jbc NP115 User manual

NP115
Nano Tweezers
INSTRUCTION MANUAL

2
Packing List
The following items are included:
NP115
Nano Tweezers
NAE
2-Tool
Nano Control Unit*
N1738
Sleeves for
NP105 & NP115 Tweezer
(one pair)
Connections
Power Socket
Main Switch
Nano Tweezers ....................................... 1 unit
Re f. NP115 -A
Manual ...................................................... 1 unit
Ref. 0029758
This manual corresponds to the following reference:
NP115-A
C115
Cartridges*
*not included, sold separately
NAE

40 mm
50 mm
60 mm
80 mm
100 mm
130 mm 130 mm
para manuales - color gris
200 mm
300 mm
3
Changing Sleeves N1738
NT115
NT115/NP115
HT420/HT470
T245
WS440
NH HEATER HOSE
HT420
HT420
HT420
NT115
NT115/NP115
HT420/HT470
T245
WS440
NH HEATER HOSE
HT420
HT420
HT420
NT115
NT115/NP115
HT420/HT470
T245
WS440
NH HEATER HOSE
HT420
HT420
HT420
NT115
NT115/NP115
HT420/HT470
T245
WS440
NH HEATER HOSE
HT420
HT420
HT420
NT105 Nano Handle
NP105 Nano Tweezers
Changing Grips N6079
Make a length-ways cut. Be careful
not to damage the handle.
Remove the old grip.
Removing Grips
Assembling Grips
Apply vaseline
inside the grip
for easier fitting
Cutter
Change the sleeves by pulling the worn ons out and by pushing the new ons onto the tweezer
arms.
Sleeve
N1738
Tweezers Arm

NAE
Control Unit
PORT
2
ROBOT
PEDAL
2
NAE
Control Unit
PORT
2
ROBOT
PEDAL
2
ROBOT
C115
C11
C105 /
C105 / C115
19:29
19:29
Port
2
Actual Temp. 25ºC
NT105
ºC
Power
45%
Selected 350ºC
350
Port
2
NT105
Hibernation
19:29
Port
2
Actual Temp. 25ºC
AN115
Hibernation
19:29
ºC
Power
45%
Selected 350ºC
350
Port
2
AN115
No Yes
NAE
Control Unit
PORT
2
ROBOT
PEDAL
2
NAE
Control Unit
PORT
2
ROBOT
PEDAL
2
ROBOT
C115
C11
C105 /
C105 / C115
19:29
19:29
Port
2
Actual Temp. 25ºC
NT105
ºC
Power
45%
Selected 350ºC
350
Port
2
NT105
Hibernation
19:29
Port
2
Actual Temp. 25ºC
AN115
Hibernation
19:29
ºC
Power
45%
Selected 350ºC
350
Port
2
AN115
No Yes
NAE
Control Unit
PORT
2
ROBOT
PEDAL
2
NAE
Control Unit
PORT
2
ROBOT
PEDAL
2
ROBOT
C115
C11
C105 /
C105 / C115
19:29
19:29
Port
2
Actual Temp. 25ºC
NT105
ºC
Power
45%
Selected 350ºC
350
Port
2
NT105
Hibernation
19:29
Port
2
Actual Temp. 25ºC
AN115
Hibernation
19:29
ºC
Power
45%
Selected 350ºC
350
Port
2
AN115
No Yes
NAE
Control Unit
PORT
2
ROBOT
PEDAL
2
NAE
Control Unit
PORT
2
ROBOT
PEDAL
2
ROBOT
C115
C11
C105 /
C105 / C115
19:29
19:29
Port
2
Actual Temp. 25ºC
NT105
ºC
Power
45%
Selected 350ºC
350
Port
2
NT105
Hibernation
19:29
Port
2
Actual Temp. 25ºC
AN115
Hibernation
19:29
ºC
Power
45%
Selected 350ºC
350
Port
2
AN115
No
Yes
NAE
Control Unit
PORT
2
ROBOT
PEDAL
2
NAE
Control Unit
PORT
2
ROBOT
PEDAL
2
ROBOT
C115
C11
C105 /
C105 / C115
19:29
19:29
Port
2
Actual Temp. 25ºC
NT105
ºC
Power
45%
Selected 350ºC
350
Port
2
NT105
Hibernation
19:29
Port
2
Actual Temp. 25ºC
AN115
Hibernation
19:29
ºC
Power
45%
Selected 350ºC
350
Port
2
AN115
No
Yes
ø 0,3
0,2 x 0,1
0,7 3,5
Ø2,5
Ø2,5
Tweezer Chisel BladeTwe eze r
Conical Bent
Changing Cartridges
Save time and change cartridges safely without having to switch the station off.
Removing Inserting Aligning
Place the cartridge into the
extractor slot (1) and pull
the tweezers to remove the
cartridge (2).
Push the tweezers onto
the new cartridge until the
reference ring*.
Use the holes to rotate
the cartridges for a proper
alignment.
*Important
For a correct connection,
it is important to push
the cartridge in until the
reference ring rests against
the tweezers.
Reference
Ring
1
2
Compatible Cartridges
The Nano Tweezers NP115 and AN115 work with C115 cartridges. Find the model that best suits your
soldering needs on www.jbctools.com
Reference
Ring
1
2
4

40 mm
50 mm
60 mm
80 mm
100 mm
130 mm 130 mm
para manuales - color gris
200 mm
300 mm
ROBOT
Tweezers
Nano Control Unit
1
Example:
Chip Compoments Rework Process using Tweezers and Pedal
P405
Pedal
Connections
Connect pedal P405 to the same port where
NP115 tweezers are connected.
In the peripherals menu for the “Pedal
Activation Mode” choose between “pressed”
and “released”.
The Pedal is frequently used to rework components with tweezers.
NP115 JBCs nano tweezers is the most effective tool for desoldering chip components but also it
facilitates its rapid placement and soldering by using a pedal connected to JBC´s NAS station.
connect to
the same port
NAE
Control Unit
PORT
2
ROBOT
PEDAL
2
NAE
Control Unit
PORT
2
ROBOT
PEDAL
2
ROBOT
C115
C11
C105 /
C105 / C115
19:29
19:29
Port
2
Actual Temp. 25ºC
NT105
ºC
Power
45%
Selected 350ºC
350
Port
2
NT105
Hibernation
19:29
Port
2
Actual Temp. 25ºC
AN115
Hibernation
19:29
ºC
Power
45%
Selected 350ºC
350
Port
2
AN115
No Yes
NAE
Control Unit
PORT
2
ROBOT
PEDAL
2
NAE
Control Unit
PORT
2
ROBOT
PEDAL
2
ROBOT
C115
C11
C105 /
C105 / C115
19:29
19:29
Port
2
Actual Temp. 25ºC
NT105
ºC
Power
45%
Selected 350ºC
350
Port
2
NT105
Hibernation
19:29
Port
2
Actual Temp. 25ºC
AN115
Hibernation
19:29
ºC
Power
45%
Selected 350ºC
350
Port
2
AN115
No Yes
NAE
Control Unit
PORT
2
ROBOT
PEDAL
2
NAE
Control Unit
PORT
2
ROBOT
PEDAL
2
ROBOT
C115
C11
C105 /
C105 / C115
19:29
19:29
Port
2
Actual Temp. 25ºC
NT105
ºC
Power
45%
Selected 350ºC
350
Port
2
NT105
Hibernation
19:29
Port
2
Actual Temp. 25ºC
AN115
Hibernation
19:29
ºC
Power
45%
Selected 350ºC
350
Port
2
AN115
No Yes
NAE
Control Unit
PORT
2
ROBOT
PEDAL
2
NAE
Control Unit
PORT
2
ROBOT
PEDAL
2
ROBOT
C115
C11
C105 /
C105 / C115
19:29
19:29
Port
2
Actual Temp. 25ºC
NT105
ºC
Power
45%
Selected 350ºC
350
Port
2
NT105
Hibernation
19:29
Port
2
Actual Temp. 25ºC
AN115
Hibernation
19:29
ºC
Power
45%
Selected 350ºC
350
Port
2
AN115
No Yes
NAE
Control Unit
PORT
2
ROBOT
PEDAL
2
NAE
Control Unit
PORT
2
ROBOT
PEDAL
2
ROBOT
C115
C11
C105 /
C105 / C115
19:29
19:29
Port
2
Actual Temp. 25ºC
NT105
ºC
Power
45%
Selected 350ºC
350
Port
2
NT105
Hibernation
19:29
Port
2
Actual Temp. 25ºC
AN115
Hibernation
19:29
ºC
Power
45%
Selected 350ºC
350
Port
2
AN115
No Yes
ø 0,3
0,2 x 0,1
0,7 3,5
Ø2,5
Ø2,5
Tweezer Chisel BladeTwe eze r
Conical Bent
Changing Cartridges
Save time and change cartridges safely without having to switch the station off.
Removing Inserting Aligning
Place the cartridge into the
extractor slot (1) and pull
the tweezers to remove the
cartridge (2).
Push the tweezers onto
the new cartridge until the
reference ring*.
Use the holes to rotate
the cartridges for a proper
alignment.
*Important
For a correct connection,
it is important to push
the cartridge in until the
reference ring rests against
the tweezers.
Reference
Ring
1
2
Compatible Cartridges
The Nano Tweezers NP115 and AN115 work with C115 cartridges. Find the model that best suits your
soldering needs on www.jbctools.com
Reference
Ring
1
2
5

NAE
Control Unit
PORT
2
ROBOT
PEDAL
2
NAE
Control Unit
PORT
2
ROBOT
PEDAL
2
ROBOT
C115
C11
C105 /
C105 / C115
19:29
19:29
Port
2
Actual Temp. 25ºC
NT105
ºC
Power
45%
Selected 350ºC
350
Port
2
NT105
Hibernation
19:29
Port
2
Actual Temp. 25ºC
AN115
Hibernation
19:29
ºC
Power
45%
Selected 350ºC
350
Port
2
AN115
No Yes
3
4
Pad Cleaning
Clean the pads with JBC´s desoldering tool
DS360.
For this operation JBC´s desoldering station
DSS is needed.
Solder Paste Dispensing
Apply the solder paste amount needed to
solder the new chip component.
The use of JBC´s DPM solder paste dispenser
is recommended.
DPM
Manual
Solder Paste
Dispenser
DS360
Micro
Desoldering Iron
Desoldering*
Lift the tweezers from the holder, press and
hold the pedal to activate the tweezers and
desolder the component.
Once the pedal is released the tweezers enters
in hibernation mode and cools down.
2
* “Press Mode” previously selected
6

40 mm
50 mm
60 mm
80 mm
100 mm
130 mm 130 mm
para manuales - color gris
200 mm
300 mm
NAE
Control Unit
PORT
2
ROBOT
PEDAL
2
NAE
Control Unit
PORT
2
ROBOT
PEDAL
2
ROBOT
C115
C11
C105 /
C105 / C115
19:29
19:29
Port
2
Actual Temp. 25ºC
NT105
ºC
Power
45%
Selected 350ºC
350
Port
2
NT105
Hibernation
19:29
Port
2
Actual Temp. 25ºC
AN115
Hibernation
19:29
ºC
Power
45%
Selected 350ºC
350
Port
2
AN115
No Yes
3
4
Pad Cleaning
Clean the pads with JBC´s desoldering tool
DS360.
For this operation JBC´s desoldering station
DSS is needed.
Solder Paste Dispensing
Apply the solder paste amount needed to
solder the new chip component.
The use of JBC´s DPM solder paste dispenser
is recommended.
DPM
Manual
Solder Paste
Dispenser
DS360
Micro
Desoldering Iron
Desoldering*
Lift the tweezers from the holder, press and
hold the pedal to activate the tweezers and
desolder the component.
Once the pedal is released the tweezers enters
in hibernation mode and cools down.
2
* “Press Mode” previously selected
5
6
Soldering
Once in position press and hold the pedal
to activate the tweezers and perform the
soldering.
Placing
Do not press the pedal.
Use the tweezers to position the component
on the previously tinned pad.
Note:
The inactive tool prevents the component from
heating up prematurely.
7

Safety
- Do not use the units for any purpose other than soldering or rework. Incorrect use may cause fire.
- The power cord must be plugged into approved bases. Be sure that it is properly grounded before
use. When unplugging it, hold the plug, not the wire.
- Do not work on electrically live parts.
- The tool should be placed in the stand when not in use in order to activate the sleep mode. The
soldering tip or nozzle, the metal part of the tool and the stand may still be hot even when the station
is turned off. Handle with care, including when adjusting the stand position.
- Do not leave the appliance unattended when it is on.
- Do not cover the ventilation grills. Heat can cause inflamable products to ignite.
- Avoid flux coming into contact with skin or eyes to prevent irritation.
- Be careful with the fumes produced when soldering.
- Keep your workplace clean and tidy. Wear appropriate protection glasses and gloves when working
to avoid personal harm.
- Utmost care must be taken with liquid tin waste which can cause burns.
- This appliance can be used by children over the age of eight and also persons with reduced physical,
sensory or mental capabilities or lack of experience provided that they have been given adequate
supervision or instruction concerning use of the appliance and understand the hazards involved.
Children must not play with the appliance.
- Maintenance must not be carried out by children unless supervised.
It is imperative to follow safety guidelines to prevent electric
shock, injury, fire or explosion.
8

40 mm
50 mm
60 mm
80 mm
100 mm
130 mm 130 mm
para manuales - color gris
200 mm
300 mm
Notes
9

Notes
10

40 mm
50 mm
60 mm
80 mm
100 mm
130 mm 130 mm
para manuales - color gris
200 mm
300 mm
Notes
11
Specifications
NP115
Nano Tweezers
Ref. NP115-A
- Max. Power Per Cartridge:
- Cable Length: 120 cm / 47.24 in
- Total Net Weight: 47 g / 0.104 lb
- Package Dimensions /Weight: 235 x 40 x 40 mm / 91 g
(L x W x H) 9.25 x 1.57 x 1.57 in / 0.201 lb
Complies with CE standards
ESD Safe

0029758-181022
This product should not be thrown in the garbage.
In accordance with the European directive 2012/19/EU, electronic equipment at the end of its life must
be collected and returned to an authorized recycling facility.
Warranty
JBC’s 2 year warranty covers this equipment against
all manufacturing defects, including the replacement
of defective parts and labour.
Warranty does not cover product wear or misuse.
In order for the warranty to be valid, equipment must
be returned, postage paid, to the dealer where it was
purchased.
Get 1 extra year JBC warranty by registering here:
https://www.jbctools.com/productregistration/
within 30 days of purchase.
40 mm
50 mm
60 mm
80 mm
100 mm
130 mm 130 mm
para manuales - color gris
200 mm
300 mm
Table of contents
Other jbc Welding Accessories manuals
Popular Welding Accessories manuals by other brands

Abicor Binzel
Abicor Binzel xFUME ABIROB AF500 operating instructions

Urrea
Urrea USCS2 User manual and warranty

Dohle
Dohle ExOn2A operating instructions

Miller Electric
Miller Electric OM-842 owner's manual

Miller
Miller A-200 Series owner's manual

Miller Electric
Miller Electric Millermatic 185 owner's manual
