jcb JCB-18IL Planning guide

INSPECTION LAMP
INSTRUCTION & USER MANUAL
EN
IM-18IL-EN
JCB-18IL
Original Instructions

2JCB-18IL
Instruction & User Manual
GENERAL WARNINGS & DISPOSAL
To reduce the risk of injury, the user must read the instruction manual.
The device must not be exposed to rain or immersed in water.
Do not allow any part of the device to come into contact with flames, or to
catch fire.
Do not dispose of batteries in household waste. Return exhausted batteries
to a local collection or recycling point.
This product has been marked with a symbol relating to removing electric and
electronic waste. The product should not be discarded with household waste
but must be returned to a collection system which conforms to the European
Directive 2012/19/EU. It will then be recycled or dismantled in order to
reduce the impact on the environment. Electric and electronic equipment can
be hazardous for the environment and for human health since they contain
hazardous substances.
This symbol is used throughout this manual to warn the user about potential
risks. Please read & understand these sections before using the device.
Personal Protective Equipment (P.P.E.), such as ear defenders, eye protection,
safety gloves and a dust mask, must be worn during the operation of the
device.
Do not expose battery pack or tool to fire or excessive temperatures above
130°C.
The month and year of manufacture can be found within the product serial number e.g.
MMYYPPPAXXXXX. Where production month (MM) and production year (YY) are included.

3
JCB-18IL
Instruction & User Manual
Contents
GENERAL POWER TOOL SAFETY WARNINGS 4
1. Work area safety 4
2. Electrical safety 4
3. Personal safety 4
4. Power tool use and care 5
5. Service 5
BATTERY SAFETY 6
CHARGER SAFETY 7
COMPONENT LIST 8
TOOL TECHNICAL DATA 9
OPERATING INSTRUCTIONS 11
Intended Use 11
Battery 11
Turning On/ Off 12
To Hang the Inspection Light 12
Adjustable Head 12
Maintenance 12
Transport and Storage 13
WARRANTY STATEMENT 14
Conditions 14
Terms 14
EC DECLARATION OF CONFORMITY 16

4JCB-18IL
Instruction & User Manual
Read all safety warnings, instructions and
specifications provided with this power
tool. Failure to follow all instructions listed below
may result in electric shock, fire and/or serious
injury. Save all warnings and instructions for
future reference.
WARNING!
The term “power tool” in the warnings refers to
your mains operated (corded) power tool or battery
operated (cordless) power tool.
1. Work area safety
m Keep work area clean and well lit.
Cluttered or dark areas invite accidents.
m Do not operate power tools in explosive
atmospheres, such as in the presence of
flammable liquids, gases or dust. Power
tools create sparks which may ignite the dust or
fumes.
m Keep children and bystanders away while
operating a power tool. Distractions can
cause you to lose control.
2. Electrical safety
m Power tool plugs must match the outlet.
Never modify the plug in any way. Do
not use any adapter plugs with earthed
(grounded) power tools. Unmodified plugs
and matching outlets will reduce risk of electric
shock.
m Avoid body contact with earthed or
grounded surfaces, such as pipes,
radiators, ranges and refrigerators. There
is an increased risk of electric shock if your body
is earthed or grounded.
m Do not expose power tools to rain or wet
conditions. Water entering a power tool will
increase the risk of electric shock.
m Do not abuse the cord. Never use the
cord for carrying, pulling or unplugging
the power tool. Keep the cord away from
heat, oil, sharp edges or moving parts.
Damaged or entangled cords increase the risk of
electric shock.
m When operating a power tool outdoors,
use an extension cord suitable for
outdoor use. Use of a cord suitable for
outdoor use reduces the risk of electric shock.
m If operating a power tool in a damp
location is unavoidable, use a residual
current device (RCD) protected supply.
Use of an RCD reduces the risk of electric shock.
3. Personal safety
m Stay alert, watch what you are doing
and use common sense when operating
a power tool. Do not use a power tool
while you are tired or under the influence
of drugs, alcohol or medication. A moment
of inattention while operating power tools may
result in serious personal injury.
m Use personal protective equipment.
Always wear eye protection. Protective
equipment such as a dust mask, non-skid safety
shoes, hard hat or hearing protection used for
appropriate conditions will reduce personal
injuries.
m Prevent unintentional starting. Ensure
the switch is in the off position before
connecting to power source and/or
battery pack, picking up or carrying the
tool. Carrying power tools with your finger on
the switch or energising power tools that have
the switch on invites accidents.
GENERAL POWER TOOL SAFETY WARNINGS

5
JCB-18IL
Instruction & User Manual
m Remove any adjusting key or wrench
before turning the power tool on. A
wrench or a key left attached to a rotating part of
the power tool may result in personal injury.
m Do not overreach. Keep proper footing
and balance at all times. This enables
better control of the power tool in unexpected
situations.
m Dress properly. Do not wear loose
clothing or jewellery. Keep your hair and
clothing away from moving parts. Loose
clothes, jewellery or long hair can be caught in
moving parts.
m If devices are provided for the connection
of dust extraction and collection facilities,
ensure these are connected and properly
used. Use of dust collection can reduce dust-
related hazards.
m Do not let familiarity gained from
frequent use of tools allow you to become
complacent and ignore tool safety
principles. A careless action can cause severe
injury within a fraction of a second.
4. Power tool use and care
m Do not force the power tool. Use the
correct power tool for your application.
The correct power tool will do the job better
and safer at the rate for which it was designed.
m Do not use the power tool if the switch
does not turn it on and off. Any power
tool that cannot be controlled with the switch is
dangerous and must be repaired.
m Disconnect the plug from the power
source and/or remove the battery pack,
if detachable, from the power tool before
making any adjustments, changing
accessories, or storing power tools. Such
preventive safety measures reduce the risk of
starting the power tool accidentally.
m Store idle power tools out of the reach
of children and do not allow persons
unfamiliar with the power tool or these
instructions to operate the power tool.
Power tools are dangerous in the hands of
untrained users.
m Maintain power tools and accessories.
Check for misalignment or binding of
moving parts, breakage of parts and any
other condition that may affect the power
tool’s operation. If damaged, have the
power tool repaired before use. Many
accidents are caused by poorly maintained power
tools.
m Keep cutting tools sharp and clean.
Properly maintained cutting tools with sharp
cutting edges are less likely to bind and are easier
to control.
m Use the power tool, accessories and
tool bits etc. in accordance with these
instructions, taking into account the
working conditions and the work to
be performed. Use of the power tool for
operations different from those intended could
result in a hazardous situation.
m Keep handles and grasping surfaces
dry, clean and free from oil and grease.
Slippery handles and grasping surfaces do not
allow for safe handling and control of the tool in
unexpected situations.
5. Service
m Have your power tool serviced by a
qualified repair person using only identical
replacement parts. This will ensure that the
safety of the power tool is maintained.

6JCB-18IL
Instruction & User Manual
m Recharge only with the charger
specified by the manufacturer. A
charger that is suitable for one type of
battery pack may create a risk of fire when
used with another battery pack.
m Use power tools only with specifically
designated battery packs. Use of any
other battery packs may create a risk of
injury and fire.
m When battery pack is not in use, keep
it away from other metal objects, like
paper clips, coins, keys, nails, screws
or other small metal objects, that can
make a connection from one terminal
to another. Shorting the battery terminals
together may cause burns or a fire.
m Under abusive conditions, liquid
may be ejected from the battery;
avoid contact. If contact accidentally
occurs, flush with water. If liquid
contacts eyes, additionally seek
medical help. Liquid ejected from the
battery may cause irritation or burns.
m Do not use a battery pack or
tool that is damaged or modified.
Damaged or modified batteries may exhibit
unpredictable behaviour resulting in fire,
explosion or risk of injury.
m Do not expose battery pack or tool
to fire or excessive temperature.
Exposure to fire or temperatures above
130°C may cause an explosion.
m Follow all charging instructions and
do not charge the battery pack or
tool outside the temperature range
specified in the instructions. Charging
improperly or at temperatures outside the
specified range may damage the battery and
increase the risk of fire.
BATTERY SAFETY

7
JCB-18IL
Instruction & User Manual
m To reduce risk of injury, only charge
JCB rechargable batteries listed in
this manual. The charger and battery
packs are specifically designed to work
together. Other types of batteries may burst
causing fire and personal injury.
m Do not allow any liquid to get inside
the charger. Electric shock may result.
m Do not expose the charger to rain or
snow.
m Under certain conditions with the
charger plugged into the power
supply, the exposed charging contacts
inside the charger can be shorted by
foreign materials. Foreign materials of a
conductive nature such as, but not limited
to, steel, wool, aluminium foil or any buildup
of metallic particles should be kept away
from charger cavities.
m Always unplug the charger from
the power supply when there is no
battery in the cavity.
m Unplug the charger from the power
supply before attempting to clean.
m Do not operate the charger with a
damaged cord or plug. Have them
replaced immediately.
m The charger is designed to operate
on standard 230V household
electrical power. Do not attempt to
use it on any other voltage.
CHARGER SAFETY
Before using charger, read all instructions and
cautionary markings on charger, battery pack
and product using battery pack.
WARNING!

8JCB-18IL
Instruction & User Manual
COMPONENT LIST
3
1
5
1. SPOTLIGHT
2. SWIVEL JOINT
3. ANGLE JOINT
4. ON/ OFF SWITCH
5. GRIP
6. J HOOK (NOT VISIBLE)
7. CHARGER*
8. BATTERY PACK* - PLEASE REFER TO TABLE ON
PAGE 11 FOR BATTERY INFORMATION
9. BATTERY TEST BUTTON AND CHARGE
INDICATOR*
4
2
6
*If applicable
8
9
7
Battery size shown for
illustrative purposes only

9
JCB-18IL
Instruction & User Manual
Power 18V d.c.
Spotlight 3W COB LED
Lumens 220
Swivel Torch Head 0 - 270°
Swivel Torch Head Stops 0, 45, 90, 135, 180, 225 & 270°
Angle Torch Head 0 - 180°
Angle Positive Stops 0, 30, 60, 90, 120, 150 & 180°
Dimensions (L x W x H) 225 x 65 x 65mm
Product Weight (Body only, w/o battery) 0.3 kg
TOOL TECHNICAL DATA
Charger Code Input Power Output
JCB-18VFC 220 - 240V ~ 50-60Hz 70W 2.4A
JCB-18SFC 220 - 240V ~ 50-60Hz 105W 4.0A
LITHIUM ION BATTERY TECHNICAL DATA
CHARGER TECHNICAL DATA
Battery
Code
Battery
Size Voltage Battery Capacity
Charge Time
(Fast Charger)
Charge Time
(Super Fast Charger)
JCB-20LI Small 18V 2.0Ah 50 mins 30 mins
JCB-30LI Large 18V 3.0Ah 80 mins 45 mins
JCB-40LI Large 18V 4.0Ah 100 mins 60 mins
JCB-50LI Large 18V 5.0Ah 120 mins 75 mins
Times given as a guide only. Battery charge and discharge times dependant on age, usage and condition.

10 JCB-18IL
Instruction & User Manual
OPERATING INSTRUCTIONS
Intended Use
A general purpose LED inspection light for the
illumination of most work area spaces.
The tool must not be modified or used for
any other purposes than the ones described in
these instructions.
Battery
Make sure the power switch is not pressed
in when inserting or replacing the battery.
NOTE
m Do not force the battery when
connecting it, use moderate pressure.
An incorrectly connected battery can
damage the battery terminals or the battery
socket on the tool.
m Use the button on the battery to check the
charging status; 4 red LEDs indicates fully
charged, where 1 indicates low battery
status.
Charging The Battery
After charging for the first time, ensure the
battery is completely discharged before
placing on charge again. Repeat this charging
and discharging cycle 4 to 5 times to ensure
battery is correctly conditioned.
WARNING!
m Place the battery charger on a level and
stable surface. Plug the charger into a 230 V
power point.
m Connect the battery to the charger so that it
clicks into place.
m Refer to the Battery Charge Level table
below for battery charger status as indicated
by LED lights.
m Unplug the charger from the power point
and remove the battery from the charger.
Battery Charge Level
Red
LED
Green
LED Battery Charge Status
Charger is connected to
mains power
Connected battery is
charging
Connected battery is fully
charged
Connected battery has a
charging fault
Charger is outside correct
operating temperature
range (<0˚C / >40˚C)
If the LEDs on the charger do not come on
when charging:
m Check that the charger’s mains adaptor is
properly plugged into the power point and
that the charger is switched on
m Check that the battery is correctly inserted
in the charger
Connecting the battery
m Connect the battery to the battery socket
on the tool so that it clicks into place.
Removing the battery
m Press the battery release button and remove
the battery from the tool.

11
JCB-18IL
Instruction & User Manual
Intended Use
This general purpose LED inspection light is
intended for the illumination of work areas and
workpieces.
The tool must not be modified or used for
any other purposes than the ones described in
these instructions.
Battery
Make sure the power switch is not pressed
in when inserting or replacing the battery.
NOTE
m Do not force the battery when
connecting it, use moderate pressure.
An incorrectly connected battery can
damage the battery terminals or the battery
socket on the tool.
m Use the “Press” button on the battery
to check the charging status; 4 red LEDs
indicates fully charged, where 1 indicates
low battery status.
Charging The Battery
m After charging for the first time, use the tool
until the battery is completely discharged.
m Repeat this charging and discharging cycle 4
to 5 times.
If the LEDs on the charger do not come on
when charging:
m Check that the charger’s mains adaptor is
properly plugged into the power point and
that the charger is switched on
m Check that the battery is correctly inserted
in the charger
m Place the battery charger on a level and
stable surface. Plug the charger into a 230 V
power point.
m Connect the battery to the charger so that
it clicks into place. The red LED lights up on
the charger when correct contact is made.
m When the battery is fully charged, after
about 45 minutes, the red LED goes off and
only the green LED stays on.
m Unplug the charger from the power point
and remove the battery from the charger.
Connecting the battery
m Connect the battery to the battery socket
on the tool so that it clicks into place.
Removing the battery
m Press the battery lock and remove the
battery from the tool.

12 JCB-18IL
Instruction & User Manual
Turning On/Off
Do not direct the light beam at persons or
animals and do not stare into the light beam
yourself (not even from a distance). Staring
into the light beam may result in serious
injury or vision loss.
WARNING!
m Press the ON/OFF button to turn the
inspection light on and off.
The inspection light lamps can get very hot.
Keep the inspection light away from com-
bustible or fragile materials, as close contact
between the lamps and other materials may
cause damage to the inspection light, melt
materials, or start fires.
WARNING!
To Hang the Inspection Light
Only hang or mount the inspection light in a
suitable area, free from obstructions. Do not
hang the inspection light from any loose cord
or live electrical power cord. Ensure the
inspection light is securely installed to prevent
a falling object hazard. Failure to follow these
instructions can result in electric shocks or
other serious personal injuries.
WARNING!
m Fold the inspection light in half at the joint.
m Lift the J hook from the slot.
m Use the J hook to hang the inspection light.
Adjustable Head
m The inspection light head can be set in a
variety of positions by means of the swivel &
universal joints.
Do not place hands or fingers between
adjustable head and frame when positioning
inspection light to avoid trapping your fingers
or hands.
WARNING!
Maintenance
Switch off the tool and disconnect the power
(remove battery/unplug) before cleaning and
maintenance. This helps avoid the risk of
electric shocks and accidental starting.
WARNING!
m Wipe the tool with a dry or damp cloth.
Do not use a wet cloth. Do not use
detergent that contains solvent or
corrosive, abrasive additives. This risks
damaging the surfaces of the tool.
m Clear the tool vents and the lamp covers of
dust and dirt after each use. Do not clean
ventilation holes by inserting sharp
objects in them, such as screwdrivers
and other similar objects.
m Stubborn contamination in areas hard to
access can be removed with compressed air
(max 3. bar).
m Regularly check all fasteners, screws and
bolts to make sure that they are tight.
Tighten any loose screws immediately or
serious injury could occur.

13
JCB-18IL
Instruction & User Manual
Never open the tool. The tool has no
internal parts that the user can service or
repair. Never try to repair the tool yourself.
Take to an authorised service centre.
WARNING!
Transport and Storage
m If the tool will remain unused for any length
of time, it should be stored in the original
packaging.
m Store the tool in a dry, frost-free, well
ventilated place with a temperature of no
more than 40°C.
m Keep all tools out of the reach of children.
m Always switch off the tool and disconnect it
from the power supply (remove the battery/
unplug the power cord) before transport.
m Always carry the tool using the purpose-
designed handle.
m Ensure that the tool is not at risk of tipping
over or exposed to excessive vibration and
shocks during transport, especially if the tool
will be transported by car or other vehicle.

14 JCB-18IL
Instruction & User Manual
WARRANTY STATEMENT
JCB Power Tools are guaranteed against manufacturing defects
for up to 5 years (extra charges may apply) from date of purchase
by simply registering your product online within 30 days. Proof of
purchase required. This does not affect your statutory rights.
To register your JCB Power Tool, please visit: jcb-tools.com
Online registration is required to receive a warranty certificate to activate your standard 3 year
warranty. You will be given the option to extend to a 5 Year Warranty (extra charges may apply).
Registration is only available online via www.jcb-tools.com. You will need your original sales
receipt, the model number and the serial number (if applicable) of your product. Kits comprising
of two or more tools are excluded from single registration and must registered individually for full
warranty cover.
Upon successful registration, a warranty certificate will be available to download, print or save as
a PDF document. The relevant warranty certificate together with the original sales receipt will be
required in the event of any claim within the warranty period..
Should you choose not to register your product within 30 days of purchase, your statutory
consumer rights will not be affected. You will need the original sales receipt as proof of purchase in
the event of a warranty claim.
Warranty cover commences from the date of purchase on the retail sales receipt and is valid only
for JCB Tools products purchased within the UK bearing the CE mark and a visible serial number.
In the unlikely event your JCB Power Tool is subject to a manufacturing fault within the warranty
period, JCB Tools may repair the product by replacing defective parts free of charge at our
discretion. In the event parts are irreplaceable JCB Tools may replace your product free of
charge. The original product will remain the property of JCB Tools in this situation.
The above repair or replacement of products will be undertaken providing that:
m The product has been subject to fair wear and tear only.
m The product has not been subject to accidental or cosmetic damage.

15
JCB-18IL
Instruction & User Manual
m The product has not been misused and has been used only in accordance with the instruction
manual provided.
m The product has not been subject to overload or insufficient servicing and maintenance.
m The product has not been subject to any abnormal environmental conditions or inappropriate
operating conditions.
m Repairs have not been attempted by an unauthorised person and no modifications have been
made to the product.
m Repairs have not been undertaken using non-genuine spare parts.
JCB Power Tools used for Hire Fleets or as part of B2B and Service Contracts are not covered by
these terms and conditions.
JCB Tools standard 3 Year and extended 5 Year Warranties excludes the following
(where relevant):
m Components normally subject to wear such as carbon brushes.
m Batteries, Chucks and Chargers.
m Accessories and consumable items.
m Cases and tool storage products.
If your product develops a fault within 30 days of purchase, return it to the retailer where it was
purchased together with your sales receipt. If a product develops a fault after 30 days a warranty
claim must be submitted.
If you have a warranty claim please take your product, original sales receipt and if applicable,
a copy of your extended warranty certificate to your place of purchase or nearest JCB Tools
retailer.
If you wish to send your product to us directly, please call us on 03308380257 to arrange
warranty claim or repair. Delivery and repair charges may apply at our discretion should the
warranty claim be invalid for any of the reasons illustrated above. In the event charges are not
accepted the product will be retained by JCB Tools and remain the property of JCB Tools.
The information on both your sales receipt and your extended warranty certificate must match.
JCB TOOLS WILL NOT BE LIABLE FOR ANY INJURIES OR CONSEQUENTIAL DAMAGES
RESULTING FROM USE OF THIS PRODUCT.

16 JCB-18IL
Instruction & User Manual
EC DECLARATION OF CONFORMITY
We,
JCB Tools
Declare that the product:
Description
18V Lithium-Ion Cordless Combi Drill
Type
JCB-18IL
Function
Illumination Of Work Areas And Workpieces
Complies with the following Directives;
EC Electromagnetic Compatibility Directive
2014/30/EU
RoHS Directive
2011/65/EU
Standards conform to
EN 55015:2013+A1
EN 61547:2009
The person authorized to compile the technical file:
Date: 20/09/2018
Signature:
Name/ title: Mya Yee Lwin / Quality Assurance Manager
Address: JCB Tools, 55 Romsey Industrial Estate, Romsey, SO51 0HR, UK.
Company REG: 11062222

17
JCB-18IL
Instruction & User Manual
