Sunny SNP Series User manual

LED AC Power Will turn on indicating that the
unit is receiving power.
LED Charge/Fully Charge will indicate if the battery is charging.
Switch On/O Use to turn the lamp on or o
(while the unit is not plugged in
Switch Test Use to test the unit
(while there is no power outages)
1. Using independent switches, the lamps are able to be turned on and o separately.
During power outages only 1 lamp can be used to double the operational time of the
battery.
2. Using high quality LEDs with a lifetime of over 50,000 hours, providing bright and
constant illimitation throughout its operation.
3. Equipped with a battery checker circuit to prevent the battery from running down
completely and extending its life.
4. The casing is made from 1 mm thick Electro-Galvanized steel coated with Epoxy
Powder and Stove Enamel making it highly resistant to rust.
USER MANUAL
Self-Contained Emergency Light SNP Series
Status Indicators and Testing Buttons
Features

1. Check if the electric socket is providing 220Vac power. If not please make sure it does
before moving on to the next step.
2. Install or hang the unit in a location where emergency illumination is required.
Make sure the unit is installed securely to prevent any possible accidents.
3. Turn the ON/OFF switch to the on position for both lamps. Both lamps should turn on.
4. Plug the unit into the electric socket which provides a 220VAC 50Hz electrical supply,
the lamps should turn o automatically.
5. After receiving a 220VAC power supply there should be the following indications.
5.1 LED AC Power will turn on indicating the unit is receiving a 220Vac power supply.
5.2 LED Charge should turn on indicating that the battery is charging.
5.3 LED FULL CHARGE will turn o when the battery is fully charged.
6. To test the operation of the unit.
6.1 Pressing the TEST switch on the unit the emergency lamps should turn on.
The lamps should turn o when the switch is released.
7. During power outages the emergency lamps will turn on automatically.
When power returns the lamps will automatically turn o and begin recharging its
battery.
NOTE : When the lamps turn on automatically, they can be switched o to conserve
battery power by using the O switch. To turn the lamp on the On switches on the unit
can be used (there are independent switches for each lamp to turn them on separately,
only one lamp can be used to extend the runtime of the battery).
1. The unit should be installed indoors away from direct sunlight and rain or moisture.
2. The unit should be stored in temperatures under 25 Degree Celsius and the battery
should be charged every 3 months to maintain its operational life.
Installation and Operation
Important Note on Using the Unit

SIDE VIEWBACK VIEWFRONT VIEW
130
L 210
H 220
H 220
W 70
L 210
H 220
- Power not getting to the unit
after plugging in.
The LED AC light does not
turn on.
- The power socket might not have
any power.
- The plug or socket is loose.
- The AC.220V fuse is blown.
- Check the 220VAC power supply.
- Check the plug and socket.
- Contact customer service.
- Emergency light does not
turn on after the power went
out.
- Emergency light only turns
on for a short time after the
power went out.
- The battery is not fully charged.
- The battery has degraded.
- Fully charge the battery.
- Contact customer service to
replace the battery
ProblemCause What to do
-The unit is not plugged in.
-Battery terminal not connected
-The lamp is faulty.
-The circuit’s wiring is loose.
-The DC fuse is blown.
-Check that the unit is plugged in.
- Please connect the battery
terminals.
-Contact customer service.
-Contact customer service.
-Contact customer service.
Initial Trouble Shooting
Dimension (mm)

For any further questions about your product
please feel free to contact SUNNY’s customer
service department.
Tel. [phone]
E-mail: [email protected]
1. The product will only be under warranty if the customer fills in the “warranty card”
and return the “return part” to the company within 7 days of purchasing the product.
If this is not done within the specified time then the warranty will be considered void.
2. The warranty only covers the unit’s internal parts for the duration specified by the
company counting from the date of purchase.
3. Please show the warranty card every time when contacting our service department
or the dealer you purchased the unit from.
4. The warranty will be considered void in the following cases.
The unit has been used outside of its intended use specified in the manual.
The unit has been used with equipment that does not meet the specifications
specified within the manual.
The unit has been damaged from impact, for example parts are dented, scratched
missing or distorted.
The unit has been modified or repaired by people not ocially certified by our
company.
The Sticker Warranty Void has been removed or torn.
The unit is damaged from negligence or incompetent use, for example, the
battery is swollen, the batter has been overcharged, the battery has been
damaged from quick charging, the battery has been short-circuited, the battery’s
charged has been completely drained.
The unit has been stored improperly, for example, it was exposed to moisture
causing rust and damage to the internal circuitry.
Damaged was caused by a malfunction in the AC power supply.
Damage from natural disaster such as fire, moisture, submersion in liquids,
chemical damage or from unavoidable circumstances.
Damage from animals or insects.
Note : Please read the manual carefully before installation and operation to understand
how to properly operate the unit.
Terms for Warranty and Service
IsOn Import-Export Co., Ltd.
2915-2917 Ladprao Road, Klongjan,
Bangkapi, Bangkok 10240
