Jason.L Quadro Square User manual

ASSEMBLY INSTRUCTIONS
Quadro Square
Desk Frame
Page 1 of 6
Need help!
Call us on
1300 527 665
www.jasonl.com.au
Tools Required: Power screwdriver; Allen key set (provided)
2 persons required for installation
Sizes:
1000x1000
1200x800
1400x800
1600x800
1800x800
2000-2400x800

ASSEMBLY INSTRUCTIONS
Quadro Square
Desk Frame
Table top x1
Legs Quadro Square x2
Beam x1
Plastic bracket x4
A
B
C
D
Allen key x2I
M8x20MM CSK x2
M8x20MM Socket head x2
M6x20MM Socket head x4
M6x30MM Socket head x4
E
F
G
H
COMPONENTS
SCREWS
Page 2 of 6
Need help!
Call us on
1300 527 665
www.jasonl.com.au
C
D
E F G H
A
B
Colour of the beam is always black, regardless desk frame colour.
*
*

F
G
ASSEMBLY INSTRUCTIONS
Quadro Square
Desk Frame
STEP 01
Using Allen Key provided, attach 2 plastic brackets per leg (D)
(as per picture above) using M6x20MM (G) Socket head screw
Using Allen Key provided, attach M8x20MM Socket head (F)-
screw socket half way into leg for both legs (B)
STEP 02
Page 3 of 6
Need help!
Call us on
1300 527 665
www.jasonl.com.au

ASSEMBLY INSTRUCTIONS
Quadro Square
Desk Frame
STEP 03
Adjust extendable beam (C) to desired
length using markers and secure beam
at that length using screws provided
Page 4 of 6
Need help!
Call us on
1300 527 665
www.jasonl.com.au
50
1200
1300
1400
1500
1600
1700
1800
1900
2000
50

ASSEMBLY INSTRUCTIONS
Quadro Square
Desk Frame
STEP 04
TOP VIEW
Attach beam (C) to legs (B) using nut insert in legs.
See point attached
Frame looks like this. Using Allen Key, attach beam (C) with Socket (E)
STEP 05
Page 5 of 6
Need help!
Call us on
1300 527 665
www.jasonl.com.au
E
E

ASSEMBLY INSTRUCTIONS
Quadro Square
Desk Frame
STEP 06
Page 6 of 6
Need help!
Call us on
1300 527 665
www.jasonl.com.au
Place desktop on top of frame - with cutout at the back of the desk.
Wood Screws to be drilled into the underneath Top.
