Jesco MAGDOS 20-100 Instruction Manual

Phone: [phone] www.jescoamerica.com Fax: [phone]
Operation & MaintOperation & Maint Operation & MaintOperation & Maint
Operation & Maintenance Insenance Ins
enance Insenance Ins
enance Instructionstructions
tructionstructions
tructions MAGDOS DEDX
Contents
1. General Description
2. System Design Guidelines
3. Safety Precautions
4. Installation (General and Electrical)
5. Startup and Operation
6. Maintenance
7. Troubleshooting
8. Parts List
Thank you for purchasing the MAGDOS DE/Thank you for purchasing the MAGDOS DE/
Thank you for purchasing the MAGDOS DE/Thank you for purchasing the MAGDOS DE/
Thank you for purchasing the MAGDOS DE/
DX diaphragm metering pump.DX diaphragm metering pump.
DX diaphragm metering pump.DX diaphragm metering pump.
DX diaphragm metering pump.
For optimum performance, please read all
Operation and Maintenance Instructions before
actual installation of this product.
Please check your shipment. If any of the
equipment you received shows signs of damage,
contact the shipping carrier immediately. Next,
please unpack the pump slowly, taking care that no
small parts are accidentally discarded. Compare
the parts supplied with the enclosed packing list
and your original purchase order.
If there are any discrepancies, contact your local
Jesco America representative immediately.
CAUTIONCAUTION
CAUTIONCAUTION
CAUTION: Metering pumps and their accessories
are often used with potentially dangerous
chemicals. Please follow all safety precautions for
any chemicals processed through your system.
If there is ever a question about appropriate
installation or use of a product, contact the
manufacturer before proceeding.
These pages contain guidelines for systemThese pages contain guidelines for system
These pages contain guidelines for systemThese pages contain guidelines for system
These pages contain guidelines for system
design and general safdesign and general saf
design and general safdesign and general saf
design and general safee
ee
etyty
tyty
ty. It is essential t. It is essential t
. It is essential t. It is essential t
. It is essential too
oo
o
review allreview all
review allreview all
review all Operation and MaintenanceOperation and Maintenance
Operation and MaintenanceOperation and Maintenance
Operation and Maintenance
InstructionsInstructions
InstructionsInstructions
Instructions before proceeding withbefore proceeding with
before proceeding withbefore proceeding with
before proceeding with
installation of this equipment.installation of this equipment.
installation of this equipment.installation of this equipment.
installation of this equipment.
1. General Description
The MAGDOS DE/DX is an intelligent solenoid driven
metering pump that combines digital technology
and state-of-the-art microprocessors with high
quality mechanics. The MAGDOS series is flexible
and versatile in the area of external control. Its
functionality incorporates the latest requirements in
metering technology.
The MAGDOS is available in two versions, the DE
and the DX. Both versions include microprocessor
control. Two chassis sizes of the MAGDOS are
available. The smaller chassis can be used for
capacities ranging from 0 to 2.8 gph and the larger
chassis for capacities ranging from 0 to 27.7 gph.
Pressure ranges are available to 150 psi,
depending on capacity.
2. System Design Guidelines
Before installing the MAGDOS DE/DX into a new or
existing system, Lutz-JESCO America Corporation
recommends careful review of your system’s design
and layout. It is essential that all local rules, codes
and regulations are followed in the design and
installation of chemical feed equipment. It is also
important that the system meets the technical
demands required, such as flow rates and
pressures. Many factors must be taken into
consideration, including process fluid
specifications, material compatibilities,
temperature, chemical handling, electrical wiring,
line losses and many more.
Ambient temperatures exceeding 104oF are not
permitted. Radiant heat of surrounding equipment
must be kept in acceptable limits to allow the
pump to sufficiently dissipate its own heat.
MAGDOS
Sizes 20-100
MAGDOS
Sizes 01-12

March 2004
Phone: [phone] www.jescoamerica.com Fax: [phone] SD 6.2
Operation & MaintOperation & Maint Operation & MaintOperation & Maint
Operation & Maintenance Insenance Ins
enance Insenance Ins
enance Instructionstructions
tructionstructions
tructions MAGDOS DEDX
Exposure to direct sunlight must be avoided. If the
pump is installed outside, provide an enclosure to
protect it against the weather. With metering pump
systems, particular attention must be paid to the
piping system. Refer to the System Design Guide
for more detailed information. (If in need of a
System Design Guide, contact Jesco America
Corporation).
Both the system designer and the operatorBoth the system designer and the operator
Both the system designer and the operatorBoth the system designer and the operator
Both the system designer and the operator
are responsible for ensuring that the entireare responsible for ensuring that the entire
are responsible for ensuring that the entireare responsible for ensuring that the entire
are responsible for ensuring that the entire
plant is constructed to preventplant is constructed to prevent
plant is constructed to preventplant is constructed to prevent
plant is constructed to prevent
unreasonable damage to plant equipmentunreasonable damage to plant equipment
unreasonable damage to plant equipmentunreasonable damage to plant equipment
unreasonable damage to plant equipment
or building resulting from leakage oror building resulting from leakage or
or building resulting from leakage oror building resulting from leakage or
or building resulting from leakage or
technical failure.technical failure.
technical failure.technical failure.
technical failure.
It is especially important that chemical plants be
designed to ensure the safety of maintenance
people and operators. We recommend installing
relief valves, splashguards, containment tanks,
and leakage probes with alarm relays to aid this
effort.
MAGDOS DE/DX pumps with integrated level
control function are equipped with a short-circuit
jack plug which must be removed before
connecting a level control by means of a jack plug.
A weather tight cable is available if using a level
control to keep the NEMA 4x protection class.
Wiring of the MAGDOS metering pump must be
carried out by a specialist according to the local
regulations. Normally the MAGDOS is connected
with a grounded plug. Please see the MAGDOS DE/
DX Specification Sheet for all electrical data.
Mounting the metering pump directly on a water
meter may result in noise level amplification. In
this case, we recommend that you mount the
pump on separate wall brackets which, for the
same reason, should be fixed to outer walls
instead of interior walls with adjacent occupied
rooms. It is also possible to mount the pump
directly on the supply tank.
Do not lay signal cables of water meters or
0(4)...20 mA controls parallel to high-voltage
current or power supply lines. Supply and signal
lines must be laid in separate channels. In the
case of junctions, a 90Þ angle is required. If the
water meter control cable is more than 6 feet long,
it must be shielded. To avoid incorrect metering
after the process is finished, provide an electric
and hydraulic interlocking system.
NOTE:NOTE:
NOTE:NOTE:
NOTE: The MAGDOS metering pumps are notThe MAGDOS metering pumps are not
The MAGDOS metering pumps are notThe MAGDOS metering pumps are not
The MAGDOS metering pumps are not
suited for use in explosive environments.suited for use in explosive environments.
suited for use in explosive environments.suited for use in explosive environments.
suited for use in explosive environments.
3. Safety Precautions
The diaphragm metering pump is designed to
pump various liquids into pressurized systems. By
nature, the application of these pumps may
present circumstances under which personal
hazards can exist. All personnel who may have
occasion to install, operate, or maintain these
pumps should be provided with the opportunity to
read this instruction manual and be familiar with
its contents. Awareness of potential hazards can
prevent accidents and injury.
Danger from Liquids HandledDanger from Liquids Handled
Danger from Liquids HandledDanger from Liquids Handled
Danger from Liquids Handled
All systems containing liquid and/or air under
pressure present the potential for unexpected
discharge of liquid in a violent manner. In
operation and servicing of the pump, all parts of
the pump and attached piping which contain liquid
should be treated cautiously, until it is known with
certainty that they have been depressurized and
drained.
Danger from Electrical HazardDanger from Electrical Hazard
Danger from Electrical HazardDanger from Electrical Hazard
Danger from Electrical Hazard
Since these pumps include electric components,
the hazard of electrical shock can exist.
Installation and wiring of electrical components
should be in accordance with the applicable
codes.
Operational HazardsOperational Hazards
Operational HazardsOperational Hazards
Operational Hazards
To avoid personal injury, please adhere to the
following guidelines:
1. Do not operate the pump if electrical compo-
nent enclosures are not in place.
2. When venting cylinders or piping during startup,
liquid will be discharged under pressure. The
use of a pressure relief valve back to the
supply tank is highly recommended. Suitable
caution should be taken to avoid contact with
the liquid and to avoid spillage or spraying of
liquid.
3. Clean up any leaked or spilled liquid immedi-
ately.
SafetySafety
SafetySafety
Safety
1. Before operating pump and accessories or
attempting to service, become familiar with
the contents of this instruction manual.
2. Observe all precautions established by plant
safety procedures.

March 2004 Phone: [phone] www.jescoamerica.com Fax: [phone]
PP 6.3SD 6.3
Operation & MaintOperation & Maint Operation & MaintOperation & Maint
Operation & Maintenance Insenance Ins
enance Insenance Ins
enance Instructionstructions
tructionstructions
tructions MAGDOS DEDX
3. Observe all chemical handling instructions
provided by the chemical supplier and/or plant
regulations.
4. Do not operate pump with closed valves in
suction and/or discharge lines.
5. Do not paint over or remove nameplates, labels,
or tags.
6. In disassembly of pump, precautions should be
taken for the possibility that a diaphragm
rupture may have allowed pumped liquid to
enter the drive system.
7. If a pump is to be used for other than original
service, first ascertain that pump is suitable for
new conditions (pressure and compatibility with
liquid to be pumped).
8. Establishment of and adherence to a regular
maintenance program can prevent problems by
early detection of unusual conditions (e.g.
unusual noise, overheating, and wetness
indicating leakage).
4. Installation
The accuracy and reliability of a metering pump
system depends on proper installation of each
component. All considerations of sound hydraulic
practice, including the elimination of air and foreign
matter, accurate and reliable seating of check
valves, proper size and length of piping, liquid
vapor pressure, viscosity, and temperature may
mean the difference between a successful or
unsuccessful installation. The application of basic
hydraulic principles during planning, installation
and operation is essential. Good suction conditions
will prevent a common cause of premature
diaphragm failures. Each installation should be
designed and built paying careful attention to all
instructions regarding handling of corrosive, toxic or
hazardous chemicals. It is of utmost importance
that all safety procedures established by the
owners and manufacturers be followed during
installation, operation and maintenance phases.
LocationLocation
LocationLocation
Location
The preferred location of a metering pump system
is indoors. Although systems can be installed
outdoors, manufacturer’s temperature ratings and
recommendations must be followed. System fluids
are subject to viscosity increase when
temperatures fall. Drive units are subject to
overheating when installed in direct sunlight or an
area with high ambient temperatures. If a system
must be installed outdoors, it should be sheltered
from the elements with heating or cooling systems
as needed. Proper installation indoors or out
should allow sufficient room for operators and
maintenance personnel to access each component
for adjustments and servicing.
5. Start Up and Operation
AA
AA
ATTENTION:TTENTION:
TTENTION:TTENTION:
TTENTION: AA
AA
Adjusdjus
djusdjus
djust st s
t st s
t strtr
trtr
trokok
okok
oke length only whilee length only while
e length only whilee length only while
e length only while
pump is running.pump is running.
pump is running.pump is running.
pump is running.
1. For first startup, set pump to maximum stroke
speed and stroke length and allow to prime.
For this purpose, it is advisable to set both
stroke adjustments to 100%. If the pump
doesn’t prime, remove discharge check valve
and pour water or chemical (if harmless) into
head. Mount the discharge check valve and
allow to prime again.
2. If a venting aid is integrated in the metering
head or is available as separate unit, open it
and wait until liquid escapes. Then close it
again. In the case of effervescent liquids, allow
the liquid to escape permanently (approxi-

March 2004
Phone: [phone] www.jescoamerica.com Fax: [phone] SD 6.4
mately 1 drop for 1-3 strokes).
3. When proper operation is achieved, set stroke
length to required output and lock adjusting
knob. Refer to the calibration table on the side
of pump to get the stroke length setting for a
selected output (ml/stroke). The back
pressure influences are taken into consider-
ation in the table, and intermediate values
must be interpolated. Depending on the
installation and the chemicals used, these
values may differ and must be checked
under operating conditions. See Calibration
Table below.
4. In the case of externally actuated pumps (e.g.
by water meters), set pump to “external.”
Initiate the water flow by opening a water
valve and check pump pulse rate. The
manufacturer of the metering equipment is
not responsible for damages due to excessive
or low flow rates resulting from faulty pump
settings or incorrect and insufficient installa-
tion of peripheral fittings.
C. Analog signal 0/4-20mA (DXC. Analog signal 0/4-20mA (DX
C. Analog signal 0/4-20mA (DXC. Analog signal 0/4-20mA (DX
C. Analog signal 0/4-20mA (DX
only)only)
only)only)
only)
To control the pump by analog signal, turn the
selector switch to either 0...20 or 4...20 positions.
The linearity of signal conversion into stroke
frequency is +/- 3%. If the signal source is not
isolated, it must be ensured that the signal line
does not come into contact with ground.
NoNo
NoNo
Nott
tt
tee
ee
e: To avoid accidental metering after the
process is finished, provide an electric or hydraulic
interlocking system.
Supply TSupply T
Supply TSupply T
Supply Tank Leank Le
ank Leank Le
ank Levv
vv
vel Contrel Contr
el Contrel Contr
el Controlol
olol
ol
To prevent the pump from being without chemical,
due to low level supply tank , a suction line level
switch with or without alarm signaling can
beconnected to the 3.5 mm input jack. The pump
is provided with a dummy plug that has to be
removedto connect level switch.
External ControlExternal Control
External ControlExternal Control
External Control
A. Contact (pulse)A. Contact (pulse)
A. Contact (pulse)A. Contact (pulse)
A. Contact (pulse)
In order to protect the pump against overheating,
the maximum input frequency is limited to 100/
70 pulses/minute; therefore, input frequency is
higher, each third or fourth metering stroke is not
carried out. Therefore, external pulse transmitters
should be selected so that the pump is controlled
with a maximum of 100/70 strokes/minute,
depending on model selected, otherwise use the
pulse division feature (DX only).
B. Contact (pulse) multiplication/B. Contact (pulse) multiplication/
B. Contact (pulse) multiplication/B. Contact (pulse) multiplication/
B. Contact (pulse) multiplication/
divisiondivision
divisiondivision
division (DX version only)(DX version only)
(DX version only)(DX version only)
(DX version only)
Input pulses can be multiplied or divided by setting
the selector switch correspondingly.
1. Standard setting is a ratio of 1:1
(one contact, one stroke)
2. Pulse Multiplication
e.g. Setting to 8
- one incoming input pulse results in 8 meter-
ing strokes
3. Pulse Division
e.g. Setting to 16
- one metering stroke is carried out after 16
input control pulses
NoteNote
NoteNote
Note: When setting pulse division to 32, the
maximum stroke frequency is reduced to 70
strokes/minute; with divisor 64, it is reduced to 36
strokes/minute.
Warning Alarm RelayWarning Alarm Relay
Warning Alarm RelayWarning Alarm Relay
Warning Alarm Relay
With the warning alarm relay (voltage-free output
Operation & MaintOperation & Maint Operation & MaintOperation & Maint
Operation & Maintenance Insenance Ins
enance Insenance Ins
enance Instructionstructions
tructionstructions
tructions MAGDOS DEDX

March 2004 Phone: [phone] www.jescoamerica.com Fax: [phone]
PP 6.5SD 6.5
contact), the following alarm states can be
transmitted.
• “Tank Empty” if a simple level switch is con-
nected. Pump stops.
• “Tank Almost Empty” if a level switch w/alarm
signaling is connected. In this case, “Tank
Empty” can not be indicated. Pump continues
metering.
• Alarm activates when the analog signal is less
than 4 mA. (e.g. cable breakage).
MAGDOS DXMAGDOS DX
MAGDOS DXMAGDOS DX
MAGDOS DX
1. Power supply cable, 115 VAC, 5.5 feet, with
grounded plug.
2. Cable for warning alarm relay, 4 feet, optional.
3. 3.5 mm jack socket for level probe connection;
can be used by 2-pin plug for simple low level
indication or by 3-pin plug for low level indica-
tion with alarm signal.
4a. Cable or connector socket for pulse input.
4b. Cable or connector socket for pulse and analog
signal input.
5. Stroke length knob for metering capacity.
6. Stroke length knob locking screw.
7. Speed frequency adjustment with changeover
switch for internal/ external control.
8. LCD display. (DX only)
9a. Red LED
• Blinks slowly in the case of alarm signaling.
• Lights permanently if the tank is empty. Pump
is then stopped automatically.
9b. Red LED on DX model
• Like 9a, plus fast blinking if, in the case of
4...20 mA analog signal control, the input signal
is less than 4 mA (e.g. due to a cable break-
age).
• Blinks slowly if selector switch (12) is set to
“0” (pump is not metering).
10. Green LED
• Lights when power supply voltage is applied
and disrupted for a short time during the
metering stroke. Blinks during the metering
stroke.
11. Calibration table (on side of pump housing).
12. Selector switch for external control
• Pulse 1:1
• Pulse multiplication or division by factors of
2, 4, 8, 16, 32, or 64
• Current input 0...20 mA or 4...20 mA
• Pump stop “0”
Operation & MaintOperation & Maint Operation & MaintOperation & Maint
Operation & Maintenance Insenance Ins
enance Insenance Ins
enance Instructionstructions
tructionstructions
tructions MAGDOS DEDX

March 2004
Phone: [phone] www.jescoamerica.com Fax: [phone] SD 6.6
Digital Display (DX Only)Digital Display (DX Only)
Digital Display (DX Only)Digital Display (DX Only)
Digital Display (DX Only)
The display indicates two types of information.
First, it reflects the number of strokes per minute.
Second, if an error occurs in the metering system,
a specific error message will be displayed.
6. Maintenance
GeneralGeneral
GeneralGeneral
General
1. After the first several hours of operation, turn
off the pump and tighten all hardware and
fittings. Retighten as needed to prevent
leakage. Do not overtighten plastic fittings.
2. Clean exterior of pump as needed with mild
soap liquid.
3. Clean and inspect check valves and dia-
phragms annually. Replace if needed.
After the First 80 Hours of OperationAfter the First 80 Hours of Operation
After the First 80 Hours of OperationAfter the First 80 Hours of Operation
After the First 80 Hours of Operation
1. Clean and inspect check valves and dia-
phragm. Replace if damaged. See ReplacingReplacing
ReplacingReplacing
Replacing
the Diaphragmthe Diaphragm
the Diaphragmthe Diaphragm
the Diaphragm procedure and disassembly
of check valves.
3. Check pump wetted end for leaks. Retighten
connections and fasteners as necessary.
Replacing the DiaphragmReplacing the Diaphragm
Replacing the DiaphragmReplacing the Diaphragm
Replacing the Diaphragm
1. Adjust stroke length knob to 0%.
2. Shut off pump and close shutoff valves in the
suction and discharge lines. Relieve pressure.
Drain suction and discharge lines if possible.
Caution: Pressure must be relievedCaution: Pressure must be relieved
Caution: Pressure must be relievedCaution: Pressure must be relieved
Caution: Pressure must be relieved
before proceeding. If pressure is notbefore proceeding. If pressure is not
before proceeding. If pressure is notbefore proceeding. If pressure is not
before proceeding. If pressure is not
relieved, dangerous chemical spray mayrelieved, dangerous chemical spray may
relieved, dangerous chemical spray mayrelieved, dangerous chemical spray may
relieved, dangerous chemical spray may
result.result.
result.result.
result.
3. Disconnect union nuts from check valves.
4. Remove pump head mounting bolts and pull
pump head/check valve assembly away from
pump. Note orientation of check valves (flow
arrows must point up). The head must not be
reinstalled upside down.
5. Turn diaphragm counterclockwise to unscrew it
from pump push rod. Note orientation of
diaphragm support plate behind diaphragm.
6. Install the support plate onto diaphragm. Install
new diaphragm by screwing it clock-wise into
pump push rod.
7. Clean inside of pump head, using appropriate
cleaning fluid compatible with materials of
construction and metered chemical.
8. Reinstall pump head, noting orientation of
check valves. Tighten head bolts evenly using
an alternating crisscross pattern.
9. Reassemble suction and discharge lines, n
shutoff valves and start pump according to the
Start Up and Operation InstructionsStart Up and Operation Instructions
Start Up and Operation InstructionsStart Up and Operation Instructions
Start Up and Operation Instructions,
Section 5, page 1.4.
10. Check for leaks and tighten accordingly.
Operation & MaintOperation & Maint Operation & MaintOperation & Maint
Operation & Maintenance Insenance Ins
enance Insenance Ins
enance Instructionstructions
tructionstructions
tructions MAGDOS DEDX
Normal Operation
Display Meaning
80
Stroke frequency of 80 strokes per
minute while operating in either
internal or external signal control
1.1 Operating condition: External
pulse control with contact ratio 1:1
1.16
Operating condition: External
pulse control with pulse
multiplication factor 16
8.1
Operating condition: External
pulse control with pulse division
divisor 8
Error Indication
Display Meaning
E-L "Tank Empty" message
I-E Loss of analog signal (i.e. cable
breakage)
OFL Input signal greater than 20 mA
with 0-20 or 4-20 mA control
OFF Selector switch is set to "0", pump
does not operate

March 2004 Phone: [phone] www.jescoamerica.com Fax: [phone]
PP 6.7SD 6.7
Disassembly & Cleaning of CheckDisassembly & Cleaning of Check
Disassembly & Cleaning of CheckDisassembly & Cleaning of Check
Disassembly & Cleaning of Check
VV
VV
Valvalv
alvalv
alveses
eses
es
Please refer to drawings below.
1. Adjust stroke length knob to 0%.
2. Shut off pump and close shutoff valves in the
suction and discharge lines. Relieve system
pressure. Drain suction and discharge lines if
possible.
Caution:Caution:
Caution:Caution:
Caution: Pressure must be relievedPressure must be relieved
Pressure must be relievedPressure must be relieved
Pressure must be relieved
before proceeding. If pressure is notbefore proceeding. If pressure is not
before proceeding. If pressure is notbefore proceeding. If pressure is not
before proceeding. If pressure is not
relieved, dangerous chemical spray mayrelieved, dangerous chemical spray may
relieved, dangerous chemical spray mayrelieved, dangerous chemical spray may
relieved, dangerous chemical spray may
result.result.
result.result.
result.
3. Disconnect suction and discharge connections
from pump head.
4. Refer to the appropriate check valve part
drawing. Remove slotted locking screw by
turning counterclockwise using a large flat
bladed screwdriver. Using a tool such as a drift
punch, carefully push all the internal compo-
nents out of the check valve body.
Operation & MaintOperation & Maint Operation & MaintOperation & Maint
Operation & Maintenance Insenance Ins
enance Insenance Ins
enance Instructionstructions
tructionstructions
tructions MAGDOS DEDX
5. Inspect balls, seats and ball guides for wear. If
excessive wear is noted, replace parts. Clean
all parts using an appropriate cleaning fluid.
6. Replace all seals.
7. Reassemble check valves, noting orientation
of the internal parts. Replace locking screw.
8. Test check valves for leaks by placing on a flat
surface with check valve seats down as shown
in the parts list drawing. Pour a small amount
of water into the top of each check valve. If
water leaks out of the bottom of the check
valve, disassemble the check valve and clean
or replace the balls and seats.
9. Reassemble check valves to pump head after
installing new seals between check valves and
head. Ensure that check valves are oriented
correctly in the pump head.
10. Reassemble suction and discharge lines, open
shutoff valves and start pump according to
Start Up and Operation Instructions. See page
1.4. Do not overtighten plastic fittings.

March 2004
Phone: [phone] www.jescoamerica.com Fax: [phone] SD 6.8
Operation & MaintOperation & Maint Operation & MaintOperation & Maint
Operation & Maintenance Insenance Ins
enance Insenance Ins
enance Instructionstructions
tructionstructions
tructions MAGDOS DEDX
Calibration of Stroke Length SettingCalibration of Stroke Length Setting
Calibration of Stroke Length SettingCalibration of Stroke Length Setting
Calibration of Stroke Length Setting
To avoid excessive metering, the discharge line
must be returned to the supply tank during setting
(if necessary). Refer to calibration tag on side of
pump to calibrate pump to system pressure.
Precise calibration will ensure proper chemical
dosing as specifically related to variables of each
pumping system.
1. With pump operating, loosen the fastening
screw and turn the stroke length adjustment
knob counterclockwise until the pump no
longer delivers or, in the case of no pressure
delivery, the flow rate has reached the mini-
mum.
2. If zero delivery could not be attained because
the knob reached the stop position:
- Loosen and remove locking screw and knob.
- Turn knob to right and place back on pump
with loose locking screw.
- Turn knob to left until pump no longer delivers
fluid.
- Turn pump off and by removing locking screw
and knob, orient knob to zero of dial indicator;
fasten with locking screw.
3. Run pump according to a setting on the
calibration table attached to the pump. If there
is a major discrepancy, correct the knob
position.
Drive SolenoidsDrive Solenoids
Drive SolenoidsDrive Solenoids
Drive Solenoids
Depending on the pump version, the solenoid size
differs. The following table shows the coil
resistance at 68Þ F (20Þ C) room temperature.
With perfect coils, the resistance tolerance should
not exceed +/- 5%. If the resistance is substantially
lower, there is a short in the coil. If the resistance
is higher, the coil is fused or the wire is broken.
Solenoid in
Pump Version
Resistance [액] +/-
5% between A-B at
115V 230V
DE/DX 01-2 30 113
DE/DX 4-12 30 91
DE/DX 20-100 14 51

March 2004 Phone: [phone] www.jescoamerica.com Fax: [phone]
PP 6.9SD 6.9
Operation & MaintOperation & Maint Operation & MaintOperation & Maint
Operation & Maintenance Insenance Ins
enance Insenance Ins
enance Instructionstructions
tructionstructions
tructions MAGDOS DEDX
Problem Possible Cause Recommended Action
Pump fails to
inject chemical.
System shut off valves are closed Open valves, prime pump.
Check valves are leaking. Inspect connections. Clean valves and reinstall or
replace. (See Start Up, page 1.4.)
Suction filter, foot valve or suction line
is leaking or blocked. Clean and seal suction line.
Check valves are incorrectly installed.
Reassemble check valves. Ensure that the balls for
the suction and discharge valves are correctly
positioned above the check valve seat (See
Maintenance Section, page 1.7).
Suction lift is too high. Install pump at lower position or install a priming aid.
Viscosity is too high.
If viscosity reading is between 100 and 400 cps,
install spring-loaded valves. Enlarge suction line inner
diameter. Use special wetted head. (Consult factory)
Pump is not
stroking.
LEDs are off. Check power supply line.
Pump is set to zero stroke. Correctly adjust pump stroke length.
Low level jack is open. Insert level probe plug or replace dummy plug.
Diaphragm return spring is broken. Replace spring.
Solenoid is defective. Check coil resistance and isolation, replace solenoid if
required.
Red low level
liquid indication
LED is blinking.
Supply tank level is low. Refill supply tank.
Red low level
liquid indication
LED is on.
Supply tank empty; level control or
dummy plug incorrectly inserted.
Fill supply tank or check suction line float. Check
dummy plug or cable connection.
Pump is
experiencing
frequent
diaphragm
failures.
Back pressure at discharge connection
is too high.
Check system pressure. Possible blocked injection
nozzle. Install pulsation dampener to even out flow.
There is sediment in metering head. Flush metering head. Install screen on foot valve.
Diaphragm was not properly tightened
into diaphragm rod.
Tighten diaphragm. Support plate must then be
positioned between diaphragm and diaphragm rod.
No diaphragm support plate.
Replace diaphragm with support plate.When
replacing diaphragm, check if deflector plate or
diaphragm rod have been corroded by process fluid.
Pump is
delivering too
much chemical.
Stroke knob shifted. Recalibrate knob (See Maintenance Section, page
1.7).
Stroke frequency is too high. Reduce frequency.
Suction pressure too high (pump
siphoning). Install back pressure valve in discharge line.
7. Troubleshooting

March 2004
Phone: [phone] www.jescoamerica.com Fax: [phone] SD 6.10
PP PP
Parar
arar
arts Lists Lis
ts Lists Lis
ts Listt
tt
t MAGDOS DEDX
Drive Unit for MAGDOS DE/DX 01-12
Item
No. Description Qty.
Part No.
01 03 07 2 4 8 12
1 Housing 1 27078
2DiaphragmRod 1 32713
3 Pressure Spring 1 29382
4 Locking Screw 4 83613
5 Snap Ring 1 84154
6Washer 1 84144
7 Cable Gland Nut 1 78786
8 Grommet 1 78787
9
Solenoid Assembly 115 VAC 1 32746 32748
Solenoid Assembly 230 VAC 1 32730 32714 32715
10 Solenoid Retaining Screw 2 83514
11 Diaphragm Insert 1 32958 28849 28850 28851 28852
12 Diaphragm 1 81683 81424 81463 81464
13 Support Plate 1 ---- 29313 23892 33897
14 Deflector Plate 1 22066
15 Dampening Ring 1 81680 78509

March 2004 Phone: [phone] www.jescoamerica.com Fax: [phone]
PP 6.11SD 6.11
PP PP
Parar
arar
arts Lists Lis
ts Lists Lis
ts Listt
tt
t MAGDOS DEDX
Drive Unit for MAGDOS DE/DX 20-100
Item
No. Description Qty. Part No.
20 40 100
1 Diaphragm Flange 1 23913 24024 24041
2 Housing 1 21593
3Solenoid Assembly 115 V 1 79021
Solenoid Assembly 230 V 1 79020
4 Sponge Rubber Cord 1 97593
5Screw 4 83105
6 Socket-Head Cap Screw 4 83668
7Washer 3 84160
8 Toothed Washer 1 84145
9 Dummy Plug 2 78788
10 Foam Rubber 3 81727
11 Armature 1 21738
12 Buffer Ring 1 78511
13 Pressure Spring 1 19617
14 Diaphragm Rod 1 19780 21599 21600
15 Deflector Plate 1 22056 22057 22058
16 Support Plate 1 28977 ---- ----
17 Diaphragm 1 81465 81466 81467
18 Leakage Pipe 1 25174 25190
19 O-Ring 1 80005 80058

March 2004
Phone: [phone] www.jescoamerica.com Fax: [phone] SD 6.12
PP PP
Parar
arar
arts Lists Lis
ts Lists Lis
ts Listt
tt
t MAGDOS DEDX
Control Unit for MAGDOS DE/DX 01-12
(refer to page ______)
Control Unit for MAGDOS DE/DX 20-1000
(refer to page _______)

March 2004 Phone: [phone] www.jescoamerica.com Fax: [phone]
PP 6.13SD 6.13
PP PP
Parar
arar
arts Lists Lis
ts Lists Lis
ts Listt
tt
t MAGDOS DEDX
Control Units for MAGDOS DE/DX 01-12
Item
No. Description Voltage/ Model
Quantity
Required
Part No.
DE DE...S DX...D DX...SD
1Housing 115 VAC 1 34130 34133
230 VAC 1 33873 33876
2 Hou si n g Seal 1 81710
3 Screw 4 83409
4Electronics 115 VAC 1 78663 78664
230 VAC 1 78682 78683 78684
5 Digital Display 1 ---- 78782
6StrokeAdjustment
01, 03 1 34045
07, 2 1 34046
4 1 34047
8, 12 1 34048
7 O-ring 1 80072
8Screw 1 83746
9 Stroke Adjustment Knob 1 32661
10 Speed Adjustment Knob 1 33877
11 Control Cover 1 22247
12 Locking Screw 1 21587
13 Screw 2 83543
14 Screw 2 83653
15 Power Supply Cable 115 VAC 1 79013
230 VAC 1 78997
16 Cable Gland Nut 1 78786
17 Grommet 2 78787
18 Warning Relay Cable 115 VAC 1 ---- 78980 ---- 78980
230 VAC 1 ---- 78800 ---- 78800
19 Jack Socket 1 33878
20 Cover Plug 3 78788
21 Insul ati on Ad ap ter Plu g 2 78916
22 Dummy Plug 1 29115
23 External Control Socket 115 VAC 1 33317
230 VAC 1 78947
24 Gland Nut Pg 9 1 78904
25 Gland Nut Pg 7 1 ---- 78615 ---- 78615
26 Calibration Table
01 1 261001
03 1 261002
07 1 261003
2 1 261004
4 1 261005
8 1 261006
12 1 261007
27 Digital Display (decal) 1 ---- 78665
28 Cable w/plug for External Control 1 32916

March 2004
Phone: [phone] www.jescoamerica.com Fax: [phone] SD 6.14
PP PP
Parar
arar
arts Lists Lis
ts Lists Lis
ts Listt
tt
t MAGDOS DEDX
Control Unit for MAGDOS DE/DX 20-100
Item
No. Description Voltage/ Model
Quantity
Required
Part No.
DE DE...S DX...D DX...SD
1Housing 115 VAC 1 34130 34133
230 VAC 1 33873 33876
2 Hou sin g Seal 1 81710
3 Screw 4 83187
4Electronics 115 VAC 1 79018 79019
230 VAC 1 79016 79017
5 Digital Display 1 ---- 78782
6 Stroke Adjustment 1 34351
7 O-ring 1 80072
8Screw 1 83746
9 Stroke Adjustment Knob 1 32661
10 Speed Adjustment Knob 1 33877
11 Control Cover 1 22247
12 Locking Screw 1 21587
13 Screw 2 83543
14 Screw 2 83653
15 Power Supply Cable 115 VAC 1 79013
230 VAC 1 78997
16 Cable Gland Nut Pg 7 1 78786
17 Grommet Pg 7 1 78787
18 Warning Relay Cable 115 VAC 1 ---- 78980 ---- 78980
230 VAC 1 ---- 78800 ---- 78800
19 Jack Socket 1 33878
20 Cover Plug 230 VAC 3 78788
21 Insulation Adapter Plug 2 78916
22 Dummy Plug 1 29115
23 3-Pole Connection Socket 115 VAC 1 33317
Cinch Plug 230 VAC 1 33879
24 Gland Nut 115 VAC 1 78904
25 Gland Nut Pg 7 1 ---- 78615 ---- 78615
26 Calibration Table
20 1 261416
40 1 261417
100 1 261418
27 Digital Display (decal) 1 ---- 78665
28 Dummy Plug 1 25084
29 Spacer 1 21594
30 Sponge Rubber Cord 1 97113
31 Cable Clamping Ring 1 84188
32 Foam Ru bb er 1 -- -- 81727
33 Socket Head Cap Screw 4 83292
34 Washer 3 84160
35 Toothed Washer 1 84145
36 Cable w/plug for External Control 115 VAC 1 32916
230 VAC 1 25096

March 2004 Phone: [phone] www.jescoamerica.com Fax: [phone]
PP 6.15SD 6.15
PP PP
Parar
arar
arts Lists Lis
ts Lists Lis
ts Listt
tt
t MAGDOS DEDX
Metering Heads
Item
No.
Description Quantity Head Material
Acylic PVC PVC w/ Vent PVDF 216 SS PP
1DiaphragmHousing
01 1 32960 32919 ---- ---- ---- ---
03, 07 1 --- ---- 25960 28114 22527 ---
2, 4 1 --- 21603 25961 28116 21611 ---
8 1 --- 21222 25962 28118 21612 ---
12 1 --- 22399 ---- 28689 21613 ---
20 1 --- 18113 ---- ---- 23912 ---
40 1 --- ---- ---- 99160 22329 22044
100 1 --- ---- ---- ---- 22394 22046
2 Socket Head Cap Screw 01-12 4 83409 83409 83409 83622 ---
3HexHeadScrew 20 4 --- 83110 ---- ---- 83110 ---
40, 100 4 --- ---- ---- 83495 83685 83495
4Washer
01 4 ---- 29778 ---- 84143 ---
20 4 --- 84160 84160 ---- 84160 ---
40, 100 4 --- ---- ---- 84174 84174 84174
5 Pressure Plate 40, 100 1 --- ---- ---- 32903 ---- 18453
6 Venting Screw 03, 07 1 --- ---- 32142 ---- ---- ---
7 Check Valve Ball 03, 07 1 --- ---- 29778 ---- ---- ---
8 Nut 03, 07 1 --- ---- 32143 ---- ---- ---
9 Vent Nipple 03, 07 1 --- ---- 32845 ---- ---- ---
10 O-ring 01 2 ---- ---- ---- ---- ---
11 Complete Diaphragm
Head Kit
01 1 33321 ---- ---- ---- ---
03, 07 1 --- ---- 25188 28115 25189 ---
2, 4 1 --- 23809 13328609 28117 23812 ---
8 1 --- 23810 13328610 28119 23813 ---
12 1 --- 23811 --- 29178 23814 ---
20 1 --- 23909 --- --- 23911 ---
40 1 --- --- --- 261530 23727 23721
100 1 --- --- --- --- 23728 23722

March 2004
Phone: [phone] www.jescoamerica.com Fax: [phone] SD 6.16
PP PP
Parar
arar
arts Lists Lis
ts Lists Lis
ts Listt
tt
t MAGDOS DEDX
Valves for MAGDOS DE/DX 01 & 03
Item
No. Description Material Part No. PVC PVDF 316 SS
1CheckValveBody
PVC 20845 1 ---- ----
PVDF 28108 ---- 1 ----
316 SS 19289 ---- ---- 1
2BallGuide
PVC 29446 2 ---- ----
PVDF 29901 ---- 2 ----
316 SS 28460 ---- ---- 2
3 Valve Ball Ceramic 81550 2 2 2
4 Valve Seat Ceramic 81549 2 2 2
5Gasket Vi ton 81371 1 ---- 1
PTFE 81580 ---- 1 ----
6 O-ring Viton 81384 1 1 1
7LockingScrew
PVC 19299 1 ---- ----
PVDF 28110 ---- 1 ----
316 SS 24031 ---- ---- 1
8 Gasket Viton 81551 1 1 1
9 O-ring Viton 80618 2 2 2
Suction Valve Assembly 29434 33700 28459
Discharge Valve Assembly 29435 33701 28461
Note: Spring-loaded check valves not available for these pump sizes.

March 2004 Phone: [phone] www.jescoamerica.com Fax: [phone]
PP 6.17SD 6.17
PP PP
Parar
arar
arts Lists Lis
ts Lists Lis
ts Listt
tt
t MAGDOS DEDX
Valves for MAGDOS DE/DX 07-12
Item
No.
Descrip-
tion Material Part No.
Suction Discharge
PVC 316 SS PVDF PVC 316 SS PVDF
Seal Material: H=Hypalon, P=PTFE, V=Viton
H P V H P V H P V H P V H P V H P V
1Valve
Body
PVC 20845 1 1 1 -- -- -- -- -- -- 1 1 1 -- -- -- -- -- --
PVDF 28108------------111------------111
316SS19289------111---- -- ------111------
2Ball
Guide
PVC 19294 2 2 2 -- -- -- -- -- -- 2 2 2 -- -- -- -- -- --
PVDF 28109------------222------------222
316SS19293------222---- -- ------222------
3Valve
Ball
Glass 29778 2 2 2 -- -- -- -- -- -- 2 2 2 -- -- -- -- -- --
316SS18044------222---- -- ------222------
PTFE 25247------------222------------222
4Valve
Seat
PVDF 81460222------222222------222
316SS81461------222---- -- ------222------
5Gasket
Viton 81138 -- -- 1 -- -- 1 -- -- 1 -- -- 1 -- -- 1 -- -- 1
PTFE 81580 -- -- -- -- -- -- -- 1 -- -- -- -- -- -- -- -- 1 --
PTFE 81677--1----1----------1----1--------
EPDM 81453 1 -- -- 1 -- -- 1 -- -- 1 -- -- 1 -- -- 1 -- --
6O-ring
EPDM 80754 1 -- -- 1 -- -- 1 -- -- 1 -- -- 1 -- -- 1 -- --
Viton 81384 -- -- 1 -- -- 1 -- -- 1 -- -- 1 -- -- 1 -- -- 1
PTFE 80617 -- 1 -- -- 1 -- -- 1 -- -- 1 -- -- 1 -- -- 1 --
7Locking
Screw
PVC 19299 1 1 1 -- -- -- -- -- -- 1 1 1 -- -- -- -- -- --
PVDF 28110------------111------------111
316SS24031------111---- -- ------111------
9O-ring
Viton 80013 -- -- 2 -- -- 2 -- -- 2 -- -- 2 -- -- 2 -- -- 2
PTFE 80627 -- 2 -- -- 2 -- -- 2 -- -- 2 -- -- 2 -- -- 2 --
EPDM 80755 2 -- -- 2 -- -- 2 -- -- 2 -- -- 2 -- -- 2 -- --
10 Gasket
Viton 81526-- 1----1----1----1----1----1
PTFE 81585 -- 1 -- -- 1 -- -- 1 -- -- 1 -- -- 1 -- -- 1 --
EPDM 81525 1 -- -- 1 -- -- 1 -- -- 1 -- -- 1 -- -- 1 -- --
Complete Valve Assembly
33497 24027 20890 34395 24029 25667 34391 28111 33703* 33498 24028 20891 34396 24030 25668 34392 28112 33704*
*Hydrolfluosilicic Acid Service (H
2
SiF
6
)

March 2004
Phone: [phone] www.jescoamerica.com Fax: [phone] SD 6.18
PP PP
Parar
arar
arts Lists Lis
ts Lists Lis
ts Listt
tt
t MAGDOS DEDX
Valves for MAGDOS DE/DX 07-12
Item
No.
Descrip-
tion Material
Part
No.
Suction Discharge
PVC 316 SS PVDF PVC 316 SS PVDF
Seal Material: H=Hypalon, P=PTFE, V=Viton
H P V H P V H P V H P V H P V H P V
1Valve
Body
PVC 20845 1 1 1 -- -- -- -- -- -- 1 1 1 -- -- -- -- -- --
PVDF28108------------111------------111
316SS 19289 -- -- -- 111---- -- ------ 111------
2Ball
Guide
PVC 24066 1 1 1 -- -- -- -- -- -- 1 1 1 -- -- -- -- -- --
PVDF 24067 -- -- -- 111---- -- ------111------
316SS 29386 -- -- -- -- -- -- 1 1 1 -- -- -- -- -- -- 1 1 1
3Valve
Ball
Glass29778111------------111------------
316SS 18044 -- -- -- 111---- -- ------ 111------
PTFE25247------------111------------111
4Valve
Seat
PVDF 81460 1 1 1 -- -- -- 1 1 1 1 1 1 -- -- -- 1 1 1
316SS81461------111---- -- ------111---- --
5Gasket
Viton 81138 -- -- 1 -- -- 1 -- -- 1 -- -- 1 -- -- 1 -- -- 1
PTFE81677--1----1----1----1----1----1--
EPDM 81453 1 -- -- 1 -- -- 1 -- -- 1 -- -- 1 -- -- 1 -- --
6O-ring
EPDM 81384 -- -- 1 -- -- 1 -- -- 1 -- -- 1 -- -- 1 -- -- 1
Viton80617--1----1----1----1----1----1--
PTFE 80754 1 -- -- 1 -- -- 1 -- -- 1 -- -- 1 -- -- 1 -- --
7Locking
Screw
PVC 19299 1 1 1 -- -- -- -- -- -- 1 1 1 -- -- -- -- -- --
PVDF28110------------111------------111
316SS24031------111---- -- ------111------
8Valve
Spring
Hastelloy
25081 1 1 1111111111111111
9O-ring
Viton 80013 -- -- 1 -- -- 1 -- -- 1 -- -- 1 -- -- 1 -- -- 1
PTFE 80627 -- 1 -- -- 1 -- -- 1 -- -- 1 -- -- 1 -- -- 1 --
EPDM 80755 1 -- -- 1 -- -- 1 -- -- 1 -- -- 1 -- -- 1 -- --
10 Gasket
Viton 81526 -- -- 1 -- -- 1 -- -- 1 -- -- 1 -- -- 1 -- -- 1
PTFE81585--1----1----1----1----1----1--
EPDM 81525 1 -- -- 1 -- -- 1 -- -- 1 -- -- 1 -- -- 1 -- --
Complete Valve Assembly
33499 25085 25087 34397 25089 25669 34393 29348
34370*
33500 25086 25088 34398 25090 25670 34394 29385
34371*
*Hydrolfluosilicic Acid Service (H
2
SiF
6
)

March 2004 Phone: [phone] www.jescoamerica.com Fax: [phone]
PP 6.19SD 6.19
PP PP
Parar
arar
arts Lists Lis
ts Lists Lis
ts Listt
tt
t MAGDOS DEDX
Valves for MAGDOS DE/DX 20
Item
No.
Descrip-
tion Material Part No.
Double Ball Spring-Loaded
Suction Discharge Suction Discharge
PVC 316SS PVC 316SS PVC PVC
Seal Material: H=Hypalon, H-Hypalon, V=Viton
H V H V H V H V H V H V
1Valve
Housing
PVC 18189 1 1 -- -- 1 1 -- -- 1 1 1 1
316SS19601---- 11---- 1 1--------
2Ball
Guide
PVC 82405 2 2 -- -- 2 2 -- -- -- -- -- --
316SS82102---- 22---- 2 2--------
PVC 23412 -- -- -- -- -- -- -- -- 1 1 1 1
3ValveBall
Ceramic1001722 22 1111
316SS 10136 2 2 2 2
4Valve
Seat
PVC8240622 22 1111
316SS 82103 2 2 2 2
5Gasket Hypalon 81037 2 2 2 2 1 1
Viton 81138 2 2 2 2 1 1
6Gasket Hypalon 81033 1 1 1 1 1 1
Viton 81285 1 1 1 1 1 1
7Gasket Hypal on 81041 1 1 1 1 1 1
Viton811411 11 111
8Valve
Spring Hastelloy 25082 1 1 1 1
Complete Valve Assembly
18187 18185 260470 19176 18188 18186 260481 19177 25161 25162 27516 27517

March 2004
Phone: [phone] www.jescoamerica.com Fax: [phone] SD 6.20
PP PP
Parar
arar
arts Lists Lis
ts Lists Lis
ts Listt
tt
t MAGDOS DEDX
Valves for MAGDOS DE/DX 40 & 100
Item
No.
Descrip-
tion Material
Part
No.
Double Ball Spring-Loaded
Suction Dischar ge Suction Discharge
PP 316SS PVDF PP 316SS PVDF PP PP
Seal Material: H=Hypalon, V=Viton
H V H V H V H V H V H V H V H V
1Valve
Body
PP 34665 1 1 -- -- -- -- 1 1 -- -- -- -- 1 1 1 1
316SS 32449 -- -- 1 1 -- -- -- -- 1 1 -- -- -- -- -- --
PVDF 34082 -- -- -- -- 1 1 -- -- -- -- 1 1 -- -- -- --
2Ball
Guide
PP3414222------ --22------ ----------
316SS 82112 -- -- 2 2 -- -- -- -- 2 2 -- -- -- -- -- --
PP 22882 -- -- -- -- -- -- -- -- -- -- -- -- 1 1 1 1
PVDF 34084 -- -- -- -- 2 2 -- -- -- -- 2 2 -- -- -- --
3Valve
Ball
Glass 82457 2 2 -- -- -- -- 2 2 -- -- -- -- 1 1 1 1
316SS 82114 -- -- 2 2 -- -- -- -- 2 2 -- -- -- -- -- --
PTFE
261504
-- -- -- -- 2 2 -- -- -- -- 2 2 -- -- -- --
4Valve
Seat
PP 82456 2 2 -- -- -- -- 2 2 -- -- -- -- 1 1 1 1
316SS 82113 -- -- 2 2 -- -- -- -- 2 2 -- -- -- -- -- --
PVDF 34083 -- -- -- -- 2 2 -- -- -- -- 2 2 -- -- -- --
5GasketHypalon 81035 1 -- 1 -- 1 -- 1 -- 1 -- 1 -- 1 -- 1 --
Viton 81198 -- 1 -- 1 -- 1 -- 1 -- 1 -- 1 -- 1 -- 1
6GasketHypalon 81238 2 -- 3 -- 2 -- 2 -- 3 -- 2 -- 1 -- 1 --
Viton 81276 -- 2 -- 3 -- 2 -- 2 -- 3 -- 2 -- 1 -- 1
7GasketHypalon 81239 2 -- -- -- 1 -- 1 -- -- -- 1 -- 1 -- 1 --
Viton 81277 -- 2 -- -- -- 1 -- 2 -- -- -- 1 -- 1 -- 1
8Valve
Spring
Hastelloy
32577 -- -- -- -- -- -- -- -- -- -- -- -- 1 1 1 1
Complete Valve Assembly
26841 26842 260471 27652 261529 261527 27356 27357 260482 27655 261528 261526 26845 25707 27353 27354
* Quantity 3 required on 316SS Double Ball valves
