User’s Manual
Socket LGA1155 Processor Mainboard
JW-H61M-L3
Rev: 1.0, July 2011
Motherboard

Disclaimer
The intellectual property of this manual belongs to our company. The ownership of all of the
products, including accessories and software etc. belong to our company. No one is permitted to
copy, change, or translate without our written permission.
We compiled this manual based on our careful attitude, but we can not guarantee the accuracy
of the contents. This manual is purely technical documentation, without any hint or other
meanings, and we won't commit users' misunderstanding of the typesetting error.
Our products are in continuous improvement and updating, Therefore, we retain the right that
we won't give notice to the users in future.
Copyright
All trademarks in this manual belong to their own registered companies.
All product names are only for identication purpose, and they are belong to the manufacturer
or brand owner(s).

Table of Contents
Chapter 1 Introduction .............................................................................................
3
1.1 Package Checklist ..................................................................................................
3
1.2 Specications ........................................................................................................
4
1.3 Mainboard Layout ..................................................................................................5
1.4 Connecting Rear Panel I/O Devices .........................................................................6
Chapter 2 Hardware Setup .......................................................................................7
2.1 Choosing a Computer Chassis .................................................................................7
2.2 Installing the Mainboard .........................................................................................7
2.3 Installation of the CPU and CPU Cooler .................................................................8
2.3.1 Installation of the CPU .................................................................................8
2.3.2 Installation of the CPU Cooler...........................................................................9
2.4 Installation of Memory Modules ..............................................................................9
2.5 Connecting Peripheral Devices ..............................................................................
10
2.5.1 Serial ATA Connectors ..................................................................................
10
2.5.2 PCI and PCI Express slots .............................................................................
10
Chapter 3 Jumpers & Headers Setup .....................................................................
11
3.1 Checking Jumper Settings ....................................................................................
11
3.2 CMOS Memory Clearing Header ............................................................................
11
3.3 Keyboard Power Function ....................................................................................
11
3.4 FAN Power Connectors .........................................................................................
12
3.5 Front Panel Switches & Indicators Headers ..........................................................
12
3.6 Additional USB Port Headers .................................................................................
13
3.7 Front Panel Audio ................................................................................................
13
3.8 S/PDIF Output Connection Header ........................................................................
14
3.9 ATX Power Input Connectors .................................................................................15
Chapter 4 BIOS Setup Utility ...................................................................................
16
4.1 About BIOS Setup ...............................................................................................
16
4.2 To Run BIOS Setup ..............................................................................................
16
4.3 About CMOS .......................................................................................................
16
4.4 The POST (Power On Self Test) ............................................................................
16
4.5 BIOS Setup — CMOS Setup Utility .......................................................................17
4.5.1 CMOS Setup Utility ........................................................................................17
4.5.2 Control Keys .................................................................................................18
4.5.3 Main menu ...................................................................................................18
4.5.4 Advanced setting ..........................................................................................19
4.5.5 Chipset setting .............................................................................................25
4.5.6 Boot setting .................................................................................................28
4.5.7 Security setting .............................................................................................29
4.5.8 JUSTw00t............. ........................................................................................29
4.5.9 Save & Exit setting........................................................................................
31
Chapter 5 Driver Installation ..................................................................................
36

- 3 -
JW-H61M-L3 User's Manual
Chapter 1 Introduction
1.1 Package Checklist
Thank you for choosing our product.
Please check with the following list of accessories, if there is any broken or missing part,
please contact your dealer or the local distributor.
• I/O Shield
• User's Manual
• Drivers DVD
• SATA Cable(s)
The items listed above are for reference only, and are subject to change without notice.

- 4 -
JW-H61M-L3 User's Manual
1.2 Specications
CPU
- Supports Intel®Core™ i7 /Core™ i5/Core™ i3/Pentium®/Celeron®
Processors in the LGA1155 Package
- Supports Intel®Turbo-boost Technology
Chipset -Intel®H61 Express Chipset
Main Memory
- Supports Dual Channel DDR3 1600(OC)/1333/1066
- Supports Dual Channel memory architecture
- Supports non-ECC, unbuffered memory, 2 x DIMM slots, Max. capacity up to
16GB
BIOS - AMI BIOS
- 1 x 32 Mb Flash ROM
Rear Panel I/O
- 1 x PS/2 Mouse port
- 1 x PS/2 Keyboard port
- 1 x VGA Display port
- 4 x USB ports
- 1 x RJ45 LAN port
- 6 Channel Audio I/O
Internal I/O
Connectors
- 1 x 24-pin EPS Power connector
- 1 x 8-pin ATX 12V power connector
- 4 x SATA connectors
- 2 x Fan Connectors: 1 x CPU Fan connector/1 x System Fan connector
- 1 x Front panel High Denition audio header
- 1 x S/PDIF Out header
- 1 x Front System Panel connector
- 1 x Serial port header
- 1 x Speaker header
- 2 x USB 2.0 headers for additional 4 USB 2.0 ports
Audio -Realtek ALC661 Channel High-Denition Audio CODEC
Manageability -WOL, PXE, PME Wake Up
Onboard LAN - Realtek Gigabit LAN
Expansion Slots - 1 x PCIe Gen.2 x16 slot
- 1 x PCI Express x1 slot
Form Factor - Micro ATX form factor: 169.9 mm x 235 mm

- 5 -
JW-H61M-L3 User's Manual
1.3 Mainboard Layout
(This picture is only for reference)

- 6 -
JW-H61M-L3 User's Manual
1.4 Connecting Rear Panel I/O Devices
The rear I/O of the mainboard provides the following I/O ports:
(This picture is only for reference)
• PS/2 Mouse: Connects to a PS/2 mouse.
• PS/2 Keyboard: Connects to a PS/2 keyboard.
• VGA：Connects to a monitor's VGA input.
• USB: The USB ports are used to connect usb2.0/1.1 devices such as scanner, speakers,
keyboard, mouse, hub, digital camera, joystick, etc.
• LAN: The LAN port allows the motherboard to connect to a local area network by means of
a network hub.
• AUDIO(Rear Panel Audio):
Line-In: Connects to the line out from external audio sources.
Line-Out: Connects to the front left and front right channel in the 5.1-channel or regular
2-channel audio system.
Mic-In: Connects to the plug from external microphone.

- 7 -
JW-H61M-L3 User's Manual
Chapter 2 Hardware Setup
2.1 Choosing a Computer Chassis
• Choose a chassis big enough to install this mainboard.
• As some features for this mainboard are implemented by cabling connectors on the
mainboard to indicators and switches or buttons on the chassis, make sure your chassis
supports all the features required.
• If there is possibility of adopting some more hard drives, make sure your chassis has
sufcient power and space for them.
• Most chassis have alternatives for I/O shield located at the rear panel. Make sure the I/O
shield of the chassis matches the I/O port conguration of this mainboard. You can nd
an I/O shield specically designed for this mainboard in its package.
2.2 Installing the Mainboard
Most computer chassis have a base with many mounting holes to allow the mainboard to
be securely attached, and at the same time, prevent the system from short circuits. There
are two ways to attach the mainboard to the
chassis base: (1) with studs, or (2) with spacers.
Basically, the best way to attach the board is with
studs. Only if you are unable to do this should you
attach the board with spacers. Line up the holes on
the board with the mounting holes on the chassis.
If the holes line up and there are screw holes, you
can attach the board with studs. If the holes line
up and there are only slots, you can only attach with
spacers. Take the tip of the spacers and insert them
into the slots. After doing this to all the slots, you can slide the board into position aligned
with slots. After the board has been positioned, check to make sure everything is OK before
putting the chassis back on.
To install this mainboard:
1. Locate all the screw holes on the mainboard and the chassis base.
2. Place all the studs or spacers needed on the chassis base and have them tightened.
3. Face the mainboard’s I/O ports toward the chassis’s rear panel.
4. Line up all the mainboard’s screw holes with those studs or spacers on the chassis.
5. Install the mainboard with screws and have them tightened.
The mainboard and its component layouts illustrated in this chapter were
based mainly on the model, unless specically stated.
Always power off the computer and unplug the AC power cord before adding or removing
any peripheral or component. Failing to do so may cause severe damage to your
mainboard and/or peripherals. Plug in the AC power cord only after you have carefully
checked everything.
To prevent shorting the PCB circuit, please REMOVE the metal studs or spacers if they are
already fastened on the chassis base and are without mounting-holes on the mainboard to
align with.

- 8 -
JW-H61M-L3 User's Manual
2.3 Installation of the CPU and CPU Cooler
Before installing the CPU, please comply with the following conditions:
1. Please make sure that the mainboard supports the CPU.
2. Please take note of the one indented corner of the CPU. If you install the CPU in the wrong
direction, the CPU will not insert properly. If this occurs, please change the insert direction
of the CPU.
3. Please add an even layer of heat sink paste between the CPU and CPU cooler.
4. Please make sure the CPU cooler is installed on the CPU prior to system use, otherwise
overheating and permanent damage of the CPU may occur.
5. Please set the CPU host frequency in accordance with the processor specications. It is not
recommended that the system bus frequency be set beyond hardware specications since
it does not meet the required standards for the peripherals. If you wish to set the frequen-
cy beyond the proper specications, please do so according to your hardware
specications including the CPU, graphics card, memory, hard drive, etc.
2.3.1 Installation of the CPU
1. Open the socket lever by
pushing the lever down and
away from the socket .
2. Lift the load plate and remove the plastic protective
socket cover. Do not touch the socket contacts and do not
discard the protective socket cover. Always replace with the
protective socket cover if the processor is being removed
from the socket.
3.Position the CPU over
the socket, ensuring that
the gold triangle is on the
bottom-left corner of the
socket, and then fit the
socket alignment keys into
the CPU notches. (marked
with circle)
5. Insert the load lever under the retention tab.
4. Close the load plate, and then push down the load lever,
please ensure that the front edge of the load plate slides
UNDER the retention knob (marked with circle).

- 9 -
JW-H61M-L3 User's Manual
2.3.2 Installation of the CPU Cooler
For proper installation, please kindly refer to the instruction manuals of your CPU Cooler.
2.4 Installation of Memory Modules
This mainboard provides two 240-pin DDRIII (Double Data Rate) DIMM slots, and supports
Dual Channel Memory Technology. For dual channel conguration, you always need to install
two identical (the same brand, speed, size and chip-type) memory modules in the DDRIII
DIMM slots to activate Dual Channel Memory Technology. Otherwise, it will operate at single
channel mode.
One DIMM:Install one memory module into DIMM 1 or DIMM 2 rst as a single-channel
operation.
Two DIMMs (dual-channel operation):
Install two memory modules into DIMM 1 and DIMM 3 or DIMM 2 and DIMM 4 rst as a dual-
channel operation.
To install system memory:
1. Power off the computer and unplug the
AC power cord before installing or
removing memory modules.
2. Locate the DIMM slot on the board.
3. Hold two edges of the DIMM module
carefully, keep away from touching its
connectors.
4. Align the notch key on the module with
the rib on the slot.
5. Firmly press the module into the slots until the ejector tabs at both sides of the slot
automatically snap into the mounting notch. Do not force the DIMM module in with extra
force as the DIMM module only ts in one direction.
6. To remove the DIMM modules, push the two ejector tabs on the slot outward
simultaneously, and then pull out the DIMM module.
Static electricity can damage the electronic components of the computer or optional
boards. Before starting these procedures, ensure that you are discharged of static
electricity by touching a grounded metal object briey.

- 10 -
JW-H61M-L3 User's Manual
2.5 Connecting Peripheral Devices
2.5.1 Serial ATA Connectors
Each SATA connector serves as one single channel to connect one SATA device by SATA
cable.
2.5.2 PCI Express slots
Install PCI Express X16 graphics card into slot “PCIE1”.
Install PCI Express X1 card into slot “PCIE2.

- 11 -
JW-H61M-L3 User's Manual
Chapter 3 Jumpers & Headers Setup
3.1 Checking Jumper Settings
• For a 2-pin jumper, plug the jumper cap on both
pins will make it CLOSE (SHORT). Remove the
jumper cap, or plug it on either pin (reserved for
future use) will leave it at OPEN position.
• For 2-pin jumper, pin 1~2 can be shorted by
plugging the jumper cap in.
3.2 CMOS Memory Clearing Header
The time to clear the CMOS memory occurs when (a)
the CMOS data becomes corrupted, (b) you forgot
the supervisor or user password preset in the BIOS
menu, (c) you are unable to boot-up the system
because the CPU ratio/clock was incorrectly set in the
BIOS menu, or (d) whenever there is modication on
the CPU or memory modules.
This header uses a jumper cap to clear the CMOS
memory and have it recongured to the default
values stored in BIOS.
• Pins 1 and 2 opened
(Default): Normal
operation.
• Pins 1 and 2 shorted:
Clear CMOS memory.
To clear the CMOS memory and load in the default values:
1. Power off the system.
2. Set pin 1 and pin 2 shorted by the jumper cap. Wait for a few seconds.
3. Power on the system.
4. For incorrect CPU ratio/clock settings in the BIOS, press <Del> key to enter the BIOS
setup menu right after powering on system.
5. Set the CPU operating speed back to its default or an appropriate value.
6. Save and exit the BIOS setup menu.
3.3 Keyboard Power Function
Pin 1-2 short: Disabled power on by keyboard.
Pin 2-3 short: Support power on by keyboard. JKB:
Disable (Default)
Enable

- 12 -
JW-H61M-L3 User's Manual
3.4 FAN Power Connectors
These connectors each provide power to the cooling fans installed in your system.
CFAN: CPU Fan Power Connector
SFAN1: System Fan Power Connector
3.5 Front Panel Switches & Indicators Headers
HD_LED (Red): Hard Driver LED connector
This connector connects to the case-mounted HD LED cable, and the LED will light when the
hard drive(s) is/are being accessed.
RST (Blue): Reset Switch
This connector connects to the case-mounted reset switch which allows you to reboot without
having to power-off the system and thus prolonging the life of the power supply or system.
PWR_ON (Black): Power Switch
Depending on the setting in the BIOS setup, this switch serves two functions which will allow
you to power-on/off the system or to enter the suspend mode.
PWR_LED (Green): Power/Standby LED
When the system's power is on, this LED will light. When the system is in the S1 (POS - Power
on Suspend) or S3 (STR - Suspend to RAM, optional) state, it will blink every second.
SPEAKER (Yellow or Black): Speaker Connector
This 4-pin connector connects to the case-mounted speaker.
These fan connectors are not jumpers. DO NOT place
jumper caps on these connectors.
Speaker

- 13 -
JW-H61M-L3 User's Manual
Pin Pin Assignment Pin Pin Assignment
1 VCC 2 VCC
3 Data 0- 4 Data 0-
5 Data 0+ 6 Data 0+
7 Ground 8 Ground
9 No Pin 10 NC
3.6 Additional USB Port Headers
3.7Front Panel Audio
The headers conform to USB 2.0/1.1 specication. Each USB header can provide two USB ports
via an optional USB bracket.
Pin No. Header HD Audio Denition AC97 Audio Denition
1 PORT1L Microphone_Left Microphone
2 AGND Ground Ground
3 PORT1R Microphone_Right MIC Power
4 PRESENCE# -ACZ_DET N/A
5 PORT2R Line2_Right Line out (R)
6 SENSE1_RETURN AuD_R_Return N/A
7 SENSE_SEND FAUDIO_JD N/A
8 No Pin N/A N/A
9 PORT2L Line2_Left Line Out(L)
10 SENSE2_RETURN AuD_L_Return N/A

- 14 -
JW-H61M-L3 User's Manual
3.8 S/PDIF Output Connection Header
S/PDIF (Sony/Philips Digital Interface) is a standard audio transfer le format. It is usually
found on digital audio equipment such as a DAT (Digital Audio Tape) machine or audio
processing device. It allows the transfer of audio from one le to another without the
conversion to and from an analog format, which could degrade the signal quality.
3
1
VCC OUT GND

- 15 -
JW-H61M-L3 User's Manual
3.9 ATX Power Input Connectors
ATXPWR (ATX Power) connector
We recommend to use our motherboard with a power supply that complies with the ATX12V
Power Supply Design Guide Version 1.1. Every ATX12V power supply unit has a standard
24-pin ATX main power connector that must be plugged into this connector. If you would like
to use an old power supply with only a 20-pin ATX main power connector, then please plug
the 20-pin ATX main power connector along with pin 1 and pin 13.
PWR12V (+12V Power) connector
Your power supply unit may come with a 4-pin or 8-pin +12V power connector. The +12V
power enables the delivery of more +12VDC current to the CPU's Voltage Regulator Module
(VRM). If available, please use the 8-pin power; otherwise please connect the 4-pin power
to this connector.
2: Reference for 8 pin PWR12V.1: Reference for 4 pin PWR12V.

- 16 -
JW-H61M-L3 User's Manual
Chapter 4 BIOS Setup Utility
BIOS stands for Basic Input and Output System. It was once called ROM BIOS when it was
stored in a Read-Only Memory (ROM) chip. Now manufacturers would like to store BIOS in
EEPROM which means Electrically Erasable Programmable Memory. BIOS used in this series
of mainboard is stored in EEPROM, and is the first program to run when you turn on your
computer.
BIOS performs the following functions:
1. Initializing and testing hardware in your computer (a process called "POST", for Power On
Self Test).
2. Loading and running your operating system.
3. Helping your operating system and application programs manage your PC hardware by
means of a set of routines called BIOS Run-Time Service.
4.1 About BIOS Setup
BIOS Setup is an interactive BIOS program that you need to run when:
1. Changing the hardware of your system. (For example: installing a new Hard Disk etc.)
2. Modifying the behavior of your computer. (For example: changing the system time or date,
or turning special features on or off etc.)
3. Enhancing your computer's behavior. (For example: speeding up performance by turning
on shadowing or cache)
4.2 To Run BIOS Setup
First access BIOS setup menu by pressing <F1> key after “POST” is complete (before OS is
loaded). After the rst BIOS be setupped(or loaded default values) and save, the <DEL> key
will be pressed if you will enter BIOS setup menu.
4.3 About CMOS
CMOS is the memory maintained by a battery. CMOS is used to store the BIOS settings you
have selected in BIOS Setup. CMOS also maintains the internal clock. Every time you turn
on your computer, the BIOS Looks into CMOS for the settings you have selected and
congures your computer accordingly. If the battery runs out of power, the CMOS data will
be lost and POST will issue a “CMOS invalid” or “CMOS checksum invalid” message. If this
happens, you have to replace the battery and check and congure the BIOS Setup for the
new start.
4.4 The POST (Power On Self Test)
POST is an acronym for Power On Self Test. This program will test all things the BIOS does
before the operating system is started. Each of POST routines is assigned a POST code, a
unique number which is sent to I/O port 080h before the routine is executed.

- 17 -
JW-H61M-L3 User's Manual
4.5 BIOS Setup — CMOS Setup Utility
4.5.1 CMOS Setup Utility
After powering up the system, the BIOS message appears on the screen,when the rst time
or when CMOS setting wrong, there is following message appears on the screen , but if
the rst BIOS be setuped(or loaded default values) and save, the <DEL> key will be
pressed if you will enter BIOS setup menu.
If this message disappears before you respond, restart the system by pressing <Ctrl> +
<Alt>+ <Del> keys, or by pressing the reset button on computer chassis. Only when these
two methods should be fail that you restart the system by powering it off and then back on.
Press DEL to Run SETUP
• In order to increase system stability and performance, our engineering staff is
constantly improving the BIOS menu. The BIOS setup screens and descriptions
illustrated in this manual are for your reference only, and may not completely
match with what you see on your screen.This chapter were based mainly on
the model, unless specifcally stated.
• Do not change the BIOS parameters unless you fully understand its function.
The menu bar on top of the screen has the following main items:
Main For changing the basic system conguration
Advanced For changing the advanced system settings
Chipset For changing the system ports settings
Boot For changing the system boot conguration
Security For changing the system security setttings
JUSTw00t For changing the overclocking settings
Save & Exit For changing CMOS mode and loading default settings
Aptio Setup Utility - Copyright (C) 2011 American Megatrends,Inc.
Main Advanced Chipset Boot Security JUSTw00t Save&Exit
BIOS Information Choose the system default
language
BIOS Vendor
Core Version
Compliency
Project Version
Build Date and Time
Memory Information
Total Memory
American Megatrends
4.6.4.1
UEFI 2.0
SB00D380
05/07/2011 12:00:19
2048 MB (DDR3 1333)
→ ←
:Select Scree
↑↓:Select Item
Enter: Select
+/-:Change Opt.
F1 :General Help
F7 :Previous Values
F8 :Fail-Safe Values
F9 :Optimized Defaults
F10:Save&Exit
ESC:Exit
System Language
System Date
System Time
Access Level
[English]
[Thu 05/07/2011]
[17:27:30]
Administrator
Version 2.11.1210. (C)Copyright 2011 American Megatrends, Inc.

- 18 -
JW-H61M-L3 User's Manual
4.5.2 Control Keys
Press F1 to pop up a small help window that describes the appropriate keys to use and the
possible selections for the highlighted item.
Control Key(s) Function Description
←
/
→
Move cursor left or right to select Screens
↑ / ↓
Move cursor up or down to select items
+/ -/PU/PD To Change option for the selected items
<Enter> To bring up the selected screen
<ESC>
Main Menu - Quit and not save changes into CMOS Status
Page Setup Menu and Option Page Setup Menu - Exit
current page and return to Main Menu
<F1> General help
<F7> Previous Values
<F8> Fail-Safe Values
<F9> Load Optimal Defaults
<F10> Save conguration changes and exit setup
4.5.3 Main menu
• BIOS Information
This Item mainly introduce the BIOS related information, such as the BIOS version, the BIOS
manufacturer, the program code versions, establish dates, memory capacity and frequency,
choose the BIOS use of language, the setting of the system date and time, access BIOS user
level, etc.
Aptio Setup Utility - Copyright (C) 2011 American Megatrends,Inc.
Main Advanced Chipset Boot Security JUSTw00t Save&Exit
BIOS Information Choose the system default
language
BIOS Vendor
Core Version
Compliency
Project Version
Build Date and Time
Memory Information
Total Memory
American Megatrends
4.6.4.1
UEFI 2.0
SB00D440
07/06/2011 11:31:41
2048 MB (DDR3 1333)
→ ←
:Select Scree
↑↓:Select Item
Enter: Select
+/-:Change Opt.
F1 :General Help
F7 :Previous Values
F8 :Fail-Safe Values
F9 :Optimized Defaults
F10:Save&Exit
ESC:Exit
System Language
System Date
System Time
Access Level
[English]
[Thu 07/01/2011]
[17:27:30]
Administrator
Version 2.11.1210. (C)Copyright 2011 American Megatrends, Inc.

- 19 -
JW-H61M-L3 User's Manual
• Launch PXE OpROM
Setting PXE ROM open and close, optional for Enalbed, Disbaled.
• Launch Storage OpROM
Setting old equipment storage ROM open and close, optional for Enalbed, Disbaled.
►
ACPI Settings
4.5.4 Advanced
Aptio Setup Utility - Copyright (C) 2011 American Megatrends,Inc.
Main Advanced Chipset Boot Security JUSTw00t Save&Exit
Legacy OpROM Support Enable or Disabe Boot
Option for Legacy
Network Devices.
Onboard Lan BootROM Control
Launch Storage OpROM
►
ACPI Settings
►
RTC Wake Configuration
►
CPU configuration
►
USB Configuration
►
Power Management
►
H/W Monitor
[Disabled]
[Enabled]
→ ←
: Select Scree
↑↓:
Select Item
Enter: Select
+/-: Change Opt.
F1 : General Help
F7 :Previous Values
F8 :Fail-Safe Values
F9 :Optimized
Defaults
F10:Save&Exit
ESC:Exit
Version 2.11.1210. (C)Copyright 2011 American Megatrends, Inc.
Aptio Setup Utility - Copyright (C) 2011 American Megatrends,Inc.
Advanced
ACPI Settings Enable or Disabe
BIOS ACPI Auto
Configuration.
Enable ACPI Auto Configuration
Enable Hibernation
ACPI Sleep State
Lock Legacy Resources
[Disabled]
[Enabled]
[S3 (Suspend to RAM)]
[Disabled]
→ ←
:Select Scree
↑↓:Select Item
Enter: Select
+/-:Change Opt.
F1 :General Help
F7 :Previous Values
F8 :Fail-Safe Values
F9 :Optimized Defaults
F10:Save&Exit
ESC:Exit
Version 2.11.1210. (C)Copyright 2011 American Megatrends, Inc.
