Electric and Dual-FuelTM Slide-In Range
Dimensions
SVE47100, SVE47500,
SVE47600, SVE87600, SVD48600
Important: Because of continuing product improvements, Jenn-Air reserves the right to change specifications without
notice. Dimensional specifications are provided for planning purposes only. For complete details see installation
instructions that accompany each product before selecting cabinetry, making cutouts or beginning installation.
www .jennair .com
Inches Centimeters
A2 35 1/2 90.2
B 29 7/8 75.9
C3 26 3/8 67.0
D 35 3/8 minimum 89.9 minimum
E 29 7/8 75.9
F 21 53.3
G 29 3/8 74.6
H 1/4 .6
I 30 1/8 ± 1/16 76.5
Notes:
1. Free-Standing installation requires optional
 backsplash. Unit does not overhang on counter.
 Side panels required if sides are exposed.
2. May vary depending on leveling legs.
3. Excluding handle. Dimension given is from
 wall to front of oven door.
X. If overhang is 1/2" to 1", dimension X=22 5/8".
 If overhang is 1" to 1 3/4", dimension X=23".
Y. The minimum clearance required between
 cabinet and cabinet drawer edge is
 minimum 7/8".
Z.  Select appropriate duct cutout
 (see ducting installation instructions).
"Drop-In Look" Option:
Order "Drop-In Look" Kit model A513. Attach
custom wood panel to supplied metal panel and clip
to range front (lower panel). Can be used with
SVE47100, SVE47500, SVE47600, SVE87600,
SVD48600.
D
F
H
G
X
Z
Y
E
E
Z
I
Free Standing
Installation1
B
AC
Slide-In
Installation
30"

Duct Length RecommendationsA
5" Dia.C 6" Dia. or
  3 1/4 x 10"C
All ElectricD 10' 60'
All GasE 10' 60'
Notes:
A. For venting up to the equivalent of 60', use standard steel ducting and elbows.
B.  IMPORTANT: See installation instructions shipped with product before selecting island cabinetry,
 making cutouts or beginning installation. For best performance, it is suggested that no more than
 three 90 degree elbows be used with 6" or 3 1/4" x 10" duct. Each foot of metal flex duct counts as two
 feet of rigid metal duct. Each flex elbow counts as two metal elbows. For longer duct runs of 31' to 60',
 the restricter ring on the blower inlet housing must be removed. 6" round or 3 1/4 x 10" duct must
 be used for ducting beyond 10' (up to 60'). Failure to follow ducting recommendations or use
 recommended ducting accessories may result in substandard performance.
C.  Count each 90 degree elbow as 5' of duct.
D. When venting electric ranges, 5" diameter round duct may be used to vent straight out the back of
 appliance and directly through the wall for runs of 10' or less.
E.  When venting dual-fuel ranges, 5" diameter round duct must be used for runs of 10' or less.
F. When installing through a slab, it is essential that the system be properly calculated, designed
 and installed before the house is built, when the slab is poured.
(Maximum)B
5" Dia. Duct
5" Dia. Duct
5" to
3 1/4" x 10"
Transition
Elbow
Rear Duct (Inside Wall)
6" Dia. Elbow
5" Wall
Cap
Through the wall in back of
the grill-range directly to
the outside
5" - 6"
Transition 6" Wall
Cap
Down through the floorF, along
the floor joists and through
the foundation or an outside wall
Out from the right of the
appliance through cabinet toe-
kick space to an outside wall
The Long Duct Run
With Jenn-Air's powerful blower,
Jenn-Air downdraft grill-ranges
can vent up to the equivalent of
60 feet.
Here's how it works.
For duct runs equivalent to 30'
or less, install as received. For
duct runs equivalent to 31' to
60', simply snap out the restricter
ring on the blower inlet housing.
See installation instructions for
specific information.
