jbc FAE1 User manual

FAE1 H13 Filter
Ref. FAE1-10 0
INSTRUCTION MANUAL
www.jbctools.com

Packing List
The following items should be included:
FAE1 H13 Filter
Ref. FAE1-100
Manual ........................................................... 1 unit
Ref. 0022639
FAE1 H13 + Carbon + M5 Filter...............1 unit
Ref. FAE1-100
INSTRUCTION MANUAL
Connect the filter tube to
the quick coupling placed
on the metal sheet
The filter has a given position.
Make sure the filter ribs mate
with the corresponding slots.
Filter replacement
2
www.jbctools.com

Fume Extractor
Ref. FAE1-1A
FAE1-2A
Filter replacement
- The unit notifies through both the display
and the Filter saturation indicator when filters
need maintenance.
- To replace the filters remove the cover by
opening the quick release levers of the
casing.
- See Filter positioning instruction on
page 2.
- Once the FAE1-100 filter has been replaced,
the carbon filter counter must be reset.
(Main Menu > Filter set > Reset carbon)
The duration of the FAE1-100 filter is 1 year
maximum once its packaging is opened.
- If the filter is changed while the fume
extractor is on, once the cover is placed the
equipment starts an automatic filter detection
process, activating aspiration for a few
seconds.
M5 Pre-filter
Ref. FA E1-110
H13 Filter
& Carbon Filter
H13 Filter & Carbon Filter
& M5 Pre-filter
Ref. FAE1-100
Read safety guidelines to do the equipment maintenance securely.
Filter saturation indicator:
Green: Filter OK
Yellow: - ≤ 20% carbon lifetime
- ≥ 80% Saturation
Red: - End of carbon lifetime
- Filter saturated
www.jbctools.com
3

Main menu
Exit
1 Reset
2 Unit
3 Port
4 Filter set
5 Counters
6 Program version
Filter set
1 Carbon life 20%
2 Saturation 80%
3Reset carbon
Back
STOP #1
Useful filter life is worn out.
Replace it and execute reset
function in the filter menu.
STOP #3
Filter not detected. Place
a filter in order to use the
fume extractor.
STOP #2
Filter obstructed. Replace
the pre-filter, if the error
remains, replace the
HEPA+carbon filter set.
WARNING #1
Useful filter life is about to
wear out. In 5 days the filter
life is going to finish.
WARNING #2
Filter is about to obstruct.
Filter set
1 Carbon life 20%
2Saturation 80%
3Reset carbon
Back
Filter set
1 Carbon life 20%
2 Saturation 80%
3Reset carbon
Back
Control Process
Filter Menu
Warning & Errors
Shows % of remaining life of the
carbon filter contained inside the
FAE1-100 filter. It is also displayed
on the main screen.
Perform this action when changing
the FAE1-100 filter. The carbon life
counter doesn’t start until the filter is
detected for the first time.
≤ 20% carbon lifetime
(Filter indicator in Yellow)
Shows % of saturation level of
FAE1-100 filter. It is also displayed
on the main screen.
≥ 80% Saturation
(Filter indicator in Yellow)
End of carbon lifetime
(Filter indicator in Red)
No filter installed
(Filter indicator in Red)
Filter saturated
(Filter indicator in Red)
4

Safety
- The equipment is only designed to filtrate the fumes generated by soldering.
- Do not use the units for the filtration of combustible, explosive or corrosive gases.
Incorrect use may cause fire.
- Maintenance must not be carried out by children unless supervised.
- Keep your workplace clean and tidy. Wear appropriate protective mask, glasses and gloves when
handling dirt filter or pre-filter.
- Saturated filters can not be cleaned and reused.
- Avoid blowing the filter or the dirty parts of the equipment, if necessary it is advisable to vacuum.
- Avoid losing particles in the unit during handling of the filter.
- Treat the saturated filters as waste depending on the filtered contaminant and the applicable
standars in each country.
European Waste Catalog classification:
15 02: Absorbents, filter materials, wiping cloths and protective clothing.
15 02 02: Absorbents, filter materials (including oil filters not otherwise specified, wiping cloths,
protective clothing contaminated by dangerous substances.
15 02 03: Absorbents, filter materials, wiping cloths and protective clothing other than those
mentioned in 15 02 02.
- In case of not complying with the filter change recommendations, the maximum particle and gas
concentrations established in each country could be exceeded.
It is imperative to follow safety guidelines to prevent electric
shock, injury, fire or explosion.
www.jbctools.com
5

Notes
6

www.jbctools.com
7

This product should not be thrown in the garbage.
Saturated filters must be collected and returned to an authorized recycling facility.
Manuals in other languages are available on our website
Warranty
JBC’s two-year warranty covers this equipment
against all manufacturing defects, including the
replacement of defective parts and labour. Warranty
does not cover product wear or misuse. In order for
the warranty to be valid, equipment must be returned,
postage paid, to the dealer where it was purchased.
0022639-0319
Specifications
- Net Weight: 2.89 kg (6.37 lb)
- Dimensions: 281 x 268 x 197 mm (11.06 x 10.55 x 7.74 in)
- Pre-filter: Medium dust filter M5 (EN 779)
- Main Filter: H13 particle filter (EN 1822)
Activated carbon filter
Complies with CE standards.
