Jason.L Horizon 3 Person 120 Degree Workstations User manual

Tools Required: Power screwdriver / Power Drill
2 persons required for installation
Special Note: No pre-drilled Nut inserts . Screws to be drilled into the underside of desktop.
ASSEMBLY INSTRUCTIONS
Horizon 3 Person
120 Degree Workstations
Size: (x3) 1200 x 1200 x 700 mm
Page 1 of 5
Need help!
Call us on
1300 527 665
www.jasonl.com.au

Screen x3 (1200mm)
3-way 120 degree connector x1 (1200mm)
Desk Legs x6
Desk leg foot insert x12
L-Shaped panel brackets x6
L-Shaped post brackets x3
Desktop x3 (1200 x 1200 x 700)
Cantilever brackets x6
bottom view
1
2
3
4
5
6
7
8
25mm self tapping screws x 3 pack9
COMPONENTS
SCREWS
Page 2 of 5
Need help!
Call us on
1300 527 665
www.jasonl.com.au
ASSEMBLY INSTRUCTIONS
Horizon 3 Person
120 Degree Workstations
Size: (x3) 1200 x 1200 x 700 mm
1
7
3
4
8
5
2
6

STEP 1
Page 3 of 5
Need help!
Call us on
1300 527 665
www.jasonl.com.au
ASSEMBLY INSTRUCTIONS
Horizon 3 Person
120 Degree Workstations
Size: (x3) 1200 x 1200 x 700 mm
Divider screens assembly
Using an allen key, please
remove 3 caps from all
screens. Bring 3 partitions
towards one another and
slide the 3-way 120 degree
connector -down between
the three screen uprights.
STEP 2
Divider screens assembly
After Sliding the 120 degree connector down between the three screen
uprights , then please slide all the 3 x L-Shaped post brackets (part n6)
on each side as per drawing. Please leave the 3 L-shaped post
brackets on the bottom of the screen.

Page 4 of 5
Need help!
Call us on
1300 527 665
www.jasonl.com.au
ASSEMBLY INSTRUCTIONS
Horizon 3 Person
120 Degree Workstations
Size: (x3) 1200 x 1200 x 700 mm
Attach the top plates to the legs.
STEP 3
Use L-Shaped panel brackets (part n5) to secure the screen to the
desktop by placing the brackets in each side of the screen and under
the desktops. The L panel brackets to be drilled with self tapping
screws into the screen and also the desktop.
STEP 6
Build the legs with 1 cantilever bracket attached to each leg.
STEP 4
Attach outer legs + cantilever brackets to desks
by drilling screws into the underneath Tops
STEP 5

Page 5 of 5
Need help!
Call us on
1300 527 665
www.jasonl.com.au
ASSEMBLY INSTRUCTIONS
Horizon 3 Person
120 Degree Workstations
Size: (x3) 1200 x 1200 x 700 mm
STEP 7
Use L-Shaped post brackets (part n6) placed on Step 1 to secure the screen
to the desktop by placing each side of the screen and under the desktops.
Please tighten the L post brackets screws to the screen and drill self
tapping screws into the desktop
Installation
completed
