Jason.L Quadro Wood A User manual

ASSEMBLY INSTRUCTIONS
Quadro Wood A desk
Size: 1000W x 600D mm
Page 1 of 6
Need help!
Call us on
1300 527 665
www.jasonl.com.au
Tools Required: Power screwdriver; Allen key set (provided)
2 persons required for installation

Need help!
Call us on
1300 527 665
www.jasonl.com.au
ASSEMBLY INSTRUCTIONS
Quadro Wood A desk
Size: 1000W x 600D mm
Table top x1
Legs Quadro A x2
Beam x1
Plastic bracket x4
A
B
C
D
Allen key x2J
M8x20MM CSK x2
M8x20MM Socket head x2
M6x20MM Socket head x4
M6x30MM Socket head x4
M6x30mm Mushroom head screw x4
E
F
G
H
I
COMPONENTS
SCREWS
Page 2 of 6
C
D
E F G H
A
B
I

Need help!
Call us on
1300 527 665
www.jasonl.com.au
ASSEMBLY INSTRUCTIONS
Quadro Wood A desk
Size: 1000W x 600D mm
Page 3 of 6
Insert the bottom of the legs as shown in the
illustration. Using Allen Key provided, attach
Mushroom Head Screw (I) - for all legs.
You will notice two colored
stickers located on each leg.
Both legs must have the colour
sticker facing away from where
the plastic brackets are inserted.
Plastic bracket holes
facing to the other side.
STEP 01 STEP 02
I

Need help!
Call us on
1300 527 665
www.jasonl.com.au
ASSEMBLY INSTRUCTIONS
Quadro Wood A desk
Size: 1000W x 600D mm
Page 4 of 6
F
G
STEP 03 STEP 04 STEP 05
Using Allen Key provided, attach 2 plastic
brackets per leg (D) (as per picture above)
using M6x20MM (G) Socket head screw
Using Allen Key provided, attach M8x20MM
Socket head (F)- screw socket half way
into leg for both legs (B)
Use fixed beam (C) 1000mm and secure beam
using screws provided to suit 1000mm desk

Need help!
Call us on
1300 527 665
www.jasonl.com.au
ASSEMBLY INSTRUCTIONS
Quadro Wood A desk
Size: 1000W x 600D mm
STEP 06
TOP VIEW
Attach beam (C) to legs (B) using nut insert in legs
See point attached
Frame looks like this. Using Allen Key, attach beam (C) with Socket (E)
STEP 07
Page 5 of 6
E
E

Need help!
Call us on
1300 527 665
www.jasonl.com.au
ASSEMBLY INSTRUCTIONS
Quadro Wood A desk
Size: 1000W x 600D mm
STEP 08
Page 6 of 6
Place desktop ontop of frame. Nut inserts in top will align with plastic
joiner brackets using M6x30MM (H) sockets attached top to frame.
nut insert nut insert
TABLE TOP
BOTTOM VIEW
H
