ASSEMBLY INSTRUCTIONS
Elements Workstation
3 Person Run
Size: 1800mm
Tools Required: Power screwdriver.
2 persons required for installation
Special Note: No pre-drilled holes or nut inserts are
provided. Wood screws will be required to be drilled
directly into underside of desk top.
Page 1 of 5
Need help!
Call us on
1300 527 665
www.jasonl.com.au

A
B
D
JJ
F
F
G
G
E
E
H
H
I
C
K
A
B
C
D
E
F
G
H
I
J
K
Phillip Head M6*15 Wood Screw (silver) x12
Phillip Flat Head M6*20 Screw (gold) x16
L
M
COMPONENTS
SCREWS
Page 2 of 5
Need help!
Call us on
1300 527 665
www.jasonl.com.au
ASSEMBLY INSTRUCTIONS
Elements Workstation
3 Person Run
Size: 1800mm
Desk top x3 (1800mm x 800mm)
Top plate x4
Leg core insert x2
Leg core return x4
Leg sleeve x8
Sleeve cover x8
Fold Scren x8
Base Foot x8
Core cover x4
Sleeve Cap x8
Extandable Beam x3

Page 3 of 5
Need help!
Call us on
1300 527 665
www.jasonl.com.au
ASSEMBLY INSTRUCTIONS
Elements Workstation
3 Person Run
Size: 1800mm
Unwrap all leg components.
Remove sleeve cap (J) and sleeve
cover (F) from all leg sleeves.
Insert base foot (H) into leg sleeve (E)
by rotating base foot (H) clockwise.
Insert sleeve cap (J) onto leg core (D)
for all legs.
Insert leg sleeve (E) onto leg core (D)
for all legs. TIP: Keep height adjustment
holes pointing outwards.
Place leg core insert (C) onto leg core
(D) for all legs.
Place core cover (I) onto leg core (D)
for all legs.
Place sleeve cover (F) over leg sleeve
(E) for all legs.
D
J
J
F
F
G
GE
E
H
H
I
C
01

Page 4 of 5
Need help!
Call us on
1300 527 665
www.jasonl.com.au
ASSEMBLY INSTRUCTIONS
Elements Workstation
3 Person Run
Size: 1800mm
Connect extendable Beam (K) to Leg Core (D)
02
D
K
Tighten Top Plate (B) to middle legs core (D) by tightening Screw (M).
04
D
BM
Tighten Top Plates (B) to outer legs core (D) by tightening Screw (M).
03
D
B
M

Page 5 of 5
Need help!
Call us on
1300 527 665
www.jasonl.com.au
ASSEMBLY INSTRUCTIONS
Elements Workstation
3 Person Run
Size: 1800mm
Attach outsider legs + beam to Desk Tops by tightening Scews (L).
05
L
L
Attach middle leg to Desk Tops by tightening Scews (L).
06
