Jasco ZigBee ZB3001 (45857) User manual

ZB3001(45857)
ZigBee®,In‐WallOn/Off/DimmerSwitch
HomeAutomationStandardVersion1.2Compliant
Introduction
ThankyouforyourpurchaseofaJascoZigBee®controldevice.JascoZigBeelightingcontrolsare
designedtoautomatelighting/homecontrolandprovideeasyremoteoperationofallyourZigBee
enableddevices.TheJascoZigBeeproductfamilyincludesavarietyofdevicestocontrollightinginyour
home.Itisuptoyouwhetheryouwanttocontroloneroomoryourentirehouseandwhetheryouwant
todoitallnoworstartwithoneroomandaddmoreovertime.
Thisdimmerswitchisdesignedforusewithpermanentlyinstalledlightingfixturesonly.Theswitch
hasbeenoptimizedforusewithincandescentlightingaswellaswithmostdimmableCFLandLED
bulbs.Themaximumloadratingsforthisswitchare600Wforincandescentbulbsand150Wfor
dimmableCFLandLED’s.Lightingcontrolledbythisswitchmustnotexceedthesestatedlimits.
NOTE:ActualperformanceofanyCFLorLEDwillvaryfrombulbtypetobulbtypeandamongdifferent
manufacturers.Itisimportanttonotethatonlybulbsthathavebeendesignedasdimmableshouldbeusedona
dimmer.Tofindoutifyourbulbisdimmable,pleasecheckthepackage,thebulbitself,orcallthebulbmanufacturer
directly.
CAUTION‐ToReduceTheRiskofOverheatingandPossibleDamagetoOtherEquipment,DoNotInstallto
ControlaMotor‐OperatedAppliance,AFluorescentLightingFixtureoraTransformerSuppliedAppliance
Therearenouserserviceablepartsinthisunit.
!Warning!
RISKOFFIRE
RISKOFELECTRICALSHOCK
RISKOFBURNS
NOT FOR USE WITH MEDICAL OR LIFE SUPPORT EQUIPMENT
ZigBee enabled devices should never be used to supply power to or control the On/Off status of medical and/
or life support equipment!
WARNING:
ControllingAppliances:
ExerciseextremecautionwhenusingZigBeedevicestocontrolappliances.OperationoftheZigBeedevicemay
beinadifferentroomthanthecontrolledappliance,alsoanunintentionalactivationmayoccurifthewrong
buttononthecontrollerinterfaceispressed.ZigBeedevicesmayautomaticallybepoweredonduetotimed
eventprogramming.Dependingupontheappliance,theseunattendedorunintentionaloperationscouldpossibly
resultinahazardous.
1. DoNotincludeZigBeedevicesinGroupsorScenesiftheycontrolappliances.
2.DoNotuseZigBeedevicestocontrolelectricheatersoranyotherapplianceswhichmaypresentahazardous
conditionduetounattendedorunintentionalorautomaticpoweroncontrol.

KeyFeatures
TurnON/OFForDIMlightingmanuallyorremotelyviatheZigBeecontroller
CanbeIncludedinmultipleGroupsandScenes
MaybeusedinsinglepoleinstallationorwithuptotwoJascoauxiliaryswitchesin2‐way,3‐
wayor4‐waywiringconfigurations
WorkswithDimmableCFL/LEDbulbsforimprovedenergyefficiency
InterchangeablePaddleswitch:White&lightalmondpaddleinpackage
OvertheAirupdates–OncejoinedtoyourZigBeenetwork,thedevicecantransparentlyreceive
updatesthroughyourZigBeegateway
EnergyMonitoring–Thedevicecanreportwattage(W)andkilowatthours(kWh).Energyusage
ismonitoredthroughtheZigBeeControllerInterface
Usesastandard,decora‐sizewallplateforsingleganginstallations(wallplatenotincluded)
BlueLEDindicatesswitchlocationinadarkroom(LEDcanbeenabled/disabledmanually)
LEDStatusIndicator–Indicatesdevicescanningduringpairingprocess
ZigBeeHA1.2Certifiedforsimplepairingandintegratedhomeautomation
ScrewTerminalinstallation;requireswiringconnectionsforLine(Hot),Load,Neutral,and
Ground.Travelerwirerequiredformultipoleinstallation
To change color of the switch
1. LifttheAirGaptabatthebaseofthecover.
2. Pushsidetabsinononesideandthentheothertoreleasecover.Liftthecoverupandoff.
3. Simplyputthenewcoverontotheswitchbyinsertingtheairgapandsidetabsandsnappingsecurely
intoplace.
Installation
Thisswitchmaybeusedinnewinstallationsortoreplaceanexistingwallswitch.Itmaybeusedbyitself
for2‐waycontrol(oneswitch&oneload),withoneJascoAuxiliarySwitchfor3‐waycontrol(two
switches&oneload)orwithtwoJascoAuxiliaryswitchesfor4‐waycontrol(threeswitches&oneload).
Whenusedbyitselffor2‐waycontrol,pleasemakesurethatthescrewterminalforthetravelerwireis
insulated(DoNotRemovethetapeovertheterminalifyouarenotusingthetravelerconnection)
WARNING‐SHOCKHAZARD
TurnOFFthepowertothebranchcircuitfortheswitchand
lightingfixtureattheservicepanel.Allwiringconnectionsmust
bemadewiththePOWEROFFtoavoidpersonalinjuryand/or
damagetotheswitch.

CONNECTIONS
TWO‐WAYCONTROL
SINGLESWITCHWIRINGUSINGONEPRIMARY
SWITCH
THREE‐WAYCONTROL
TWOSWITCHWIRINGUSINGONEPRIMARY
ANDONEAUXILIARYSWITCH
FOUR‐WAYCONTROL
THREESWITCHWIRINGUSINGONEPRIMARYANDTWOAUXILIARYSWITCHES
Single,DualandTripleGangBoxes
The metal plate surrounding the switch assembly is a heat sink. The maximum load rating (600W) is
provided when installed in a single gang box with the full heat sink. Multiple dimmer switches may be
installed in dual or triple gang boxes and, if necessary, one or both sides of the heat sink may be
removed by bending it at the score lines. There is a corresponding reduction in the switch’s load rating
when ganged. DO NOT exceed the following loads:

CFL/LEDRATINGIncandescentRATINGNumberofDimmersHeatSink
150W600W1SwitchinSingleGang
Box
Full–Notabsremoved
125W500W2SwitchesinDouble
GangBox
Onetabremoved
(Inner)
100W400W3SwitchesinTriple
GangBox
Bothtabsremoved
ObserveImportantWiringInformation
Important:Thisswitchisratedforandintendedtoonlybeusedwithcopperwire.
Thehome’selectricalwiresmaybeattachedtothescrewterminalsorinsertedintotheholesinthe
backoftheswitchenclosureandclampedinplacebytighteningthescrewterminals.Alwaysfollowthe
recommendedwirestriplengthswhenmakingwiringconnections.
Wiregaugerequirements
• Use14AWGorlargerwiressuitableforatleast80°Cforsupply(HOT),Load,Neutral,Groundand
Travelerconnections.
Wirestriplength:
•Forattachmenttoscrewterminals:Stripinsulation1in(25mm)
•Forattachmentusingtheenclosure’sholes:Stripinsulation5/8”(16mm)
ULspecifiesthatthetighteningtorqueforthescrewsis14Kgf‐cm(12lbf‐in).
SINGLESWITCHWIRING
1. Shutoffpowertothecircuitatfuseboxorcircuitbreaker.
2. Removewallplate.
!Warning:VerifypowerisOFFtoswitchboxbeforecontinuing.
3. Removetheswitchmountingscrews.
4. Carefullyremovetheswitchfromtheswitchbox.DONOTdisconnectthewires.
5. Therearefivescrewterminalsontheswitch;thesearemarked
LINE(Hot)
Neutral
LOAD
GROUND
TRAVELER
TheTravelerterminalisonlyusedfor3‐wayor4‐waywiringandshouldremaininsulatediftheswitchis
beinginstalledina2‐waysystem(oneswitch&oneload).Matchthesescrewterminalstothewires
connectedtotheexistingswitch.
6. Disconnectthewiresfromtheexistingswitch.
7. ConnectthegreenorbarecoppergroundwiretotheGROUNDterminal.
8. ConnecttheblackwirethatgoestothelighttotheterminalmarkedLOAD.
9. Connecttheblackwirethatcomesfromtheelectricalservicepanel(Hot)totheterminalmarked
LINE.

10.Connectthewhitewiretotheneutralterminal.
Note:ULspecifiesthatthetighteningtorqueforthescrewsis14Kgf‐cm(12lbf‐in).
11.InsertSwitchintotheswitchboxbeingcarefulnottopinchorcrushwires.
12.Securetheswitchtotheboxusingthesuppliedscrews.
13.Mountthewallplate.
14.Reapplypowertothecircuitatfuseboxorcircuitbreakerandtestthesystem.

OPTIONALforTHREEorFOUR‐WAYCONTROL:

ConnecttheTravelerwire(usuallyRed)tothescrewterminalmarkedTRAVELERontheprimaryswitch
(DoNotremovethetapeovertheterminalifyouarenotusingthetravelerconnection).Theotherend
ofthisTravelerwireconnectstotheTRAVELERscrewterminalontheAuxiliarySwitch.

1.Theauxiliaryrequiresthefollowing3wiringconnections:
a.TheTravelerwire.Thisisusedtosendvoltagesignalstotheprimaryswitch.Thesignalsfromthe
auxiliarytelltheprimaryswitchwhatactiontoperform.
b.Ground.
c.Neutral.
2.DONOTconnecttheauxiliaryswitchtothehome’sblackHot(Line)wire.



Oncetheswitchisproperlywired,youshouldbeabletousetherockertomanuallyturnOn/Offanddim
theconnectedload

BasicOperation
TheconnectedlightcanbeturnedON/OFFintwoways:
1. Manuallyfromthefrontpanelofthein‐wallswitch
2. RemotelywithaZigBeeController
MANUALCONTROL

TheFrontPanelRockerSwitchallowstheuserto:

TurnON/OFFtheconnectedlighting.
•ToturntheconnectedlightingON:Tapthetopoftherocker.
•ToturntheconnectedlightingOFF:Tapthebottomoftherocker.

ToBRIGHTEN/DIMtheconnectedlighting
•Tobrightentheconnectedlighting,pressandholdthetopoftherockeruntilthedesired
brightnessisachieved
•Todimtheconnectedlighting,pressandholdthebottomoftherockeruntilthedesired
brightnessisachieved

Thedimmerswitchretainsthepreviousdimmersetting.Whenturningthedimmerswitchonby
tappingthetoprocker,thedimmerwillautomaticallyreturntothepreviousdimsetting.

REMOTECONTROL
ZigBeedevicescanbecontrolleddirectlybyyourZigBeeControllerandremotelyoverlongdistances
withaPCormobilephoneappifyourhome’scontrollerfunctionsasagatewayconnectedtoan
internetrouter.
TocontrolthedeviceremotelyitmustbepairedtotheZigBeeControllerasinstructed
ZigBeeNetworkPairing
JointheswitchtotheZigBeeNetwork
1. FromyourZigBeeController’sinterface,choosetoaddlightingdeviceandenter
Locating/Pairingmodeasinstructedbythecontroller.
2. AfterapplyingpowertotheIn‐Wallswitch,yourIn‐WallSwitchwillbeginautoscanmodeasit
searchesforacontrollertopairwith
Auto‐Scan:LEDStatusIndicatorBlinks3xevery10secondsasthedevicescansfora
compatiblenetworkcontrollertopairwithuntilTimeout.
Timeout:Auto‐ScanmodewilleventuallytimeoutaftertheLEDStatuslightstops
blinking.IfdeviceTimeoutoccursbeforetheswitchhasjoinedtheZigBeenetwork,
pressanybuttonontheswitchtoresumescanning.
3. AftertheswitchislocatedandpairedtotheZigBeenetwork,theLEDStatusIndicatorwillstop
blinkingandtheswitchwillappearinyourcontroller’smenu.SetuptheswitchasanOn/Off
controlandtitletheswitchinawaythatwillbeeasytoidentify.
ThemoduleisnowpairedtotheZigBeenetworkandcanbecontrolledremotely.
ResetDevice(RemovefromZigBeeNetwork)
FromtheZigBeeController
Fromyourcontrollerorhubinterface,choosetoremoveordeletethelightingdeviceasinstructed.The
devicewillberemovedfromtheZigBeenetworkfollowingindicationfromyourcontroller.All
configurationparameterswillberesetafterthedeviceisremovedfromthenetwork.
Manual
Resettingtofactorydefaultsrequiretheuserto:
1. Lifttheair‐gapswitchatthebottomoftherockertoOFFpositiontopowerdownthedevice.
2. HolddowntheUPbutton
3. PushIntheair‐gapswitchtoONpositiontopowerupthedevice.
4. ReleaseUPbuttonwithin4secondsafterpowerup.

LEDParameters
Toassistwithlocatingtheswitchinadarkroom,theLEDglowsbluewhenthelightswitchisturnedOFF.
ToturnLEDoff:
Taptoprocker(ONSwitch)3xquicklyandthentapbottomrocker(OFFSwitch)1x
TorestoreLED:
UsethesameseriesofbuttonpressesusedtodisabletheLEDtorestore
WARRANTY
JASCOProductswarrantsthisproducttobefreefrommanufacturingdefectsforaperiodoftwoyearsfromthe
originaldateofconsumerpurchase.Thiswarrantyislimitedtotherepairorreplacementofthisproductonlyand
doesnotextendtoconsequentialorincidentaldamagetootherproductsthatmaybeusedwiththisproduct.This
warrantyisinlieuofallotherwarranties,expressedorimplied.Somestatesdonotallowlimitationsonhowlong
animpliedwarrantylastsorpermittheexclusionorlimitationofincidentalorconsequentialdamage,sotheabove
limitationsmaynotapplytoyou.Thiswarrantygivesyouspecificrights,andyoumayalsohaveotherrightswhich
varyfromstatetostate.PleasecontactCustomerServiceat800‐654‐8483(option1)between7:30AM–5:00PM
CSTorviaourwebsite(www.jascoproducts.com)iftheunitshouldprovedefectivewithinthewarrantyperiod.
FCCandICCompliance
U2ZZB3001
TheFederalCommunicationCommissionRadioFrequencyInterferenceStatementincludesthe
followingparagraph:
TheequipmenthasbeentestedandfoundtocomplywiththelimitsforaClassBDigitalDevice,
pursuanttopart15oftheFCCRules.Theselimitsaredesignedtoprovidereasonableprotectionagainst
harmfulinterferenceinaresidentialinstallation.Thisequipmentuses,generates,andcanradiateradio
frequencyenergyand,ifnotinstalledandusedinaccordancewiththeinstruction,maycauseharmful
interferencetoradiocommunication.However,thereisnoguaranteethatinterferencewillnotoccurin
aparticularinstallation.Ifthisequipmentdoescauseharmfulinterferencetoradioortelevision
reception,whichcanbedeterminedbyturningtheequipmentoffandon,theuserisencouragedtotry
tocorrecttheinterferencebyoneormoreofthefollowingmeasures:
Reorientorrelocatethereceivingantenna
Increasetheseparationbetweentheequipmentandreceiver
Connecttheequipmentintoanoutletonacircuitdifferentfromthattowhichthereceiveris
connected
Consultthedealeroranexperiencedradio/TVtechnicianforhelp
Operationissubjecttothefollowingtwoconditions:
Thisdevicemaynotcauseinterference
Thisdevicemustacceptanyinterference,includinginterferencethatmaycauseundesired
operationofthedevice.

ImportantNote:TocomplywiththeFCCRFexposurecompliancerequirements,nochangetothe
antennaorthedeviceispermitted.Anychangetotheantennaorthedevicecouldresultinthedevice
exceedingtheRFexposurerequirementsandvoiduser’sauthoritytooperatethedevice.
Caution: Exposure to Radio Frequency Radiation. To comply with FCC/IC RF exposure compliance
requirements, a separation distance of at least 20 cm must be maintained between the antenna of
this device and all persons. This device must not be co-located or operating in conjunction with any
other antenna or transmitter.
CompliancewithICRulesand
RegulationsIC:6924A‐ZB3001
JascoProductsCompany
Model:ZB3001(45857)
CANICES‐3(B)/NMB‐3(B)
This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to
the following two conditions: (1) this device may not cause interference, and (2) this device must
accept any interference, including interference that may cause undesired operation of the device.
OPERATINGSPECIFICATIONS
Power120VAC,60Hz
Signal(Frequency)2.4GhzIEEE802.15.4
MaximumloadfortheZigBeecontrolledIn‐WallSwitch:
o600WIncandescent
o150WDimmableCFL/LED
oGangRatings:
Numberof
Dimmers
CFL/LEDRATINGIncandescent
RATING
1SwitchinSingle
GangBox
150W600W
2Switchesin
DoubleGangBox
125W500W
3Switchesin
TripleGangBox
100W400W
OperatingTemperatureRange:32‐104°F(0‐40°C)
Forindooruseonly.
ComplieswithFCCandIndustryCanadaregulations
Use14AWGorlargerwiressuitableforatleast80°C

Recommended Compatible Dimmable CFL/LED Bulbs

LampTypeCFL/
LEDLampMfg.LampModel
Lamp
Watts
LEDEcosmart1255018W
CFLEcosmart4012323W
CFLEcosmart2R3015DIM15W
CFLEcosmart40114(SKU#238875)14W
CFLSylvaniaCF14EL/TWIST/DIM14W
LEDSylvaniaLED10PAR20/DIM/P/930/FL30 10W
LEDSylvaniaLED8A19/DIM/0/8278W
LEDPhilips92900022273W
CFLGEFLE26/2/DV/R4026W
LEDFeitPAR30L/LEDG515W
LEDFeitG25/DM/LED10W
LEDFeitPAR20/LEDG59.5W
LEDUtilitechLPAR20/LEDG59.5W
CFLEcosmart40114(SKU#709447)14W
LEDPhilips3.5E26BA12DBBAAA3.5W
LEDMiseengardeLED7P20DS827/207W
CFLUtilitechLPAR20DM/LED(338804)7.5W
LEDPhilips9E26PA19DCAAAA8W


JASCOProducts
10E.MemorialRd
OklahomaCity,OK73114
www.jascoproducts.com

ZigBee®isaregisteredUStrademarkoftheZigBeeAlliance

Theimages,productinformationandspecificationslistedinthisdocumentarepreliminaryandsubject
tochange

