JGaurora A8S User manual

JGAURORA 3D PRINTER
MODEL: A8S
USER GUIDE

----3D Printer User Guide
1
Contents
1. Preface ....................................................................................................................................................................2
1.1 Introduction ............................................................................................................................................................ 2
1.2 Safety advice ........................................................................................................................................................... 2
1.3 Filament requirements............................................................................................................................................ 2
1.4 Environmental requirements.................................................................................................................................. 2
2. About A8S ............................................................................................................................................................... 3
2.1 Basic reference........................................................................................................................................................ 3
2.2 Overview of A8S...................................................................................................................................................... 3
2.3 Extruder Nozzle Assembly (Exploded View Diagram) ............................................................................................. 4
2.4 Tool box lists............................................................................................................................................................ 5
3. About JGcreat software............................................................................................................................................6
3.1 Software installation ............................................................................................................................................... 6
3.2 JGcreat introduction ............................................................................................................................................... 7
4. Basic printing ......................................................................................................................................................... 11
4.1 Control menu introduction ................................................................................................................................... 11
4.2 Main menu introduction ....................................................................................................................................... 12
4.3 Platform leveling ................................................................................................................................................... 12
4.4 Filament loading.................................................................................................................................................... 13
4.5 Trial printing.......................................................................................................................................................... 15
4.6 Filament replacement notes ................................................................................................................................. 16
5. Common problems and solutions ........................................................................................................................... 17
6. 3D printer maintenance ......................................................................................................................................... 18
6.1 Daily maintenance................................................................................................................................................. 18
6.2 Basic maintenance ................................................................................................................................................ 18
6.3 Maintenance of moving components ................................................................................................................... 18
7. Support and service details .................................................................................................................................... 19

----3D Printer User Guide
2
1. Preface
I.1 Introduction
The JGAURORA A8S User Guide was written to help new A8S users to start their printing journey with the
JGAURORA A8S. Even if you are familiar with earlier JGAURORA machines or experienced with 3D printing technology,
we still recommend that you read through this guide, that will help you have a better 3D printing experience.
1.2 Safety Advice
1) During printing, the temperature of the printing nozzle tip can heat up to 250℃. To avoid being burned, be
careful to avoid touching the nozzle while it is hot. The heated bed can also heat up to 100C, so please allow the bed
to cool down after printing, before you try to remove your completed prints.
2) While the printer is operating, there is a danger of hands or fingers being crushed by moving parts. To prevent
injury, please keep hands and long hair safely away from moving components, while the printer is operating.
3) Always use the A8S with a properly grounded outlet. Do not modify the A8S power plug.
Attention: Before power on, please check the input power is compatible with your local standard.( Method:
Observe the power switch at the hole of back base, if your local voltage is 230V, then adjust it to 230V, Similarly, if
the voltage is 115V, then adjust it to 115V.)
4) Please be careful when removing prints. The print bed is a glass sheet, so to avoid damage, please avoid using
excessive force. We recommend wearing protective glasses while removing prints. If you are using a spatula or
scraper to remove prints, please wear gloves to protect your hands from serious injury, and be careful not to damage
the print bed surface.
1.3 Filament requirements
Do not abuse the filament. Please make sure you use the JGAURORA filament or the filament from the brands
certified by JGAURORA. All polymers degrade with time. Do not unpack until filament is needed. Filament should be
stored at room temperature:15-30ºC, and in dry conditions.
PLA filament in particular can absorb moisture from the air, to become brittle and unsuitable for printing. If you
are not printing for extended periods of time, it is recommended to remove the filament and store it in an air-tight
box. Use the filament holes in the spool to hold the loose end of the filament, to prevent it coming loose and
becoming tangled.
1.4 Environmental requirements
The ambient temperature in the printing environment should be between 5 to 4ºC, with humidity between 20%
to 50%. Using the printer outside of these conditions may result in reduced or inconsistent printing quality.

----3D Printer User Guide
3
2. About A8S
2.1 Basic reference
Model number: A8S
Device size: 620*450*600mm
Layer thickness: 0.05- 0.3mm（suggest 0.1mm）
Device weight: 34.8kg
Printing speed: 10 - 150mm/s (suggest 30 to 60mm/s)
Package size: 740*560*720mm
Nozzle temperature: Room temperature to 250ºC
Package weight: 42.8kg
Nozzle diameter: 0.4mm
Build size: 350*250*300 mm
Hot bed temperature: Room temperature to 110ºC
Platform material: Black Diamond Glass heated plate
Support material: PLA /ABS/WOOD/PETG/TPU
LCD display: 4.3” Touch Screen
Filament diameter: 1.75mm
Connectivity: USB cable/ USB stick
Language: English/German/French/Spanish/Japanese
Support Formats: STL/OBJ/G-Code
Environmental requirements:
Temperature 5 to 40ºC, Humidity 20% to 50%
OS: Windows, Linux, Mac
AC Input: AC115 OR 230V, manually switchable
Software: Cura/Simplify 3d/JGcreat(Win 7 64 bit)
2.2 Views of A8S

----3D Printer User Guide
4
2.3 Extruder Nozzle Assembly (Exploded View Diagram)
Item No.
Parts Name
1
Blower Cooling Fan
2
Heater block
3
Extruder PCB board
4
Thermistor
5
Heating tube
6
Cooling Duct
7
Extruder cover
Item No.
Parts Name
8
Stepper motor
9
Extruder plate
10
Limit switch
11
Extruder gear
12
Extruder slider
13
Heat sink
14
Square Extruder Cooling fan

----3D Printer User Guide
5
2.4 Tool box lists

----3D Printer User Guide
6
3. About JGcreat software
3.1 Software installation
Copy the files in USB stick to your PC, then double click the software installation icon. Then, follow the
installation instructions, as shown in the photos below.
Double click
Double

----3D Printer User Guide
7
After clicking the “Finish” icon, the software is installed, and ready for use.
3.2 JGcreat introduction
1) Open the software(JGcreat)
Double click to
Open “JGcreat”

----3D Printer User Guide
8
2) Choose the language you prefer (English as an example):

----3D Printer User Guide
9
3) Add Printer
4) Load 3d file and slice it
Load an stl or obj 3d file. Select the appropriate print quality. The lower right corner of the software shows "Slicing",
which converts the 3D model file, into the standard G-Code instructions that the printer uses to run.
Choose the
print quality
you prefer

----3D Printer User Guide
10
After slicing completed, the lower right corner of the software shows "Save to file".
5) Copy the G-code to the USB stick, and insert it into the USB port on the A8S printer. Then, select the gcode file to
print through the touch screen interface.
Note: Please refer to the JGcreat instructions document on the USB stick for how to operate the JGcreat software.

----3D Printer User Guide
11
4. Basic printing
4.1 Control menu introduction
MAIN MENU
MOVE
HEAT
PRINT
Printing
Choose model
to print
STOP
PAUSE/
START
PLA/ABS Option
Setting of hot end/ hot bed
HOME(X/Y/Z)
X HOME
FILAMENT OUT
FILAMENT IN
Back
WIFI
LEVELING
Y HOME
Z HOME
BACK
SETTING
X RIGHT/LEFT
Y FORWARD/BACKWARD
EXTRUDER TEMP.
HOT BED TMEP.
BACK
IN
OUT
BACK
CONFIRM
CANCEL
FAN SPEED
Z UP/DOWN
LANGUAGE SWITCH

----3D Printer User Guide
12
4.2 Introduction of main screen
4.3 Platform leveling
Click “LEVELING”in the main screen, show as below :
WIFI
USB STICK CONNECTION
Select model file to print
Leveling the hot bed
Preheat hot end/hot bed
Move axis
Extruder temp.
Hot bed temp.
Filament In
Filament out
Language transfer
Wifi
Point 2
Point 1
Point 3
Point 4

----3D Printer User Guide
13
Press “LEVELING”, the printer head to back to home automatically, then press the 4 points to make leveling, as below
showing:
Please Note: You may find it helpful to refer to the video demonstrating platform leveling, that is found in the
included USB stick.
4.4 Filament loading
Click [ PREHEAT ] to enter “Preheat menu”->select the relative filament to preheat. Here, we are using PLA as an
example.
Press “point 1”,
the head move
to right back
Press“point 4”,
the head move
to right front
Press “point 3”,
the head move
to left front
Press “point
2”, the head
move to left
back
front

----3D Printer User Guide
14
While waiting for the nozzle to heat, we can install the onboard filament holder.
Note：For smooth operation, ensure the spool is installed correctly, so that it rotates clockwise during printing.
Click [IN] once
nozzle temp.
reaches 200ºC
When the filament
comes out of the
nozzle, loading
is completed.
Assemble the
holder on the
right.
Tighten the screw.
Load the filament
into the filament
tube.
Load the filament
spool to the holder.

----3D Printer User Guide
15
4.5 Trial printing
1) Model loading: Select and load the 3d file you want to print, or drag it directly into the software window.
2) G-code save: After slicing of the 3d file is finished, click the “Save to File” button in the lower right corner to save
the file onto the USB stick, with an appropriate file name.
2) Insert the USB stick into the USB port on the A8S, and then click "PRINT" on the Main Menu , and then select the
3D Gcode file. Click "START" and the A8S will being to preheat the nozzle and printing platform. When the
temperature of then nozzle reaches the temperature set in the slicer software, the 3D printing of the model will
begin.
Click
“Open File”
Save the file

----3D Printer User Guide
16
Note: When printing, if the first layer does not adhere to the platform, please stop printing and re-level
the printing platform and the nozzle, to set the correct gap.
4.6 Filament replacement notes
1) While printing a model, if the filament is close to running out, please follow these steps for reloading filament:
a: Click “PAUSE”at the printing menu, the X axis will then go to the home position.
b: Next click “OUT”to eject the filament out and remove the spool after the filament is ejected.
c: Install a new roll of filament, then click the “IN”icon until feeding is completed. Once the filament reaches the
nozzle, as small amount of plastic should start to extrude from the nozzle, in order to ensure the nozzle is primed for
printing. If this does not occur, extrude plastic manually until the nozzle is primed.
d: Click the “Back”button to enter into the model printing mode, then click the “RESUME”button to resume printing.
2) When replacing filament, please ensure the nozzle has been preheated to operating temperature first, before
performing the filament change. Please do not pull it out violently, otherwise it will cause severe damage to the
nozzle and extruder assembly.
Click “Print”
Select the file you
wish to print.

----3D Printer User Guide
17
5. Common problems and solutions
Item
Problem description
Reason
Solution
1
Filament breaks at the
top of extruder mouth
A. Filament has run out .
B. Filament was exposed to
moisture, and has become
brittle..
C. Filament was plugging
the throat.
A. Replace filament before its gone.
B. Store filament in air-tight
container when finished printing.
Replace with fresh filament spool.
C. Clean the throat. Refer to video
on the USB stick for instructions.
2
Filament slips in
extruder
Filament is too thin, or has
been ground down by
extruder gear.
Retract filament and cut out the
thin filament section.
3
Temperature is
incorrect.
Temperature sensor is
malfunctioning.
Contact support for advice on
replacement of temperature sensor.
4
Model is malformed
Timing belts may be too
loose. Timing belt pulley
may be loose.
Check and tighten the screw and
belts.
5
Model is warped
The print bed is not level
Re-level print bed, and retry print.
6
G-code generation
failed
Incorrect setting or wrong
save path
Choose the correct machine type
and select the correct save path
7
Software Installation
failed
OS may not be supported
Install only on compatible OS

----3D Printer User Guide
18
6. 3D printer maintenance
1. Daily maintenance
1) Before using the machine to print, make observe the safety recommendations.
2) Regularly clean and maintain the equipment. Clean the surface of the nozzle, print bed, moving parts and
other parts, to help prevent wear caused by excessive dust.
3) After each repair and maintenance, ensure all disassembled parts have been put back in their original place
to avoid mechanical failures that may be caused by missing parts or incorrect re-assembly.
2. Basic maintenance
1) Before operating the 3D printer, it is necessary to inspect the printer, and perform maintenance before use:
Inspect the nozzle for blockage or damage
Check the printing platform is calibrated and clean.
Check the printer is on a flat surface and is stable.
Check that screws and nuts are tight, and that no parts of the printer are loose or wobbly.
Check whether motion rails require cleaning or lubrication with oil.
When parts or lines are damaged or worn out, you should replace them before printing.
2) In the operation of the 3D printer, ensure not only that the design of each print model does not exceed the actual
printable volume of the device, but also do not allow the machine to work in too high a temperature or under too
much load. Otherwise, not only will it not print the object, but it can also damage the machine because of
overloaded work.
3) For best print results, please remove the filament remaining in the extrusion head after finishing printing.
Seal filament in air-tight containers to prevent material from absorbing moisture, which can cause filament to
become brittle and break during printing.
3. Maintenance of Moving Components
If you notice the printer has become noisy, or vibrates excessively, you may need to clean the rail rods and add some
lubricating oil to reduce friction.
To Clean and Lubricate: first, with a clean dust cloth, clean the grease or dust from the moving parts. Then apply
3-5ml (about 5-8 drops) lubricating oil along the motion rails. Brush the oil along the respective parts or rail axis, and
move the moving parts along the rails back and forth, in order to distribute oil within the bearings and to lubricate
the entire length of the guide rails and polished rods.

----3D Printer User Guide
19
7. Supports and service
1. Please see the Warranty Card for details on our policies for repair and support.
2. If your printer is malfunctioning or damaged, for your safety, and to avoid further damaging the printer, please
contact the after-sale service center or our support team for advice first, before attempting any repair.
Shenzhen Aurora Technology Co., Ltd
Headquarter Address: 5F Building 1 Longquan Technology Park, Tongsheng community,
Dalang street Longhua district, Shenzhen, 518109 China
Company homepage: www.jgaurora3d.com
Tel of after sales service center/support team: 0755-29735649
Email of support: [e-mail] or [e-mail]
Skype: teresa-jiguang QQ: 2880478450
Official website Official Facebook
Please provide the machine code to us when asking for support:
