 1
• User's Manual X 1
• Driver/Utility DVD X 1
• Serial ATA Signal Cable X 2
The items listed above are for reference only, and are subject to change without notice.

- 4 -
JW-A780LM-D3 V2.0 User's Manual
1.2 Specications
CPU
- Support AMD(R) Socket AM3 processors
- Support AMD Phenom II x4/Phenom II x3/Phenom II x2/Athlon II x4/Athlon II
x3/Athlon II x2/ Sempron 1xx
Main Chipset - AMD®760G+ SB710
Built in Radeon™ HD 3000 Graphics, DirectX®10 Ready
Main Memory
- Supports 2 x 1.5V DDR3 DIMM sockets supporting up to 4 GB of system memory
- Supports Dual channel memory architecture
- Supports for DDR3 1066/1333MHz memory modules
BIOS
- AMI BIOS,supports Plug&Play
- Supports Advanced Power Management ACPI,STR
- CPU temperature, Fan speed, System Voltage monitoring
Rear Panel I/O
- 1 x PS/2 Mouse port
- 1 x PS/2 Keyboard port
- 1 x DVI port
- 1 x VGA port
- 1 x RJ45 port
- 4 x USB 2.0 ports, USB 1.1 is compliant
- 3 x Audio ports (Line In / Line Out / MIC In)
Internal I/O
Connectors
- 1 x 24-pin ATX main power connector
- 1 x 4-pin ATX 12V power connector
- 1 x IDE connector
- 4 x SATA 3Gb/s connectors (supports SATA RAID 0, RAID 1, RAID 0+1 )
- 1 x CPU fan header
- 1 x System fan header
- 1 x Front panel header
- 1 x Front panel audio header
- 1 x S/PDIF Out header
- 1 x Serial port header
- 2 x USB 2.0 headers for additional 4 USB 2.0 ports (by cables)
Sound - Onboard 6-channel HD Audio Codec
- Front Panel Jumper, provides stereo MIC port on front panel
Onboard LAN - Onboard 10/100/1000Mbps compatible LAN
Expansion Slots
- 1 x PCI Express x16 slot (PCI Express 2.0)
- 1 x PCI slot
- Support PCI Bus interface v2.3 compliant
Form Factor - Micro-ATX (235mm*185mm)

- 5 -
JW-A780LM-D3 V2.0 User's Manual
1.3 Mainboard Layout
(This picture is only for reference)

- 6 -
JW-A780LM-D3 V2.0 User's Manual
1.4 Connecting Rear Panel I/O Devices
The rear I/O part of these mainboard provides the following I/O ports:
(This picture is only for reference)
• PS/2 Mouse: Connects to a PS/2 mouse.
• PS/2 Keyboard: Connects to a PS/2 keyboard.
• DVI: Connects to a monitor's DVI input.
• VGA: Connects to a monitor's VGA input.
• USB: The USB ports are used to connect USB 2.0/1.1 devices such as scanner, speakers,
keyboard, mouse, hub, digital camera, joystick, etc.
• LAN: The LAN port allows the motherboard to connect to a local area network by means of
a network hub.
• AUDIO (Rear Panel Audio):
Line-in (Light Blue): This jack is used to connect to the line out from any external audio
sources such as MP3 player, CD player, AM/FM radio tuner, etc.
Line-out (Front Left/Right Jack, Lime): This jack is used to connect to the front left and
right channel speakers of the audio system.
Mic-in (Pink): This jack is used to connect an external microphone.

- 7 -
JW-A780LM-D3 V2.0 User's Manual
Chapter 2 Hardware Setup
2.1 Choosing a Computer Chassis
• Choose a chassis big enough to install this mainboard.
• As some features for this mainboard are implemented by cabling connectors on the
mainboard to indicators and switches or buttons on the chassis, make sure your chassis
supports all the features required.
• If there is possibility of adopting some more hard drives, make sure your chassis has
sufcient power and space for them.
• Most chassis have alternatives for I/O shield located at the rear panel. Make sure the I/O
shield of the chassis matches the I/O port conguration of this mainboard. You can nd
an I/O shield specically designed for this mainboard in its package.
2.2 Installing Mainboard
Most computer chassis have a base with many mounting holes to allow the mainboard to
be securely attached, and at the same time, prevent the system from short circuits. There
are two ways to attach the mainboard to the
chassis base: (1) with studs, or (2) with spacers.
Basically, the best way to attach the board is with
studs. Only if you are unable to do this should you
attach the board with spacers. Line up the holes on
the board with the mounting holes on the chassis.
If the holes line up and there are screw holes, you
can attach the board with studs. If the holes line
up and there are only slots, you can only attach with
spacers. Take the tip of the spacers and insert them
into the slots. After doing this to all the slots, you can slide the board into position aligned
with slots. After the board has been positioned, check to make sure everything is OK before
putting the chassis back on.
To install this mainboard:
1. Locate all the screw holes on the mainboard and the chassis base.
2. Place all the studs or spacers needed on the chassis base and have them tightened.
3. Face the mainboard’s I/O ports toward the chassis’s rear panel.
4. Line up all the mainboard’s screw holes with those studs or spacers on the chassis.
5. Install the mainboard with screws and have them tightened.
The mainboard and its component layouts illustrated in this chapter were
based mainly on model “760G Series”, unless specically stated.
Always power off the computer and unplug the AC power cord before adding or removing
any peripheral or component. Failing to do so may cause severe damage to your
mainboard and/or peripherals. Plug in the AC power cord only after you have carefully
checked everything.
To prevent shorting the PCB circuit, please REMOVE the metal studs or spacers if they are
already fastened on the chassis base and are without mounting-holes on the mainboard to
align with.

- 8 -
JW-A780LM-D3 V2.0 User's Manual
2.3 Installation of the CPU and CPU Cooler
Before installing the CPU, please comply with the following conditions:
1. Please make sure that the mainboard supports the CPU.
2. Please take note of the one indented corner of the CPU. If you install the CPU in the wrong
direction, the CPU will not insert properly. If this occurs, please change the insert direction
of the CPU.
3. Please add an even layer of heat sink paste between the CPU and CPU cooler.
4. Please make sure the CPU cooler is installed on the CPU prior to system use, otherwise
overheating and permanent damage of the CPU may occur.
5. Please set the CPU host frequency in accordance with the processor specications. It is not
recommended that the system bus frequency be set beyond hardware specications since
it does not meet the required standards for the peripherals. If you wish to set the frequen-
cy beyond the proper specications, please do so according to your hardware
specications including the CPU, graphics card, memory, hard drive, etc.
2.3.1 Installation of the CPU
1. Unlock the socket by pressing the
lever sideways, then lift it up to a 90
o
.
2. Position the CPU above the socket such
that the CPU corner with the gold
triangle matches the socket corner with
a small triangle.
3. Carefully insert the CPU into the socket
until it ts place.
4. When the CPU is in place, push down
the socket lever to secure the CPU.
The lever clicks on the side tab to
indicate that it is locked.
Figure 1
Figure 2
Figure 3

- 9 -
JW-A780LM-D3 V2.0 User's Manual
2.3.2 Installation of the CPU Cooler
For proper installation, please kindly refer to the instruction manuals of your CPU Cooler.
2.4 Installation of Memory Modules
This mainboard provides four 240-pin DDRIII (Double Data Rate) DIMM slots, and supports
Dual Channel Memory Technology. For dual channel conguration, you always need to install
two identical (the same brand, speed, size and chip-type) memory modules in the DDRIII
DIMM slots to activate Dual Channel Memory Technology. Otherwise, it will operate at single
channel mode.
To reach the performance of Dual Channel DDR3, the following rules must be obeyed:
Populate DIMM modules of the same type and size on slots [DIMM1]+[DIMM2]
To install system memory:
1. Power off the computer and unplug the
AC power cord before installing or
removing memory modules.
2. Locate the DIMM slot on the board.
3. Hold two edges of the DIMM module
carefully, keep away from touching its
connectors.
4. Align the notch key on the module with
the rib on the slot.
5. Firmly press the module into the slots until the ejector tabs at both sides of the slot
automatically snap into the mounting notch. Do not force the DIMM module in with extra
force as the DIMM module only ts in one direction.
6. To remove the DIMM modules, push the two ejector tabs on the slot outward
simultaneously, and then pull out the DIMM module.
Static electricity can damage the electronic components of the computer or optional
boards. Before starting these procedures, ensure that you are discharged of static
electricity by touching a grounded metal object briey.

- 10 -
JW-A780LM-D3 V2.0 User's Manual
2.5 Connecting Peripheral Devices
2.5.1 Serial ATA Connectors
The Serial ATA (SATA) connectors are used to connect Serial ATA drives. Connect one end of
the Serial ATA cable to a Serial ATA connector and the other end to your Serial ATA device.
2.5.2 PCI and PCI Express slots
Install PCI Express X16 graphics card into slot “PCIE1”.
Install PCI card into slot “PCI1” .

- 11 -
JW-A780LM-D3 V2.0 User's Manual
Chapter 3 Jumpers & Headers Setup
3.1 Checking Jumper Settings
• For a 2-pin jumper, plug the jumper cap on both
pins will make it CLOSE (SHORT). Remove the
jumper cap, or plug it on either pin (reserved for
future use) will leave it at OPEN position.
• For 3-pin jumper, pin 1~2 or pin 2~3 can be
shorted by plugging the jumper cap in.
How to identify the PIN1 jumpers?
Please check the mainboard carefully, the PIN1
is marked by "1" or white thick line.
3.2 CMOS Memory Clearing Header
The time to clear the CMOS memory occurs when (a)
the CMOS data becomes corrupted, (b) you forgot
the supervisor or user password preset in the BIOS
menu, (c) you are unable to boot-up the system
because the CPU ratio/clock was incorrectly set in the
BIOS menu, or (d) whenever there is modication on
the CPU or memory modules.
This header uses a jumper cap to clear the CMOS
memory and have it recongured to the default
values stored in BIOS.
• Pins 1 and 2 shorted
(Default): Normal
operation.
• Pins 1 and 2 shorted:
Clear CMOS memory.
To clear the CMOS memory and load in the default values:
1. Power off the system.
2. Set pin 1 and pin 2 shorted by the jumper cap. Wait for a few seconds.
3. Power on the system.
4. For incorrect CPU ratio/clock settings in the BIOS, press <Del> key to enter the BIOS
setup menu right after powering on system.
5. Set the CPU operating speed back to its default or an appropriate value.
6. Save and exit the BIOS setup menu.
3.3 Keyboard Power Function(JKB)
Pin 1-2 short: Disabled power on by keyboard
Pin 2-3 short: Support power on by keyboard

- 12 -
JW-A780LM-D3 V2.0 User's Manual
3.4 FAN Power Connectors
These connectors each provide power to the cooling fans installed in your system.
CFAN or CFAN1: CPU Fan Power Connector
SFAN1: System Fan Power Connector
3.5 Front Panel Switches & SPEAKER- Headers
SPEAKER
HD_LED (Red): Hard Driver LED connector
This connector connects to the case-mounted HD LED cable, and the LED will light when the
hard drive(s) is/are being accessed.
RST (Blue): Reset Switch
This connector connects to the case-mounted reset switch which allows you to reboot without
having to power-off the system and thus prolonging the life of the power supply or system.
PWR_ON (Black): Power Switch
Depending on the setting in the BIOS setup, this switch serves two functions which will allow
you to power-on/off the system or to enter the suspend mode.
PWR_LED (Green): Power/Standby LED
When the system's power is on, this LED will light. When the system is in the S1 (POS - Power
on Suspend) or S3 (STR - Suspend to RAM, optional) state, it will blink every second.
SPEAKER (Yellow or Black): Speaker Connector
This 4-pin connector connects to the case-mounted speaker.
These fan connectors are not jumpers. DO NOT place
jumper caps on these connectors.

- 13 -
JW-A780LM-D3 V2.0 User's Manual
Pin Pin Assignment Pin Pin Assignment
1 VCC 2 VCC
3 Data 0- 4 Data 0-
5 Data 0+ 6 Data 0+
7 Ground 8 Ground
9 No Pin 10 NC
3.6 Additional USB Port Headers
3.7 Front Panel Audio Headers
Pin No. Header HD Audio Denition AC97 Audio Denition
1 PORT1L Microphone_Left Microphone
2 AGND Ground Ground
3 PORT1R Microphone_Right MIC Power
4 PRESENCE# -ACZ_DET N/A
5 PORT2R Line2_Right Line out (R)
6 SENSE1_RETURN AuD_R_Return N/A
7 SENSE_SEND FAUDIO_JD N/A
8 No Pin N/A N/A
9 PORT2L Line2_Left Line Out(L)
10 SENSE2_RETURN AuD_L_Return N/A

- 14 -
JW-A780LM-D3 V2.0 User's Manual
3.8 Serial Port Header
Pin Pin Assignment Pin Pin Assignment
1 DCD 2 RXD
3 TXD 4 DTR
5 GND 6 DSR
7 RTS 8 CTS
9 RI
This JCOM1 header supports a serial port module.
3.9 S/PDIF Output Connection Header
S/PDIF (Sony/Philips Digital Interface) is a standard audio transfer le format. It is usually
found on digital audio equipment such as a DAT (Digital Audio Tape) machine or audio
processing device. It allows the transfer of audio from one le to another without the
conversion to and from an analog format, which could degrade the signal quality.

- 15 -
JW-A780LM-D3 V2.0 User's Manual
3.10 Power Connectors
ATXPWR (ATX Power) connector
We recommend to use our motherboard with a power supply that complies with the ATX12V
Power Supply Design Guide Version 1.1. Every ATX12V power supply unit has a standard
24-pin ATX main power connector that must be plugged into this connector. If you would like
to use an old power supply with only a 20-pin ATX main power connector, then please plug
the 20-pin ATX main power connector along with pin 1 and pin 13.
Figure 2: Reference for 8 pin PWR12V.
Figure 1: Reference for 4 pin PWR12V.
PWR12V (+12V Power) connector
Your power supply unit may come with a 4-pin or 8-pin +12V power connector. The +12V
power enables the delivery of more +12VDC current to the CPU's Voltage Regulator Module
(VRM). If available, please use the 8-pin power; otherwise please connect the 4-pin power to
this connector.

- 16 -
JW-A780LM-D3 V2.0 User's Manual
Chapter 4 BIOS Setup Utility
BIOS stands for Basic Input and Output System. It was once called ROM BIOS when it was
stored in a Read-Only Memory (ROM) chip. Now manufacturers would like to store BIOS in
EEPROM which means Electrically Erasable Programmable Memory. BIOS used in this series
of mainboard is stored in EEPROM, and is the first program to run when you turn on your
computer.
BIOS performs the following functions:
1. Initializing and testing hardware in your computer (a process called "POST", for Power On
Self Test).
2. Loading and running your operating system.
3. Helping your operating system and application programs manage your PC hardware by
means of a set of routines called BIOS Run-Time Service.
4.1 About BIOS Setup
BIOS Setup is an interactive BIOS program that you need to run when:
1. Changing the hardware of your system. (For example: installing a new Hard Disk etc.)
2. Modifying the behavior of your computer. (For example: changing the system time or date,
or turning special features on or off etc.)
3. Enhancing your computer's behavior. (For example: speeding up performance by turning
on shadowing or cache)
4.2 To Run BIOS Setup
First access BIOS setup menu by pressing <F1> key after “POST” is complete (before OS is
loaded). After the rst BIOS be setupped(or loaded default values) and save, the <DEL> key
will be pressed if you will enter BIOS setup menu.
4.3 About CMOS
CMOS is the memory maintained by a battery. CMOS is used to store the BIOS settings you
have selected in BIOS Setup. CMOS also maintains the internal clock. Every time you turn
on your computer, the BIOS Looks into CMOS for the settings you have selected and
congures your computer accordingly. If the battery runs out of power, the CMOS data will
be lost and POST will issue a “CMOS invalid” or “CMOS checksum invalid” message. If this
happens, you have to replace the battery and check and congure the BIOS Setup for the
new start.
4.4 The POST (Power On Self Test)
POST is an acronym for Power On Self Test. This program will test all things the BIOS does
before the operating system is started. Each of POST routines is assigned a POST code, a
unique number which is sent to I/O port 080h before the routine is executed.

- 17 -
JW-A780LM-D3 V2.0 User's Manual
4.5 BIOS Setup — CMOS Setup Utility
4.5.1 CMOS Setup Utility
After powering up the system, the BIOS message appears on the screen,when the rst time
or when CMOS setting wrong, there is following message appears on the screen , but if
the rst BIOS be setuped(or loaded default values) and save, the <DEL> key will be
pressed if you will enter BIOS setup menu.
If this message disappears before you respond, restart the system by pressing <Ctrl> +
<Alt>+ <Del> keys, or by pressing the reset button on computer chassis. Only when these
two methods should be fail that you restart the system by powering it off and then back on.
After pressing <F1> or <Del> key, the main menu appears.
4.5.2 Control Keys
Press F1 to pop up a small help window that describes the appropriate keys to use and the
possible selections for the highlighted item.
Please check the following table for the function description of each control key.
Press F1 to Run SETUP
• In order to increase system stability and performance, our engineering staff is
constantly improving the BIOS menu. The BIOS setup screens and descriptions
illustrated in this manual are for your reference only, and may not completely
match with what you see on your screen.
• Do not change the BIOS parameters unless you fully understand its function.
Control Key(s) Function Description
←
/
→
Move cursor left or right to select Screens
↑ / ↓
Move cursor up or down to select items
+/ -/PU/PD To Change option for the selected items
<Enter> To bring up the selected screen
<ESC>
Main Menu - Quit and not save changes into CMOS Status
Page Setup Menu and Option Page Setup Menu - Exit
current page and return to Main Menu
<F1> General help
<F2/F3> Change Colors
<F7> Discard Changes
<F8> Load Failsafe Defaults
<F9> Load Optimal Defaults
<F10> Save conguration changes and exit setup

- 18 -
JW-A780LM-D3 V2.0 User's Manual
4.5.3 Main Setting
This is the System Overview, The System Time, System Date, Primary IDE information,
SATA port information and USB Device.
►
System Information
Please Enter this submenu, this will be display BIOS verison, build date, ID number, also will
display CPU type, Speed, count, and Memory Size and so on.
BIOS SETUP UTILITY
Main Advanced Boot Security Power JUSTw00T! Exit
System Overview
←
Select Screen
↑↓
Select Item
Enter Go to Sub Screen
F1 General Help
F10 Save and Exit
ESC Exit
►
System Information
System Time
System Date
Language
Power On Beep
[21:50:32]
[Mon 07/12/2011]
[English]
[Enabled]
►
IDE Master
►
IDE Slave
►
SATA Port1
►
SATA Port2
►
SATA Port3
►
SATA Port4
: [Not Detected]
: [Not Detected]
: [Hard Disk]
: [Not Detected]
: [Not Detected]
: [Not Detected]
v02.61 (C)Copyright 1985-2006, American Megatrends, Inc.
BIOS SETUP UTILITY
Main
System Overview
←
Select Screen
↑↓
Select Item
F1 General Help
F10 Save and Exit
ESC Exit
AMIBIOS
Version :08.00.15
Build Date:05/10/11
ID :RS78H0A1
Processor
AMD Phenom(tm) 5200 Quad-Core Processor
Speed :2311MHz
Count :2
System Memory
Size :768MB
v02.61 (C)Copyright 1985-2006, American Megatrends, Inc.
• AMIBIOS Displays the auto-detected BIOS information.
• Processor Displays the auto-detected CPU specication.
• System Memory
Displays the auto-detected system memory.
・Press <Esc> key to return to "Main" menu.
• System time
This item sets the time you specify(usually the current time)in the format of [Hour],[Minute]and
[Second].
• System date
This item sets the date you specify(usually the current date0in the format of [Month],[Date],
and [Year].

- 19 -
JW-A780LM-D3 V2.0 User's Manual
• Language
Allows you to selects the current default language used by the BIOS.
• Powe On Beep
Options: Disabled,Enabled.
►
IDE Master/Slave; SATA Port 1 /2/3/4
This item sets the status of auto detection of SATA/IDE devices while enterting setup, and
BIOS will auto detects the presence of SATA/IDE devices. Press "Enter" Key to enter the
submenu.
BIOS SETUP UTILITY
Main
SATA Port1 Disabled: Disables LBA
Mode.
Auto: Enables LBA
Mode if the device
supports it and the
device is not already
formatted with LBA
Mode disabled.
←
Select Screen
↑↓
Select Item
+- Change Option
F1 General Help
F10 Save and Exit
ESC Exit
Device :Hard Disk
Vendor :ST380215AS
Size :80.0GB
LBA Mode :Supported
Block Mode:16Sectors
PIO Mode :4
Async DMA :MultiWord DMA-2
Ultra DMA :Ultra DMA-6
S.M.A.R.T.:Supported
LBA/Large Mode
Block (Multi-Sector Transfer)
PIO Mode
DMA Mode
S.M.A.R.T
32Bit Data Transfer
[Auto]
[Auto]
[Auto]
[Auto]
[Auto]
[Enabled]
v02.61 (C)Copyright 1985-2006, American Megatrends, Inc.
• LBA/Large Mode
Enables or disables the LBA mode. Setting to [Auto] enables the LBA mode if the device
supports this mode, and if the device was not previously formatted with LBA mode disabled.
• Block (Multi-Sector Transfer)
Enables or disables data multi-sectors transfers. When set to [Auto] , the data transfer from
and to the device occurs multiple sectors at a time if the device supports multi-sector transfer
frature. When set to [Disabled] , the data transfer from and to the device occurs one sector at
a time.
• PIO Mode
Allows you to select the data transfer mode.
• DMA Mode
Selects the DMA mode.
• S.M.A.R.T
Set the Smart Monitoring, Analysis, and Reporting Technology.
• 32Bit Data Transfer
Enables or disables 32-bit data transfer.
・Press <Esc> key to return to "Main" menu.
