Jetson Atlas User manual

Atlas
Fat Tire Electric Bike.
A guide for your ride.
IMPORTANT: READ CAREFULLY AND RETAIN FOR FUTURE REFERENCE.
MODEL: JATLAS-BLK
Designed in Brooklyn

Jetson's top two riding rules:
Be safe. Have fun!

2
Contents
........................................................................................................................................................
...................................................................................................................................................
...................................................................................................................................................
.....................................................................................................................................................
.......................................................................................................................................................
.....................................................................................................................................................
......................................................................................................................
................................................................................................................................................
.............................................................................................................................................
...................................................................................................................................................
.................................................................................................................................
........................................................................................................................................
..........................................................................................................................................
.............................................................................................................................................
.......................................................................................................................................
Safety Warnings
Warranty Coverage
Product Overview
Specs & Features
Rider Suitability
Online Resources
1. Getting Started
Unfolding & Folding the Handlebar
Attaching the Seat
Attaching the Pedals
Securing the Bell
Securing the Front Relector
2. Preparing to Ride
Adjusting the Handlebar
Repositioning the Seat
Charging the Battery
Tire Inlation & Pressure

3
3. Functions & Features
Powering On & O
Checking Battery Charge Level
Using the Lights
Using the Bell
Using the Kickstand
Folding & Unfolding the Pedals
4. Making Moves
Riding Your Atlas
Using Pedal Assist
Using the Throttle
Activating Cruise Control
Traditional Biking
Using the Brakes
Maximizing Riding Range & Speed
5. Safe Journeying
Pre-Ride Safety Checks
Proper Helmet Positioning
Care & Maintenance
.................................................................................................................................................
............................................................................................................................
.....................................................................................................................................................
.........................................................................................................................................................
..............................................................................................................................................
............................................................................................................................
...................................................................................................................................................
.................................................................................................................................................
.................................................................................................................................................
.....................................................................................................................................
..................................................................................................................................................
...................................................................................................................................................
......................................................................................................................
.........................................................................................................................................
...................................................................................................................................
................................................................................................................................................

4
• Before use, please read the user manual and safety warnings carefully, and make sure you understand and accept all the safety
instructions. The user will be responsible for any loss or damage caused by improper use.
• Please check the drive system and frame before riding to ensure safety.
• Before each cycle of operation, the operator shall perform the preoperation checks speciied by the manufacturer:
That all guards and pads originally supplied by the manufacturer are in proper place and in serviceable condition;
That the braking system is functioning properly; That any and all Atlas guards, chain guards, or other covers or guards supplied
by the manufacturer are in place and in serviceable condition; That tires are in good condition, inlated properly, and have
suicient tread remaining; The area that the product is to be operated should be safe and suitable for safe operation.
• Components shall be maintained and repaired in accordance with the manufacturer’s speciications and using only the
manufacturer’s authorized replacement parts with installation performed by dealers or other skilled persons.
• Don’t allow hands, feet, hair, body parts, clothing, or similar articles to come in contact with moving parts, wheels, or drive
train, while the bike is in use.
• This product should not be used by children or persons with reduced physical, sensory or mental capabilities, or lack of
experience and knowledge, unless they have been given supervision or instruction (IEC 60335-1/A2:2006).
• Unsupervised children should not play with the product (IEC 60335-1/A2:2006).
• Adult supervision is required.
• The rider should not exceed 220 lb.
• Never use near motor vehicle.
• Units shall not be operated to perform racing, stunt riding, or other maneuvers, which may cause loss of control, or may cause
uncontrolled operator/passenger actions or reactions.
• Avoid sharp bumps, drainage grates, and sudden surface changes. Bike may suddenly stop.
• Avoid streets and surfaces with water, sand, gravel, dirt, leaves, and other debris. Wet weather impairs traction, braking, and visibility.
• Avoid riding around lammable gas, steam, liquid, or dust that could cause ire.
• Operators shall adhere to all of the manufacturer’s recommendations and instructions, as well as comply with all laws and
ordinances: Units without headlights shall be operated only with adequate daylight conditions of visibility, and; Owners shall
be encouraged to highlight (for conspicuity) using lighting, relectors, and for low-riding units, signal lags on lexible poles.
• Do not ride at night.
• Only ride the product with adequate daylight conditions for visibility.
• Persons with the following conditions shall be cautioned not to operate: Those with heart conditions; Pregnant women;
Persons with head, back, or neck ailments, or prior surgeries to those areas of the body; and persons with any mental or
physical conditions that may make them susceptible to injury or impair their physical dexterity or mental capabilities to
recognize, understand, and perform all of the safety instructions and to be able to assume the hazards inherent in unit use.
• Do not ride after drinking or taking prescription medication.
• Do not carry items when riding.
Safety Warnings

5
• Never operate the product while barefoot.
• Always wear shoes and keep shoelaces tied.
• Make sure your feet are always placed securely on the deck/pedal.
• Operators shall always use appropriate protective equipment, including but not limited to: a helmet with appropriate
certiication, protective clothing, knee pads, and elbow pads.
• Always give way to pedestrians.
• Be alert to things in front and far away from you.
• Do not allow distractions when riding, such as answering the phone or engaging in any other activities.
• The product cannot be ridden by more than one person.
• When riding the product along with other riders, always keep a safe distance to avoid a collision.
• When turning, be sure to maintain your balance.
• Riding with improperly adjusted brakes is dangerous and can result in serious injury or death.
• Applying brakes too hard or too suddenly can lock up a wheel, which could cause you to lose control and fall. Sudden or
excessive application of the brake may result in injury or death.
• If the brake loosens, please adjust with the hexagon wrench, or please contact the Jetson Care Team.
• Replace worn or broken parts immediately.
• The area that the product is to be operated should be safe and suitable for safe operation.
• Check whether all safety labels are in place and understood before riding.
• The owner shall allow the use and operation of the unit after a demonstration that such operators can understand and operate
all components of the unit before use.
• Recommended to charge indoors.
• Use caution when changing the batteries. Do not change batteries near lammable materials. Remove batteries from the bike
when not in use for long periods of time.
• Prolonged exposure to UV rays, rain, and the elements may damage the enclosure materials. Store indoors when not in use.
MODIFICATIONS
Do not attempt to disassemble, modify, repair, or replace the product or any components of the unit without instruction from
the Jetson Care Team. This will void any warranty, and can lead to malfunctions which may cause injury.
ADDITIONAL OPERATION PRECAUTIONS
• Do not lift the product o the ground while it is on and the wheels are in motion. This can result in freely spinning wheels,
which may cause injury to yourself or others nearby.
• Do not jump on or o the product, and do not jump while using it.
• Always keep your feet irmly planted on the pedals while in operation.
• The Consumer Product Safety Commission advises that the riding of small wheel diameter bicycles at excessive speeds can
lead to instability and is not recommended.
• Always wear a properly itted helmet when you ride your bicycle. Do not ride at night. Avoid riding in wet conditions.

6
MAINTENANCE PRECAUTIONS
For all maintenance repairs and needs beyond the capability of the consumer, which may include but not be limited to: such
as proper maintenance of brakes, control cables, bearing adjustments, wheel adjustments, lubrication, relectors, tires and
handlebar and seat adjustments, please contact the Jetson Care Team for assistance at:
ridejetson.com/support
US & Canada 1-[phone]
DISPOSAL OF USED BATTERY
Battery may contain hazardous substances which could endanger the environment and human health. This symbol
marked on the battery and/or packaging indicates that used battery shall not be treated as municipal waste.
Batteries should be disposed of at an appropriate collection point for recycling. By ensuring the used batteries are
disposed of correctly, you will help prevent potential negative consequences for the environment and human health. The
recycling of materials will help to conserve natural resources. For more information about recycling of used batteries,
please contact your local municipality waste disposal service.
NOTICE OF COMPLIANCE
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not
cause harmful interference, and (2) this device must accept any interference received, including interference that may cause
undesired operation.
WARNING: Changes or modiications to this unit not expressly approved by the party responsible for compliance could void
the user’s authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15
of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee
that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment o and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit dierent from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Shielded cables must be used with this unit to ensure compliance with the Class B FCC limits.
CALIFORNIA PROPOSITION 65
WARNING:
This product can expose you to the chemical Cadmium which is known to the State of California to cause cancer
and birth defects or other reproductive harm. For more information, go to www.P65warning.ca.gov.

7
Warranty Coverage
ONE-YEAR GENERAL LIMITED WARRANTY
All new Jetson products are warranted against defects in materials and workmanship for a period of one year from the
date of original retail purchase when used in accordance with Jetson's user manuals (refer to ridejetson.com/support).
Under this warranty, you will be able to direct your claims to Jetson even in situations where you purchased the
Jetson Product from one of our authorized retailers.
To read the full terms of our warranty, visit ridejetson.com/warranty.

1
2
3
4
5
6
713
14
15
8
9
10
11
12
16
8
Product Overview
1. HANDLEBAR
a. POWER BUTTON
b. BELL
c. LEFT HANDBRAKE
d. HANDLEBAR CLAMP
e. FRONT REFLECTOR
f. BATTERY INDICATOR LIGHTS
g. CRUISE CONTROL BUTTON
h. TWIST THROTTLE
i. RIGHT HANDBRAKE
2. HANDLEBAR STEM
3. HEADLIGHT
4. FOLDING LATCH WITH
LOCKING RING
5. REFLECTOR
6. WHEEL
7. TIRE VALVE WITH DUST CAP
8. FRONT FENDER
9. PEDAL*
10. CHARGING PORT WITH COVER
11. SEAT*
12. REAR REFLECTOR
13. SEAT CLAMP
14. BRAKE LIGHT
15. REAR FENDER
16. KICKSTAND
17. CHARGER
18. CHARGING CABLE
INCLUDED TOOLS FOR ASSEMBLY, TIGHTENING, AND MAINTENANCE:
MULTITOOL INCLUDING
PHILLIPSHEAD SCREWDRIVER
AND ASSORTED ALLEN KEYS
15 MM SPANNER
WRENCH
* NOT PREATTACHED; REQUIRES SETUP

9
NOTE: IMAGES MAY NOT REFLECT EXACT APPEARANCE OF ACTUAL PRODUCT.
17 18
1
2
413
3
6
5
9
8
7
10
12
14
11
16
15
ab
h
e
d
c
fi
g

10
Specs & Features
• PRODUCT DIMENSIONS, UNFOLDED: 49.2” L × 18.9” W × 42” H
• PRODUCT DIMENSIONS, FOLDED: 49.2” L × 14” W × 29.5” H
• PRODUCT WEIGHT: 48.5 LBS
• TIRE SIZE: 14” H X 3” W
• BATTERY: 36V, 6.0AH LITHIUMION
• CHARGER: UL 100  240V
• CHARGING TIME: UP TO 5 HOURS
Rider Suitability
FOR SAFE AND COMFORTABLE RIDING, THERE SHOULD
BE A CLEARANCE OF AT LEAST 13 INCHES BETWEEN
THE CROTCH AND THE TOP TUBE OF THE BICYCLE
FRAME WHEN THE RIDER STRADDLES THE BICYCLE
WITH BOTH FEET FLAT ON THE GROUND.
• MOTOR: 350W
• MAX SPEED: 15.5 MPH
• MAX THROTTLE RANGE: 15 MILES
• BRAKE TYPE: FRONT AND REAR DISC
• WEIGHT LIMIT: 220 LBS
• RECOMMENDED AGE: 14+
1-3
inches

11
WARNING:
FAILURE TO COMPLY WITH THE FOLLOWING INSTRUCTIONS MAY RESULT IN INJURY TO THE CHILD OR OTHERS.
• KEEP SMALL PARTS AWAY FROM CHILDREN DURING ASSEMBLY.
• ACCESSORY MUST BE ASSEMBLED AND REMOVED BY AN ADULT.
• FREQUENTLY INSPECT THE PRODUCT FOR DAMAGE.
* ADULTS MUST ASSIST CHILDREN IN THE ASSEMBLY AND INITIAL ADJUSTMENT PROCEDURES OF THE PRODUCT.
Scan for our most updated
Atlas onboarding materials
and support resources.
Online Resources

12
1. Getting Started
1.1 Unfolding & Folding the Handlebar
WHEN TO UNFOLD: FOR RIDING
WHEN TO FOLD: FOR STORAGE AND TRANSPORT
IMPORTANT: THE DIRECTIONS GIVEN IN THIS MANUAL—RIGHT, LEFT, FRONT, REAR—ARE ORIENTED AS THE RIDER WOULD
SEE THEM WHEN SITTING ON THE BICYCLE. THE "RIGHT SIDE" OF THE BIKE, FOR EXAMPLE, IS THE SIDE WHERE THE RIDER’S
RIGHT HAND AND RIGHT FOOT WILL BE.
PROP THE ATLAS UPRIGHT ON ITS KICKSTAND PRIOR TO ASSEMBLY. REFER TO SECTION 5.5.
HOW TO UNFOLD:
1. GENTLY RAISE THE HANDLEBAR UNTIL
THE STEM IS RESTING VERTICALLY ON
THE FRAME.
STEM

13
LATCH
13
2. PUSH THE LATCH IN UNTIL IT CLICKS INTO THE
CLOSED LATCHED POSITION.

14
LOCKING RING
LOCKING RING TAB
3. SECURE THE LATCH WITH THE LOCKING RING:
ROTATE THE RING CLOCKWISE AROUND THE
STEM UNTIL THE TAB ON THE RING SLIDES
INTO THE TAB SLOT ON THE LATCH.
4. CHECK THAT THE LATCH IS SECURED BY
ENSURING THAT IT CANNOT BE PULLED OPEN.
IMPORTANT: NEVER RIDE THE ATLAS WITHOUT THE FOLDING
LATCH CLOSED AND SECURED BY THE LOCKING RING.

15
HOW TO FOLD:
1. ROTATE THE LOCKING RING COUNTERCLOCKWISE AROUND THE STEM UNTIL THE TAB CLEARS FROM THE TAB SLOT ON
THE FOLDING LATCH.
2. WHILE HOLDING THE HANDLEBAR STEM STEADY WITH ONE HAND, USE THE OTHER HAND TO PULL
THE LATCH OPEN UNLATCHED.
3. GENTLY LOWER THE HANDLEBAR DOWN TOWARDS THE SIDE OF THE BIKE OPPOSITE THE LATCH.
1. 2. 3.
LOCKING RING LATCH
LOCKING RING TAB

16
1.2 Attaching the Seat
1. PULL OPEN THE LATCH ON THE SEAT CLAMP.
2. LOCATE THE "MINIMUM INSERTION" MARK ENGRAVED NEAR THE BOTTOM OF THE SEAT POST.
3. HOLD THE SEAT IN POSITION ABOVE THE BIKE.
4. LOWER THE SEAT POST THROUGH THE CLAMP AND INTO THE SEAT TUBE UNTIL THE MINIMUM INSERTION MARK IS
BELOW THE CLAMP. IF THE CLAMP OPENING IS TOO NARROW TO RECEIVE THE POST, YOU CAN WIDEN IT BY TURNING
THE KNOB ON THE CLAMP COUNTERCLOCKWISE WHILE HOLDING THE LATCH STEADY.
5. WHILE HOLDING THE SEAT AT THE DESIRED HEIGHT, CLOSE THE LATCH ON THE CLAMP.
SEAT POST
MINIMUM INSERTION MARK
CLAMP LATCH SEAT CLAMP
CLAMP KNOB
(opposite side- not shown)

17
6. CHECK THAT THE SEAT IS SECURE: USE YOUR HAND TO PUT DOWNWARD PRESSURE ON THE SEAT.
IF THE SEAT POST SLIPS FURTHER DOWN INTO THE TUBE, BRING IT BACK TO POSITION AND TIGHTEN
THE CLAMP BY TURNING THE KNOB CLOCKWISE.
TROUBLESHOOTING: IF YOU CANNOT OPEN THE CLAMP LATCH WITH EASE, THE KNOB MAY BE TOO TIGHT.
LOOSEN THE KNOB BY TURNING IT COUNTERCLOCKWISE.

18
1.3 Attaching the Pedals
1. ALIGN THE SPINDLE ON PEDAL MARKED "R" WITH THE HOLE AT THE END OF THE CRANK ARM ON
THE RIGHT SIDE OF THE BIKE.
2. HOLD THE PEDAL BASE STEADY AND, TAKING CARE THAT THE SPINDLE ENTERS THE HOLE STRAIGHT,
USE YOUR OTHER HAND TO TWIST THE SPINDLE CLOCKWISE INTO THE HOLE FOR A FEW ROTATIONS.
PEDAL R
SPINDLE
CRANK ARM
