Jet Hybrid Style User manual

HYBRID STYLE TABLESAW
XACTA®Fence II system
withT-square design and HDPE sideboards
Enclosed cabinet
Channels dust to a 4" port for fast, clean dust collection
Poly-V belt drive system
Reduces vibration and heat build up resulting in better power transfer
Left tilting
for more controlled beveled cutting
Cast iron wings
for longer work surface and support area
Independent leaf safety guard
Protects operator from blade while cutting, even at 45° tilt
Moveable power switch with reset and power light
lets you customize the position of your on/off switch for convenience, safety
Large heavy-duty handwheels
Helps you make precise adjustments with less effort
jettools.com
OPTIONAL ACCESORIES
Stock Number 708780K
Model Number JWSS-10CSPF
Table Type STATIONARY
Right Rip Capacity (in.) 30
Motor (TEFC) 1-3/4HP, 1Ph,
115V
Miter Gauge Type Standard
Blade Diameter (in.) 10
Arbor Diameter (in.) 5/8
Maximum Depth of Cut (in.) 3-1/3
Maximum Cut Depth at 45º (in.) 2-1/8
Table in Front of Blade
at Maximum Cut (in.) 11-1/2
Maximum Cross Cut (in.) 28-1/2
Blade to Front of Table (in.) 11-1/2
Maximum Width of Dado (in.) 13/16
Maximum Dado Diameter (in.) requires zero clearance insert 8
Table Height (in.) 35-1/4
Table Size without Wings (L x W/in.) 21-1/4 x 27
Overall Dimensions (W x D x H/in.) 60 x 40 x 40
Arbor Speed (RPM) 4,000 RPM
Dust Port (in.) 4
Distance Between Sliding Table and Blade (in.)
Net Weight (lbs.) 409
Mobile Base
708119
Zero Clearance Insert
708791
Roller Stand
709207
Moveable power
switch with
reset and power
light
Poly-V belt
drive system
Independent
leaf safety
guard
Features an XACTA®
Fence II System that
holds securely to
constantly ensure
accurate cuts
