Jason.L San Fran User manual

Special Note: Please ignore any pre-drilled holes or nut inserts that maybe present in your top(s).
They will not match your particular table/desk base and woods screws will be required to be screwed
directly into the underside of the top.
Tools Required: Power screwdriver.
Page 1 of 4
Need help!
Call us on
1300 527 665
www.jasonl.com.au
INSTALLATION GUIDE
San Fran
Boardroom Frame
Sizes:
3000 x 1200
3200 x 1100
3600 x 1200

Leg x4
Adjustable Foot x4
Leg Cable Cover x4
Rail Lengths x2
Rail Lengths x4
Intermediate Leg x1 (490mm)
2 Way Connector x4
2 Way Connector Cap x4
3 Way Connector x2
3 Way Connector Cap x2
Rail Space Bracket (Plastic support) x3
Slot Nut x6
Table Top x2
Support Connector (Metal arm) x4
1
2
3
4
5
6
7
8
9
10
11
12
13
14
M8x20mm Dome Head x20
M8x12mm Dome Head x4
M8x20mm Cap Head x6
M5x20mm Self Tapping x24
15
16
17
18
COMPONENTS
SCREWS
Page 2 of 4
Need help!
Call us on
1300 527 665
www.jasonl.com.au
INSTALLATION GUIDE
San Fran
Boardroom Frame
13
3
6
1
11 16
14
12 10
2
75
9
8
4
17 15

01 02
04
Slide the 2 way connectors over each leg, and securely lock into place
using M8x20mm cap head bolts. Slide 3 way connectors into intermediate
leg & secure into place using M8x20mm cap head bolts.
Loosely connect the longer M8x20mm dome head bolt and slot nut through the
rail spacer bracket. Slide onto required rails and fully tighten in place.
Securely connect legs to rails lengths using the shorter M8x20mm dome
head bolts.
03
Loosely connect the shorter M8x12mm dome head bolt and slot nut through the
metal rail spacer bracket. Slide onto required rails and fully tighten in place.
Page 3 of 4
Need help!
Call us on
1300 527 665
www.jasonl.com.au
INSTALLATION GUIDE
San Fran
Boardroom Frame

05
Securely connect legs to rails widths using the shorter
M8x12mm dome head bolts.
Ensure the work surfaces are centered over the frame. Fully tighten all M5x20mm
self tapping screws through each leg rail spacer and support connector bracket
into the work surfaces.
Cancel any power box cable using the magnetic leg cable covers.
Page 4 of 4
Need help!
Call us on
1300 527 665
www.jasonl.com.au
07
06
INSTALLATION GUIDE
San Fran
Boardroom Frame
