JBT FRESH'N SQUEEZE User manual

January 2017
Multi-Fruit Juicer
Operator & Service Manual

2FNS-0002-060-EN January 2017 Rev F
Multi-Fruit Juicer
Operator & Service Manual
Copyright © John Bean Technologies Corporation 2017
JBT Corporation
400 Fairway Avenue
Lakeland, FL 33801
[phone]
Manual No. FNS-0002-060-EN

3FNS-0002-060-EN January 2017 Rev F
Table of Contents
Important Safety Information ······································4
Specifications ··························································6
General Information ··················································7
Operating Instructions ············································· 10
Operator Do's and Don'ts ·········································· 13
Cleaning Instructions ··············································· 14
Maintenance ··························································· 20
Troubleshooting Table ············································ 27
Troubleshooting ····················································· 28
Rebuilding ····························································· 34
Rebuild Tooling Kit and Spare Parts Kit ····················· 48
Juicing Parts, 060-00099 ··········································· 50
Hopper Assembly Parts, 060-00043 ···························· 52
Drive Parts, 060-00103··············································· 54
Upper Drive Arm Assembly Parts, 060-00116 ··············· 56
Rod End Assembly, Upper Cup Drive Parts 060-00114,
060-00114-01 for Field Replacement···························· 57
Orifice Drive Arm Assembly Parts, 060-00115··············· 58
Rod End Assembly, Orifice Drive Parts, 060-00113,
060-00113-01 for Field Replacement···························· 59
Frame & Stand Assembly Parts, 060-00117 ················· 60
Bracng Rail Kit, 060-10126 ········································ 62
Cover Assembly Parts, ABS, 060-00118······················· 64
Cover Assembly Parts, Stainless Steel, 060-01001········ 66
Splash Shield Assembly Parts, 060-01054···················· 69
Decals, Warning Labels, Bumpers ······························ 70
Electrical Parts, 060-00034········································· 72
Electrical Box Assembly Parts (115 Volt), 060-00168 ····· 74
Electrical Box Assembly Parts (220 Volt), 060-00169 ····· 76
Motor Assembly Parts (110 Volt), 060-00106
and (220 Volt), 060-00196··········································· 78
Miscellaneous Parts·················································· 80

4FNS-0002-060-EN January 2017 Rev F
Important Safety Information
You can help prevent personal injury and/or property damage.
Please read this manual carefully before operating the Multi-Fruit Juicer.
DO NOT attempt any operation until you understand exactly how the machine functions.
If uncertainty remains after studying this manual, please contact John Bean Technologies
Corporation.
We're here to help. With proper handling, the JBT Multt-Fruit Juicer will provide safe, efficient
and convenient service for years to come.
North America
JBT Corporation
400 Fairway Ave
Lakeland, FL 33801
USA
Phone: [phone]
Fax: [phone]
Europe
JBT Corporation, S.L.
Julián Camarillo 26, 4º
28037 Madrid Spain
Phone: [phone]
Fax: [phone]
South Africa
JBT (Pty) Ltd.
Koper Street
Brackenfell
Cape Town, South Africa 7560
Phone: [phone]
Fax: [phone]
www.jbtcorporation.com
Brazil
JBT Máquinas e Equipamentos Industriais Ltda.
Av. Eng. Camilo Dinucci 4605
14808-900 Araraquara
São Paulo Brazil
Phone: [phone]
Fax: [phone]
Latin America
JBT Corporation
Carr. Mty-Saltillo Km 7—Bodega 4
Colonia Las Mitras
Santa Catarina, NL
Mexico 66350
Phone: [phone]
Fax: [phone]
Asia / Pacific
JBT (Shanghai) Co. Ltd.
Room 3002-3003
Haitong Security Building
No. 689 Guangdong Road
Shanghai 200001,
China
Phone: [phone]
Fax: [phone]
Revision History
Manual Code
Rev.
No.
Date
Pages
Change History
060-00203
1
03/15/09
62, 63, 65, 66, 67
Updates and modifications
060-00203
2
03/15/11
6, 50, 54, 68, 69,
70, 71, 72, 73, 74
Updates to specifications and part numbers for
assemblies 060-00099-F, 060-00103-F, 060-00034-D,
060-00168-C, 060-00169-C, 060-00106C, 060-00196-C
FNS-0002-060-EN
A
09/15/14
Entire manual
Updates, modifications and alignment to JBT global
version control and inventory standards
FNS-0002-060-EN
B
12/15/15
Entire manual
Addition of new Fresh 'n Squeeze logo
FNS-0002-060-EN
C
3/1/16
62
Updates for part number information for assembly
060-00118
FNS-0002-060-EN
D
8/9/16
40, 50, 51, 60
Update of torque values and illustration on Page 41.
Updates for part number information for assemblies
060-00117, 060-00099
FNS-0002-060-EN
E
12/14/16
Entire manual
Edits and additions
FNS-0002-060-EN
F
1/19/17
50, 51
Update to parts list/drawing for Juicing Parts, 060-00099

5FNS-0002-060-EN January 2017 Rev F
Safety Labels
The safety labels shown below appear on the Juice Extractor. Safety labels provide essential
instructions on how to avoid possible hazards.
Please, for your safety: FOLLOW THOSE INSTRUCTIONS AT ALL TIMES.
Should the Juicer safety labels become damaged or unreadable, contact JBT Corporation for
replacement labels.
Safety Instructions
Carefully review the following safety instructions.
Make them a habit when using the JBT Corporation Multi-Fruit Juicer.
1. If Juicer continues to run when any access cover is open, the interlock switch is defective.
Turn Juicer off immediately. Call for service.
2. Prevent unauthorized access to Juicer by locking all covers with supplied key.
3. Prevent unauthorized operation of Juicer by placing electrical plug inside cart door.
4. NEVER attempt to make any safety device inoperative.
5. NEVER operate or perform maintenance or repair work on the Juicer when taking any kind of
drug or sedative, when under the influence of alcohol, or when fatigued.
6. ALWAYS check adjustment of all nuts, bolts, and screws after installation, repair, or periodic
maintenance.

6FNS-0002-060-EN January 2017 Rev F
Specifications
Technical Specifications
Fruit size: 2 1/2" to 3 3/4" diameter (6.5 cm to 9.5 cm)
Oranges —FL:·································· 125 to 50 count
Oranges —CA: ································· 138 to 48 count
Grapefruit —FL: ································ 56 to 48 count
Hopper capacity:································ 40 Ib. (1 carton) (18 kg)
Reservoir capacity:····························· 3.5 gal. (1 carton) (13.2 liters)
Waste container capacity: ···················· 40 Ib. of peel (2 cartons) (18 kg)
Speed:············································· 20 fruit/minute
(20 to 60 gallons/hour)
(75 to 225 liters/hour)
Electrical Specifications
115V, 60 Hz Single Phase 20 AMP Service on a dedicated circuit
10 GA. wire —up to 200 ft. from main breaker panel
or
220 VAC, 50 Hz / 60Hz Single Phase 16 AMP Service
10 GA. wire —up to 200 ft. from main breaker panel
Shipping Specifications
Machine With Stand:
Height: 67" (170 cm)
Width: 27" (69 cm)
Depth: 32" (81 cm)
Weight: 535 Ibs (243 kg)
Patents
U.S. Patents - #4905586 and #4922814
and Patents Pending

7FNS-0002-060-EN January 2017 Rev F
General Information
The JBT Corporation Juicer is designed to provide years of dependable service. It uses a
unique patented design to extract every available amount of juice from the fruit with the
least amount of peel oil. The peel is completely separated from the juice and juice sacs
before being compressed and strained.
The machine will juice all types of citrus —oranges, grapefruit, lemons, limes, tangerines,
etc. —without changing or adjusting parts. In fact, different varieties and sizes of fruit can
be juiced to create various fruit juice blends.
Clean-up is simple, requiring disassembly of only five parts. All waste material —peel,
membranes, and seeds —is collected in a disposable garbage bag for easy removal and
disposal.
The Juice Extractor is solidly built using heavy duty components in all assemblies, including
the drive. It is simple to operate and uses a minimal number of parts.
ALWAYS follow cleaning and maintenance schedules in this manual to prevent equipment
damage.
Figure 1. JBT Multi-Fruit Juicer

8FNS-0002-060-EN January 2017 Rev F
Figure 2. Multi-Fruit Juicer –Exterior Components
Cart Cover
¼ turn lock
Juice
Components
Cover
Single Feed Hole
¼ turn lock
Hopper Cover
Hopper
On-Off Switch
Stirrer Handle
Juice Reservoir
Valve
Juice Reservoir
Cart Door
Juice Nozzle
¼ turn lock
Drive Cover
Back Cover

9FNS-0002-060-EN January 2017 Rev F
Figure 3. Juicing Components Assembly
Figure 4. Inside Cart Door
Lower Cup
Upper Cup
Spanner Screw
Juice Manifold
Pull Pin
Upper Drive
Splash Plate
Lower Cutter
Spanner Nut (2)
Lower Drive
Splash Plate
Strainer Tube
Orifice Tube
NOTE: Groove Portion of
Orifice Tube in Slot
Garbage Bag Hooks
Waste Container
Spanner Wrench
Storage Pan
Cleaning Tools

10 FNS-0002-060-EN January 2017 Rev F
Operating Instructions
Equipment Check
Before pluggingthe Multi-Fruit Juicerinto an electrical outlet, the following steps
must be performed:
1. Locate the Multi-Fruit Juicer on alevel surface.
This will prevent fruit feed problems.
CAUTION:WHEN MOVING JUICER, ALWAYS TRANSPORT ON LEVEL SURFACE.
USE RAMPS IF NECESSARY. AVOID LEDGES, IRREGULAR FLOORS
OR DRAIN INDENTIONS. TO AVOID TIPPING, NEW JUICER UNITS ARE
SHIPPED WITH BRACING RAILS. UNITS IN THE FIELD CAN BE
UPGRADED USING THE BRACING RAIL KIT.
SEE FIGURE 5 FOR INSTALLATION INFORMATION.
2. Lock both rear casters.
To lock, push down on caster with foot. To unlock, push again with foot.
3. Check waste container.
Open cart door to verify that waste container is in place. A plastic bag may be
attached to the hooks above the waste container (30 gallon capacity or equivalent).
4. Check juicing components.
a. Twist and pull juice nozzle off.
b. Use key to unlock juicing components cover. Open cover and check that juicing
components are installed and securely fastened. See Figure 3, Page 9.
5. Close and lock all access covers.
There are 4 separate access covers: hopper cover, juicing components cover, cart
door (cover) and back cover.
NEVER operate juicer unless all covers are in place.
6. Replace juice nozzle. Wet the o-ring before installing the nozzle.
7. Make sure juice reservoir is firmly in place.
8. Make sure juice reservoir valve is in closed position.
9. Check the hopper for foreign objects.
Remove any foreign objects found in the hopper.
10. Make sure floor area around Juicer is clean and free of obstructions and water.
Wear appropriate non-slip footwear when water is necessary.
