JETWAY MI92 User manual

TECHNICAL MANUAL
of
Intel Q470E Express Chipset
Based Mini-ITX M/B
NO. G03-MI92-F
Revision: 1.0
Release date: November 30, 2020
Trademark:
* Specifications and Information contained in this documentation are furnished for information use only, and are
subject to change at any time without notice, and should not be construed as a commitment by manufacturer.

i
Environmental Protection Announcement
Do not dispose this electronic device into the trash while discarding. To minimize
pollution and ensure environment protection of mother earth, please recycle.

ii
ENVIRONMENTAL SAFETY INSTRUCTION............................................................................. iii
USER’S NOTICE...............................................................................................................................iv
MANUAL REVISION INFORMATION...........................................................................................iv
ITEM CHECKLIST............................................................................................................................ iv
CHAPTER 1 INTRODUCTION OF THE MOTHERBOARD
1-1 FEATURE OF MOTHERBOARD.........................................................................................1
1-2 SPECIFICATION.................................................................................................................... 2
1-3 LAYOUT DIAGRAM...............................................................................................................3
CHAPTER 2 HARDWARE INSTALLATION
2-1 JUMPER SETTING................................................................................................................ 7
2-2 CONNECTORS AND HEADERS........................................................................................ 11
2-2-1 CONNECTORS........................................................................................................11
2-2-2 HEADERS................................................................................................................ 15
CHAPTER 3 INTRODUCING BIOS
3-1 ENTERING SETUP................................................................................................................ 20
3-2 BIOS MENU SCREEN...........................................................................................................21
3-3 FUNCTION KEYS...................................................................................................................22
3-4 GETTING HELP......................................................................................................................22
3-5 MENU BARS........................................................................................................................... 23
3-6 MAIN MENU............................................................................................................................ 24
3-7 ADVANCED MENU................................................................................................................25
3-8 CHIPSET MENU..................................................................................................................... 41
3-9 SECURITY MENU.................................................................................................................. 45
3-10 BOOT MENU........................................................................................................................... 48
3-11 SAVE & EXIT MENU..............................................................................................................49
TABLE OF CONTENT

iii
Environmental Safety Instruction
Avoid the dusty, humidity and temperature extremes. Do not place the product in
any area where it may become wet.
0 to 40 centigrade is the suitable temperature. (The temperature comes from the
request of the chassis and thermal solution)
Generally speaking, dramatic changes in temperature may lead to contact
malfunction and crackles due to constant thermal expansion and contraction from
the welding spots’ that connect components and PCB. Computer should go
through an adaptive phase before it boots when it is moved from a cold
environment to a warmer one to avoid condensation phenomenon. These water
drops attached on PCB or the surface of the components can bring about
phenomena as minor as computer instability resulted from corrosion and oxidation
from components and PCB or as major as short circuit that can burn the
components. Suggest starting the computer until the temperature goes up.
The increasing temperature of the capacitor may decrease the life of computer.
Using the close case may decrease the life of other device because the higher
temperature in the inner of the case.
Attention to the heat sink when you over-clocking. The higher temperature may
decrease the life of the device and burned the capacitor.

iv
USER’S NOTICE
COPYRIGHT OF THIS MANUAL BELONGS TO THE MANUFACTURER. NO PART OF THIS MANUAL,
INCLUDING THE PRODUCTS AND SOFTWARE DESCRIBED IN IT MAY BE REPRODUCED, TRANSMITTED
OR TRANSLATED INTO ANY LANGUAGE IN ANY FORM OR BY ANY MEANS WITHOUT WRITTEN
PERMISSION OF THE MANUFACTURER.
THIS MANUAL CONTAINS ALL INFORMATION REQUIRED TO USE THIS MOTHER-BOARD SERIES AND WE
DO ASSURE THIS MANUAL MEETS USER’S REQUIREMENT BUT WILL CHANGE, CORRECT ANY TIME
WITHOUT NOTICE. MANUFACTURER PROVIDES THIS MANUAL “AS IS” WITHOUT WARRANTY OF ANY
KIND, AND WILL NOT BE LIABLE FOR ANY INDIRECT, SPECIAL, INCIDENTAL OR CONSEQUENTIAL
DAMAGES (INCLUDING DAMAGES FOR LOSS OF PROFIT, LOSS OF BUSINESS, LOSS OF USE OF DATA,
INTERRUPTION OF BUSINESS AND THE LIKE).
PRODUCTS AND CORPORATE NAMES APPEARING IN THIS MANUAL MAY OR MAY NOT BE
REGISTERED TRADEMARKS OR COPYRIGHTS OF THEIR RESPECTIVE COMPANIES, AND THEY ARE
USED ONLY FOR IDENTIFICATION OR EXPLANATION AND TO THE OWNER’S BENEFIT, WITHOUT
INTENT TO INFRINGE.
Manual Revision Information
Reversion Revision History Date
1.0 First Edition November 30, 2020
Item Checklist
Motherboard
Cable(s)

1
Chapter 1
Introduction of the Motherboard
1-1 Feature of Motherboard
Intel®Q470E express chipset
LGA 1200 CPU socket for the 10th Intel®Core™i7/ i5 /i3, Celeron & Pentium®
processors (TDP Max support 65W)
Support 2* DDR4 Max 2933MHz SO-DIMM up to 64GB and dual channel function
2* HDMI port, DP port & eDP with support for 3 independent displays
Integrated with 2 *Intel Gigabit Ethernet LAN chip
Support 2 * COM port (COM1/2 support RS232/422/485)
Support up to 4 * USB 3.1 Gen.2 port,2 * USB 3.1 Gen.1 port & 2 * USB 2.0 port
Support 4 * SATAIII (6Gb/s) Devices with RAID 0, 1, 5, 10 mode
Support 1* PCIE 3.0 x16 slot, 1 * M.2 M-key 2280 slot (SATA/PCIex4) support
NVMe, 1* M.2 E-key 2230 slot (PCIex1/USB2.0) support CNVi
Support onboard TPM 2.0 (option)
Support Smart FAN function
Supports ACPI S3 Function
Compliance with ErP Standard
Support Watchdog Timer Technology
Solution for Edge Computing / Digital Signage/Industrial PCs/Factory
Automation/Public Sector/Digital Security/Surveillance

2
1-2 Specification
Spec
Description
Design
Mini-ITX form factor; PCB size:17.0x17.0cm
Chipset
Intel Q470E Express Chipset
CPU Socket
Intel LGA 1200 Socket supports 10th Core
i7/i5/i3/Pentium/Celeron processors (Max. 65W TDP)
*Note:for detailed CPU support information please visit our
website
Memory Slot
2*DDR4 SO-DIMM slot support 2* DDR4 SDRAM
Maximum frequency: 2933MHz
Maximum capacity: up to 64GB
Support dual channel function
*Note:Memory frequency range also depends on CPU support
Expansion
Slot
1* PCIE x16 slot (PCIE2)
1* M.2 E-key 2230 PCIex1/USB2.0 slot support CNVi (M2E)
*Note:M2E slot maximum current limit is 2A while using 3.3V.
Storage
4*SATAIII 6G/s ports with support for RAID 0/1/5/10 mode
1*M.2 M-key 2280 SATA/PCIex4 slot support NVMe(M2M)
*Note:M2M slot maximum current limit is 2A while using 3.3V.
Gigabit LAN
Chip
1* Intel i211AT Gigabit Ethernet LAN chip & 1* Intel i219-LM
Gigabit PHY LAN chip
Support Fast Ethernet LAN function of providing
10/100/1000Mbps Ethernet data transfer rate
Audio Chip
Realtek 6-channel Audio Codec integrated
Audio driver and utility included
BIOS
128Mb AMI Flash ROM
Multi I/O
Rear Panel I/O:
2* RS232/422/485 COM port (COM1-2)
2* HDMI port & 1* DP port
4* USB 3.2 (Gen.2) 10Gbps port

3
2* USB 3.2 (Gen.1) 5Gbps port
2* RJ-45 LAN port
1* 3-jack audio connector (Line-in, Line-out, MIC)
Internal I/O Connectors & Headers:
1* 24-pin main power connector
1* 4-pin 12V power connector
1* CPUFAN connector & 1* SYSFAN connector
1* Front panel header
1* 9-Pin USB 2.0 header for 2* USB 2.0 ports
1* GPIO header
1* SMBUS header
1* PS2 Keyboard & Mouse header
1* Front panel audio header
1* EDP header
1-3 Layout Diagram
Rear IO Diagram
HDMI Port
USB3.2 (Gen.2)
Ports
COM1
RS232/422/485
Serial Port
COM2
RS232/422/485
Serial Port
HDMI Port
DP Port
RJ-45 LAN Ports
USB 3.2 (Gen.1)
Ports
Line-In
Line-Out
MIC

4
Motherboard Internal Diagram
LGA 1200
CPU Socket
Intel Q470E Chipset
ATX Type
Main Power Connector
DDR4
SODIMM Slots
(SODIMM1/SODIMM2)
Front Panel
Header
GPIO
Header
USB 2.0 Port
Header
Front Panel
Audio Header
M.2 E-Key Slot
(M2E)
M.2 M-Key Slot
(M2M)
PCIE x16 Slot
(PCIE2)
ATX 12V
Power Connector
SYSFAN1 Connector
CPUFAN1
Connector
SMBUS Header
EDP Port Header
PS/2 Keyboard &
Mouse Header
4*SATAIII Ports
*Rear IO
Connector
(Refer to Page-3)

5
Motherboard Jumper Positions
JP13
JAT_ATX
JP2
JBAT
JP12
COPEN

6
Jumper
P/N
Name
Description
Pitch
JP12
COM1 Port Pin9 Function Select
4-pin Block
2.0mm
JP13
COM2 Port Pin9 Function Select
4-pin Block
2.0mm
JBAT
Clear CMOS RAM Settings
3-pin Block
2.0mm
JP2
Flash Descriptor Override
2-pin Block
2.0mm
JAT_ ATX
ATX Mode / AT Mode Select
3-pin Block
2.0mm
COPEN
Case Open Display Select
2-pin Block
2.0mm
Connectors
P/N
Name
COM1-2
RS232/422/485 Serial COM Port Connector X2
HDMI1_2
HDMI Port Connector X2
DP
Display Port Connector
USB3
USB 3.2 (Gen.1) Port Connector X2
UL2/UL1
Top: RJ-45 LAN Connector X2
Mid. & Bottom: USB 3.2 (Gen.2) Port Connector X4
AUDIO
Top: Line-in Connector
Middle: Line-out Connector
Bottom: MIC Connector
ATXPWR
ATX Type Main Power Connector
ATX12V
12V Power Connector
SATA1/2/3/4
SATAIII Port Connector
CPUFAN1
CPU FAN Connector
SYSFAN
System FAN Connector
Headers
P/N
Name
Description
Pitch
FP
Front Panel Header(PWR LED/ HD
LED/Power Button /Reset)
9-pin Block
2.54mm
GPIO
GPIO Port Header
10-pin Block
2.0mm
FP_USB1
USB 2.0 Port Header
9-pin Block
2.0mm

7
SMBUS
SMBUS Header
5-pin Block
2.0mm
FP_AUDIO
Front Panel Audio Header
9-pin Block
2.0mm
PS2KBMS1
PS2 Keyboard & Mouse Header
6-pin Block
2.54mm
EDP
EDP Header
40-pin Block
1.25mm
Chapter 2
Hardware Installation
2-1 Jumper Setting
JP12 (4-pin): COM1 Port Pin9 Function Select
*Note:Maximum current limit is 500mA while using 5V or 12V.
JP12

8
JP13 (4-pin): COM2 Port Pin9 Function Select
*Note:Maximum current limit is 500mA while using 5V or 12V.
JBAT (3-pin): Clear CMOS RAM Settings
JP13
JBAT

9
JP2(2-pin): Flash Descriptor Override Select
Pin1
JP2 → Flash Descriptor Override
Pin1
1-2 Closed: Disable Flash
Descriptor Security (override).
1-2 Open: Enable Security Measures
in the Flash Descriptor(Default);
JAT_ATX (3-pin): ATX Mode/AT Mode Select
*ATX Mode Selected: Press power button to power on after power input ready;
AT Mode Selected: Directly power on as power input ready.
JP2
JAT_ATX

10
COPEN (2-pin): Case Open Message Display Function Select
COPEN → Case Open Detection
Override
Pin1
CASE OPEN
GND
Pin (1&2) Closed:When Case open function pin short to GND, the Case open
function was detected. When used, needs to enter BIOS and enable ‘Case Open
Detect’function. In this case if your case is removed, next time when you restart your
computer, a message will be displayed on screen to inform you of this.
COPEN

11
2-2 Connectors and Headers
2-2-1 Connectors
Rear Panel Connectors
*Refer to Page-3 Rear IO Diagram
Icon
Name
Function
RS232/422/485
Serial Port
Mainly for user to connect external MODEM or other
devices that supports
Serial Communications Interface.
HDMI Port
To connect display device that support HDMI
specification.
Display Port
To the system to corresponding display device with
compatible DP cable.
USB 3.2 (Gen.1) Port
To connect USB keyboard, mouse or other devices
compatible with USB 3.2 (Gen.1) specification. Ports
support up to 5Gbps data transfer rate.
RJ-45 LAN Port
This connector is standard RJ-45 LAN jack for
Network connection.
USB 3.2 (Gen.2) Port
To connect USB keyboard, mouse or other devices
compatible with USB 3.2 (Gen.2) specification. Ports
support up to 10Gbps data transfer rate.
Audio Connectors
Blue: Line-in Connector
Green: Line-out Connector
Pink : MIC Connector
*Note:Maximum current limit for USB ports from UL1/UL2/USB3 is 1.5A while using
5V working voltage.

12
(1) COM1-2: RS232/422/485 Ports
COM1/COM2 port can function as RS232/422/485 port. In normal settings
COM1/COM2 functions as RS232 port. With compatible COM cable COM1/COM2
can function as RS422 or RS 485 port. User also needs to go to BIOS to set
‘Transmission Mode Select’ for COM1/COM2 at first, before using specialized cable
to connect different pins of this port.
1
2
3
4
5
6
7
8
9
RS232 DCD#
RS232 SIN
RS232 SOUT
RS232 DTR#
GND
RS232 RI#
RS232 CTS#
RS232 RTS#
RS232 DSR#
Pin1
For RS422 Mode
RS422TX-(B)
RS422TX+(A)
RS422RX+(A)
RS422RX-(B)
(B)
For RS485 Mode
RS485 D-(B)
RS485 D+(A)

13
(2) ATXPWR(24-pin block): Main Power Connector
PIN
ROW1
ROW2
1
+3.3V
+3.3V
2
+3.3V
-12V
3
GND
GND
4
+5V
Soft Power on
5
GND
GND
6
+5V
GND
7
GND
GND
8
Power OK
-5V
9
+5V Stand by
+5V
10
+12V
+5V
11
+12V
+5V
12
+3.3V
GND
Pin1
Pin12
Row1
Row2
(3) ATX12V (4-pin block): ATX-Type 12V Power Connector
Pin No.
Definition
1
GND
2
GND
3
+12V
4
+12V
Pin1
4
2
3

14
(4) SATA1/2/3/4 (7-pin): SATAIII Port connector
These are high-speed SATAIII port that supports 6GB/s transfer rate.
Pin No.
Definition
1
GND
2
TXP
3
TXN
4
GND
5
RXN
6
RXP
7
GND
(5) CPUFAN1 (4-pin): CPU Fan Connector
Pin1
+12V Fan Power
GND
Fan Speed
Control
*Note: Maximum current limit is 1.5A while using 12V working voltage.
CPUFAN1
SATA2
SATA4
SATA1
SATA4

15
(6) SYSFAN1(4-pin): System Fan Connector
Pin1
+12V Fan Power
GND
Fan Speed
Control
*Note:Maximum current limit is 1.5A while using 12V working voltage.
2-2-2 Headers
(1) FP (9-pin): Front Panel Header
GND
RSTSW
Pi n1
2
HDDLED+
HDDLED-
VCC5V
PWRLED+
PWRLED-
PWRBTN
GND
*Note:Maximum current limit is 1A while using 5V working voltage.
FP
SYSFAN1
