Jay-tech RDO 1000 Mounting instructions

RDO 1000 Roller Door Opener
RDO 1800 Light Industrial Roller
Door Opener
Installation Instructions and User Guide
WARNING
Please read this manual carefully before installation and use. The installation of your
new door opener must be carried out by a technically qualified person. Attempting to
install or repair the door opener without suitable technical experience may result in
severe personal injury, death and / or property damage.

- 1 -
START BY READING THESE IMPORTANT
SAFETY INSTRUCTIONS
WARNING
• Failure to comply with the following instructions may
result in serious personal injury or property damage.
• Read and follow all instructions carefully.
• This This opener is designed and manufactured to meet
Australian Standards AS/NZS 60335.2.95:2012 and
AS/NZS 60335.1:2011 when installed correctly.
These safety alert symbols mean WARNING : A possible
risk to personal safety or property damage exists.
1.Keep garage door balanced. Do not let the garage door
opener compensate for a binding or sticking garage door.
Sticking, binding or unbalanced doors must be repaired
before installing this opener.
2.Do not wear rings, watches or loose clothing. while
installing or servicing a garage door opener. Wear gloves and
suitable protective clothing where appropriate.

- 2 -
3.Frequently examine the door installation, in particular,
springs and mountings for signs of wear, damage or
imbalance. Do not use if repair or adjustment is needed since
springs and hardware are under extreme tension and a fault
can cause serious personal injury.
4.To avoid serious personal injury from entanglement,
remove all ropes, chains and locks connected to the
garage door before installing the door opener.
5.Installation and wiring must be in compliance with your
local building and electrical codes.
6.The safety reverse system test is very important. Your
garage door MUST reverse on contact with a 40 mm obstacle
placed on the floor. Failure to properly adjust the opener may
result in serious personal injury from a closing garage door.
Repeat the test once a month and make any necessary
adjustments.
7.This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capability,
or lack of experience and knowledge, unless they have been

- 3 -
given supervision or instruction concerning use of the
appliance by a person responsible for their safety.
8.Automatic Drive - Keep away from the area of the door as
it may operate unexpectedly.
9.This opener should not be installed in a damp or wet
space exposed to weather.
10.The opener must not be used on a wicket door (door
within a door).
11.Photo Beams must be used for all installations where
the closing force as measured on the bottom of the door
is over 400 N (40 kg). Excessive force will interfere with the
proper operation of the safety reverse system or damage the
garage door.
12.After installation, ensure that the parts of the door do
not extend over public footpaths or roads.
13. Install the wireless wall control (or any additional wall
control) in a location where the garage door is visible, at a
height of at least 1.5 m and out of the reach of children.

- 4 -
Do not allow children to operate push button(s) or
transmitter(s). Serious personal injury from a closing garage
door may result from misuse of the opener.
14.Permanently fasten the Warning Labels in prominent
places, adjacent to wall controls and manual release
mechanisms as a reminder of safe operating procedures.
15.Activate opener only when the door is in full view, free
of obstructions and the opener is properly adjusted. No
one should enter or leave the garage while the door is in
motion.
16.Do not allow children to play near the door, or with
door controls.
17. If the supply cord is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualified persons
in order to avoid hazard.
18.Disconnect electric power and battery to the garage
door opener before making repairs or removing covers.

- 5 -
KEEP THESE INSTRUCTIONS
CONTENTS
PAGE
CONTENTS
PAGE
SAFETY INSTRUCTIONS························· 1-5
IR Beam setting·················································12
PACKING LIST······································6
Auto-close setting················································12
TOOLS REQUIRED··································6
Installation direction setting·······································13
DOOR REQUIREMENTS·····························6
Lock door setting (Optional function) ······························13
TESTING THE DOOR································7
Half-open setting (Optional function) ······························13
INSTALLING THE STOP COLLAR·····················7
Alarm and maintenance function··································13
INSTALLING THE WEIGHT BAR (PROVIDED)··········7
TESTING THE SAFETY REVERSE SYSTEM·················14
THE RELEASE HANDLE & CORD·····················8
FIXING WARNING LABELS································14
OPERATING THE MANUAL RELEASE·················8
INSTALL THE IR BEAMS (OPTIONAL ACCESSORY) ········15
PINNING THE DOOR································9
INSTALL UNIVERSAL RECEIVER (OPTIONAL ACCESSORY) ·15
ATTACHING EXTENSION POLES (IF REQUIRED) ······9
INSTALL A FLASHING LIGHT (OPTIONAL ACCESSORY) ·····16
LEFT / RIGHT HAND INSTALLATION··················9
MAINTENANCE··········································16
INSTALLATION PROCEDURE·····················10-11
FINAL NOTES············································16
BASIC FUNCTION SETTING AND APPLICATION····11-13
IMPORTANT INFORMATION FOR THE USER················17
Pairing the receiver and transmitter·······················11
SPECIFICATIONS·········································17
Travel limit setting, Opening & closing force self-learning·······11
COMMON FAULTS & SOLUTIONS··························18
Safety reverse force adjustment····························12
Warranty Information ·····························19-20

- 6 -
3.DOOR REQUIREMENTS
The maximum allowable door height is 5.5m. The door must be of continuous corrugated sheet
construction and spring balanced. Door axle diameter must not exceed 35mm.
Ensure that there is at least 45 mm from the edge of the curtain to the edge of the bracket. If the
roller door drum is on the edge of the curtain or is a smaller diameter, additional clearance may be
required.
If the drum is more than 60 mm from the curtain edge or of a smaller diameter, an extension
pole kit may be required (section 10).
Ensure there is a suitable power point near the opener.
1.Packing List
Standard list ：
1.Rolling garage door opener X 1；
2.Remote control X 2；
3.Instructions X 1；
4.Clutch pull rope X 1；
5.Warning Label X 1；
Selection list：
1.Weight bar X 1;
2.Wall switch X 1;
3.Extension pole bag X 1;
2.TOOLS REQUIRED
Ladder
Socket wrench
Adjustable
Wrench
Drill
Marker Pen
13MM Socket
≥250MM Socket
Extension
Philips-head
Screwdriver
6.5MM Drill Bit

- 7 -
4.TESTING THE DOOR
Complete the following test to ensure your door
is well balanced, and not sticking or binding:
• Disable all locks and remove any ropes connected
to the garage door.
• Lift the door to about halfway and then release it.
The door should remain spring balanced.
• Raise and lower the door to determine if there are
any sticking or binding points (20 kg is the absolute
maximum allowable to raise or lower the door in
any position).
• If your door does not hold in place or the door
binds or sticks, call a qualified door technician
before installing the opener.
5.INSTALLING THE STOP COLLAR
•Install the stop collar on the opposite end to where
the opener is to be installed.
• Fit the stop collar hard against the boss of the door
drum. Ensure the U-bolt holding the door shaft to the
door bracket is tightly
secured.
6.INSTALLING THE WEIGHT BAR (PROVIDED)
• Place the weight in the center of the door (as shown).
• Use a pencil to mark the two-hole positions.
• If the door curtain does not have a handle you will need to
drill two 6.5 mm holes through the two marked positions,
then place the weight bar on the inside of the door.
• Use the bolts and nuts (provided) to fasten the weight bar in
place.
NOTE: If the door has a lifting handle, remove the
handle, nuts & bolts. Place weight bar over the handle
holes, insert extended bolts through the weight bar &
fasten handle back in place (may not always be possible).
SAFETY CHECK!
Is the stop collar installed?
YES: proceed to the next step
NO: install the stop collar before proceeding

- 8 -
7.THE RELEASE HANDLE & CORD
• Thread one end of the rope through the hole in the
top of the red release handle so that “NOTICE”
reads correctly.
• Secure with an overhand knot at least 25 mm from
the end of the rope to prevent slipping.
• Thread the other end of the rope through the loop
of the manual release cable.
• Adjust rope length so the handle (when installed)
will be no higher than 1.8 m above the floor. Secure with an overhand knot.
NOTE: Final adjustment of handle height should be completed after the opener is installed. If it is
necessary to cut the rope, heat seal the cut end to prevent unravelling.
8.OPERATING THE MANUAL RELEASE
To disengage the opener
Pull the release cord down firmly；
To re-engage the opener
Pull the release cord down firmly；
NOTE:
Disable all locks and remove any ropes connected to
the garage door.
Take care when operating the manual release as an
open door may fall rapidly due to weak or broken
springs.

- 9 -
9.PINNING THE DOOR
Note: A ballooning door may delay
the safety reversal response and can
compromise garage door security.
• To remedy any ballooning place
self-tapping metal screws or rivets
where the curtain leaves the roll. Secure
these through the curtain into the drum
wheel at each end of the roll.
• After determining the correct fastener
location as shown, lift the door
approximately half a turn from the closed
position to allow access for drilling.
10.ATTACHING EXTENSION POLES (IF REQUIRED)
Optional accessory
• Align the extension pole holes with the drive legs.
• Slide the reinforcing brace over the poles.
• Insert the extension poles into the drive leg and fix in place
using screws provided.
* Reinforcing brace must be used.
11.LEFT / RIGHT HAND INSTALLATION

- 10 -
12.INSTALLATION PROCEDURE
Do not allow people to walk under or around the door during the installation process as
serious injury can occur.
NOTE: The opener can be installed on either side of the door. The following instructions are
for RIGHT HAND INSTALLATIONS (as illustrated i.e. inside the garage looking out). For left
hand installations, reverse the instruction terminology (eg LEFT for RIGHT etc).
Preparation:
• Place the opener in manual release mode (refer
section 8).
• Open the roller door fully. For safety, tie a rope
around the door.
• Ensure the door axle U-BOLT and door mounting
bracket on the left-hand side (non-opener side) are
securely fastened.
• Support the door with a door stand or similar
device to safely support the door.
• Mark the position of the door shaft on the
right-hand door bracket (for reassembly purposes).
• While the door is supported, remove the right-hand
axle U-Bolt and door mounting bracket from the wall.
Install the opener:
• Slide the opener over the door axle and engage
the drive legs into the door drum wheel, either side
of a spoke. Extensions may be necessary (refer
section 10).
• Refit the door mounting bracket to the wall. If the
door bracket needs to be relocated due to opener
width refer to section 3.
• Clamp the opener on the door axle and door
bracket in the marked position using the clamp
assembly supplied (tighten to 25 –28 Nm).
• If side room exceeds 95mm clamp independently to
the door axle as illustrated in section 3.
• Remove all ropes and the support stand.
• Check the operation of the door in manual mode by
raising and lowering by hand. It should operate
smoothly without sticking or binding. The disengage
handle should already be attached less than 1.8m
above the floor (refer section 4 and section 7).
Connect the power:
• Position the power cable away from the door curtain and any moving parts.
• Plug the opener into a nearby power point and turn ON.

- 11 -
13. BASIC FUNCTION SETTING AND APPLICATION
13.1 Matching the receiver and transmitter
Coding Transmitters:
Press and hold “Code”button for 1 second until the LED dot
illuminates. Press desired button on transmitter once, the dot will
extinguish, press the same transmitter button again and the dot will
flash fast for 8 times, and then return to standby mode. The transmitter
is now coded into the receiver.
Repeat the above steps to code more transmitters. The receiver has the capacity to store 20
transmitters.
If the led display flashes “F”and returns to standby mode (after you have pressed the Code
button), this indicates that the memory storage is full (20 transmitters). Follow the steps below to
delete all transmitters that are stored in the receiver memory: Press and hold “CODE”button for
more than 8 seconds until the LED flashes “C”, all the stored codes are deleted.
NOTE：If a transmitter is not paired within 20 seconds, it will return to standby mode automatically.
13.2 Travel limit setting Opening & closing force self-learning
Press and hold “SET” button for 3 seconds until the LED flashes “1”.
Press “SET” button again for 1 second. “1” should now display as steady
(not flashing).
Adjust the up limit by pressing “UP” button.
Fine-tune by pressing “UP” or “DOWN” button to determine the final up
limit position (the LED flashes “n” or “u” during opening or closing), then press “SET” button, the
display will now show “2” automatically.
Adjust the down limit by pressing “DOWN” button.
Fine –tune by pressing “UP” or “DOWN” button to determine the final down limit position (the LED
flashes “n” or “u” during opening or closing), then press “SET” button.
If the opener stops operating and the LED flashes “H” or “C”, this indicates there’s no hall signal or
the opener is overloaded. Call a Professional Technician as the door may require maintenance.
The opener will operate a cycle automatically to remember the limit positions and the original
opening & closing force, then return to standby mode.
During learning, if the door stops unusually, and flashes “Ξ”, “C”, “O”. “L” for 5 seconds, this indicates
there’s no hall signal, overload, overtime or the wrong limit setting.
• The opener courtesy LEDs should turn ON.
• The opener must now be programmed for:
1.DOOR TRAVEL LIMITS (Section 13.2)
2.RIGHT- OR LEFT-HAND OPERATION (Section 13.6)
3.FORCE SETTING (Section 13.3)

- 12 -
13.3 Safety reverse force adjustment
Press and hold on “SET” button for 3 seconds until the LED flashes “1”.
Press “UP” or “DOWN” button until LED flashes “2”, then press “SET”
button. The unit is now in force adjustment mode. The LED displays the
current set force.
Press “UP” button to increase the force and “DOWN” button to
decrease the force. The maximum force is 9 and the minimum is 1. Press “SET” button to confirm,
then the opener returns to standby mode.
The default setting of safety reverse force is 3.
13.4 IR Beam setting
Press and hold on “SET” button for 3 seconds until the LED flashes “1”.
Press “UP” or “DOWN” button until the LED flashes “3”, press “SET”
button. It’s now under IR Beam setting mode. The LED displays the
current setting.
Press “UP” button, the LED displays “1”, the IR Beam Function is
available. Press “DOWN” button, the LED displays “0” to cancel this function. Press “SET” button to
confirm. The opener returns to standby mode.
The default setting of IR Beam is “0”.
Notice:
•Disable the IR Beam function if no IR Beam sensors are installed.
•We urge you to consider fitting IR Beams to your new garage door opener. In many countries these
devices are compulsory to assist in preventing serious injury or property damage.
13.5 Auto-close setting
Press and hold on “SET” button for 3 seconds until the LED flashes “1”.
Press “UP” or “DOWN” to increase or decrease, adjust the LED to
flash ”4”, then press “SET” button to enter into auto-close setting, the
LED displays the current setting.
Press “UP” or “DOWN” button to adjust the auto-close time. Press “UP”
button once, the auto-close time will increase 1 minute, the maximum
time is 9 minutes. Press “DOWN” button once, the auto-close time decreases by 1 minute. The
auto-close function will be turned off when the LED displays “0”. Press “SET” button to confirm, the
opener will return to standby mode.
The auto-close function is only available when the door is fully open and the IR Beam function is on.
The default setting is “0”.
13.6 Installation direction setting
Press and hold on “SET” button for 3 seconds until the LED flashes “1”.
Press “UP” or “DOWN” to increase or decrease, adjust the LED to
flash ”5”, then press “SET” button.
The display will show “R” or “ L”, hold down the “UP” or “Down” button
to change. Press the “SET” button, the LED will display the current
setting.

- 13 -
NOTE: “L” means left hand installation，“R” means right hand installation (viewed inside
looking out)
13.7 Lock door setting (Optional function)
Press and hold “SET” button for 3 seconds until the LED flashes “1”.
Press “UP” or “DOWN” button to increase or decrease. Adjust the LED
to flash “6”, press “SET” button to enter into lock door setting. The LED
displays the current setting.
Press “UP” button, the LED displays “1”, the lock door function is on. Press “DOWN” button, the LED
displays”0”, the lock door function is off. Press “SET” button to confirm, the opener returns to standby
mode.
When the lock door function is on and the door is fully closed, the opener will lock the door
automatically. And then the door can only be opened by a transmitter after being unlocked by the
“lock” key(S2) on the transmitter. (If the opener is not unlocked by the S2 button on the transmitter,
the light will flash twice when pressing the open key on the transmitter)
The default setting is: Off
13.8 Half-open setting (Optional function)
Press and hold “SET” button for 3 seconds until the LED flashes “1”.
Press “UP” or “DOWN” button to increase or decrease. Adjust the LED to
flash “7”. Press “SET” button to enter into half-open setting. The LED
displays the current setting.
Press “UP” or “DOWN” button to increase or decrease. When the LED displays ”1”, the half-open
height is 30cm. When the LED displays “2”, the half-open height is 60cm. When the LED displays “3”,
the half-open height is 90cm. When the LED displays “0”, the half-open function is off. Press “SET”
button to confirm, the opener returns to standby mode.
If the half-open function is on, only when the door is fully closed, the door can be half-opened by the
“S1” key on the transmitter. If the door is at another position, the “S1” key will not work.
The default setting is : Off
13.9 9. Alarm and maintenance function
When the LED flashes and the display shows "A", this means the opener working cycles have been
exceeded. Call Technician for service.

- 14 -
14.TESTING THE SAFETY REVERSE SYSTEM
The safety reverse system test is important.
The garage door must reverse on contact with a 40 mm obstacle laid flat on the floor.
Failure to properly adjust the
opener may result in serious
personal injury from a closing
garage door.
Operate the door in the down
direction. The door must reverse
upon contact with the obstacle. If the
door stops on the obstacle, remove
obstacle and repeat limit and force
setting (refer section 13.3).
Repeat test of the safety reverse system.
15.FIXING WARNING LABELS
Once you have completed your installation and
successfully carried out the safety reverse
system test (outlined above), install the warning
labels provided with your opener as shown.
The WARNING label must be installed in a
prominent place near any fixed control.
Any fixed wall control or wireless door control
must be mounted at a height of no less than 1.5
m out of the reach of children.
Read the safety instructions (page 1) for further
details concerning safety.

- 15 -
17.INSTALLING A UNIVERSAL RECEIVER OR PUSH BUTTON
16.INSTALL THE IR BEAMS (OPTIONAL ACCESSORY)
NOTE: This accessory must be used for all installations where the closing force as measured
on the bottom of the door is over 400 N (40 kg).
ENABLING THE IR BEAM SYSTEM:(Section 13.4)
*Door may operate unexpectedly, therefore do not allow anything to stay in the path of the
door.

- 16 -
18.INSTALLING A FLASHING LIGHT (OPTIONAL ACCESSORY)
Only use 24V DC Flashing Lights.
19.MAINTENANCE
No particular maintenance is required for the logic circuit board.
Check that the door is properly balanced, and all working parts are in good
Condition at least twice per year.
Check the reversing sensitivity at least twice a year and adjust if necessary.
Make sure that the safety devices are working effectively (IR Beams, etc.)
Notice: An incorrectly operating door can affect the life of the automatic opener due to
incorrect loads and will void the warranty. We strongly recommend having a
Professional service the door annually.
20.FINAL NOTES
This manual is only used by technical persons who are qualified to carry out the installation.
It is important for the installer to show their clients correct operation of the opener including the use
of the manual disengagement cord.
Inform the owner about the need of regular maintenance, especially regarding a regular check
of the safety and reversing devices.

- 17 -
22.SPECIFICATIONS SILENTDRIVE
Model
MR350
MR400
RD01000
Opening Speed
200MM/S
200MM/S
200MM/S
Rated Lifting Weight
(350N)
(400N)
(450N)
Max Lifting Force
600N
800N
1000N
Rated door area
18 m²
20 m²
22 m²
Max door weight
100kgs
110kgs
120kgs
Drum Rotations
5.5
5.5
5.5
Power Supply
220VAC-240VAC/50Hz -60Hz ; 110VAC-127VAC/50Hz-60Hz
Motor Type
24V DC permanent magnet
General working time
≤60s
Working Temperature
-20℃- +50℃
Transmitter Frequency
433.92MHz
Coding Type
Rolling code
Coding Combination
Over 4.29 billion
Lights
24V / 12pcs LED bulbs
21.IMPORTANT INFORMATION FOR THE USER
Once the opener has been installed, the user must be informed about the risks that can arise if it is
used improperly. The user must avoid placing himself/herself in dangerous situations such as standing
within the door’s operating range when it is moving.
Do not let children play near the door and keep the remote controls out of their reach.
All services, repairs or checks must be carried out by professionally qualified persons and should
be noted on a maintenance register kept by the user.
IMPORTANT NOTE: In the case of a malfunction the user must call an authorized installer and
should not attempt the repair themselves.

- 18 -
COMMON FAULT & SOLUTIONS
Fault appearance
Fault cause
Solutions
Opener won’t function
1. Power supply
1. Check the power supply.
Opener doesn’t work,
LED displays “-”
Incorrect “UP”or “DOWN”travel
limit settings
Program “UP”and “DOWN”travel limits again.
The door will open, but
won’t close
In operation with IR Beam.
Or IR Beam function is enabled
but with no IR Beam connected.
Check IR Beam for obstruction.
Cancel the IR Beam function if there’s no IR
Beam connected. (follow the instruction manual)
Open and close action
is reversed
Reversed connection of the
positive and negative of motor
wire to the control board or
direction setting wrong.
* Power off firstly, open the motor cover and
reverse the positive and negative motor wire on
the control board. Re-set the travel limit.
Reset travel direction for LH or RH installations
Door auto reverses to
fully open position
before closing
completely
In operation with safety reverse
function. Door not well balanced
or an obstacle
1. Check the door springs or any obstructions
2. Re-set the travel limit.
3. Call Professional Technician
Transmitter doesn’t
work
1. Flat battery
2. Antenna is loose or not well
extended
3. Signal interference
1. Replace the battery
2. Extend the antenna on the opener
3. Check for faulty door bells, baby monitors,
alarms etc
Unable to pair new
transmitters
1. Memory is full
2. New transmitters are not
compatible with opener
1. Press and hold “CODE” button for more than 8
seconds until the LED flashes “C”, this will delete
all stored codes, then pair all transmitters again.
2. Use only Jaytech transmitters
LED displays “C”,
opener does not work
1. Motor plug wire is loose
2. Control board is damaged
1. Re-insert motor plug wire
* 2. Replace new control board
LED displays “Ξ”,
opener does not work
1. Motor is damaged
1.Pull the release cord down firmly.
* 2. Replace the motor
LED displays “Ξ”,after
opener operates
several centimeters
only
1. Hall element wire plug loose
between hall element and
control board.
2. Hall element or control board
is damaged
1. Check the wire plug
* 2. Check the hall element
* 3. Replace control board
The LED lamp flashes
and displays “A”
Opener working cycle exceeds
the maximum limit and needs
maintenance
* Call a Professional Technician
Note: Only qualified professional persons can carry out maintenance marked with “*”.

- 19 -
PRODUCT WARRANTY For 5 years from the date of installation (2 years RDO 1800) this product
will be repaired, or replaced free of charge, if defective in material or workmanship.
ADDITIONAL WARRANTY ON PARTS Replacement parts for any defective parts on this product will be
furnished, free of charge. Any costs for professional installation are included.
WARRANTY RESTRICTION This Garage Door Opener Warranty does not cover light bulbs or fuses, which
are expendable items, or repair parts necessary because of operator abuse or negligence, including the failure
to adjust and operate this garage door opener according to instructions contained in the owners’ manual. This
warranty also does not cover any problems caused by interference or impact damage and does not cover
remote controls.
This warranty remains valid providing the door has been serviced at least every 3 years (1 year RDO 1800) by
any professional garage door company since the installation of this opener. Proof of service will be requested
and failure to produce this may void your warranty.
Warranty is void if damage or premature wear to the opener is sustained by a broken, unbalanced, worn or
damaged garage door.
Original purchase receipt / Invoice is required to process a warranty claim.
If a Technician is requested to attend and rectify the issue and it is reasonably deemed to be caused by other
factors other than a product fault the customer agrees that they may be charged a call out fee, plus any parts
required to complete the repair. Liability –Australia only
Under no circumstances shall the Seller be liable for consequential, incidental or special damages arising in
connection with the use, or inability to use, the Unit. In no event shall the Seller's liability for damages or injury
arising from breach of law or contract or for negligence, exceed the cost of repairing or replacing the Unit or
refunding the purchase price of the Unit. Under Division 2 Part V of the Trade Practices Act, 1974, certain
warranties and conditions (Implied Terms) are implied into contracts for the supply of goods or services if the
goods or services are of a kind ordinarily acquired for personal, domestic or household use or consumption.
Liability for breach of those Implied Terms cannot be excluded or limited and the limitations and exclusions
above do not apply to the Implied Terms. Except for the Implied Terms and the warranties set out above, the
Seller excludes all warranties and conditions implied by statute, at law, in fact or otherwise.
Our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are
entitled to a replacement or refund for a major failure and compensation for any other reasonably foreseeable
loss or damage. You are also entitled to have the goods repaired or replaced if the goods fail to be of
acceptable quality and the failure does not amount to a major failure.
If you believe you have a faulty product you may submit a warranty request by contacting the company listed
below.
