Jason.L Switch System 2 Person Workstation User manual

INSTALLATION GUIDE
Switch System
2 Person Workstation
Size: 1600mm
Tools Required: Power screwdriver.
Special Note: No pre-drilled holes or nut inserts are provided.
Wood screws will be required to be drilled directly into underside of desk top.
Page 1 of 4
Need help!
Call us on
1300 527 665
www.jasonl.com.au

Table Top x2 (1600x800mm)
Leg x4
Leg Bracket x4
Beam Bracket x8
Long Beam x2 (1225mm)
Short Beam x2 (1200mm)
L-Bracket x10
1
2
3
4
5
6
7
Hex Nut x4
L-Bracket screws x10
Hex Head screws x16
M8x25mm Dome Head x4
8
9
10
11
COMPONENTS
SCREWS
Page 2 of 4
INSTALLATION GUIDE
Switch System
2 Person Workstation
Size: 1600mm
Need help!
Call us on
1300 527 665
www.jasonl.com.au
6
4
3
7
9
11
2
1
5
8

Page 3 of 4
INSTALLATION GUIDE
Switch System
2 Person Workstation
Size: 1600mm
Need help!
Call us on
1300 527 665
www.jasonl.com.au
Join 3 L-Bracket through each Long Beam
and 2 L-Bracket through each Short Beam.
Join Leg Brackets to each Leg using screws to secure them, as follow.
Securely connect each Beam to each Beam Bracket. Screw to secure. Insert Hex Nut on each Beam Bracket.
01
03 04
02

INSTALLATION GUIDE
Switch System
2 Person Workstation
Size: 1600mm
Need help!
Call us on
1300 527 665
www.jasonl.com.au
Page 4 of 4
Position as presented, and proceed to screw
to ensure each corner of the frame.
Once we get the whole frame ready, ensure the worksurface is
centered over the frame. If you are planning to install a divider
screen, leave a 25mm gap between tables.
25mm
05 06
Directly screw into table tops, using L-Bracket screws
through each L-Bracket.
07
Note: If you are planning to install Pincer Brackets
like the image to the right, you need to attach these
brackets before continuing.
