JCM GLOBAL UBA-RC Series User manual
© 2018, JAPAN CASH MACHINE CO., LTD.
website: http://www.jcmglobal.com
UBA-RC™Series
Banknote Recycler
Operation and Maintenance
Manual
(Revision 3)
P/N 960-100928R_Rev. 3 {EDP #192692}
Issue #4088-SME-01-03
This product document (hereinafter referred to as “Manual”) is fully covered by legal Copyrights owned by the JAPAN
CASH MACHINE CO., LTD. (hereinafter referred to as “JCM”) under Japanese laws and other foreign countries.
This Manual contains many copyrighted, patented, or properly registered equipment items manufactured by JCM, that
are prohibited and illegal to duplicate, replicate, copy in whole, or in part, without the express authorization by JCM with
the following exceptions:
1. When an authorized JCM agency or distributor duplicates the Manual for sales promotion and/or service
maintenance of the product, or technical service personnel education as required; and
2. When an end user duplicates the Manual to maintain operation of the product or operate the product in general.
JCM retains all rights to amend, alter, change or delete any portion of this Manual in whole, or in part, or add items
thereto without notice regarding the product or its related products.
JCM is a registered trademark of JAPAN CASH MACHINE CO., LTD. All other product names mentioned herein may be
registered trademarks or trademarks of their respective companies. Furthermore, ™, ®and © are not always mentioned
in each case throughout this publication.
Copyright © 2018 By JAPAN CASH MACHINE CO., LTD.
UBA-RC™ Series Banknote Recycler Operation and Maintenance Manual
International Compliance
• RoHS Directives
• UL & c-UL Marks
• CE Mark
• CB Scheme
• FCC Directives
Electrical Current Symbol
Direct Current: indicates Direct Current values on product labels.
REVISION HISTORY
Rev No.Date Reason for Update Comment
A 10/24/11 Initial Version
1 12/30/13 Specification, Exploded View, Parts Lists and Copyright changes
per JCM Engineering and Technical Support recommendations
2 9/16/15 Updated Product Descriptions, Parts Lists
3 2/7/18 Updated Product Descriptions in Section 1 and updated Parts Lists
in Section 7
or or or or
File No. E142330, Subscriber 857947001, Vol. 2
JPULA-03913
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not
cause harmful interference, and (2) this device must accept any interference received, including interference that may cause
undesired operation.
Note: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the
FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Issue #4088-SME-01-03
P/N 960-100928R_Rev. 3 {EDP #192692} © 2018, JAPAN CASH MACHINE CO., LTD.
i
UBA-RC™ Series
Banknote Recycler
Table of Contents
Page
1 GENERAL INFORMATION ................................................................................. 1-1
Description .................................................................................................................. 1-1
UBA-RC Unit Assembly ............................................................................................. 1-1
Model Descriptions .................................................................................................... 1-2
Type Descriptions ....................................................................................................... 1-2
Software Descriptions ................................................................................................ 1-2
Precautions ................................................................................................................. 1-2
User Cautions ...........................................................................................................................1-3
Installation Cautions ..............................................................................................................1-3
Mounting, Dismounting & Transportation ...............................................................................1-3
Preventive Maintenance ............................................................................................. 1-3
Banknote Fitness Requirements ..............................................................................................1-4
Banknote Storage Requirements .............................................................................................1-4
Primary Features ........................................................................................................ 1-4
Component Names ..................................................................................................... 1-5
Specifications ............................................................................................................. 1-6
Technical Specifications ...........................................................................................................1-6
Environmental Specifications ..................................................................................................1-7
Electrical Specifications ............................................................................................................1-7
Structural Specifications ...........................................................................................................1-7
Unit Dimensions ......................................................................................................... 1-8
Entire Unit Outside Dimensions ...............................................................................................1-8
Entire Unit Outside Dimensions (Continued) ............................................................................1-9
Technical Contact Information ................................................................................ 1-10
Americas ................................................................................................................................1-10
JCM American .....................................................................................................................1-10
Europe, Middle East, Africa & Russia ....................................................................................1-10
JCM Europe GmbH .............................................................................................................1-10
UK & Ireland ...........................................................................................................................1-10
JCM Europe (UK Office) ......................................................................................................1-10
Asia and Oceania ...................................................................................................................1-10
JCM Gold (HK) Ltd. .............................................................................................................1-10
JAPAN CASH MACHINE CO., LTD.(HQ) ............................................................................1-10
2 INSTALLATION .................................................................................................. 2-1
Installation Procedure ................................................................................................ 2-1
Cable Interconnection ................................................................................................ 2-2
DIP Switch Configuration .......................................................................................... 2-2
Jumper Configurations .............................................................................................. 2-2
Connector Pin Assignments ..................................................................................... 2-3
Connector Pin Assignments (Continued) .................................................................................2-4
Connector Pin Assignments (Continued) .................................................................................2-5
Connector Pin Assignments (Continued) .................................................................................2-5
Preventive Maintenance ............................................................................................. 2-6
Restoring Banknotes ................................................................................................................2-6
Restoring Banknotes using the UBA Transport Unit ..............................................................2-6
Table of Contents
P/N 960-100928R_Rev. 3 {EDP #192692} © 2018, JAPAN CASH MACHINE CO., LTD.
ii
Page
UBA-RC™ Series Banknote Recycler
Restoring Banknotes Directly into the Recycler Unit ............................................................. 2-6
Retrieving Banknotes ................................................................................................ 2-6
Sending Retrieved Banknotes to the Cash Box ....................................................................... 2-6
Sending Retrieved Banknotes to the Cash Box by Command ................................................ 2-6
Retrieving Banknotes Directly ..................................................................................................2-6
Dispense Settings ...................................................................................................... 2-7
Clearing a Banknote Jam .......................................................................................... 2-7
Cleaning Procedure ................................................................................................................. 2-7
Sensor Cleaning Procedure .................................................................................................. 2-7
Sensor and Roller Locations ..................................................................................... 2-9
Standard Interface Circuit Schematics ................................................................... 2-10
Operational Flowcharts .............................................................................................2-11
Operational Flowcharts (Continued 1) ................................................................................... 2-12
Operational Flowcharts (Continued 2) ................................................................................... 2-13
Operational Flowcharts (Continued 3) ................................................................................... 2-14
Operational Flowcharts (Continued 4) ................................................................................... 2-15
Operational Flowcharts (Continued 5) ................................................................................... 2-16
Operational Flowcharts (Continued 6) ................................................................................... 2-17
Operational Flowcharts (Continued 7) ................................................................................... 2-18
3 COMMUNICATIONS ........................................................................................... 3-1
Americas .................................................................................................................................. 3-1
JCM American ....................................................................................................................... 3-1
Europe, Middle East, Africa & Russia ...................................................................................... 3-1
JCM Europe GmbH ............................................................................................................... 3-1
UK & Ireland ............................................................................................................................ 3-1
JCM Europe (UK Office) ........................................................................................................ 3-1
Asia and Oceania .................................................................................................................... 3-1
JCM Gold (HK) Ltd. ............................................................................................................... 3-1
JAPAN CASH MACHINE CO., LTD.(HQ) .............................................................................. 3-1
4 DISASSEMBLY/REASSEMBLY ......................................................................... 4-1
Tool Requirements ..................................................................................................... 4-1
Power Source Board Removal .................................................................................. 4-1
Lifter Motor Encoder Board Assy Removal ............................................................. 4-1
Recycler CPU Board Assy Removal ......................................................................... 4-2
Emission Side Double Note Sensor Removal ......................................................... 4-2
Lifter Motor Assy Removal ........................................................................................ 4-3
Upper & Lower Full Sensor PT/Upper & Lower End Sensor LED Removal .......... 4-3
Upper & Lower Full Sensor LED/Upper & Lower End Sensor PT/
Lifter Home Position Sensor LED & PT Removal .................................................... 4-4
Upper & Lower Flapper Pusher Lever Solenoid Removal ...................................... 4-5
Flapper Open/Close Circuit Board Removal ............................................................ 4-5
Banknote Transaction Sensor/Transport Unit Encoder Board &
Double Note Sensor PT Removal ............................................................................. 4-6
Banknote Transaction Sensor & Box Sensor Board Removal ............................... 4-6
Recycler Encoder Board Removal ............................................................................ 4-7
Upper & Lower Recycler Transport Motor Assy Removal ...................................... 4-7
Timing Belt Removal .................................................................................................. 4-8
P/N 960-100928R_Rev. 3 {EDP #192692} © 2018, JAPAN CASH MACHINE CO., LTD.
iii
Page
UBA-RC™ Series Banknote Recycler
Table of Contents
Pick Roller Removal ................................................................................................... 4-8
Feed Roller Removal .................................................................................................. 4-9
Impeller and Stop Roller Removal .......................................................................... 4-10
O-Ring (Pusher Plate) Removal .............................................................................. 4-11
Roller Timing Belt and O-Ring Removal ................................................................ 4-11
Pusher Plate Re-installation ...................................................................................................4-12
5 WIRING DIAGRAMS ........................................................................................... 5-1
Entire System Wiring Diagram .................................................................................. 5-1
Transport Unit & Frame Unit Wiring Diagram (Partial) ............................................ 5-2
Frame Unit Wiring Diagram (Partial) ........................................................................................5-3
6 PERFORMANCE TESTS .................................................................................... 6-1
Download and Installation Workbench Tool Requirements ................................... 6-1
JCM Tool Suite Standard Edition Installation .......................................................... 6-1
JCM Tool Suite Standard Edition .............................................................................. 6-3
Firmware Download Procedure ................................................................................. 6-3
Calibration ................................................................................................................... 6-5
When to Calibrate .....................................................................................................................6-5
Calibration Tool Requirements .................................................................................................6-5
UBA-RC Reference Paper .......................................................................................................6-5
Placing the Reference Paper ...................................................................................................6-5
Calibration and Testing Program ..............................................................................................6-5
Sensor Calibration and Performance Testing ...........................................................................6-5
Model Information Confirmation ...............................................................................................6-8
Reading the Model Information ................................................................................................6-9
Reading the UBA-RC Maintenance Tool Version .....................................................................6-9
Individual Calibration and Performance Test ........................................................ 6-10
Sensor Test Screen ................................................................................................................6-10
Individual Calibration ..............................................................................................................6-10
Load Sensor Data ................................................................................................................6-10
Double Note Detection Sensor Calibration ..........................................................................6-10
RC Full Sensor Button Calibration ....................................................................................... 6-11
Individual Performance Test ................................................................................................... 6-11
Get All Sensor State ...........................................................................................................6-13
Performance Test without a PC ............................................................................... 6-14
Performance Test without PC Procedure ...............................................................................6-15
Banknote Acceptance Test ..................................................................................................6-15
7 EXPLODED VIEWS AND PARTS LISTS ........................................................... 7-1
Entire UBA-RC Unit Exploded View .......................................................................... 7-1
Entire UBA-RC Unit Parts List ..................................................................................................7-2
UBA-RC Frame Unit 1 Exploded View ...................................................................... 7-3
UBA-RC Frame Unit 1 Parts List ..............................................................................................7-4
UBA-RC Frame Unit 2 Exploded View ...................................................................... 7-5
UBA-RC Frame Unit 2 Parts List ..............................................................................................7-6
UBA-RC Frame Unit 3 Exploded View ...................................................................... 7-7
UBA-RC Frame Unit 3 Parts List ..............................................................................................7-8
UBA-RC Frame Unit 4 Exploded View ...................................................................... 7-9
UBA-RC Frame Unit 4 Parts List ............................................................................................7-10
UBA-RC Frame Unit 5 Exploded View .................................................................... 7-11
Table of Contents
P/N 960-100928R_Rev. 3 {EDP #192692} © 2018, JAPAN CASH MACHINE CO., LTD.
iv
Page
UBA-RC™ Series Banknote Recycler
UBA-RC Frame Unit 5 Parts List ........................................................................................... 7-12
UBA-RC RC Space 1 Exploded View ...................................................................... 7-13
UBA-RC RC Space 1 Parts List ............................................................................................. 7-14
UBA-RC RC Space 2 Exploded View ...................................................................... 7-15
UBA-RC RC Space 2 Parts List ............................................................................................. 7-15
UBA-RC RC Space 3 Exploded View ...................................................................... 7-16
UBA-RC RC Space 3 Parts List ............................................................................................. 7-17
UBA-RC RC Space 4 Exploded View ...................................................................... 7-18
UBA-RC RC Space 4 Parts List ............................................................................................. 7-19
UBA-RC RC Space 5 Exploded View ...................................................................... 7-20
UBA-RC RC Space 5 Parts List ............................................................................................. 7-21
UBA-RC Rear Transport Assembly 1 Exploded View ........................................... 7-22
UBA-RC Rear Transport Assembly 1 Parts List .................................................................... 7-22
UBA-RC Rear Transport Assembly 2 Exploded View ........................................... 7-23
UBA-RC Rear Transport Assembly 2 Parts List .................................................................... 7-24
UBA-RC Rear Transport Assembly 3 Exploded View ........................................... 7-25
UBA-RC Rear Transport Assembly 3 Parts List .................................................................... 7-26
UBA-RC Rear Transport Assembly 4 Exploded View ........................................... 7-27
UBA-RC Rear Transport Assembly 4 Parts List .................................................................... 7-28
UBA-RC Rear Transport Assembly 5 Exploded View ........................................... 7-29
UBA-RC Rear Transport Assembly 5 Parts List .................................................................... 7-30
UBA-RC Rear Transport Assembly 6 Exploded View ........................................... 7-31
UBA-RC Rear Transport Assembly 6 Parts List .................................................................... 7-32
WBA-SH2 Cash Box Exploded View 1 .................................................................... 7-33
WBA-SH2 Cash Box Parts List 1 ........................................................................................... 7-33
WBA-SH2 Cash Box Exploded View 2 .................................................................... 7-34
WBA-SH2 Cash Box Parts List 2 ........................................................................................... 7-35
WBA-SH2 Cash Box Exploded View 3 .................................................................... 7-36
WBA-SH2 Cash Box Parts List 3 ........................................................................................... 7-36
WBA-SH2 Cash Box Exploded View 4 .................................................................... 7-37
WBA-SH2 Cash Box Parts List 4 ........................................................................................... 7-38
WBA-SH2 Cash Box Exploded View 5 .................................................................... 7-39
WBA-SH2 Cash Box Parts List 5 ........................................................................................... 7-40
UBA-RC Large Cash Box Frame Unit Exploded View ........................................... 7-42
UBA-RC Large Cash Box Frame Unit Parts List .................................................................... 7-42
Optional Lock Unit Exploded View ......................................................................... 7-43
Optional Lock Unit Parts List ..................................................................................................7-44
8 INDEX .................................................................................................................. 8-1
A TROUBLESHOOTING ........................................................................................ A-1
Introduction ................................................................................................................A-1
Troubleshooting Overview .......................................................................................................A-1
Malfunction LED Error Codes .................................................................................................. A-1
LED Indicator Conditions .........................................................................................................A-1
UBA-RC Recycler Unit Width and Length Guide Replacement
Procedure ....................................................................................................................A-4
Length Guide Replacement ..................................................................................................... A-4
Length Guide Installation .........................................................................................................A-4
Width Guide Replacement ....................................................................................................... A-5
P/N 960-100928R_Rev. 3 {EDP #192692} © 2018, JAPAN CASH MACHINE CO., LTD.
v
Page
UBA-RC™ Series Banknote Recycler
Table of Contents
Maintenance Equipment Requirements ...................................................................A-6
Additional UBA-RC Maintenance Equipment .......................................................................... A-6
Reference Paper Handling ...................................................................................................... A-6
B GLOSSARY .........................................................................................................B-1
P/N 960-100928R_Rev. 3 {EDP #192692} © 2018, JAPAN CASH MACHINE CO., LTD.
vii
UBA-RC™ Series
Banknote Recycler
List of Figures
Page
Figure 1-1 UBA-RC Unit Assembly ........................................................................ 1-1
Figure 1-2 Precautionary Symbols ......................................................................... 1-2
Figure 1-3 Unacceptable Banknotes ...................................................................... 1-4
Figure 1-4 Banknote Storage Insertion Cautions ................................................... 1-4
Figure 1-5 UBA-RC Component Names ................................................................ 1-5
Figure 1-6 UBA-RC Banknote Recycler Standard Unit with Bezel
Outside Dimensions .............................................................................. 1-8
Figure 1-7 UBA-RC Banknote Recycler Standard Unit with Bezel,
Lock Unit and Outside Dimensions ....................................................... 1-8
Figure 1-8 UBA-RC Banknote Recycler Standard Unit with Bezel
Outside Dimensions .............................................................................. 1-9
Figure 1-9 UBA-RC Banknote Recycler Standard Unit with Bezel,
Lock Unit and Outside Dimensions ....................................................... 1-9
Figure 2-1 M4 Screws Locations (Right/Left) ......................................................... 2-1
Figure 2-2 M4 Screws Locations (Rear & Bottom) ................................................. 2-1
Figure 2-3 Cable Interconnection ........................................................................... 2-2
Figure 2-4 UBA CPU Circuit Board Bottom View ................................................... 2-2
Figure 2-5 Banknote Restoration Methods ............................................................ 2-6
Figure 2-6 Retrieving Recycler Banknotes ............................................................. 2-6
Figure 2-7 Clearing a Banknote Jam 1 .................................................................. 2-7
Figure 2-8 Clearing a Banknote Jam 2 .................................................................. 2-7
Figure 2-9 Sensor and Roller Cleaning .................................................................. 2-8
Figure 2-10 UBA-RC Sensor, Roller and Belt Cleaning Locations .......................... 2-9
Figure 2-11 UBA-RC Photo-Coupler Circuit Interface Schematic Diagram ........... 2-10
Figure 2-12 UBA-RC RS232C Circuit Interface Schematic Diagram ..................... 2-10
Figure 2-13 UBA-RC Bezel Circuit Interface Schematic Diagram ......................... 2-10
Figure 2-14 UBA-RC Operational Flowchart (Primary Sequence) ......................... 2-11
Figure 2-15 UBA-RC Operational Flowchart (Validation) ....................................... 2-12
Figure 2-16 UBA-RC Operational Flowchart (Validation Retry) ............................. 2-13
Figure 2-17 UBA-RC Operational Flowchart (Stacking/Recycle Unit) ................... 2-14
Figure 2-18 UBA-RC Operational Flowchart (Stacking/Cash Box) ........................ 2-15
Figure 2-19 UBA-RC Operational Flowchart (Dispensing) ..................................... 2-16
Figure 2-20 UBA-RC Operational Flowchart (Abnormal Banknote Detection
when Dispensing) ............................................................................... 2-17
Figure 2-21 UBA-RC Operational Flowchart (Retrieving) ...................................... 2-17
Figure 2-22 UBA-RC Operational Flowchart (Retrieving to Cash Box) .................. 2-18
Figure 4-1 Power Source Circuit Board Removal .................................................. 4-1
Figure 4-2 Lifter Motor Encoder Circuit Board Assembly Removal ........................ 4-2
Figure 4-3 Connector & Harness Removals .......................................................... 4-2
Figure 4-4 Recycler CPU Circuit Board Removal .................................................. 4-2
Figure 4-5 Emission Side Double Note Sensor Removal ...................................... 4-3
List of Figures
P/N 960-100928R_Rev. 3 {EDP #192692} © 2018, JAPAN CASH MACHINE CO., LTD.
viii
Page
UBA-RC™ Series Banknote Recycler
Figure 4-6 Lifter Motor Bracket Removal ................................................................ 4-3
Figure 4-7 Lifter Motor Assy Removal .................................................................... 4-3
Figure 4-8 Rear Frame & Middle Frame Removal ................................................. 4-3
Figure 4-9 Rear Transport Assy Removal .............................................................. 4-4
Figure 4-10 Left Frame Plate Removal .................................................................... 4-4
Figure 4-11 Frame Guide 4 Removal ....................................................................... 4-4
Figure 4-12 Full Sensor PTs and End Sensor LEDs Removal ................................. 4-4
Figure 4-13 Frame Guide 3 Removal ....................................................................... 4-4
Figure 4-14 Full Sensor LEDs, End Sensor PTs and Lifter Home Position
Sensor LED/PT Removal ...................................................................... 4-5
Figure 4-15 Upper & Lower Flapper Pusher Lever Solenoid Removal .................... 4-5
Figure 4-16 Flapper Open/Close Circuit Board Removals ....................................... 4-6
Figure 4-17 Banknote Transaction Sensor/ Transport Unit Encoder
Circuit Board & Double Note Sensor Removal ..................................... 4-6
Figure 4-18 Banknote Transaction Sensor & Box Detection
Circuit Board Removal .......................................................................... 4-6
Figure 4-19 Recycler Encoder Circuit Board Removal ............................................. 4-7
Figure 4-20 Gear & Shaft Removal .......................................................................... 4-7
Figure 4-21 Recycler Transport Motors Removal ..................................................... 4-7
Figure 4-22 Rear Transport Upper Frame & Shaft Removal .................................... 4-8
Figure 4-23 Timing Belt Cover Removals ................................................................. 4-8
Figure 4-24 Timing Belt/Pulley Removal .................................................................. 4-8
Figure 4-25 RC Centering Guide Removal ............................................................... 4-9
Figure 4-26 End Lever Removal ............................................................................... 4-9
Figure 4-27 Pick Roller Removal .............................................................................. 4-9
Figure 4-28 RC Transport Race Removal ................................................................ 4-9
Figure 4-29 Transport Race Shaft Removal ............................................................. 4-9
Figure 4-30 Feed Roller Removal .......................................................................... 4-10
Figure 4-31 Flapper Removals ............................................................................... 4-10
Figure 4-32 Spring Removals ................................................................................. 4-10
Figure 4-33 Impeller Shaft Removals ..................................................................... 4-10
Figure 4-34 Impeller & Stop Roller Removal .......................................................... 4-11
Figure 4-35 Pusher Mechanism Removal .............................................................. 4-11
Figure 4-36 O-Ring Removals ................................................................................ 4-11
Figure 4-37 Pusher Plate Removal ........................................................................ 4-11
Figure 4-38 Pusher Drive Gear Removal ............................................................... 4-12
Figure 4-39 Pusher Timing Belt Removal 1 ............................................................ 4-12
Figure 4-40 Pusher Timing Belt Replacement ........................................................ 4-12
Figure 4-41 Pusher Timing Belt Removal 2 ............................................................ 4-12
Figure 4-42 Pulley & O-Ring Removal ................................................................... 4-12
Figure 4-43 Pusher Plate Removal ........................................................................ 4-12
Figure 5-1 UBA-RC Entire System Wiring Diagram (24V) ..................................... 5-1
Figure 5-2 UBA-RC Transport Unit/Frame Unit System Wiring Diagram (Part 1) .. 5-2
Figure 5-3 UBA-RC Frame Unit System Wiring Diagram (Part 2) .......................... 5-3
List of Figures
P/N 960-100928R_Rev. 3 {EDP #192692} © 2018, JAPAN CASH MACHINE CO., LTD.
ix
UBA-RC™ Series Banknote Recycler
Page
Figure 6-1 Tool and Harness Connection ...............................................................6-1
Figure 6-2 setup.exe Location ................................................................................6-1
Figure 6-3 Install Shield Wizard Screen..................................................................6-1
Figure 6-4 Installation File Extracting Screen .........................................................6-2
Figure 6-5 Customer Information Screen................................................................6-2
Figure 6-6 Destination Folder Screen .....................................................................6-2
Figure 6-7 Current Settings Confirmation ...............................................................6-2
Figure 6-8 Installation Status Confirmation.............................................................6-2
Figure 6-9 Installation Completion Screen..............................................................6-2
Figure 6-10 JCM Tool Suite Short-cut Icon...............................................................6-3
Figure 6-11 JCM Tool Suite Standard Edition ..........................................................6-3
Figure 6-12 UBA-RC DIP Switch Setting ..................................................................6-3
Figure 6-13 DIP Switch Location ..............................................................................6-3
Figure 6-14 Select Download....................................................................................6-3
Figure 6-15 Invalid File! Dialog Pop-Up Screen........................................................6-3
Figure 6-16 Select Firmware 1..................................................................................6-4
Figure 6-17 Select Firmware 2..................................................................................6-4
Figure 6-18 Select Firmware 3..................................................................................6-4
Figure 6-19 Download Progress Screen...................................................................6-4
Figure 6-20 Download Progress Screen...................................................................6-4
Figure 6-21 Download Completed Screen................................................................6-5
Figure 6-22 KS-087 Reference Paper ......................................................................6-5
Figure 6-23 Reference Paper Insertion.....................................................................6-5
Figure 6-24 UBA Transport DIP Switch Setting ........................................................6-6
Figure 6-25 DIP Switch Setting.................................................................................6-6
Figure 6-26 DIP Switch Location ..............................................................................6-6
Figure 6-27 Model Information Screen .....................................................................6-6
Figure 6-28 Model Information Screen .....................................................................6-6
Figure 6-29 UBA-RC Maintenance Tool Screen 1....................................................6-6
Figure 6-30 UBA-RC Maintenance Tool Screen 2....................................................6-6
Figure 6-31 UBA-RC Maintenance Tool Screen 3....................................................6-7
Figure 6-32 UBA-RC Maintenance Tool Screen 4....................................................6-7
Figure 6-33 UBA-RC Maintenance Tool Screen 5....................................................6-7
Figure 6-34 UBA-RC Maintenance Tool Screen 6....................................................6-7
Figure 6-35 UBA-RC Maintenance Tool Screen 7....................................................6-7
Figure 6-36 UBA-RC Maintenance Tool Screen 8....................................................6-8
Figure 6-37 UBA-RC Maintenance Tool Screen 9....................................................6-8
Figure 6-38 Calibration Completed Dialog Box.........................................................6-8
Figure 6-39 Serial No. Screen Button Location ........................................................6-8
Figure 6-40 Model Information Saving Screen 1 ......................................................6-8
Figure 6-41 Model Information Saving Screen 2 ......................................................6-8
Figure 6-42 Model Information Saving Completed Screen .......................................6-9
Figure 6-43 Sensor Calibration Screen Button .........................................................6-9
Figure 6-44 Loading Model Information Screen 1.....................................................6-9
List of Figures
P/N 960-100928R_Rev. 3 {EDP #192692} © 2018, JAPAN CASH MACHINE CO., LTD.
x
Page
UBA-RC™ Series Banknote Recycler
Figure 6-45 Loading Model Information Screen 2 .................................................... 6-9
Figure 6-46 Version Information Screen 1................................................................ 6-9
Figure 6-47 Version Information Screen 2................................................................ 6-9
Figure 6-48 Sensor Test Selection ......................................................................... 6-10
Figure 6-49 Test Function Listing Screen............................................................... 6-10
Figure 6-50 Calibration Test Function Screen Buttons........................................... 6-10
Figure 6-51 Load Sensor Data ............................................................................... 6-10
Figure 6-52 Double Note Detection Sensor............................................................ 6-11
Figure 6-53 RC Full Sensor.................................................................................... 6-11
Figure 6-54 Test Function Screen Buttons............................................................. 6-11
Figure 7-1 Entire UBA-RC Unit Exploded View ...................................................... 7-1
Figure 7-2 UBA-RC Frame Unit 1 Exploded View .................................................. 7-3
Figure 7-3 UBA-RC Frame Unit 2 Exploded View .................................................. 7-5
Figure 7-4 UBA-RC Frame Unit 3 Exploded View .................................................. 7-7
Figure 7-5 UBA-RC Frame Unit 4 Exploded View .................................................. 7-9
Figure 7-6 UBA-RC Frame Unit 5 Exploded View ................................................ 7-11
Figure 7-7 UBA-RC RC Space 1 Exploded View ................................................. 7-13
Figure 7-8 UBA-RC RC Space 2 Exploded View ................................................. 7-15
Figure 7-9 UBA-RC RC Space 3 Exploded View ................................................. 7-16
Figure 7-10 UBA-RC RC Space 4 Exploded View ................................................. 7-18
Figure 7-11 UBA-RC RC Space 5 Exploded View ................................................. 7-20
Figure 7-12 UBA-RC Rear Transport Assembly 1 Exploded View ......................... 7-22
Figure 7-13 UBA-RC Rear Transport Assembly 2 Exploded View ......................... 7-23
Figure 7-14 UBA-RC Rear Transport Assembly 3 Exploded View ......................... 7-25
Figure 7-15 UBA-RC Rear Transport Assembly 4 Exploded View ......................... 7-27
Figure 7-16 UBA-RC Rear Transport Assembly 5 Exploded View ......................... 7-29
Figure 7-17 UBA-RC Rear Transport Assembly 6 Exploded View ......................... 7-31
Figure 7-18 WBA-SH2 Cash Box Exploded View 1 ............................................... 7-33
Figure 7-19 WBA-SH2 Cash Box Exploded View 2 ............................................... 7-34
Figure 7-23 UBA-RC Large Cash Box Frame Unit Exploded View ........................ 7-42
Figure 7-24 UBA-RC Optional Lock Unit Exploded View ....................................... 7-43
Figure A-1 Opening the Recycler Unit Door ...........................................................A-4
Figure A-2 Length Guide Removal .........................................................................A-4
Figure A-3 New Length Guide Installation 1 ...........................................................A-4
Figure A-4 New Width Guide Installation 2 .............................................................A-5
Figure A-5 New Width Guide Installation 3 .............................................................A-5
Figure A-6 New Width Guide Installation 4 .............................................................A-5
Figure A-7 Additional Maintenance Equipment Requirements ...............................A-6
P/N 960-100928R_Rev. 3 {EDP #192692} © 2018, JAPAN CASH MACHINE CO., LTD.
xi
UBA-RC™ Series
Banknote Recycler
List of Tables
Page
Table 1-1 UBA-RC Model Number Specifications ................................................ 1-2
Table 1-2 UBA-RC Type Specifications ................................................................ 1-2
Table 1-3 UBA-RC Software No. Specifications ................................................... 1-2
Table 1-4 UBA-RC Technical Specifications ........................................................ 1-6
Table 1-5 UBA-RC Environmental Specifications ................................................. 1-7
Table 1-6 UBA-RC Electrical Specifications ......................................................... 1-7
Table 1-7 UBA-RC Structural Specifications ........................................................ 1-7
Table 2-1 UBA Transport Unit DIP Switch Settings .............................................. 2-2
Table 2-2 UBA-RC Unit DIP Switch Settings ........................................................ 2-2
Table 2-3 Photo Coupler Interface Connection Pin Assignments ......................... 2-3
Table 2-4 RS232C Interface Connection Pin Assignments .................................. 2-4
Table 2-5 Power Supply Pin Assignments ............................................................ 2-5
Table 2-6 Front Panel Bezel Interface Connection Pin Assignments ................... 2-5
Table 2-7 UBA-RC Sensor Type Cleaning Methods ............................................. 2-9
Table 6-1 Sensor Calibration Configuration ........................................................ 6-11
Table 6-2 Performance Test Configurations ....................................................... 6-12
Table 6-3 Get All Sensor State Configurations ................................................... 6-13
Table 6-4 Non-PC Performance Test Item and Configuration ............................ 6-14
Table 7-1 UBA-RC Unit Parts List ......................................................................... 7-2
Table 7-2 UBA-RC Frame Unit 1 Parts List .......................................................... 7-4
Table 7-3 UBA-RC Frame Unit 2 Parts List .......................................................... 7-6
Table 7-4 UBA-RC Frame Unit 3 Parts List .......................................................... 7-8
Table 7-5 UBA-RC Frame Unit 4 Parts List ........................................................ 7-10
Table 7-6 UBA-RC Frame Unit 5 Parts List ........................................................ 7-12
Table 7-7 UBA-RC RC Space 1 Parts List .......................................................... 7-14
Table 7-8 UBA-RC RC Space 2 Parts List .......................................................... 7-15
Table 7-9 UBA-RC RC Space 3 Parts List .......................................................... 7-17
Table 7-10 UBA-RC RC Space 4 Parts List .......................................................... 7-19
Table 7-11 UBA-RC RC Space 5 Parts List .......................................................... 7-21
Table 7-12 UBA-RC Rear Transport Assembly 1 Parts List ................................. 7-22
Table 7-13 UBA-RC Rear Transport Assembly 2 Parts List ................................. 7-24
Table 7-14 UBA-RC Rear Transport Assembly 3 Parts List ................................. 7-26
Table 7-15 UBA-RC Rear Transport Assembly 4 Parts List ................................. 7-28
Table 7-16 UBA-RC Rear Transport Assembly 5 Parts List ................................. 7-30
Table 7-17 UBA-RC Rear Transport Assembly 6 Parts List ................................. 7-32
Table 7-18 WBA-SH2 Cash Box Parts List 1 ........................................................ 7-33
List of Tables
P/N 960-100928R_Rev. 3 {EDP #192692} © 2018, JAPAN CASH MACHINE CO., LTD.
xii
Page
UBA-RC™ Series Banknote Recycler
Table 7-19 WBA-SH2 Cash Box Parts List 2 ........................................................ 7-35
Table 7-20 WBA-SH2 Cash Box Parts List 3 ........................................................ 7-36
Table 7-21 WBA-SH2 Cash Box Parts List 4 ........................................................ 7-38
Table 7-22 WBA-SH2 Cash Box Parts List 5 ........................................................ 7-40
Table 7-23 UBA-RC Large Cash Box Frame Unit Parts List ................................. 7-42
Table 7-24 UBA-RC Optional Lock Unit Parts List ................................................ 7-44
Table A-1 UBA Unit LED Code Conditions ............................................................A-1
Table A-2 RC Unit LED Color Type Error Code Conditions ..................................A-2
Table A-3 Recycler Unit LED Code Conditions .....................................................A-3
Table A-4 Various Recycler Unit LED Flashing Error Code Conditions ................A-3
Table A-5 Additional Maintenance Equipment Parts List .......................................A-6
P/N 960-100928R_Rev. 3 {EDP #192692} © 2018, JAPAN CASH MACHINE CO., LTD.
1-1
UBA-RC™ Series
Banknote Recycler
Section 1
Description
This section provides a general overview of the
UBA-RC™Series Banknote Recycler Unit
Assembly (UBA-10/12-SH2/SS-RC; UBA-RC™)
pictured in Figure 1-1. This section is designed to
help you navigate through this guide with ease, and
provides the following information:
• UBA-RC™ Unit Assembly
• Model Descriptions
• Precautions
• Primary Features
• Component Names
• Specifications
• Unit Dimensions
• Technical Contact Information
In order to make operation of this device easier and
make navigation within this manual simpler, the
following illustrations were used within the text:
• Safety Instructions, which need to be
observed in order to protect the operators and
equipment, have been written in bold text and
have been given the following pictographs:
• Special Notes, which affect the use of the
Banknote Recycler have been written in italic
text and have been given the pictograph:
• Steps, requiring the operator to perform
specific actions are given sequential numbers
(1., 2., 3., etc).
1 GENERAL INFORMATION
Figure 1-1 UBA-RC Unit Assembly
UBA-RC Unit Assembly
Figure 1-1 UBA-RC Unit Assembly
O
PTIONAL
B
EZEL
A
SSEMBLY
UBA V
ALIDATION
A
SSEMBLY
UBA-RC
F
RAME
U
NIT
UBA-RC R
ECYCLER
A
SSEMBLY
UBA-RC C
ASH
B
OX
A
SSEMBLY
(N
OT
I
NCLUDED
)
NOTE: Cash Box Locks are
Provided Selection
an Optional User
(N
OT
I
NCLUDED
)
B
EZEL
S
PACER
(B
EHIND
B
EZEL
)
P/N 960-100928R_Rev. 3 {EDP #192692} © 2018, JAPAN CASH MACHINE CO., LTD.
1-2
Section 1 UBA-RC™ Series Banknote Recycler General Information
Model Descriptions
Table 1-1 lists the Product Model Number
descriptions.
Type Descriptions
Table 1-2 lists the Product Type Number
Descriptions.
Software Descriptions
Table 1-3 lists the Software Number
Specifications.
Precautions
The Figure 1-2 symbols are defined as follows:
1. (Type 1) Do not insert a torn, folded, or wet
Banknotes into the Unit, as this action may cause
a Banknote jam inside the Unit.
2. (Type 2) Do not expose the Recycler Unit to
water or any wet liquids. The Unit contains
several precision electronic devices which can be
damaged if water or liquid of any kind is sprayed
or spilled into the Unit.
3. (Type 3) Do not install the Unit into a dusty
environment. Dust may affect and degrade the
Recycler’s performance.
Table 1-1 UBA-RC Model Number Specifications
NoModel: UBA - 1 * * - * *** * - RC
No(1) (2)(3) (4) (5) (6) (7)
(1) Product Series Name
(2) CPU Circuit Board
0 = Flash ROM (8Mbit)
2 = Flash ROM (16Mbit)
(3) Transport Unit Type
none = Standard
(4) Option Unit (Input Section)
none = Standard
(5) Stacker Type
SH2 = Horizontal Down (82mm Specification)
SS = Vertical Down (Large Cash Box)
(6) Box Access
None = Front Access (Standard)
(7) Recycler Function
RC = Recyclable
Table 1-2 UBA-RC Type Specifications
NoType: * 0 0 - 0 0 - * * 1 * * * * * * * *
No.o (1,2,3) (4,5) (6,7,8,9,10,11,12,13,14,15,16)
(1) Cash Box Capacity
4 = 400 notes (New Banknote)
8 = 800 notes (New Banknote)
(2) Cash Box Type
0 = Standard
(3) Cash Box Handle
0 = Standard
(4) Transport Section
0 = Standard (Earlier Type)
1 = 3.3v Flash ROM CPU Board
(5) Transport Cover
0 = Standard (Blue)
(6)
Optional Bezel
0 = None
1 = Black/Green LED (UBA/iPRO Standard Bezel 85)
2 = Blue/Blue LED (UBA/iPRO Standard Bezel 85)
A = Blue/Blue (2-Line) (UBA/iPRO Standard Bezel 85)
(7) Bezel Spacer
0 = No
1 = Yes
(8) Optional Power Circuit Board
1 = Standard (Power Board Featured)
(9) Input/Output Signal
P = Photo-Coupler Isolation
R = RS232C
(10) External Communication Harness
0 = None
1 = Standard (with Power Harness)
(11) RC1 Recycler Unit Banknote Width Guide*
0 = None
1 = Width Guide 62 (Gray)
2 = Width Guide 67 (Red)
3 = Width Guide 72 (Blue)
(12) RC2 Recycler Unit Banknote Width Guide*
(13)
RC1 Recycler Unit Banknote Length Guide*
(14)
RC2 Recycler Unit Banknote Length Guide*
(15) Lock Unit
0 = No (without Lock)
1 = Yes (with Lock)
(16) Optional Cash Box Fastener
0 = None
1 = Thumb Twist Lock Fastener for the Cash Box
*. Refer to each Country’s “Software Information Sheet”.
Table 1-3 UBA-RC Software No. Specifications
No
Software: UBA-10(*)-(*)SH2(*)-RC * * * - 0 * * - V * .**
No(A) (B) (C) (D)
(A) Software Model Name
(B) Denomination (Country)*
*. The Country Code is indicated by three (3) Alphabetical Characters
following the JIS Country Standard abbreviation.
(C) Interface Protocol Name
(D) Software Version
Table 1-2 UBA-RC Type Specifications
NoType: * 0 0 - 0 0 - * * 1 * * * * * * * *
No.o (1,2,3) (4,5) (6,7,8,9,10,11,12,13,14,15,16)
0 = None
1 = Width Guide 62 (Gray)
2 = Width Guide 67 (Red)
3 = Width Guide 72 (Blue)
0 = None
1 = Length Guide 120 (Gray)
2 = Length Guide 127 (Red)
3 = Length Guide 133 (Blue)
4 = Length Guide 140 (Orange)
5 = Length Guide 147 (Green)
6 = Length Guide 152 (Black)
7 = Length Guide 158 (Black)
0 = None
1 = Length Guide 120 (Gray)
2 = Length Guide 127 (Red)
3 = Length Guide 133 (Blue)
4 = Length Guide 140 (Orange)
5 = Length Guide 147 (Green)
6 = Length Guide 152 (Black)
7 = Length Guide 158 (Black)
Figure 1-2 Precautionary Symbols
Type 1 Type 2 Type 3
Figure 1-2 Precautionary Symbols
P/N 960-100928R_Rev. 3 {EDP #192692} © 2018, JAPAN CASH MACHINE CO., LTD.
1-3
General Information UBA-RC™ Series Banknote Recycler Section 1
User Cautions
Careful measures are taken in the design of this
product to ensure its quality; however, the follow-
ing cautions should be read and understood by all
users in order to confirm safe operation.
I
NSTALLATION
C
AUTIONS
The Installation Cautions are defined as follows:
1. Do not allow the Unit to endure or operate at a
high temperature, in high humidity and/or in a
dusty environment.
2. Do not install the Unit into an area where exces-
sive vibration or shock are present.
3. The Unit is not designed for outside installation.
Be sure that the Host Machine contains enough
protection to avoid wet or dusty conditions when
installing in either an indoor or open-air space.
4. Avoid exposing the Unit to direct Sunlight and/or
Incandescent Lamp illumination having a
Gradient Angle of 15 Degree or more, and an
illumination index of 3000 Lux or less.
5. Ensure that the Host Machine is designed for
daily operational access for maintenance
and/or clearing a Banknote jam.
6. When installing the equipment, connect the
Frame Housing to the Frame Ground of the Host
Machine.
7. If an unused Interface Harness exists, cut the
Harness off short to avoid attracting static elec-
tricity or a short circuit possibility that may cause
damage to the Unit.
8. Because this equipment is a component product,
close the Host Machine’s door before using it.
9. Do not operate the UBA-RC™Unit while the
Cash Box and/or the Recycler Unit’s door is open.
Personal injury may occur.
10. This Unit is designed to use a current limiting
Power Source. Be sure that the Host Machine’s
cabinet material design meets local safety stan-
dards.
M
OUNTING
, D
ISMOUNTING
& T
RANSPORTATION
Methods for Mounting, Dismounting, and Trans-
porting the Unit are as follows:
1. Be sure to turn the Power OFF to the UBA-RC™
Unit before mounting or removing the Recycler
Unit from its permanent location. Attaching or
unplugging Connector Plugs from their Recepta-
cles while the Power is ON may damage the Unit.
2. When reassembling a Unit’s Section, ensure that
each part is replaced in its correct location.
3. Be sure to carry the Unit by both hands when
transporting it. Holding the Unit by one hand may
cause personal injury if the Unit accidentally
becomes disassembled and falls away from the
Frame housing.
4. Be careful not to use excessive outside pressure
on the Recycler Unit, or subject it to excessive
vibration during transportation.
5. Check that the UBA™Transport Section does not
drop off the Unit Frame while pulling the Recy-
cler forward from the Frame.
Preventive Maintenance
The Preventive Maintenance requirements are
defined as follows:
1. Be sure to turn the Power OFF before beginning a
maintenance procedure. The equipment produces
improper operating signals while in maintenance
mode that may cause personal injury.
2. When closing the Recycler Unit, ensure all ser-
vice door locks click into place.
3. If the UBA™Validator Section is dirty due to dust,
foreign objects or other such debris adhering to it,
the Banknote acceptance rate will degrade. Clean
the Transport Unit once a month to keep its per-
formance stable.
4. Use a soft, lint-free cloth, cotton swab or a com-
pressed air spray to clean dust and debris from the
Banknote path and the inside areas of the
Recycler.
5. Do not redesign or disassemble the Recycler Unit.
Unauthorized use by inadequately-trained
personnel, or use outside the original manufac-
turer’s intent for operation voids the warranty.
Caution: DO NOT use any alcohol,
solvents, abrasive cleaning agents,
or citrus-based cleaners that can
damage the plastic surface of the
device when cleaning it.
Caution: Make Interface Harness
connections to the Host Machine
shorter than 9.84 Feet (3 Meters) in
length. Cut off all unused portions
of the Interface Harness wiring to
avoid static electrical effects or
short circuit possibilities that
could cause damage to the Unit.
WARNING: This Unit is designed
for use with a Current limiting
Power Source! Design the Host
Cabinet space to meet all local
related safety standards.
P/N 960-100928R_Rev. 3 {EDP #192692} © 2018, JAPAN CASH MACHINE CO., LTD.
1-4
Section 1 UBA-RC™ Series Banknote Recycler General Information
Banknote Fitness Requirements
The following Banknote types may not validate
correctly, or can cause a Banknote jam and/or dam-
age to the Unit’s Transport path. Banknotes exhibit-
ing the conditions listed below and illustrated in
Figure 1-3 should be avoided:
• Torn
• Having excessive folds
• Dirty
• Wet
• Having excessive wrinkles
• Adhering foreign objects and/or oil
Banknote Storage Requirements
The following conditions are required when placing
Banknotes directly into the Recycler Unit’s Bins.
1. Replace the minimum Banknote count as required
for Recycler initialization, so the Banknotes will
be available for use during a standard recycle
function.
• The maximum number of recyclable Banknotes
in a Recycler Unit’s Bin should be:
– Approximately 100 Notes if the Banknotes are
all new
– Approximately 70 Notes if the Banknotes are
a mixed Street Grade level.
2. Do not use any Banknotes indicated in Figure 1-3
“Unacceptable Banknotes ” shown on this page.
3. Make one edge of the Banknote bundle smooth.
4. Verify that no curled or folded Banknotes exist.
5. Before placing Banknotes into the Recycler Bins
(especially new Notes), Flip-over and Fan-Flip
the Banknote bundle; then curve the middle of the
Banknote bundle to form a downward angled
structure (Figure 1-4 a).
6. Verify that the Holographic image portion of a
Banknote is always at the front end of the inser-
tion direction (Figure 1-4 b).
7. Make sure the denomination of each Banknote
bundle inserted is correctly placed in the same
direction.
8. Make sure the Banknote bundle inserted is of the
same denomination and from the same Country
when restoring by hand.
9. Insert the Banknotes being recycled into the
Recycler Unit’s Bins carefully until the bundle
reaches the very back of the Bin.
10. Verify that the bottom Note of a Banknote bundle
is not curled or folded when inserting the Bank-
note bundle into a Recycler Unit’s Bin.
Primary Features
The UBA-RC™Series Banknote Recycler contains
the following primary features:
• Allows a high capacity, compact size,
Recycling Unit available for two (2) different
Banknote denominations
• The Friction Roller System eases operation and
maintenance of the Recycler Unit
• The Automatic Centering Mechanism allows
the Unit to read Banknotes ranging from 62mm
to 82mm in width: a maximum of 158mm in
length, and it will automatically center
Banknotes inserted obliquely to help improve
the acceptance rate
• A secure Recycler Unit containing a Key Lock
is composed of durable, impact-resistant
plastic construction to assure safe and secure
cash handling.
• The JCM patented Anti-Pullback Mechanism
provides powerful protection against Banknote
stringing operations.
Figure 1-3 Unacceptable Banknotes
Figure 1-3 Unacceptable Banknotes
Damaged Banknotes
Wrinkled Banknotes
Curled Banknotes
Folded or Partial Banknotes
NOTE: Do not insert more than the
above recommended recyclable
Banknotes as the count indicates!
Figure 1-4 Banknote Storage Insertion Cautions
Figure 1-4 Banknote Storage Insertion Cautions
x
Adjust shapes
before restoring
recyclable
Banknotes. x
a
Hologram
End
aaa
b
P/N 960-100928R_Rev. 3 {EDP #192692} © 2018, JAPAN CASH MACHINE CO., LTD.
1-5
General Information UBA-RC™ Series Banknote Recycler Section 1
Component Names
Figure 1-5 illustrates the UBA-RC™component names and locations.
Figure 1-5 UBA-RC Component Names
Figure 1-5 UBA-RC Component Names
A
B
E
G
H
I
L
M
D
F
N
J
K
123
5
4
C: Front Panel Access Door
NOTE: The Front Panel Access Door
should NOT BE LEFT OPEN when the
UBA-RC Bin Assembly is re-installed
into the Frame.
Recycler Unit Assembly
Rear Side
Front Side
Optional Lock
O
U
P
Q
R
T
C
S
V
NOTE: The Optional Lock is available
for installation on the right or left side
of a UBA-RC Unit.
A.UBA Transport Unit (User Supplied)
B.UBA Unit Upper Guide Access Lever
C.Front Panel Access
1.USB mini-B Type Receptacle (for performing
Software downloads and adjustments)
2.8 Position DIP Switch Block
3.UBA Transport Unit LEDs (Green & Red)
4.Front Bezel Receptacle (for the Optional Bezel
Assembly Plug)
5.Centering LED
6.Transport Unit Release Lever
D.RC Unit DIP Switch Block
E.RC Unit LEDs (Green, Red & Yellow)
F. Recycler Unit Release Pushbutton
G.Restore Pushbutton (for moving Banknotes from the
Recycler Unit into the Cash Box)
H.Recycler Unit Lock (Supplied with Key)
I. Recycler Unit
J. Cash Box Lock Holes (Locks are User Supplied
Options)
K.Cash Box
L. Bezel Accessory (One of 3 Options Available)
M.Bezel Spacer
N.Centering Guide Release Port
O.Interface Connector (Connects to the Host Machine)
P. Housing Frame
Q.RC1-Bin Assembly Banknote Space
R.RC2-Bin Assembly Banknote Space
S.Banknote Width Guide
T. Banknote Length Guide
U.Power Connector
V. Optional Lock Unit (Right or Left side)
P/N 960-100928R_Rev. 3 {EDP #192692} © 2018, JAPAN CASH MACHINE CO., LTD.
1-6
Section 1 UBA-RC™ Series Banknote Recycler General Information
Specifications
Technical Specifications
Table 1-4 UBA-RC Technical Specifications
Acceptance Rate:
98% or greater*
The following Banknote Types are excluded:
a) Banknotes with excess or poor magnetism or unclear graphics
b) Double (dual) Banknotes
c) Worn, dirty, wet, stained, torn or excessively-wrinkled Banknotes
d) Banknotes having folded corners or edges
e) Banknotes having the wrong cut dimensions or a printing displacement
*. Refer to the “Software Information Sheet” for each Country’s Acceptance Rate parameters.
Banknote Types Accepted†:
†. Banknote size widths are limited by the specific Guide Types inserted.
Recycler Unit
•Length: 120-158mm (4.72-6.22 in.)‡
•Width: 62-82mm (2.44-3.22 in.)
Cash Box
•Length: 120-165mm (4.72-6.49 in.)
•Width: 62-82mm (2.44-3.22 in.)
‡. Contact each region’s local JCM representative if the Banknote length is over 165mm (6.49 in.).
Barcode Coupon**:
**.Refer to the specific Country’s Barcode Coupon Specification for more details.
Standard Specification
a) Interleaved Barcode Read: 2 of 5
b) Narrow Bar Width: 0.5mm-0.6mm (0.019-0.023 in.)
c) Wide Bar to Narrow Bar ratio = 3:1
d) Characters: 18 Characters
e) Print Position: Middle (Divides a Coupon equally to the left, right, top and
bottom of the Coupon’s center line)
f) Print Width: Wider than 10mm (0.39 in.)
Insertion Direction: Banknote: Refer to the specific Country’s “Software Information Sheet”
Barcode Coupon: Two-way (with Barcode Surface facing upward)
Processing Speed††:
††.Excludes the time lag associated with Host Communication (Power Supply: +24V DC, Temperature: 25º C ±5º C).
From Banknote insertion to Vend signal output:
•Approximately 4 seconds
From Banknote insertion to stacking operation completion:
•Approximately 8 seconds (to Recycler Unit)
•Approximately 7 seconds (to Cash Box)
From dispense beginning, to dispensing operation completion:
•Approximately 4 seconds
From retrieve beginning to retrieving operation completion:
•Approximately 7 seconds
Escrow: 1 Note
Diagnostic Indicators:
Transport Unit: Two Single-Color LEDs (Red/Green)
RC Unit: Two Tri-Color LEDs (Red/Green/Yellow)
Centering Home Position Indicator LED (Red)
Cash Box‡‡:
‡‡.Cash Box Lock(s) and Key(s) are provided by User (2 Key Hole Caps are fitted in place to cover existing holes when shipped).
Steel: Secure Type (WBA-SH2 Cash Box Design)
Plastic: Secure Type (UBA/iPRO Large Cash Box Design)
Cash Box Capacity: 400 Notes (New Banknotes Only) (WBA-SH2 Cash Box Design)
800 Notes (New Banknotes Only) (UBA/iPRO Large Cash Box Design)
Recycler Unit: Key Lockable, 2 Denomination Integral Recycler (Friction Roller System)
Recycler Unit Capacity: 100 Notes (New Banknotes Only)
Recycle Unit Storage Method: Stores Banknotes from the Acceptor (Recommended)
Stores Banknotes directly
Interfaces: Photo-Coupler Isolation, TTL & RS232C
