JETWAY P4XFM User manual

P4XFM/P4XFMU/P4MFM/P4MFMU
P4MFU533/P4MFP533
P4MFU533T/P4MFP533T
USER'S MANUAL
M/B For Socket 478 Pentium 4 Processor
NO. G03-P4XFMR9A
Release date: March 2003
Trademark:
* Specifications and Information contained in this documentation are furnished for information use only, and are
subject to change at any time without notice, and should not be construed as a commitment by manufacturer.

i
USER’S NOTICE ............................................................................................................1
MANUAL REVISION INFORMATION ...........................................................................1
COOLING SOLUTIONS................................................................................................1
CHAPTER1 INTRODUCTION OF P4XFM//P4XFMU/P4MFM/P4MFMU/
P4MFU533/P4MFP533/P4MFMU533T/P4MFP533T MOTHERBOARD
1-1 FEATURE OF MOTHERBOARD..........................................................................2
1-2 SPECIFICATION .....................................................................................................3
1-3 PERFORMANCE LIST............................................................................................4
1-4 LAYOUT DIAGRAM & JUMPER SETTING.......................................................5
CHAPTER 2 HARDWARE INSTALLATION
2-1 HARDWARE INSTALLATION STEPS ................................................................7
2-2 CHECKING MOTHERBOARD'S JUMPER SETTING......................................7
2-3 INSTALL CPU ..........................................................................................................8
2-3-1 GLOSSARY....................................................................................................8
2-3-2 ABOUT INTEL PENTIUM 4 478-PIN CPU...............................................9
2-4 INSTALL MEMORY................................................................................................9
2-5 EXPANSION CARD.................................................................................................10
2-5-1 PROCEDURE FOR EXPANSION CARD INSTALLATION ..................10
2-5-2 ASSIGNING IRQ FOR EXPANSION CARD ............................................11
2-5-3 INTERRUPT REQUEST TABLE FOR THIS MOTHERBOARD..........11
2-5-4 AGP SLOT .....................................................................................................12
2-6 CONNECTORS, HEADERS....................................................................................12
2-6-1 CONNECTORS .............................................................................................12
2-6-2 HEADERS......................................................................................................15
2-7 STARTING UP YOUR COMPUTER.....................................................................18
CHAPTER 3 INTRODUCING BIOS
3-1 ENTERING SETUP..................................................................................................19
3-2 GETTING HELP.......................................................................................................19
3-3 THE MAIN MENU ...................................................................................................20
3-4 STANDARD CMOS FEATURES............................................................................21
3-5 ADVANCED BIOS FEATURES..............................................................................22
3-6 ADVANCED CHIPSET FEATURES......................................................................24
3-6-1 DRAM TIMING SETTINGS.......................................................................25
3-6-2 AGP FUNCTION SETTINGS......................................................................26
3-6-3 PCI TIMING SETTINGS.............................................................................26
3-7 INTEGRATED PERIPHERALS.............................................................................26
3-7-1 ONCHIP IDE FUNCTION...........................................................................27
3-7-2 ONCHIP DEVICE FUNCTION ..................................................................28
3-7-3 ONCHIP SUPER IO FUNCTION...............................................................29
3-8 POWER MANAGEMENT SETUP.........................................................................30
3-8-1 PM WAKE UP EVENTS .............................................................................31
3-8-1.1 IRQS ACTIVITIES....................................................................................31
3-9 PNP/PCI CONFIGURATION SETUP....................................................................32
3-9-1 IRQ RESOURCES........................................................................................33
3-10 PC HEALTH STATUS............................................................................................33
3-11 MISCELLANEOUS CONTROL............................................................................34
3-12 LOAD STANDARD/OPTIMIZED DEFAULTS...................................................35
3-13 SET SUPERVISOR/USER PASSWORD ..............................................................35
CHAPTER 4 DRIVER & FREE PROGRAM INSTALLATION
MAGIC INSTALL SUPPORTS WINDOWS 9X/ME/NT4.0/2000/XP..........................36
4-1 VIA 4 IN 1 INSTALL VIA SERVICE PACK 4 IN 1 DRIVER...........................37
4-2 VGA INSTALL VIA P4M266 VGA DRIVER...........................................38
4-3 SOUND INSTALL ALC/CMI AUDIO CODEC DRIVER..............................39
4-4 LAN INSTALL VIA 10/100MB LAN CONTROLLER DRIVER .............41
4-5 PC-HEALTH WINBOND HARDWARE DOCTOR MONITORING SOFTWARE.42
4-6 MAGIC BIOS INSTALL BIOS LIVE UPDATE UTILITY......................................43
4-7 USB2.0 INSTALL VIA USB2.0 DEVICE DRIVER......................................44
4-8 PC-CILLIN INSTALL PC-CILLIN2002 ANTI-VIRUS PROGRAM...................45
4-9 HOW TO DISABLE ON-BOARD SOUND............................................................46
4-10 HOW TO UPDATE BIOS ........................................................................................46
TABLE OF CONTENT

1
USER’S NOTICE
COPYRIGHT OF THIS MANUAL BELONGS TO THE MANUFACTURER. NO PART OF THIS MANUAL,
INCLUDING THE PRODUCTS AND SOFTWARE DESCRIBED IN IT MAY BE REPRODUCED,
TRANSMITTED OR TRANSLATED INTO ANY LANGUAGE IN ANY FORM OR BY ANY MEANS WITHOUT
WRITTEN PERMISSION OF THE MANUFACTURER.
THIS MANUAL CONTAINS ALL INFORMATION REQUIRED TO USE P4XFM/P4XFMU/P4MFM/P4MFU533/
P4MFP533/P4MFU533T/P4MFP533T MOTHER-BOARD AND WE DO ASSURE THIS MANUAL MEETS USER’S
REQUIREMENT BUT WILL CHANGE, CORRECT ANY TIME WITHOUT NOTICE. MANUFACTURER PROVIDES
THIS MANUAL “AS IS” WITHOUT WARRANTY OF ANY KIND, AND WILL NOT BE LIABLE FOR ANY
INDIRECT, SPECIAL, INCIDENTIAL OR CONSEQUENTIAL DAMAGES (INCLUDING DAMANGES FOR
LOSS OF PROFIT, LOSS OF BUSINESS, LOSS OF USE OF DATA, INTERRUPTION OF BUSINESS AND THE
LIKE).
PRODUCTS AND CORPORATE NAMES APPEARING IN THIS MANUAL MAY OR MAY NOT BE
REGISTERED TRADEMARKS OR COPYRIGHTS OF THEIR RESPECTIVE COMPANIES, AND THEY ARE
USED ONLY FOR IDENTIFICATION OR EXPLANATION AND TO THE OWNER’S BENEFIT, WITHOUT
INTENT TO INFRINGE.
Manual Revision Information
Reversion Revision History Date
9.0 Ninth Edition March 2003
Item Checklist
5P4XFM/P4XFMU/P4MFM/P4MFMU/P4MFU533/P4MFP533/P4MFMU533T/P4MFP533T
motherboard
5Cable for IDE/Floppy
□Cable for COM2 Connector (Option)
5CD for motherboard utilities
□Cable for USB Port 3/4 (Option)
5P4XFM/P4XFMU/P4MFM/P4MFMU/P4MFU533/P4MFP533/P4MFMU533T/P4MFP533T
User’s Manual
Intel Pentium 4 Processor Family
Cooling Solutions
As processor technology pushes to faster speeds and higher performance, thermal management
becomes increasingly crucial when building computer systems. Maintaining the proper thermal
environment is key to reliable, long-term system operation. The overall goal in providing the proper
thermal environment is keeping the processor below its specified maximum case temperature.
Heatsinks induce improved processor heat dissipation through increased surface area and concentrated
airflow from attached fans. In addition, interface materials allow effective transfers of heat from the
processor to the heatsink. For optimum heat transfer, Intel recommends the use of thermal grease and
mounting clips to attach the heatsink to the processor.
When selecting a thermal solution for your system, please refer to the website below for collection of
heatsinks evaluated and recommended by Intel for use with Intel processors. Note, those heatsinks are
recommended for maintaining the specified Maximum T case requirement. In addition, this collection
is not intended to be a comprehensive listing of all heatsinks that support Intel processors.
For vendor list of heatsink and fan, please visit :
http://developer.intel.com/design/Pentium4/components/index
Chapter 1

2
Introduction of P4XFM/P4XFMU/P4MFM/P4MFMU/
P4MFU533/P4MFP533/P4MFU533T/P4MFP533T Motherboard
1-1 Feature of motherboard
The P4XFM/ P4XFMU/ P4MFM/ P4MFMU/ P4MFU533/ P4MFP533/ P4MFU533T/
P4MFMP533T motherboard is design for use Intel Pentium 4 Processor in 478 Pin Package
Processor with the VIA P4X266E/P4M266/P4M266A(CE) Chipset delivers a high
performance and professional desktop platform solution. Which utilize the Socket 478 design
and the memory size expandable to 2.0GB.
These motherboards use the newest VIA P4X266E/P4M266/P4M266A(CE) Chipset.
Supports 533MHz System Bus in data transfer rate for P4XFM/P4XFMU/P4MFU533/
P4MFP533/P4MFU533T/P4MFP533T, P4MFU533T/P4MFP533T motherboard supports
Hyper Threading CPU, and 400MHz System Bus in data transfer rate in P4MFM/P4MFMU. The
motherboard provided 100MHz/133MHz Memory clock frequency, support PC133/ PC100
SDRAM and DDR266/DDR200 DDR Module. The VIA VT8233A/VT8235 V-Link LPC
South Bridge in P4XFM/ P4XFMU/ P4MFM/ P4MFMU/ P4MFU533/ P4MFPT533/
P4MFU533T /P4MFP533T offer ULTRA ATA 133 to provide speedier HDD throughout that
boosts overall system performance.
The P4MFPT embedded VIA VT6103 PHYceiver offer LAN function provide 10/100 MHz
full and half duplex operation.
These motherboards also has an integrated AC’97 2.1 CODEC on board which is fully
compatible with Sound Blaster Pro®that gives you the best sound quality and compatibility.
The P4MFM/P4MFMU/P4MFU533/P4MFP533/P4MFU533T/P4MFP533T integrated High
Performance & High Quality 3D Accelerator supports Ultra-AGPII with 2GB/s bandwidth,
built-in MPEG-2/1 Video Decoder and Video Accelerator supports VCD DVD HDTV
decoding and playback, supports graphic and video overlay function. Built-in programmable
24-bit true-color RAMDAC up to 250MHz pixel clock. Programmable frame buffer size from
8MB and up to 32MB. For those wanting even greater graphic performance, an AGP 4X slot
is included on the board, support AGP 2X/4X capability and Fast write Transaction.
With USB control as well as capability of expanding to 4 USB 1.1 function ports for
P4XFM/P4MFM delivering 2x12Mb/s bandwidth, expending to 6 USB 2.0 function ports for
P4XFMU/P4MFMU/P4MFU533/P4MFP533/P4MFU533T/P4MFP533T delivering 480Mb/s
bandwidth and rich connectivity, these motherboards meet future USB demand also has built-
in hardware monitor function to monitor and protect your computer.
A useful software tool “Magic BIOS” examines the BIOS version automatically with the
correct version available on the web, links the site for users to download the latest version of
BIOS and updates the BIOS. Use “Magic BIOS”, users can download and update BIOS
automatically and completed under the OS easily.
These motherboards provide high performance & meets future specification demand. It is
really wise choice for your computer.
1-2 Specification
Spec Description

3
Design ∗Micro ATX form factor 4 layers PCB size: 24.4x24.4cm
Chipset ∗VIA P4X266E North Bridge Chipset for P4XFM/P4XFMU
VIA P4M266 North Bridge Chipset for P4MFM/P4MFMU
P4M266A North Bridge for P4MFU533/P4MFP533
P4M266A(CE) North Bridge for P4MFU533T/P4MFP533T
∗VIA VT8233A South Bridge Chipset for P4XFM/P4MFM
VIA VT8235 South Bridge for P4XFMU/P4MFMU
/P4MFU533/P4MFP533/P4MFU533T/P4MFP533T
CPU Socket
(mPGA478B Socket) ∗Support Intel Pentium 4 478 Pin package utilizes Flip-Chip Pin
Grid Array (FC-PGA2) package processor
∗Support 1.5G∼2.8G 478 Pin Pentium 4 processor
P4MFU533T/P4MFP533T Support Hyper Threading CPU
∗Reserves support for future Intel Pentium 4 processors
Memory Socket ∗168-pin SDR SDRAM module socket x2 and 184-pin DDR
Module socket x 2
∗Support 2 pcs PC133 SDRAM Module expandable to 1.0GB, or
2 pcs DDR266/DDR200 DDR Modules Expandable to 2.0GB
Expansion Slot ∗AGP slot x1 support AGP 2.0 & 4X mode
∗32-bit PCI slot x3
Integrate IDE ∗Two PCI IDE controllers support PCI Bus Mastering, ATA
PIO/DMA and the ULTRA DMA 33/66/100/133 functions that
deliver the data transfer rate up to 133 MB/s
LAN (for P4MFP533
/P4MFP533T) ∗Support Fast Ethernet LAN function provide 10/100 Mb/s data
transfer rate
VGA
(Only for P4Mxxx
Serial Model)
∗Integrated High Performance & High Quality 3D Accelerator
∗Support Ultra-AGPII with 2GB/s bandwidth
∗Built-in programmable 24-bit true-color RAMDAC up to
250MHz pixel clock
∗Programmable frame buffer size from 8MB and up to 32MB.
Audio ∗AC’97 Digital Audio controller integrated
∗AC’97 Audio CODEC on board
∗Audio driver and utility included
BIOS ∗Award 2MB Flash ROM
Multi I/O ∗PS/2 keyboard and PS/2 mouse connectors
∗Floppy disk drive connector x1
∗Parallel port x1, Serial port X2
∗USB connector x2
∗USB headers x4 (connecting cable option)
∗Audio connector (Line-in, Line-out , MIC & Game Port)
1-3 Performance List
The following performance data list is the testing result of some popular benchmark
testing programs. These data are just referred by users, and there is no responsibility

4
for different testing data values gotten by users (the different Hardware & Software
configuration will result in different benchmark testing results.)
Performance Test Report
CPU: Intel Pentium 4 1.9GHz mPGAB package
DRAM: 256MB DDR266 x1 (SAMSUNG K4H280838B-TCB0)
256MB SDRAM x1 (KINGMAX KSV684T4A1A-06)
VGA Expansion Card: NVDIA Geforce2 MX-400 64MB (1024x768xHi-color)
Hard Disk Driver: IBM DTLA-305040 (ATA-100)
BIOS: Award Optimal default
OS: Win 98SE
DDR266 PC133 SDRAM
3D Mark 2000 5432 5360
3D Mark 2001 2509 2479
3D Winbench 2000 104 102
Final Reality 9.99 9.06
Content Creation Winstone 2000 43.2 41.5
Content Creation Winstone 2001 50.3 49.5
Content Creation Winstone 2002 20.1 18.6
Business Winstone2001 44.1 42.8
Winbench 99:
CPU Mark 99 111 101
FPU Winmark 99 6610 6610
Business Disk Winmark99 7150 7090
Hi-end Disk Winmark99 18800 18500
Business Graphic Winmark 434 428
Hi-end Graphic Winmark 1260 1230
SYS Mark 2000/2001 : SISMark 2000/2001 Rating (Internet Content Creation /
Office Productivity)
SISMark 2000 208 (226/195) 200 (217/188)
SISMark 2001 150 (175/129) 142 (160/126)
SISOFT Sandra 2001 :
Dhrystone ALU MIPS 3626 3630
Whetstone FPU MFLOPS 1137/2371 1135/2368
Int ALU/RAM MB/S 1181 701
Float FPU/RAM MB/S 1183 701
Integer SSE2 IT/S 7547 7554
Floating-Point SSE2 IT/S 9352 9350
QUAKE3 DEMO1 FPS 169.1 146.7
DEMO2 FPS 169.7 146.1
WCPUID System/CPU Clock 101/1918.93 101/1918.93
1-4 Layout Diagram & Jumper Setting
PRINT GAME/MIDI PORT
(For P4MFP533/P4MFP533T)
LAN

5
Jumpers
Jumper Name Description Page
JBAT CMOS RAM Clear 3-pin Block P.7
JP1 Keyboard Power On Enable/Disabled 3-pin Block P.7
Connectors
VGA
(For P4MFM/
/P4MFMU/P4MFU533
/P4MFP533/P4MFU533T
/P4MFP533T)
PS/2 Mouse
COM1
PS/2
Keyboard
USB
LINE-OUT
LINE-IN
MIC
Front Panel Audio
PC99 Back Panel
AGP Slot
Floppy Connector
VIA Chip P4X266E/
P4M266/P4M266A(CE)
Clear CMOS (JBAT)
ATX Power Conn.
CPU FAN
CPU Socket
DDR SDRAM DIMM x2
ATX 12V Power Conn.
USB Port/
LAN Connector
PS2 KB/Mouse Port
ATX P6 Power
ATA 133 IDE Conn.
SDR SDRAM DIMM x2
VIA VT8233A/
VT8235 Chip
K/B Power ON Jumper (JP1)
IR Connector
Wake On LAN
USB Port Front Panel Connector
2M Flash ROM BIOS
CD Audio
PCI Slot
Winbond W83697HF Chip
COM2 Connector
System FAN
System FAN1
(USB1 for P4MFMU/P4XFMU
/P4MFU533/P4MFP533
/P4MFU533T/P4MFP533T)
(USB1, USB2)

6
Connector Name Description Page
ATXPWR ATX Power Connector 20-pin Block P.12
ATX12V ATX 12V Power Connector 4-pin Block P.12
ATXP6 ATX P6 Power Connector 6-pin Block P.13
PS2KBM PS/2 Mouse & PS/2 Keyboard
Connector 6-pin Female P.13
CN1 USB Port Connector 4-pin Connector P.13
LAN
(for P4MFP533/
P4MFP533T)
RJ-45 LAN Port Connector RJ-45 Connector P.13
PARALL Parallel Port Connector 25-pin Female P.13
AUDIO_GAME Audio/Game Connector 3 phone jack + 15-pin Connector P.13
COM1 Serial Port COM1 Connector 9-pin Connector P.13
VGA VGA Connector 15-pin Female P.13
FDD Floppy Driver Connector 34-pin Block P.14
IDE1/IDE2 Primary/Secondary IDE Connector 40-pin Block P.14
Only for P4MFM/P4MFMU/P4MFU533/P4MFP533/P4MFU533T/P4MFP533T
Headers Header Name Description Page
COM2 Serial Port COM2 header 9-pin Block P.15
AUDIO SPEAKER, MIC header 9-pin Block P.15
USB2 USB Port Headers 9-pin Block P.15
USB1 (for P4MFMU/P4XFMU/
P4MFU533/P4MFP533/
P4MFU533T/P4MFP533T)
USB Port Headers 9-pin Block P.15
HD LED IDE activity LED 2-pin Block P.15
RESET Reset switch lead 2-pin Block P.15
SPEAK PC Speaker connector 4-pin Block P.15
PWR LED Power LED 2-pin Block P.16
PWR BTN Power switch 2-pin Block P.16
WOL Wake On-LAN Headers 3-pin Block P.16
SFAN1, SYSFAN, CPUFAN FAN Headers 3-pin Block P.16
IR IR infrared module Headers 5-pin Block P.17
CD_IN CD Audio-In Headers 4-pin Block P.17
Expansion Sockets
Socket/Slot Name Description Page
ZIF Socket 478 Pin CPU Socket 478-pin mPGA CPU Socket P.9
SDR1, SDR2 SDRAM Module Socket 168-pin SDR SDRAM Module
Expansion Socket P.9
DDR1, DDR2 DDR Module Socket 184-pin DDR Module Socket P.9
PCI1 ∼PCI3 PCI Slot 32-bit PCI Local Bus Expansion slots P.10
AGP AGP 4X Mode Slot AGP Expansion Slot P.12
Chapter 2
Hardware installation
2-1 Hardware installation Steps
Before using your computer, you had better complete the following steps:

7
1. Check motherboard jumper setting
2. Install CPU and Fan
3. Install System Memory (DIMM)
4. Install Expansion cards
5. Connect IDE and Floppy cables, Front Panel /Back Panel cable
6. Connect ATX Power cable
7. Power-On and Load Standard Default
8. Reboot
9. Install Operating System
10. Install Driver and Utility
2-2 Checking Motherboard’s Jumper Setting
(1) CMOS RAM Clear (3-pin) : JBAT
A battery must be used to retain the motherboard configuration in CMOS RAM short 1-2
pins of JBAT to store the CMOS data.
To clear the CMOS, follow the procedure below:
1. Turn off the system and unplug the AC power
2. Remove ATX power cable from ATX power connector
3. Locate JBAT and short pins 2-3 for a few seconds
4. Return JBAT to its normal setting by shorting pins 1-2
5. Connect ATX power cable back to ATX power connector
Note: When should clear CMOS
1. Troubleshooting
2. Forget password
3. After over clocking system boot fail
CMOS RAM Clear Setting
2-3 closed Clear CMOS
JBAT
13
JBAT
13
1-2 closed Normal
(2) Keyboard Power On function Enabled/Disabled: JP1
When setting Enabled you can using keyboard by key in password to power on system.

8
JP1 13
JP1 13
Keyboard Power On Setting
2-3 closed K/B Power ON Enabled1-2 closed K/B Power ON Disable
(Default)
2-3 Install CPU
2-3-1 Glossary
Chipset (or core logic) - two or more integrated circuits which control the interfaces between
the system processor, RAM, I/O devises, and adapter cards.
Processor slot/socket - the slot or socket used to mount the system processor on the
motherboard.
Slot (AGP, PCI, ISA, RAM) - the slots used to mount adapter cards and system RAM.
AGP - Accelerated Graphics Port - a high speed interface for video cards; runs at 1X
(66MHz), 2X (133MHz), or 4X (266MHz).
PCI - Peripheral Component Interconnect - a high speed interface for video cards, sound
cards, network interface cards, and modems; runs at 33MHz.
ISA - Industry Standard Architecture - a relatively low speed interface primarily used for
sound cards and modems; runs at approx. 8MHz.
Serial Port - a low speed interface typically used for mouse and external modems.
Parallel Port - a low speed interface typically used for printers.
PS/2 - a low speed interface used for mouse and keyboards.
USB - Universal Serial Bus - a medium speed interface typically used for mouse, keyboards,
scanners, and some digital cameras.
Sound (interface) - the interface between the sound card or integrated sound connectors and
speakers, MIC, game controllers, and MIDI sound devices.
LAN (interface) - Local Area Network - the interface to your local area network.
BIOS (Basic Input/Output System) - the program logic used to boot up a computer and
establish the relationship between the various components.
Driver - software, which defines the characteristics of a device for use by another device or
other software.
Processor - the "central processing unit" (CPU); the principal integrated circuit used for
doing the "computing" in "personal computer"
Front Side Bus Frequency - the working frequency of the motherboard, which is generated
by the clock generator for CPU, DRAM and PCI BUS.
CPU L2 Cache - the flash memory inside the CPU, normal it depend on CPU type.

9
2-3-2 About Intel Pentium 4 478-pin CPU
This motherboard provides a 478-pin surface mount, Zero Insertion Force (ZIF) socket,
referred to as the mPGA478B socket supports Intel Pentium 4 processor in the 478 Pin
package utilizes Flip-Chip Pin Grid Array (FC-PGA2) package technology.
The CPU that comes with the motherboard should have a cooling FAN attached to prevent
overheating. If this is not the case, then purchase a correct cooling FAN before you turn on
your system.
WARNING! Be sure that there is sufficient air circulation across the processor’s
heatsink and CPU cooling FAN is working correctly, otherwise it may
cause the processor and motherboard overheat and damage, you may install
an auxiliary cooling FAN, if necessary.
To install a CPU, first turn off your system and remove its cover. Locate the ZIF socket and
open it by first pulling the level sideways away from the socket then upward to a 90-degree
angle. Insert the CPU with the correct orientation as shown below. The notched corner
should point toward the end of the level. Because the CPU has a corner pin for two of the
four corners, the CPU will only fit in the orientation as shown.
CPU ZIF mPGAB Socket
Colden Arrow
mPGA478B
When you put the CPU into the ZIF socket. No force require to insert of the CPU, then press
the level to Locate position slightly without any extra force.
2-4 Install Memory
This motherboard provides two 184-pin DDR DUAL INLINE MEMORY MODULES
(DIMM) sites for DDR memory expansion available from minimum memory size of 64MB to
maximum memory size of 2.0GB SDR SDRAM, or two 168-pin SDR DIMM sites for
SDRAM memory for maximum memory size of 2.0GB.
Valid Memory Configurations
Bank 184-pin DDR DIMM PCS Total Memory
Bank 0, 1 (DDR1) DDR266/DDR200 DDR DRAM Module X1 64MB∼1.0GB
Bank 2, 3 (DDR2) DDR266/DDR200 DDR DRAM Module X1 64MB∼1.0GB
Total System Memory (Max. 2.0GB) X2 64MB∼2.0GB
Bank 168-pin SDR DIMM PCS Total Memory
Bank 0, 1 (SDR1) PC133/PC100 SDR DRAM Module X1 64MB∼1.0GB
Bank 2, 3 (SDR2) PC133/PC100 SDR DRAM Module X1 64MB∼1.0GB
Total System Memory (Max. 2.0GB) X1 64MB∼2.0GB

10
Generally, installing SDR/DDR SDRAM modules to your motherboard is very easy, you can
refer to figure 2-4 to see what a 168-pin SDR/184-pin DDR SDRAM module looks like.
DDR2 (BANK2+ BANK3
)
DDR1 (BANK0+ BANK1
)
SDR1 (BANK0+ BANK1
)
SDR2 (BANK2+ BANK3
)
NOTE! When you install DIMM module fully into the DIMM socket the eject tab
should be locked into the DIMM module very firmly and fit into its
indention on both sides.
WARNING! For the SDR SDRAM CLOCK is set at 133MHz, use only PC133/DDR266-
compliant SDR/DDR Modules. When this motherboard operate at 133Mhz,
most system will not even boot if non-compliant modules are used because
of the strict timing issues, if your SDR/DDR Modules are not PC133/
DDR266-compliant, set the SDRAM clock to 100MHz to ensure system
stability.
NOTE! It is only can install either SDRAM or DDR Module at one time. Don’t
install both DDR Module and SDR Module at same time, it will have risk
to damage your Memory and Motherboard.
2-5 Expansion Cards
WARNING! Turn off your power when adding or removing expansion cards or other
system components. Failure to do so may cause severe damage to both
your motherboard and expansion cards.
2-5-1 Procedure For Expansion Card Installation
1. Read the documentation for your expansion card and make any necessary hardware or
software setting for your expansion card such as jumpers.
2. Remove your computer’s cover and the bracket plate on the slot you intend to use.
3. Align the card’s connectors and press firmly.
4. Secure the card on the slot with the screen you remove above.
5. Replace the computer system’s cover.
6. Set up the BIOS if necessary.
7. Install the necessary software driver for your expansion card.
Figure 2-4

11
2-5-2 Assigning IRQs For Expansion Card
Some expansion cards need an IRQ to operate. Generally, an IRQ must exclusively assign to
one use. In a standard design, there are 16 IRQs available but most of them are already in use.
Standard Interrupt Assignments
IRQ Priority Standard function
0 N/A System Timer
1 N/A Keyboard Controller
2 N/A Programmable Interrupt
3 * 8 Communications Port (COM2)
4 * 9 Communications Port (COM1)
5 * 6 Sound Card (sometimes LPT2)
6 * 11 Floppy Disk Controller
7 * 7 Printer Port (LPT1)
8 N/A System CMOS/Real Time Clock
9 * 10 ACPI Mode when enabled
10 * 3 IRQ Holder for PCI Steering
11 * 2 IRQ Holder for PCI Steering
12 * 4 PS/2 Compatible Mouse Port
13 N/A Numeric Data Processor
14 * 5 Primary IDE Channel
15 * 1 Secondary IDE Channel
* These IRQs are usually available for ISA or PCI devices.
2-5-3 Interrupt Request Table For This Motherboard
Interrupt request are shared as shown the table below:
INT A INT B INT C INT D INT E INT F INT G INT H
Slot 1 √
Slot 2 √
Slot 3
√
Onboard USB 1 √
Onboard USB 2 √
AC97/MC97
√
IMPORTANT! If using PCI cards on shared slots, make sure that the drivers support
“Shared IRQ” or that the cards don’t need IRQ assignments. Conflicts will
arise between the two PCI groups that will make the system unstable or
cards inoperable.

12
2-5-4 AGP Slot
This motherboard provides an AGP Slot, support the 2X/4X AGP VGA card.
AGP SLOT
2-6 Connectors, Headers
2-6-1 Connectors
(1) Power Connector (20-pin block) : ATXPWR
ATX Power Supply connector. This is a new defined 20-pins connector that usually
comes with ATX case. The ATX Power Supply allows to use soft power on momentary
switch that connect from the front panel switch to 2-pins Power On jumper pole on the
motherboard. When the power switch on the back of the ATX power supply turned on,
the full power will not come into the system board until the front panel switch is
momentarily pressed. Press this switch again will turn off the power to the system
board.
PIN ROW2 ROW1
1 3.3V 3.3V
2 -12V 3.3V
3 GND GND
4 Soft Power On 5V
5 GND GND
6 GND 5V
7 GND GND
8 -5V Power OK
9 +5V +5V (for Soft Logic)
10 +5V +12V
Pin 1
(2) ATX 12V Power Connector (4-pin block) : ATX12V
This is a new defined 4-pins connector that usually comes with ATX Power Supply. The
ATX Power Supply which fully support Pentium 4 processor must including this
connector for support extra 12V voltage to maintain system power consumption.
Without this connector might cause system unstable because the power supply can not
provide sufficient current for system.
Pin 1
2x notch 4x notch

13
(3) ATX P6 Power Connector (6-pin block) : ATXP9
This is a new defined 6-pins connector that usually comes with ATX Power Supply. The ATX
Power Supply which fully support Pentium 4 processor must including this connector for
support extra 3.3V and 5V voltage to maintain system power consumption. Without this
connector might cause system unstable because the power supply can not provide sufficient
current for system.
Power Plugs from Power SupplyPower Connector on Motherboard
BLK
BLK
BLK
ORG
ORG
RED
GND
GND
GND
3.3V
3.3V
5V
(4) PS/2 Mouse & PS/2 Keyboard Connector: PS2KBM
The connectors for PS/2 keyboard and PS/2 Mouse.
(5) USB Port connector: CN1
The connectors are 4-pin connector that connect USB devices to the system board.
(6) LAN Port connector: LAN (only for P4MFP533/P4MFP533T)
This connector is standard RJ45 connector for Network
(7) Parallel Port Connector (25-pin female): PARALL
Parallel Port connector is a 25-pin D-Subminiature Receptacle connector. The On-board
Parallel Port can be disabled through the BIOS SETUP. Please refer to Chapter 3
“INTEGRATED PERIPHERALS SETUP” section for more detail information.
(8) Audio and Game Connector : AUDIO_GAME
This Connector are 3 phone Jack for LINE-OUT, LINE-IN, MIC and a 15-pin
D-Subminiature Receptacle Connector for joystick/MIDI Device.
Line-out : Audio output to speaker
Line-in : Audio input to sound chip
MIC : Microphone Connector
Game/MIDI : For joystick or MIDI Device
(9) Serial Port COM1 : COM1
COM1 is the 9-pin D-Subminiature male connector. The On-board serial port can be disabled
through BIOS SETUP. Please refer to Chapter 3 “INTEGRATED PERIPHERALS SETUP” section
for more detail information.
(10) VGA Connector (15-pin D-Sub) Connector: VGA
(for P4MFM/P4MFMU/P4MFU533/P4MFP533/P4MFU533T/P4MFP533T)
VGA is the 15-pin D-Subminiature female connector for display monitor.
(11) Floppy drive Connector (34-pin block): FDD
COM1 VGA
PS/2
Keyboard USB
LINE-OUT
LINE-IN
MIC
PS/2
Mouse PRINT GAME/MIDI PORTLAN

14
This connector supports the provided floppy drive ribbon cable. After connecting the
single plug end to motherboard, connect the two plugs at other end to the floppy drives.
Pin 1
Floppy Drive Connector
(12) Primary IDE Connector (40-pin block): IDE1
This connector supports the provided IDE hard disk ribbon cable. After connecting the
single plug end to motherboard, connect the two plugs at other end to your hard disk(s).
If you install two hard disks, you must configure the second drive to Slave mode by
setting its jumpers accordingly. Please refer to the documentation of your hard disk for
the jumper settings.
Primary IDE Connector
Pin 1
(13) Secondary IDE Connector (40-pin block): IDE2
This connector connects to the next set of Master and Slave hard disks. Follow the
same procedure described for the primary IDE connector. You may also configure two
hard disks to be both Masters using one ribbon cable on the primary IDE connector and
another ribbon cable on the secondary IDE connector.
Secondary IDE Connector
Pin 1
•Two hard disks can be connected to each connector. The first HDD is referred to as the
“Master” and the second HDD is referred to as the “Slave”.
•For performance issues, we strongly suggest you don’t install a CD-ROM or DVD-ROM
drive on the same IDE channel as a hard disk. Otherwise, the system performance on this
channel may drop.
2-6-2 Headers
(1) Serial Port2 COM2 Header (9-pin) : COM2

15
COM2
Pin 1
N
ote: Orient the read marking on the
COM2 ribbon cable to pin 1
Serial Port2 COM2 Header
(2) Line-Out/MIC Header for Front Panel (9-pin): AUDIO
This header connect to Front Panel Line-out, MIC connector with cable.
Without install the cable, this header default setting is 5-6 short, 9-10 short. When you
install the cable you have take off these jumpers.
Line-Out, MIC Headers
A
UDIO Pin 1
AUD_MIC
AUD_FPOUT_L
AUD_MIC_BIAS
AUD_FPOUT_R
A
UD_GND
AUD_RET_L
A
UD_RET_
R
H
P
_ON
AUD_VCC
2
9 10
(3) USB Port Headers (9-pin) : USB2,
USB1 (for P4XFMU/P4MFMU/P4MFU533/P4MFP533/P4MFU533T/P4MFP533T)
These headers are used for connecting the additional USB port plug. By attaching an
option USB cable, your can be provided with two additional USB plugs affixed to the
back panel.
(4) IDE Activity LED: HD LED
This connector connects to the hard disk activity indicator light on the case.
(5) Reset switch lead: RESET
This 2-pin connector connects to the case-mounted reset switch for rebooting your
computer without having to turn off your power switch. This is a preferred method of
rebooting in order to prolong the lift of the system’s power supply. See the figure
below.
(6) Speaker connector: SPEAK
This 4-pin connector connects to the case-mounted speaker. See the figure below.
(7) Power LED: PWR LED

16
The Power LED is light on while the system power is on. Connect the Power LED
from the system case to this pin.
(8) Power switch: PWR BTN
This 2-pin connector connects to the case-mounted power switch to power ON/OFF the
system.
System Case Connections
HDLED
RESET
VCC5
GND
VCC5 ACPILED
PWRBT
PWRBTN
ACPILED
HDDLED
RSTSW
NC GND
JW_FP
SPEAK
SPK
R
GND
NC
VCC5
Pin 1
Pin 1
(9) Wake On-LAN Headers (3-pin) : WOL
This connector connects to a LAN card with a WAKE ON-LAN output. This
connector power up the system when a wake up signal is received through the LAN
card.
NOTE: This feature requires that Wake On LAN or Ring In Wake up is enabled.
Wake-On-LAN Headers
WOL
13
5VSB GND WOL
(10) FAN Headers (3-pin) : SFAN1, SYSFAN, CPUFAN
These connectors support cooling fans of 350mA (4.2 Watts) or less, depending on the
fan manufacturer, the wire and plug may be different. The red wire should be positive,
while the black should be ground. Connect the fan’s plug to the board taking into
consideration the polarity of connector.

17
SFAN1
1
3
SYSFAN
13
FAN Speed Headers
CPUFAN
1
3
(11) IR infrared module Headers (5-pin) : IR
This connector supports the optional wireless transmitting and receiving infrared
module. You must configure the setting through the BIOS setup to use the IR function.
IR infrared module Headers
IR
Pin 1
GND
IRRX
NC
VCC5
IRTX
2
5
6
(12) CD Audio-In Headers (4-pin) : CD_IN
CD_IN are the connectors for CD-Audio Input signal. Please connect it to CD-ROM
CD-Audio output connector.
CD Audio-In Headers
CD_I N 4
1

18
2-7 Starting Up Your Computer
1. After all connection are made, close your computer case cover.
2. Be sure all the switch are off, and check that the power supply input voltage is set to
proper position, usually in-put voltage is 220V∼240V or 110V∼120V depending on your
country’s voltage used.
3. Connect the power supply cord into the power supply located on the back of your system
case according to your system user’s manual.
4. Turn on your peripheral as following order:
a. Your monitor.
b. Other external peripheral (Printer, Scanner, External Modem etc…)
c. Your system power. For ATX power supplies, you need to turn on the power supply
and press the ATX power switch on the front side of the case.
5. The power LED on the front panel of the system case will light. The LED on the monitor
may light up or switch between orange and green after the system is on. If it complies
with green standards or if it is has a power standby feature. The system will then run
power-on test. While the test are running, the BIOS will alarm beeps or additional
message will appear on the screen.
If you do not see any thing within 30 seconds from the time you turn on the power. The
system may have failed on power-on test. Recheck your jumper settings and connections
or call your retailer for assistance.
Beep Meaning
One short beep when displaying logo No error during POST
Long beeps in an endless loop No DRAM install or detected
One long beep followed by three short
beeps Video card not found or video card memory bad
High frequency beeps when system is
working CPU overheated
System running at a lower frequency
6. During power-on, press <Delete> key to enter BIOS setup. Follow the instructions in
BIOS SETUP.
7. Power off your computer: You must first exit or shut down your operating system
before switch off the power switch. For ATX power supply, you can press ATX power
switching after exiting or shutting down your operating system. If you use Windows 9X,
click “Start” button, click “Shut down” and then click “Shut down the computer?”
The power supply should turn off after windows shut down.
