1-1 Feature of Motherboard
Onboard Intel®Elkhart Lake Series Processor, with low power consumption never
denies high performance
Support 1* DDR4 3200MHz SO-DIMM, maximum capacity up to 16GB
Support 2* RS232/RS422/RS485 COM Ports
Onboard 1* M.2 M-key (2242/2280, SATA/PCIe Gen.3x2 interface) support NVMe
Onboard 1* M.2 E-key (2230, USB2.0/PCIe Gen.3x1 interface)
Onboard 1* M.2 B-key (3042/3052, USB3.1 interface)
Support 1* SATAIII (6Gb/s) Device & 1* SIM card slot
Support 1* External USB3.1(Gen.2), 1* External USB2.0, 2* Internal USB2.0
Support 4* i225V 2.5GbE RJ-45 LAN ports
Onboard 32GB eMMC (Option for MF13-03 series)
Onboard Lockable 12V DC-in PWR jack
Support CPU Over-Temperature protection
Support CPU Over-Current/Under Voltage protection
Support CPU Smart FAN
Compliance with ErP standard
Support Watchdog function

2
1-2 Specification
Spec
Description
Design
3.5” SBC Form Factor; PCB size: 148mm * 102mm
Embedded CPU
Integrated with Intel®Elkhart Lake series CPU
*CPU model varies from different IPC options. Please consult your dealer
for more information of onboard CPU.
Memory
1* DDR4 SO-DIMM slot Support 1* DDR4 3200MHz SO-DIMM up to
16GB
* Note: Memory clock supporting range is decided by specific CPU of
the model. For more memory compatibility information please consults
your local dealer.
Expansion Slot
1* M.2 E-key (2230, USB2.0/PCIe Gen.3x1 interface) (M2E1)
1* M.2 B-key (3042/3052, USB3.1 interface; co-function with
SIMCARD1)(M2B1)
SIMCARD1: 1* SIM card slot (co-function with M2B1 slot)
LAN Chip
Integrated with 4* Intel i225-V PCI-E 2.5Gigabit LAN chip
Support Fast Ethernet LAN function of providing
10/100/1000/2500Mbps Ethernet data transfer rate
Storage
1* SATAIII 6Gb/s port
1* M.2 M-key (2242/2280, SATA/PCIe Gen.3x2 interface) support
NVMe (M2M)
Onboard 32GB eMMC (optional for MF13-03)
BIOS
AMI Flash ROM
Rear I/O
1* Lockable 12V DC-in power Jack
1* USB 3.1(Gen.2) port
1* USB 2.0 port
4* 2.5Gbps RJ-45 LAN ports
1* RS232/RS422/RS485 COM Port (COM1)
Internal I/O
1* 2-Pin internal 12V DC-in power connector
1* SATA Power-out connector
1* CPUFAN connector
1* Front panel header
1* LAN_LED header

3
1* 9-pin USB 2.0 header (Expansible to 2* USB 2.0 ports)
1* RS232/422/485 serial port header (FP_COM2)
1* PS/2 keyboard & mouse header
1* SMBUS header
1* GPIO header
1* HDMI header
1-3 Layout Diagram
Rear IO Panel Diagram:
Warning!!
The board has a 12V DC-in power connector (DCIN) in I/O back panel and an internal ATX12V
(ATXPWR) power connector. User can only connect one type of compatible power supply to
one of them to power the system.
RS232/485/422
COM1 Serial Port
2.5Gbps RJ-45 LAN Ports
(LAN 1/2/3/4)
USB 2.0 Port
USB 3.1(Gen.2) Port
12V DC-in
PowerConnector
(Lockable)

4
Motherboard Internal Diagram-Front Side
*Note: M2B1 slot co-functions with SIM card ; please install compatible 3G/4G/5G LTE card into SIM
card holder as well for full function.
RS232/422/485
Serial Port Header (FP_COM2)
HDMI1 Header
USB 2.0 Header
SATA III Port
SATA Power-out Connector
JPCAS_80P
M.2 M-key Slot
(M2M)
JBAT
GPIO Header
CPUFAN Connector
PS/2 Keyboard & Mouse Header
SMBUS Header
AT_MODE
Front Panel Header (JW_FP)
Internal 12V DC-In
Power Connector
12V DC-in
Power Jack (Lockable)
Top: USB2.0 Port
Bottom: USB 3.1(Gen.2) Port
2.5Gbps RJ-45 LAN Ports
(LAN 1/2/3/4)
RS232/422/485 Serial Port (COM1)
JPCOM2
JPCOM1
LAN_LED Header
BATCON
*SIM Card Slot
M.2 E-key Slot (M2E1)
M2M_PWR
M.2 B-key Slot
(M2B1)
M2B_PWR
M2E_PWR

5
Connectors
Connector
Name
DCIN1
Lockable 12V DC-in power Jack
USB31
Top: USB 2.0 Port Connector
Bottom: USB 3.1(Gen.2) Port Connector
LAN1/2/3/4
2.5Gbps RJ-45 LAN Port Connector x 4
COM1
RS232/485/422 Serial Port Connector
ATXPWR
Internal 12V DC–in Power Connector
SATA1
SATAIII Connector
SATAPWR
SATA Power-out Connector
CPUFAN
CPUFAN Connector
Headers
Header
Name
Description
Pitch
JW_FP
Front Panel Header(PWR LED/
HDD LED/Power Button /Reset)
8-pin Block
2.54mm
SMBUS
SMBUS Header
5-pin Block
2.0mm
PS2KBMS
PS/2 Keyboard & Mouse Header
6-pin Block
2.54mm
GPIO
GPIO Port Header
10-pin Block
2.0mm
FP_USB21
USB 2.0 Header
9-pin Block
2.0mm
HDMI1
HDMI Port Header
19-pin Block
2.0mm
FP_COM2
RS232/485/422 Serial Port Header
9-pin Block
2.0mm
LAN_LED
LAN Activity LED Header
8-pin Block
2.54mm

6
Jumpers
Jumper
Name
Description
Pitch
AT_MODE
ATX Mode/AT Mode Select
3-Pin Block
2.0mm
JBAT
Pin (1&2): Clear RTC
Pin(3&4): Clear CMOS
Pin(5&6): ME Disable
6-Pin Block
2.0mm
JPCAS_80P
Pin (1&2): SHORT_CASE OPEN
Pin(3&4): SHORT_80 PORT
4-Pin Block
2.0mm
JPCOM1
COM1 Pin9 Function Select
4-Pin Block
2.0mm
JPCOM2
FP_COM2 Pin9 Function Select
4-Pin Block
2.0mm
M2B_PWR
M.2 B-key Power Select
3-Pin Block
2.0mm
M2E_PWR
M.2 E-key Power Select
3-Pin Block
2.0mm
M2M_PWR
M.2 M-key Power Select
3-Pin Block
2.0mm
Chapter 2
Hardware Installation
2-1 Jumper Setting
AT_MODE (3-pin): ATX Mode/AT Mode Select Pitch=2.0mm
1
3
1
3
1-2 Closed：ATX Mode Selected;
2-3 Closed：AT Mode Selected.
*ATX Mode Selected: Press power button to power on after power input ready;
AT_MODE

7
AT Mode Selected: Directly power on as power input ready.
Pin (1-2) of JBAT (6-pin): Clear RTC Pitch=2.0mm
1-2 Closed: Clear RTC.
1-2 Open: Normal(Default);
2
Pin 1
Pin 1
2
Pin (3-4) of JBAT (6-pin): Clear CMOS Pitch=2.0mm
3-4 Closed: Clear CMOS.
3-4 Open: Normal(Default);
2
Pin 1
Pin 1
2
3
4
3
4
JBAT
JBAT

8
Pin (5-6) of JBAT (6-pin): ME Disable Pitch=2.0mm
5-6 Closed: ME Disable.
5-6 Open: Normal(Default);
2
Pin 1
Pin 1
2
3
4
3
4
5
6
5
6
Pin (1-2) of JPCAS_80P (4-pin): SHORT_CASE OPEN Pitch=2.0mm
3
4
1-2 Open: Normal(Default);
2
1
1-2 SHORT:CASE OPEN
1
2
3
4
JBAT
JPCAS_80P

9
PIN (3-4) of JPCAS_80P (4-pin): SHORT_80 PORT Pitch=2.0mm
3
4
3-4 Open: Normal(Default);
2
1
3-4 SHORT:80 PORT
1
2
3
4
JPCOM1 (4-pin) :COM1 Pin9 Function Select Pitch=2.0mm
4-6 Closed:
RI=12V
3-4 Closed:
RI=5V
2-4 Closed:
RI=RS232
1
3
5
4
6
2
6
4
2
5
3
1
6
4
2
5
3
1
JPCAS_80P
JPCOM1
COM1

10
JPCOM2 (4-pin) :FP_COM2 Pin9 Function Select Pitch=2.0mm
4-6 Closed:
RI=12V
3-4 Closed:
RI=5V
2-4 Closed:
RI=RS232
1
3
5
4
6
2
6
4
2
5
3
1
6
4
2
5
3
1
M2B_PWR (3-pin): M.2 B-key Power Select Pitch=2.0mm
2-3 Closed:
VCC= 3VSB
1-2 Closed:
VCC= VCC3
1
3
2
1
3
2
M2B_PWR
JPCOM2
FP_COM2

11
M2E_PWR (3-pin): M.2 E-key Power Select Pitch=2.0mm
2-3 Closed:
VCC= 3VSB
1-2 Closed:
VCC= VCC3
1
3
2
1
3
2
M2M_PWR (3-pin): M.2 M-key Power Select Pitch=2.0mm
2-3 Closed:
VCC= 3VSB
1-2 Closed:
VCC= VCC3
1
3
2
1
3
2
M2E_PWR
M2M_PWR

12
2-2 Connectors and Headers
2-2-1 Connectors
(1) Rear I/O Connectors
Icon
Name
Function
12V DC-in Power
Connector (Lockable)
For user to connect compatible power
adapter to provide power supply for the
system.
USB 2.0 Port
To connect USB keyboard, mouse or other
devices compatible with USB specification.
USB 3.1(Gen.2) Port
To connect USB keyboard, mouse or other
devices compatible with USB specification.
USB 3.1(Gen.2) ports supports up to
10Gbps data transfer rate.
2.5Gbps RJ-45 LAN Port
This connector is standard 2.5Gbps RJ-45
LAN jack for Network connection.
RS232/485/422
COM1 Serial Port
2.5Gbps RJ-45 LAN Ports
(LAN 1/2/3/4)
USB 2.0 Port
USB 3.1(Gen.2) Port
12V DC-in
PowerConnector
(Lockable)

13
RS232/485/422 Serial Port
Mainly for user to connect external MODEM
or other devices that supports Serial
Communications Interface.
(2) ATXPWR (2-pin Block): Internal 12V DC-in Power Connector
Pin1
Pin.
Definition
1
GND
2
+12V DC_IN
(3) SATA1 (7-pin): STATIII Port Connector
SATA1 is a high-speed SATAIII port that supports 6Gb/s transfer rate.
Pin No.
Definition
1
GND
2
TXP
3
TXN
4
GND
5
RXN
6
RXP
7
GND
ATXPWR
SATA1

14
(4) SATAPWR (4-pin): SATA HDD Power-Out Connector
Pin1
Pin No.
Definition
1
+5V
2
GND
3
GND
4
+12V
Warning: Make sure that Pin-1 of compatible SATA Power connector is inserted into corresponding
Pin-1 of SATAPWR to avoid possible damage to the board and hard disk driver!
(5) CPUFAN (4-pin): CPU FAN Connector
Pin1
+12V Fan Power
GND
Fan Speed
Control
SATAPWR
CPUFAN

15
2-2-2 Headers
(1) JW_FP (8-pin): Front Panel Header Pitch=2.54mm
HDDLED+
GPIO30
Pin1
2
HDDLED-
GPIO32
RSTSW
GND
PWRLED+
PWRBTN
GND
PWRLED-
(2) SMBUS (5-pin): SM BUS Header Pitch=2.0mm
Pin1
SMBUS_ALERT
SMBUS_DATA
VCC3
SMBUS_DA
TA
GND
SMBUS_DA
TA
SMBUS_CLK
JW_FP
SMBUS
