Jetson SLINGSHOT User manual

1
SLINGSHOT
ELECTRIC SCOOTER
-MANUAL-

2
TABLE OF CONTENTS
A. Introduction 3
B. Included In The Box 4
C. Features And Specs 5
D. Assembly 6
E. Charging the Battery 7
F. Operating the Slingshot 8
G. Care and Maintenance 10
H. Safety Warnings 11
I. Warranty 13
J. Product Registration 14

3
Congratulations on your new Jetson Slingshot Electric Scooter! The
Slingshot is an innovative and fun electric scooter, ready to take on
everyday use. Before your rst ride, check whether the wheels are
damaged, or parts are loose. If there are any abnormalities, please
contact Jetson Customer Support at 1-[phone] or email us at
[e-mail].
This product manual can help you understand, use, and maintain your
Slingshot. In order to avoid danger caused by collisions, falls, and
loss of control, please use caution and learn how to ride the Slingshot
safely. Jetson and authorized dealers cannot be held liable for injury or
damage caused from riding the Slingshot. Users ride at their own risk.
The rider is responsible for consequences caused by violating warnings
or improper operations.
If you want to return this product for any reason, be sure to rst call or
email us before taking it back to the store so we can assist you.
INTRODUCTION

4
INCLUDED IN THE BOX
1. Stem Base
2. Stem
3. Deck
4. Rear Foot Brake
5. Kickstand
6. Charging Port
1
2
3
4
5
6

5
FEATURES AND SPECS
MODEL: SLINGSHOT
WHEEL SIZE: FRONT: 6”
REAR: 5”
MAX SPEED: 6 MPH
MAX RANGE: 4 MILES
BATTERY TYPE: LEAD ACID
BATTERY CAPACITY: 12V, 9AH (6V, 4.5AH*2
PIECES)
MOTOR TYPE: CHAIN
MOTOR: 60W
CHARGER: UL AC110-240V
CHARGE TIME: 4 HOURS
PRODUCT WEIGHT: 14 LBS
WEIGHT LIMIT: 120 LBS
RECOMMENDED AGE: 7+
WATER RESISTANT: NO
7. Handlebar
8. Thumb Throttle
8
7

6
The Slingshot comes partially assembled, you will need to attach the
Stem into the Stem Base to fully assemble the Slingshot.
First, slide the Stem into the Stem Base. Align the holes in the Stem and
Stem Base. Then, place the Small Bolt and Washer through the front hole
of the Stem and the Long Bolt through the back of the Stem. Turn the
Small Bolt until it is tight and secure.
ASSEMBLY
Small Bolt
and Washer Large Bolt

7
Your Slingshot comes with a built-in rechargeable lead-acid battery.
Always use the provided charger only. The charging port is located on
the left side of the Slingshot. Please remember to cover the Charging
Port when you are done charging the Slingshot. Before your rst ride
you must fully charge the Slingshot - charge for 7 hours for the rst 3
times you use it. For every ride after, charge your Slingshot until it is
fully charged, and NOT LONGER. Do not leave any chargers plugged in
overnight, or leave it plugged in past the charge time.
CHARGING THE BATTERY
1. Plug one end of the power cord into a grounded AC outlet and the
other into the Slingshot’s charging port. The red charging light on the
charger unit will turn on.
2. The red light will turn green once fully charged. Recharge the
Slingshot after each use.
(Please note: Always plug the charger into the wall rst before the
device. If the wall outlet doesn’t have power and you plug the charger
into the device rst, it will light green, even if the battery is not full. So
always plug into the wall rst to make sure there is power.)
THE CHARGER OFFERS A CHARGING STATUS ON THE TOP OF THE
CHARGER:
CHARGING LIGHT RED: Battery is charging.
CHARGING LIGHT GREEN: Charging is complete.
Don’t use the Slingshot if the battery emits strange odors, overheats,
or begins leaking. If the battery does leak, do not touch any leaking
materials, as the battery contains dangerous substances. Do not open
the battery and do not insert anything into the battery.
Only use the provided charger for the Slingshot. Do not charge the
battery if it has over-discharged. It should be discarded for your safety.
Do not turn on the Slingshot while it is charging.

8
OPERATING THE SLINGSHOT
TURNING THE SLINGSHOT ON AND OFF
To turn the Slingshot on, ip the Power Switch located on the right side
of the Slingshot under the Deck to “On.”
To turn the Slingshot off, rst make sure the Slingshot is not in motion.
Then, ip the Power Switch to “Off.”
SAFE RIDING
Helmet: Most serious injuries that occur while riding are head injuries.
This could be prevented by wearing a helmet.
Elbow and Knee Pads: For added protection, always wear elbow and
knee pads when riding your Slingshot, to prevent any serious injuries.
Get to know the Slingshot before riding it. Test your control over it.
Make your turns slowly and cautiously, and give yourself stopping
distance. It is recommended you practice your rst ride on the Slingshot
in an open space with no obstacles in your way.
Power
Button

9
USING THE THUMB THROTTLE
To activate the motor, press down on the Thumb Throttle. Get
accustomed to the acceleration of the throttle.
Thumb
Throttle
FOOT POSITION
Before riding, put your foot as close as possible to the front of the Deck,
and your other foot on the ground. Make sure that your driving route is
clear. To start riding, boost yourself forward with your foot that is on the
ground. Keep one foot behind the other, (it’s more comfortable to place
one foot forward and the other one turned at 70-90°). It will help you
gain more stability. The turns on the Slingshot are commanded by the
direction you turn the Handlebar/Front Wheel in. Before turning, look
both ways to make sure your path is clear.
HOW TO APPLY THE BRAKE
To apply the brake, press down on the Rear Foot Brake with your back
foot. Using the Rear Foot Brake will also deactivate the motor.

10
CARE AND MAINTENANCE
DRIVING RANGE
The average range of the Slingshot is 4 miles. However, a lot of factors
will affect how far you can go per charge:
• Driving surface: A smooth, at surface will increase driving
distance.
• Weight: More weight means less distance.
• Ambient temperature: Please ride and store the Slingshot
under recommended temperature, which will increase its
longevity and driving distance.
• Maintenance: Timely battery charging and maintenance will
increase driving distance.
• Speed and driving style: Maintaining a moderate speed will
increase distance. Frequent starting and stopping, acceleration,
and decelertion will reduce it.
SPEED LIMIT
The top speed of the Slingshot is 6 mph.
WEIGHT LIMIT
The maximum load is 120 lbs. Going above the maximum weight limit
can cause injury or damage the Slingshot.
CLEANING THE SLINGSHOT
To clean the Slingshot carefully wipe with a damp cloth, then dry with
a dry cloth. Do not use water to clean the Slingshot, as the electrical
and electronic systems may get wet, resulting in personal injury or
malfunction of the Slingshot.
BATTERY
• Keep the Slingshot away from re and excessive heat.
• To avoid damage to the battery, never subject the Slingshot to intense
physical shock, severe vibration, or impact.
• Protect the Slingshot from water or moisture.
• Never disassemble the Slingshot or its battery.
• If there are any issues with the battery, please contact Jetson
Customer Support at 1-[phone] or email us at
[e-mail].
