Jarv BTHL-101 User manual

Jarv Nmotion Advance
BTHL-101 Bluetooth Stereo Earbuds
Users Guide

Features:
• Wireless technology using Bluetooth 4.0 A2DP
• Comfortable lightweight in-ear design with ear hooks for
added support
• High Denition Stereo Sound with Noise Reduction
• Rechargeable battery with Up to 6 Hours of Talk/Music
time
• Stream Audio from any Bluetooth Device
• Built-In Noise Canceling Microphone for taking calls
• On Board Controls has built in Volume, Play, Pause and
Answer functionality
• Tangle Free cable

Package Contents:
• Jarv Nmotion Advance BTHL-101 Bluetooth Stereo Earbuds
• Micro USB Charging Cable
• 3 sets of ear bud tips and hooks (S,M,L)
• Carry pouch
• Users Guide
Jarv Nmotion Advance
BTHL-101 Bluetooth Stereo Earbuds
Users Guide

Control Unit:
1. Volume – / Next Track
2. Multi-Function Button - Power/Play/Pause/Pair
3. Volume +/Previous Track
4. Pairing/Power LED Indicator
5. Microphone
6. Micro USB Charging port
1.
2.
3.
4.
5.
6.

LED Indicator Guide
Status Indicator
Power On Flashing Blue Light
Power O Red Light then turns o
Charging Red Light
Charging complete Blue Light
Pairing Mode Red And Blue Light ash
alternately. Once Paired Blue
light will ash slowly.
Low Power Flashing Red Light

Getting Started
To use your Jarv NMotion Advance Bluetooth Stereo headset,
please follow the steps below:
1. Ensure your Bluetooth headset is fully charged.
2. Pair your Bluetooth headset to a Bluetooth-enabled device
prior to use. (See Pairing your Headset instructions)
Charging Your Headset
Your Nmotion Advance headset comes with a built-in
rechargeable battery and a Micro USB charging cable.
Your Nmotion Advance headset can be charged either
directly from an AC power supply (not included) or through
your PC via a micro USB cable (included). Charge fully before
use. The battery indicator will turn red when charging and
turn blue once charging is complete. Initial charging time is
approximately 2 hours.
Pairing Your Headset
In order to use your Jarv Nmotion Advance Bluetooth Stereo
Earbuds with a Bluetooth-enabled device, you will rst need to
pair the two.

1. Place the headset and the mobile phone where they are
easily viewable and no more than one meter apart.
2. Ensure that the headset is fully charged
3. Ensure that the headset is turned o (Very important)
4. Press the Pairing button (multi-function button) for
approximately 8-9 seconds until the red and blue light ash
alternately which indicates that you are in Pairing Mode.
(Note: A blue light will turn on at rst but keep pressing
down the pairing button until it changes to a ashing blue/
red light which indicates that you are in pairing mode)
5. Activate your mobile phone’s Bluetooth pairing function.
6. Set the mobile phone to search for Bluetooth devices within
range and select “Nmotion Advance BTHL-101”from the list
of devices shown.
7. If you are prompted for a Passcode enter“0000”and press
“ok” to pair the headset with your mobile phone. (Note: If the
Bluetooth version of your phone is 2.1, there is no need to
enter the passcode when pairing.)
8. Now you can use your Bluetooth headset to listen to music,
and make and receive phone calls. Some mobile phones
will connect automatically to the Jarv Nmotion Bluetooth
Earbuds when restarted.

Powering On the Headset
Press and hold down the Multi-Function button for 3 seconds
until a blue light appears
Powering O the Headset
Once powered on, Press and hold down the Multi-Function
button for 3 seconds until a red light appears.
Wearing Your Headset
The Left / Right indicator is located on the inside of the
Earbuds.
Using Your Headset
Answering a Call
When you receive a call, the ring tone will be heard through
the headset. Short Press the Multi-Function button once to
accept the call, or answer the call normally via your mobile
phone.
Rejecting a Call
Press the Multi-Function button for 2 seconds to reject the
incoming call.

Ending a Call
Short Press the Multi-Function button to end the call or end
the call directly from your mobile phone.
Redialing a Call
Press the Multi-Function button twice to redial the last dialed
phone number on your mobile phone.
Adjusting the Volume
Short Press the Volume + to increase volume or Volume – to
decrease volume. You will hear a beep when you reach the
maximum or minimum volume level. (You can also adjust the
volume on your handset or device)
Play/Pause Music
When the Bluetooth headset is connected with your mobile
phone, press the Multi-Function button once to play music.
Short Press the Multi-Function button to pause music.
(Attention: your mobile phone must support A2DP prole.)
Previous Track
Press the “Volume +” key to select the previous track.

Next Track
Press the “Volume -” key to select the next track.
Connection With The Last Paired Device
When powered on, the headset will automatically connect
with the last successfully paired device. If the connection
is successful, it enters standby mode. If the devices fail to
connect within 5 minutes after the pairing has been initiated,
the headset will turn o automatically.
Troubleshooting
If you are unable to connect your headset and mobile phone,
please try the following:
Ensure that your headset is fully charged and powered on.
Ensure that the headset is paired with your mobile phone.
Ensure that your mobile phone’s Bluetooth feature is activated.
Please refer to your mobile phone user guide for specic
instructions.
Ensure that the headset is within a 10 meter (30 ft.) range of
your mobile phone and that there are no obstructions, such as
walls or other electronic devices, between the two.

If the above steps do not solve your problem, please remove
your mobile phone battery for a short time and recharge the
headset. Repeat the troubleshooting sequence.
Warranty
At Jarv, we are dedicated to making the best quality product
we can. To back this up, your Jarv Bluetooth earphones are
warrantied for One (1) full year from the date of purchase.
Please visit our website www.jarvmobile.com for more details
or email us at: [e-mail]
Safety Information
Check local laws regarding the use of mobile phones and
headsets while driving.
If you use the headset while driving, ensure that your attention
and focus remains on the road and you drive in a responsible and
safe manner.
Never allow children to play with the headset, as the small parts
may be a choking hazard.
Observe all signs that require an electrical device or RF radio
product to be switched o in designated areas. These could
include hospitals, airplanes, blasting areas, and potentially

explosive environments.
Never mount or store your headset over an air bag deployment
area, a serious injury may result when the air bag deploys.
Do not open or mutilate the built-in battery.
Dispose of batteries according to local regulations. Do not
dispose as household waste.
Care and Maintenance of Your Headset
i. Consider turning your headset o before placing it in your
pocket or bag. If the Power button is accidentally activated,
your mobile phone may place an unintended call. Your
Bluetooth headset comes with a premium quality carry
pouch for your convenience.
ii. Do not expose the headset to liquid, moisture or humidity,
as it is not waterproof.
iii. Do not use abrasive cleaning solvents to clean the headset.
iv. Do not expose the headset to extreme temperatures. The
best storage temperature range is from 40-80 F, otherwise,
the life of the headset will be aected.
v. Do not dispose of the headset in re as it this may result in
an explosion.

vi. Do not bring your headset into contact with sharp objects
as this will cause scratches and can damage the headset.
vii. Do not attempt to disassemble the headset, as it does not
contain serviceable components.
viii. If you do not use the headset for long periods, be sure
to store it in a dry place, free from extreme temperature
conditions and dust. For best protection, use the included
storage pouch.

Product Specications
Basic Specs:
Model No. BTHL-101
Product Size: 23.5 X 0.1 X 0.8 inches
Product Weight: 0.65 oz.
Working Voltage: 3.7V
Charging Voltage: DC 5V
Charging Time - Less than 2 hours
Charging current: 100 mAh
Bluetooth Version: Bluetooth 4.0 A2DP
Built-In Microphone
Driver: 10mm
Wireless Range: 33 feet
DC Battery power: Built-in rechargeable lithium battery
Battery:
Battery Specs: 3.7V 80mAh x 1
Battery Size: 0.2 X 0.4 X 0.8 inches
Battery life: Up to 6 hours of Talk/Music Time
Stand-by Time: Up to 100 hours

Actual performance may vary due to the user’s habits, dierent
modes of operation, and mobile phone settings. This manual is
for reference purposes only. The specications and design of the
headset may change without prior notice. Actual product may
dier slightly from the image on the packaging
Warning and Precautions
WARNING: To prevent re or shock hazard, do not expose this
unit to rain or moisture.
WARNING: Do not place this unit directly onto furniture
surfaces with any type of soft, porous, or sensitive nish. As
with any rubber compound made with oils, the feet could
cause marks or staining where the feet reside. We recommend
using a protective barrier such as cloth or a piece of a glass
between the unit and the surface to reduce the risk of damage
and/or staining.
WARNING: Lithium batteries, like all rechargeable batteries are
recyclable and should be recycled or disposed of in normal
household waste. Contact your local government for disposal

or recycling practices in your area. They should be incinerated
since they might explode.
NOTE: This device uses an internal rechargeable lithium-
ion battery that should last the lifetime of the device. If you
suspect your battery may be dead after several attempts to
charge, please visit www.jarvmobile.com for support.
Never disassemble the unit or attempt to remove the battery
as that could cause leakage of an electrolyte substance
FCC Warnings
WARNING: Changes or modications to this unit not expressly
approved by the party responsible for compliance could void
the user’s authority to operate the equipment.
NOTE: This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to Part
15 of the FCC rules. These limits are designed to provide
reasonable protections against harmful interference in a
residential installation. This equipment generates, uses, and
can radiate radio frequency and, if not installed and used

in accordance with the instructions, may cause harmful
interference to radio communications. However, there is
no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference
to radio or television reception, which can be determined by
turning the equipment on and o, the user is encouraged to
try to correct the interference by one or more of the following
measures.
• Reorient or relocate the receiving antenna
• Increase the separation between the equipment and
receiver
• Connect the equipment into an outlet on a circuit dierent
from that to which the receiver is connected
