Jesco DL-FLEX2-NPX-TW User manual

INSTALLATION INSTRUCTIONS
DL-FLEX2-NPX-TW
www.jescolighting.com
Instruction sheet subject to
change without prior notice
4/8/2022
Page 1 of 6
IMPORTANT SAFETY INSTRUCTIONS
Please read carefully before using product. Protect yourself and others by observing all safety information, warnings and
cautions. Failure to comply with instructions could result in personal injury and/or damage to product or property.
Please retain instruction sheet for future reference.
When installing or using this product, basic safety precautions should always be followed including the following:
1. Read all instructions before attempting to install this product.
2. Ensure main power is off before installing or wiring this product.
3. Ensure correct voltage is being used for this product.
4. Do not use if there is visible damage to the fixture or cord insulation. Inspect periodically.
5. Do not install in direct sunlight to avoid damaging the phosphor on the LEDs.
6. Do not submerge in any liquid or use the product where liquid might pool.
7. Disconnect electrical power before adding to or changing the configuration of this product.
8. Fixtures must be installed by a qualified/certified electrician in accordance with all national and local electrical and
construction codes and regulations.
CAUTIONS

INSTALLATION INSTRUCTIONS
DL-FLEX2-NPX-TW
www.jescolighting.com
Instruction sheet subject to
change without prior notice
4/8/2022
Page 2 of 6
INSTALLATION
1. Configure design and layout of the system before attempting to install this product. Do not exceed the maximum
operating temperature of 122 degrees Fahrenheit. For dry or damp location use only.
Product
Max Run Length
DL-FLEX2-NPX-TW
16’
Note –For dimming applications refer to the spec sheet and the wiring diagrams below.
2. Turn off electricity
Before beginning installation, switch circuit breaker off or remove fuse.
3. Determine location to install components
Refer to WIRING DIAGRAMS
4. Prepare LED flexible tape for installation
Cut the LED strip to desired lengths as required for your application. Only cut the LED strips along the designated
cut line as shown. Cutting anywhere else will damage the LED light strip.
5. Optional – Assemble Crystal Connectors
See CRYSTAL CONNECTOR INSTRUCTIONS on page 6 and 7.
6. Mount the LED Flexible tape
Clean the mounting surface. Remove backing on the flexible tape to expose adhesive (ensure ambient temperature
is minimum 50°F for proper adhesion). Carefully press the flexible tape to the mounting surface. Avoid pressing on
the yellow phosphor or any electrical component, avoid using excessive force and avoid pinching. When bending
tighter than a 1” radius, do so only at the cut mark.

INSTALLATION INSTRUCTIONS
DL-FLEX2-NPX-TW
www.jescolighting.com
Instruction sheet subject to
change without prior notice
4/8/2022
Page 3 of 6
a) Optional – Install into Aluminum Channel
(Channels are field-cuttable)
Install the mounting clips to the mounting surface (1 clip per 24 inches is recommended). Clean the channel
surface. Remove backing on the flexible tape to expose adhesive. Carefully press the flexible tape into the
aluminum channel. Avoid pressing on the LEDs or any electrical component, avoid using excessive force and
avoid pinching. Insert the channel into the mounting clips.
b) Optional – Install Aluminum Channel Lens Cover
After inserting the flexible tape, align the channel cover with the aluminum channel. Carefully press the lens into
the aluminum channel. The lens will snap into place. Do not use excessive force.
c) Optional – Insert Aluminum Channel End Caps for finished look. Live end cap for power feed end and dead end
cap finishes for the other end.

INSTALLATION INSTRUCTIONS
DL-FLEX2-NPX-TW
www.jescolighting.com
Instruction sheet subject to
change without prior notice
4/8/2022
Page 4 of 6
7. Connect Power Supply
Using the power connector, connect to the power supply.. Ensure the wires are connected correctly by observing the
polarity.
NOTE: Each reel comes with input hardwire power connectors pre-assembled to one end of the reel.
WIRING DIAGRAMS
NOTE: Vertical mounting recommended for LED drivers
NOTE: Leave at least 1” spacing between LED drivers to allow for airflow to prevent heat buildup
NOTE: Leave the power connector with enough slack to account for expansion and contraction due to tempearature changes
RADIO FREQUENCY – With LC-RF-400-RCV and LC-RF-400H-RGB/LC-RF-410W-RGB
DMX

INSTALLATION INSTRUCTIONS
DL-FLEX2-NPX-TW
www.jescolighting.com
Instruction sheet subject to
change without prior notice
4/8/2022
Page 5 of 6
CRYSTAL CONNECTOR INSTRUCTIONS:
INSTALLATION INSTRUCTIONS FOR POWER FEED OR CONNECTING CABLE
1. Peel back about ½” of the double-sided adhesive cover at the back of
the LED strip. Then push the strip into the gap, making sure that the
polarity matches. Red is + and Black is -.
2. Make sure the LED strip is pushed all the way in and the edge of the
LED strip reach the inner wall of the connector.
3. Use tools to clamp down on the conductors protruding from the top of
the connector so that the pins on the conductor pierce the copper pads on
the LED strip.
4. Once the conductors are flush with the top of the connector, the
connection is complete.

INSTALLATION INSTRUCTIONS
DL-FLEX2-NPX-TW
www.jescolighting.com
Instruction sheet subject to
change without prior notice
4/8/2022
Page 6 of 6
INSTALLATION INSTRUCTIONS FOR TAPE-TO-TAPE CONNECTOR
1. Peel back about ½” of the double-sided adhesive cover at the back of
both the LED strips. Then push both strips into the gap, making sure that
the polarity matches.
2. Make sure both edges meet at the middle on the connector.
3. Use tools to clamp down on the conductors protruding from the top of
the connector so that the pins on the conductor pierce the copper pads on
the LED strip.
4. Once the conductors are flush with the top of the connector, the
connection is complete.
