JBL Studio 235C Installation and operation manual

JBL®Studio 235C
Dual 2.5-way 6.5" Center Channel Loudspeaker
Hear each word no matter where you’re sitting
No matter where you stand or sit in a room when watching a movie, TV show, or game console, you
deserve the best possible listening experience. As part of the groundbreaking 9-piece JBL Studio 2
loudspeaker series, the Studio 235C 2.5-way Dual 6.5" center channel loudspeaker lets you do just
that, stunning your ear with a signature listening experience like no other – wherever you’re positioned.
The Studio 235C center channel’s dual 6.5" PolyPlas drivers deliver pitch-perfect vocal clarity and
tight, accurate bass to anywhere in a listening space. Add to these the Studio 235C’s built-in High
Definition Imaging (HDI) waveguide design and 1" CMMD Lite high-frequency driver, both of which
take their cues from JBL’s own legendary M2 Master Reference monitor, and your cinematic senses
get sharpened to a pin-drop. Combine all this with the sleek, urbane design of the loudspeaker itself–
both inside and out – and you’re dealing with a champion breed of sound and technology ready to
define its era.
1" CMMD®Lite high-frequency driver for crisp, clean, powerful
highs with low-distortion and wide dynamics
High Definition Imaging (HDI) waveguide design for astounding
imaging, natural balance, and remarkable high-frequency detail at
any position in the room
Dual 6.5" PolyPlas drivers for enhanced clarity and realism and
tight, extended bass response
Solid cabinet construction with soft-rounded edges and no visible
fasteners
Gloss black side panels add a touch of elegance to the sleek
cabinet design
Soft-touch paint covers the horn and driver trim rings for a clean,
timeless look that blends easily with any décor
Rear-firing Slipstream bass ports minimize port turbulence and
audible distortion in the bass response

JBL®Studio 235C
Dual 2.5-way 6.5" Center Channel Loudspeaker
Features
Dual 6.5" PolyPlas drivers deliver unrivaled accuracy, subtlety, and realism
From whatever angle you hear it, the Studio 235C shines as a dynamic, accurate center channel
loudspeaker. Decades of JBL acoustic research and development have let us develop a loudspeaker
with twin 6.5" PolyPlas drivers able to dish out double the power, nuance, and lifelike realism of JBL
sound to any given area of a listening space.
1" CMMD®Lite high-frequency driver and High Definition Imaging (HDI) waveguide
bring cinema-grade imaging and natural balance to your listening experience
The apex of 67 years of pioneering sound research at our JBL labs, the Studio 235C incorporates
groundbreaking innovations like a High Definition Imaging (HDI) waveguide design and a 1" CMMD
Lite high-frequency driver into its framework. Together, these advances let you experience your sound
purely and cinematically, with all the precision imaging, high-frequency detail, natural balance, and full
spectrum mastery of advanced home theater.
Visually striking 21st century design features that can’t fail to seduce
The house rule at JBL is to make it look as good as it sounds. And with the Studio 235C, we’ve made
no exception. With 21st century elegance that incorporates soft-rounded edges, black gloss paneling,
and soft-touch paint, we’ve built something that seduces the eye as much as it commands the ear.
What’s in the box:
JBL®Studio 235C Dual 2.5-way 6.5" Center Channel
Loudspeaker
Owner’s Manual
Rubber Cushion Pads x 4
Product specifications:
Type: Dual 2.5-way 6.5" Center Channel Loudspeaker
Dual 165mm (6.5") PolyPlas low-frequency transducers
High Definition Imaging (HDI) horn design
- 25mm (1") CMMD®Lite high frequency dome
Recommended amplifier power: 20 – 150W
Frequency response: 55Hz – 22kHz
Sensitivity: 91dB
Impedance: 8 Ohms
Slipstream rear-firing bass port
Gold-plated binding-post speaker terminals
Dimensions (H x W x D): 194mm x 645mm x 249mm
(7-5/8" x 25-3/8" x 9-13/16")
Weight: 11.9 kg (26.3 lb)
HARMAN International Industries, Incorporated
8500 Balboa Boulevard, Northridge, CA 91329 USA
www.jbl.com
© 2013 HARMAN International Industries, Incorporated. All rights reserved.
JBL is a trademark of HARMAN International Industries, Incorporated, registered in the United States and/or
other countries. The “Hear the truth” logo is a trademark of HARMAN International Industries, Incorporated.
Features, specifications and appearance are subject to change without notice.
