JETWAY JBC38AZ02-2LU User manual

Quick Installation Guide
NO: G03-JC38AZ02QIG-F
Rev: 1.0
Release Date: 2022-02-11
Notice:
The photos in this file are for illustration purpose only. The model may not be the latest version. Please refer
to the product you purchased for actual specification.

I/O Outlets:

Dimension and Outlines:
I. To Dissemble the Chassis
1. Put the system upon a stable platform with this side up, as the photo shows.

2. Locate the screws at the spots marked on this cover and unscrew them one by one to open the chassis.
3. Remove the screw in the marked spot on front panel.
4. Remove the screw in the marked spot on rear panel.

5. Lift the cover up to open the chassis.
6. The overview of the internal layout of the system.
