JETWAY NF695 Series User manual

NF695 Series
User sManual
NO. G03-NF695-F
Revision: 2.0
Release date:October18,2018
Trademark:
*Specifications and Information contained inthis documentation arefurnished forinformation use only,and are
subjecttochangeat anytimewithout notice,and shouldnot be construed asacommitmentbymanufacturer.

ii
Environmental Protection Announcement
Donotdisposethiselectronicdeviceintothe trashwhilediscarding.Tominimize
pollutionandensureenvironmentprotectionofmotherearth,pleaserecycle.

iii
ENVIRONMENTALSAFETYINSTRUCTION.......................................................................... iv
USER SNOTICE....................................................................................................................... v
MANUALREVISIONINFORMATION...................................................................................... v
ITEMCHECKLIST..................................................................................................................... v
CHAPTER 1 INTRODUCTION OF THEMOTHERBOARD
1-1FEATUREOF MOTHERBOARD............................................................................... 1
1-2SPECIFICATION......................................................................................................... 2
1-3LAYOUTDIAGRAM................................................................................................... 4
CHAPTER 2 HARDWAREINSTALLATION
2-1JUMPER SETTING..................................................................................................... 10
2-2CONNECTORSANDHEADERS............................................................................... 15
2-2-1CONNECTORS............................................................................................. 15
2-2-2HEADERS..................................................................................................... 18
CHAPTER 3 INTRODUCINGBIOS
3-1ENTERINGSETUP..................................................................................................... 26
3-2BIOSMENU SCREEN................................................................................................ 27
3-3FUNCTION KEYS....................................................................................................... 27
3-4GETTINGHELP.......................................................................................................... 28
3-5MEMU BARS.............................................................................................................. 28
3-6MAIN MENU................................................................................................................ 29
3-7ADVANCED MENU.................................................................................................... 30
3-8CHIPSETMENU......................................................................................................... 42
3-9SECURITYMENU....................................................................................................... 45
3-10BOOTMENU.............................................................................................................. 48
3-11SAVE& EXITMENU .................................................................................................. 49
TABLE OF CONTENT

iv
Environmental SafetyInstruction
lAvoidthe dusty,humidityand temperatureextremes.Donotplacethe productin
anyarea whereitmaybecomewet.
l0to60 centigrade isthesuitabletemperature.(The figurecomesfromthe request
ofthemainchipset)
lGenerallyspeaking,dramaticchangesintemperaturemaylead tocontact
malfunctionandcracklesdue toconstantthermalexpansionandcontractionfrom
the weldingspots thatconnectcomponentsandPCB.Computershouldgo
throughanadaptivephasebeforeitbootswhen itismovedfromacold
environmenttoawarmeronetoavoidcondensationphenomenon.Thesewater
dropsattached onPCBorthe surfaceofthe componentscan bringabout
phenomenaasminorascomputerinstabilityresultedfromcorrosionand oxidation
fromcomponentsandPCBorasmajorasshortcircuitthatcan burnthe
components.Suggeststartingthe computeruntil thetemperaturegoesup.
lTheincreasingtemperatureofthecapacitormaydecreasethelifeofcomputer.
Usingthe closecasemaydecreasethelifeofotherdevicebecausethehigher
temperatureintheinnerofthe case.
lAttention totheheatsinkwhen you over-clocking.The highertemperaturemay
decreasethelifeofthedeviceandburnedthecapacitor.

v
USER SNOTICE
COPYRIGHTOFTHIS MANUALBELONGSTOTHE MANUFACTURER. NOPARTOFTHISMANUAL,
INCLUDINGTHE PRODUCTSAND SOFTWARE DESCRIBED IN ITMAYBEREPRODUCED, TRANSMITTED
ORTRANSLATED INTOANY LANGUAGEIN ANYFORMORBY ANY MEANSWITHOUTWRITTEN
PERMISSION OFTHE MANUFACTURER.
THIS MANUALCONTAINS ALL INFORMATIONREQUIREDTOUSE THIS MOTHER-BOARD SERIESANDWE
DOASSURE THISMANUALMEETSUSER SREQUIREMENTBUTWILL CHANGE,CORRECTANY TIME
WITHOUTNOTICE.MANUFACTURER PROVIDES THIS MANUAL “ASIS”WITHOUTWARRANTYOFANY
KIND, AND WILL NOTBE LIABLEFORANY INDIRECT,SPECIAL,INCIDENTIALORCONSEQUENTIAL
DAMAGES (INCLUDINGDAMANGES FORLOSS OFPROFIT,LOSS OFBUSINESS, LOSS OFUSE OFDATA,
INTERRUPTION OFBUSINESS AND THE LIKE).
PRODUCTSANDCORPORATENAMES APPEARINGIN THIS MANUALMAY ORMAYNOTBE
REGISTERED TRADEMARKSORCOPYRIGHTSOFTHEIR RESPECTIVE COMPANIES, AND THEY ARE
USED ONLYFORIDENTIFICATIONOREXPLANATIONAND TOTHE OWNER SBENEFIT,WITHOUT
INTENTTOINFRINGE.
ManualRevision Information
ReversionRevision HistoryDate
2.0SecondEditionOctober18, 2018
ItemChecklist
RMotherboard
RUser sManual
RCD formotherboardutilities
RCable(s)

1
Chapter 1
Introduction ofthe Motherboard
1-1 Featureof Motherboard
lIntel®ApolloLakeseriesSoCProcessor,withlowpowerconsumptionnever
denieshighperformance
l1*SO-DIMM slot supports1*1867MHzDDR3L SO-DIMM, upto8GB
l
RealtekALC662Audio
l
1/2*10/100/1000 based-TXethernet ports(optional)
lOnboard1*SATAIII port&1*M.2Socket3slotforM-Keytype 2242/2260 SATA
SSD
lSupport HDMI/VGA/LVDS oreDPmultiple-displaysolution (optional)
lSupport 2/10*COMport expansion(optional)
l4*ExternalUSB 3.0&6/2*InternalUSB 2.0(optional)
lOnboard1* full-sizeMini-PCIE slot& 1*SIMcardslot(optional)
l1*InternalPS2Keyboard& Mousepinheader
lCompliancewithErP standard
lSupportWatchdogfunction
lSupportTPMfunction(optional)
lSolutionforDigitalSignage, POS & IndustrialAutomation

2
1-2 Specification
Spec
Description
Design lMini-ITXformfactor; PCBsize: 17.0x17.0cm
CPUl
Intel®ApolloLake *SoC CPU
*CPU modelvaries fromdifferentIPC options. Please consult your
dealer formoreinformation ofonboardCPU.
Memory l1*DDR3L SO-DIMMslot
lSupport DDR3L 1867MHzSO-DIMMup to8GB
ExpansionSlot lMPE1:1*full-sizeMini-PCIEslot
l
SIMCARD: 1*SIMcardslot (Optionalfor NF695HV series)
Storage l1*SATAIII 6Gb/sport
l1*M.2Socket3slot(M2, M-key,supporttype-2242 /2260SATA
SSD)
LANChip
l2*RTL8111H GbE(Optionalfor NF695HV series)
l1*RTL8111H GbE(Optionalfor NF695L series)
l
Support FastEthernetLAN functionof providing
10/100/1000Mbps Ethernet datatransferrate
AudioChip lRealtek ALC662 HD AudioCodec integrated
lAudiodriver and utilityincluded
BIOS lAMI Flash ROM
RearI/O
l1*DCIN (12V)Power Jack
l2*RJ-45 LANport (Optionalfor NF695HV series)
l1*RJ-45 LANport (Optionalfor NF695L series)
l1*HDMI port+1*VGAport (Optional for NF695HV series)
l2*HDMI port (Optional for NF695L series)
l
4*USB3.0port
l
1*Line-out port

3
Internal I/O
l1*Front panelheader
l3*9-pinUSB 2.0header (Optionalfor NF695HV series)
l1*9-pinUSB 2.0header(Optionalfor NF695L series)
lCOM1/2: 2*9-pinSerialportheader
l
COM3-6/COM7-10 : 2*Serialportheaderexpansion block
(Optionalfor NF695HV series)
l
2*LAN activityLEDheader (Optionalfor NF695HV series)
l
1*LAN activityLEDheader(Optional for NF695L series)
l
1*PS2Keyboard/Mouse header
l1*Front panelaudioheader
l1*10-pinGPIOheader
l1*SMBUS header
l1*frontpanelbuzzer header
l1*LVDS header(*Selectablewith EDP)
l1*EDP header(*Selectablewith LVDS)
l1*LVDS/EDP inverterheader
Note:
1. The module should be DDR3L1.35V SODIMM and not exceeding 8GB total capacity.
2.TheSODIMM installed should be of orabovethe memory clock the modelsupported, otherwisethe
board will not start.

4
1-3 LayoutDiagram
RearIOPanel Diagram:
NF695HVSeries:
NF695LSeries:
Warning!!The boardhasa12VDC-inpowerconnector(DCIN3)inI/O back panelandan
internal12Vpowerconnector(DCIN2). Usercanonlyconnectone type ofcompatiblepower
supplytoone ofthemtopower the system.
DCIN
LAN1
RJ-45
LAN Port
HDMI1
Port
USB3.0
Ports
Line-out
VGA
Port
LAN2
RJ-45
LAN Port
Line-out
DCIN
HDMI2
Port
LAN1
RJ-45
LAN Port
HDMI1
Port
USB3.0
Ports

5
MotherboardInternal Diagram
NF695HVSeries:
Note: SIMCARD slot onlywork when compatibleSIMcard installed&3GLANcard installed infull-sizeMini-PCIE (MPE1) slot.
*RearIO
Connector
(RefertoPage-4)
IntelCPU
SATAP
ower
-
out
Connector
Full-size
Mini-
PCIE Slot
(MPE1)
M.2Socket3Slot
(M2)
*
SIMCARD
Slot
EDP
USB 2.0Ports
Front Panel
Header
*
Serial PortHeaderBlock
(COM7
-
10)
*
Serial PortHeaderBlock
(COM3
-
6)
SerialPort Headers
(COM1/COM2)
Front Panel
Audio
Header
PS/2 Keyboard&
Mouse
Header
Inverter
LVDS
SATA
III
Port
FP_BUZZ
Header
CPUFAN
SMBUSHeader
SYSFAN
GPIO
Port
Header
Internal
12V
DC-inConnector
DDR3L
Slot
(SODIMM1)
*LAN1_LEDHeader
*LAN2_LEDHeader

6
NF695LSeries:
*RearIO
Connector
(RefertoPage-5)
IntelCPU
SATAP
ower
-
out
Connector
Full-size
Mini-
PCIE Slot
(MPE1)
M.2Socket3Slot
(M2)
EDP
USB 2.0Port
Front Panel
Header
SerialPort Headers
(COM1/COM2)
Front Panel
Audio
Header
PS/2 Keyboard&
Mouse
Header
Inverter
LVDS
SATA
III
Port
FP_BUZZ
Header
CPUFAN
SMBUSHeader
SYSFAN
GPIO
Port
Header
Internal
12V
DC-inConnector
DDR3L
Slot
(SODIMM1)
*LAN1_LEDHeader

7
JumperPositions:
*Note: thediagramaboveisfrom NF695HV seriesand servesasillustration purposeonly. JMD3 is
optionalto NF695HV seriesmodels, please referto themodelyou purchased foractualspecifications.
JP2
JMD1
JMD2
*JMD3
JP1
ATX_AT
JP4
JP3

8
Jumper
Jumper Name Description
JMD1 COM1SerialPortPowerSelect4-pinBlock
JMD2 COM2SerialPortPowerSelect 4-pinBlock
*JMD3
(Optional) COM3SerialPortPowerSelect 4-pinBlock
JP1 MPE1 Mini-PCIE Power3VSB / 3.3VSelect 3-PinBlock
ATX_AT ATXMode/ ATModeSelect 3-PinBlock
JP4 LVDS/EDPInverterPower3.3V/5V/12V Select3-pinBlock
JP3 LVDS/EDPPanelPower3.3V/5V/12V Select 4-pinBlock
JP2
Pin1&2 CASE OPEN
Pin3&4 TXE Override
Pin5&6 ClearCMOS
Pin7&8 ClearME_RTC
8-pinBlock
*Note: JumperJMD3 isonlyoptionalfor NF695HV series.
Connectors
Connector Name
DCIN3 12V DC inputPowerJack
*
HDMI2
(Optional) HDMI Port Connector
*VGA
(Optional) VGA Port Connector
LAN1 RJ-45 LANPort Connector
*
LAN2
(Optional) RJ-45 LANPort Connector
HDMI1 HDMI Connector
USB31 USB3.0Port Connector
USB32 USB3.0Port Connector
FP_HP
T
op:
AudioLine-out Port Connector
DCIN2 Internal12V DC-inPowerConnector
SATA1 SATAIIIPort Connector

9
SATAPW SATA PowerConnector
CPUFAN CPUFan Connector
SYSFANSystemFanConnector
*Note: VGA/LAN2 isonlyoptionalfor NF695HV series; HDMI2 isonlyoptionalfor NF695L series.
Headers Header Name Description
FP Front PanelHeader
(PWRLED/ HDD LED/
PowerButton/Reset)
9-pinBlock
F_USB1/ F_USB2/
F_USB3 USB 2.0Header9-pinBlock
COM1 RS232 SerialPort Header 9-pinBlock
COM2 RS232 SerialPort Header 9-pinBlock
*COM3
-
6
(Optional)
RS232 SerialPort ComboBlock 36-pinBlock
*COM7
-
10
(Optional)
RS232 SerialPort ComboBlock 36-pinBlock
LAN1_LED LANActivityLEDHeader2-pinBlock
*LAN2_LED
(Optional)
LANActivityLEDHeader2-pinBlock
PS2KBMS PS2 keyboard&Mouse 6-pinBlock
FP_AUDIO Front PanelAudioHeader 9-pinBlock
GPIO GPIO Port Header 10-pinBlock
SMBUS SMBUS Header 5-pinBlock
FP_BUZZ BuzzerHeader 2-pinBlock
INVERTER LVDS INVERTERHeader 8-pinBlock
EDP EDPWafer 40-pinBlock
LVDS LVDS Header 32-pinBlock
*Note: COM3-6/COM7-10/LAN2_LED isonlyoptionalfor NF695HV series.

10
Chapter 2
Hardware Installation
2-1 JumperSetting
(1)JMD1(4-pin): COM1PortPin9Function Select
JMD1
COM1 PortPin-9
6 4 2
3 1 5
1 3 5
2 4 6
1
3 5
2
4
6
2-4Closed:
RING(Default); 3-4Closed:
5V; 4-6Closed:
12V.
(2)JMD2(4-pin): COM2HeaderPin9FunctionSelect
JMD2
COM2 HeaderPin-9
6 4 2
3 1 5
1 3 5
2 4 6
1
3 5
2
4
6
2-4Closed:
RING(Default); 3-4Closed:
5V; 4-6Closed:
12V.
JMD1
J
MD2

11
(3)JMD3(4-pin): COM3HeaderPin9FunctionSelect
1 3
4
6 2
6 4 2
5 3 1
6
4 2
5 3 1
5
JMD3 COM3HeaderPin-9
2-4Closed:
RING(Default); 3-4Closed: 5V; 4-6Closed: 12V.
*Note: JMD3 isonlyoptionalfor NF695HV seriesmodelswith COM3 serialport header(from
COM3-6 combo block).
(4)JP1 (3-pin): MPE1Mini-PCIE SlotPowerVCC3.3V / 3VSBSelect
1
3
1
3
JP1 MPE1PowerVCCSelect
1-2Closed:MPE1VCC=3.3V(Default);
;
2-3Closed:MPEVCC=3VSB.
JMD3
JP1

12
(5)ATX_AT(3-pin): AT/ATX ModeSelect
1
3
1
3
ATX_AT ATX/ATModeSelect
1
-
2
C
losed
:
ATXMode
(Default)
;
;
2-3Closed:ATMode.
*ATX ModeSelected:Press powerbuttontopoweronafterpowerinputready;
ATModeSelected: Directlypoweronaspowerinputready.
(6)JP4 (3-pin): LVDS /EDP InverterBacklightVCC 5V/12V Select
1
3
1
3
JP4 LVDSPanel VCC Select
1
-
2
C
losed
:
VCC=5V
(Default)
;
;
2-3Closed:VCC=12V.
ATX_AT
JP4

13
(7)JP3 (4-pin): LVDS /EDP PanelVCC 3.3V/5V/12V Select
JP3
LVDSPanelVCC
4-6Closed:
VCC=12V.
6
5
4
3
2
1
3-4Closed:
VCC=5V;
2-4Closed:
VCC=3.3V
(Default);
3
4
1
2
5
6
6
5
4
3
2
1
1
2
3
4
5
2
6
5
4
3
2
1
1
2
3
4
5
2
(8)JP2 (8-pin): Jumper Combo Block
Pin1&2ofJP2 (8-pin): Case OpenMessageDisplayFunction Select
1-2Open:
Normal (Default);
1
1-2Closed:
Case Open.
1
2
2
Pin(1-2)Close: WhenCaseOpen function pinshorttoGND,theCaseOpen function
wasdetected.WhenUsed,needstoenterBIOSandenable Case OpenDetect’
function.Inthiscaseifyourcaseisremoved,nexttimewhen yourestartyour
computer, amessagewill be displayedonscreen toinformyou of this.
JP3
JP2

14
Pin3&4ofJP2 (8-pin): TXE OverrideSetting
3-4Open
Normal
(Default)
;
1
3-4Closed
TXEOverride.
1
2
2
3
4
3
4
Pin5&6ofJP2 (8-pin):ClearCMOS
5-6Open:
Normal (Default);
1
5-6Closed:
ClearCMOS.
1
2
2
3
4
5
6
3
4
5
6
Pin7&8ofJP2 (8-pin): ClearME_RTC
7-8Open
Normal (Default);
1
7-8Closed
ClearME_RTC.
1
2
2
3
4
5
4
6
7
8
3
5
7
4
6
8
JP2
JP2
JP2

15
2-2 Connectorsand Headers
2-2-1Connectors
(1)RearI/OConnectors
*RefertoPage-4.
Icon NameFunction
PowerJack 12VDC–insystempower connector
For user toconnect compatiblepower adapter to
provide power supplyfor the system.
HDMI Port
Toconnect displaydevicethat support HDMI
specification.
*VGAPort
(Optional) Toconnect displaydevicethat support VGA
specification.
RJ-45 LANPortThisconnector isstandardRJ-45LANjackfor
Networkconnection.
USB 3.0 Port ToconnectUSBkeyboard, mouseor other
devices compatiblewithUSB specification.USB
3.0portssupportsup to5Gbps datatransfer rate.
Line-Out
Thisconnector canfunctions as audioLine-Out
jackand MICjackwithcompatiblecables &
devices.
*Note: The diagramsabovearefrom NF695HV seriesand servesasillustration purposeonly.Inthe
case of anydifferencesplease referto the modelyou purchased foractualspecifications.
