jbc FAE1 User manual

FAE1 H14 Filter
Ref. FAE1-200
INSTRUCTION MANUAL
www.jbctools.com

Packing List
The following items are included:
FAE1 H14 Filter
Ref. FAE1-200
Manual ........................................................... 1 unit
Ref. 0026264
FAE1 H14 + Carbon + M5 Filter...............1 unit
Ref. FAE1-200
INSTRUCTION MANUAL
Connect the filter tube to
the quick coupling placed
on the metal sheet
The filter has a given position.
Make sure the filter ribs mate
with the corresponding slots.
Filter replacement
2
www.jbctools.com

Fume Extractor
Ref. FAE1-1A
FAE1-2A
Filter replacement
- The unit notifies through both the display
and the Filter saturation indicator when filters
need maintenance.
- To replace the filters remove the cover by
opening the quick release levers of the
casing.
- See Filter positioning instruction on
page 2.
- Once the FAE1-200 filter has been replaced,
the carbon filter counter must be reset.
(Main Menu > Filter set > Reset carbon)
The duration of the FAE1-200 filter is 1 year
maximum once its packaging is opened.
- If the filter is changed while the fume
extractor is on, once the cover is placed the
equipment starts an automatic filter detection
process, activating aspiration for a few
seconds.
M5 Pre-filter
Re f. FA E1-110
H14 Filter
& Carbon Filter
H14 Filter & Carbon Filter
& M5 Pre-filter
Ref. FAE1-200
Read safety guidelines to do the equipment maintenance securely.
Filter saturation indicator:
Green: Filter OK
Yellow: - ≤ 20% carbon lifetime
- ≥ 80% Saturation
Red: - End of carbon lifetime
- Filter saturated
www.jbctools.com
3

Main menuMain menu
Exit
1 Reset
2 Unit
3 Port
4 Filter set
5 Counters
6 Program version
Filter setFilter set
1 Carbon life 20%
2 Saturation 80%
3Reset carbon
BackBack
STOPSTOP ##11
Useful filter life is worn out.
Replace it and execute reset
function in the filter menu.
STOPSTOP ##33
Filter not detected. Place
a filter in order to use the
fume extractor.
STOPSTOP ##22
Filter obstructed. Replace
the pre-filter, if the error
remains, replace the
HEPA+carbon filter set.
WARNINGWARNING ##11
Useful filter life is about to
wear out. In 5 days the filter
life is going to finish.
WARNINGWARNING ##22
Filter is about to obstruct.
Filter setFilter set
1 Carbon life 20%
2Saturation 80%
3Reset carbon
BackBack
Filter setFilter set
1 Carbon life 20%
2 Saturation 80%
3Reset carbon
BackBack
Control Process
Filter Menu
Warning & Errors
Shows % of remaining life of the
carbon filter contained inside the
FAE1-200 filter. It is also displayed
on the main screen.
Perform this action when changing
the FAE1-200 filter. The carbon life
counter doesn’t start until the filter is
detected for the first time.
≤ 20% carbon lifetime
(Filter indicator in Yellow)
Shows % of saturation level of
FAE1-200 filter. It is also displayed
on the main screen.
≥ 80% Saturation
(Filter indicator in Yellow)
End of carbon lifetime
(Filter indicator in Red)
No filter installed
(Filter indicator in Red)
Filter saturated
(Filter indicator in Red)
4

Safety
- The equipment is only designed to filtrate the fumes generated by soldering.
- Do not use the units for the filtration of combustible, explosive or corrosive gases.
Incorrect use may cause fire.
- Maintenance must not be carried out by children unless supervised.
- Keep your workplace clean and tidy. Wear appropriate protective mask, glasses and gloves when
handling dirt filter or pre-filter.
- Saturated filters can not be cleaned and reused.
- Avoid blowing the filter or the dirty parts of the equipment, if necessary it is advisable to vacuum.
- Avoid losing particles in the unit during handling of the filter.
- Treat the saturated filters as waste depending on the filtered contaminant and the applicable
standars in each country.
European Waste Catalog classification:
15 02: Absorbents, filter materials, wiping cloths and protective clothing.
15 02 02: Absorbents, filter materials (including oil filters not otherwise specified, wiping cloths,
protective clothing contaminated by dangerous substances.
15 02 03: Absorbents, filter materials, wiping cloths and protective clothing other than those
mentioned in 15 02 02.
- In case of not complying with the filter change recommendations, the maximum particle and gas
concentrations established in each country could be exceeded.
It is imperative to follow safety guidelines to prevent electric
shock, injury, fire or explosion.
www.jbctools.com
5

Notes
6

Notes
www.jbctools.com
7

This product should not be thrown in the garbage.
In accordance with the European directive 2012/19/EU, electronic equipment at the end of its life must
be collected and returned to an authorized recycling facility.
Warranty
JBC’s 2 year warranty covers this equipment against
all manufacturing defects, including the replacement
of defective parts and labour.
Warranty does not cover product wear or misuse.
In order for the warranty to be valid, equipment must
be returned, postage paid, to the dealer where it was
purchased.
www.jbctools.com 0026264-1020
Specifications
- Net Weight: 2.89 kg (6.37 lb)
- Dimensions: 281 x 268 x 197 mm (11.06 x 10.55 x 7.74 in)
- Pre-filter: Medium dust filter M5 (EN 779)
- Main Filter: H14 particle filter (EN 1822)
Activated carbon filter
Complies with CE standards.
