Jimi VL502 User manual

VL502
LTE OBDII GNSS TRACKER
User Manual V1.0
The product speci󽗉cations and information in this document are for reference
only and no prior notice will be given if any change is made. Unless otherwise
stated, the content of this document is not a guarantee in any form.

CONTENTS




1.1 Appearance -------------------------------------------------01
1.2 Pinout -----------------------------------------------------01
1.3 Status LED Indication ------------------------------------ 02

2.1 SIM Card Attachment -------------------------------------03
2.2 Installing the Device --------------------------------------04

6.1 Special Note ------------------------------------------------10
6.2 Warranty Terms --------------------------------------------10
6.3 Note ----- -----------------------------------------------------11
󽗉
3.1 Con󽗉guring APN and Server Parametes -------------04
3.2 Default con󽗉guration settings ------------------------- 05

4.1 Features -----------------------------------------------------06
4.2 Basic characteristics --------------------------------------06

01
Overview


Pin Number Pin Name description
4 GND(-) Ground
5 GND(-) Ground
6 CAN_H CAN high
7 K-Line
14 CAN_L CAN low
15 L-Line
16 VCC(9-36)V DC(+) Power supply(9-36V DC)

Making connections simpler
02

Fast blink [0.1s-0.1s(on-o󽗈)] The battery is low.
Slow blink [2s-2s(on-o󽗈)] The device is charging.
Solid on The charging is complete.
Slow blink [0.1s-2s(on-o󽗈)] The device operates correctly.
O󽗈 The battery is under voltage or
encounters an internal failure.

Fast blink [0.3s-0.3s(on-o󽗈)] The device is searching for
satellite signals.
Solid on The GNSS module is already
󽗉xed a position.
O󽗈 Device is in sleep mode or not
operating.

Fast blink [0.3s-0.3s(on-o󽗈)] The GMS is initializing.
Solid on The device is in a call/online.
O󽗈 Network error or no SIM card.


03
Installation

・Step 1 Prepare a Nano-SIM.
・ Step 2 Attach the SIM.
Place the Nano-SIM card on the SIM card tray and insert it into the
SIM card slot.
Tips:
・After the SIM is in inserted, the device powers on using the backup
battery. If the device fails to power due to low battery, you can connect
the device to the OBDIl connector of the vehicle to obtain power.
・The SIM card must be inserted correctly, If the SIM is identified and
requires a PIN, please disable the PIN request.

Making connections simpler
04

・Connecting the device to the vehicle:
Find OBDII Connector in your vehicle (the following 󽗉gure shows most
of common OBD II connector locations).
Quick SMS con󽗉guration
󽗉
To ensure the device gets online and operates correctly, you are advised to
check the APN and server settings. You can set the APN and the server via
SMS commands if necessarily.
・APN settings
It is recommended to contact your network operator to con󽗉rm the
APN information. Then you can use your phone to deliver the following
SMS command to the VL502:
APN, apnname#
For example: APN, internet#

05
󽗉
Or if your local APN contains a user name and password, you can use
the following command to set the APN:
APN, apnname, user, password#
For example: APN, internet, CLENTE, AMENA#
・Server settings
It is recommended to contact your platform service provide to con󽗉rm
the domain name and IP address of their serve. Then you can use your
phone to deliver the following command to the VL502:
SERVER, mode, domain name/IP, port, protocol#
For example:
SERVER,1, www. ydpat. com,8011,0#
SERVER,0,211.154.135.113,8011,0#
"Mode=1"means to set the server parameters via the domain name;
"Mode=0"means to set the server parameters via the IP address.
"Protocol=0"means to connect to the server using TCP protocol.
・Movement and ignition detection:
Vehicle movement will be detected by accelerometer.
Ignition will be detected by vehicle power voltage between 9-36 V.
・Device will send a alert noti󽗉cation to the server if one of these events
happen:
Vehicle keeps moving at speeds above the threshold for a preset duration.
Driver steps on the brake or gas pedal hard, corners rapidly.
The device is plugged or unplugged from the OBDII connector.

Making connections simpler
06
Introduction


・Communication via 4G LTE networks. Two complementary positioning
systems ensure the locations to be accurately displayed on cloud platform.
・Obtains real data of vehicle (accurate mileage, fault code, ACC status,
fuel consumption statistics, battery voltage, engine speed, etc.)
・Two complementary positioning systems ensure the locations to be
accurately displayed on cloud platform
・Get instant alerts for 4 kinds of dangerous driving behavior, depending on
your needs.
・Instant alerts for atypical events such as car fault, collision, overspeed,
device pull-out, engine idling, low battery, geo-fence entry/exit, etc.
・Through bluetooth connection you can con󽗉gure parameters, upgrade
software, and debug.
・Ensures constant tracking in the area with poor GPS signal or even without
it.
・Simply plug this device into OBD Il socket, you don't have to turn to
professionals.
Positioning system GPS/BDS
Frequency L1
Positioning accuracy <2.5m CEP
Track sensitivity -162 dBm
Acquisition sensitivity -148 dBm (cold) /-156 dBM (hot)
TTFF (open sky) Avg. hot start <1sec
Avg. cold start ≤ 32sec


07
Communication network LTE Cat M1&NB
Frequency Cat M1： B2/ B4/B5 /B12/B13
Cat NB2: B2 /B4/B5/B12/B13

Battery 160mA/3.7V
Input voltage 9-36VDC

Data K-Line, CAN Bus Data
Data Reading
Allow information to be read from OBDII
port upports OBD protocols:
ISO 9141-2 (5 baud init, 10.4 kbaud)
ISO 14230-4 KWP (5 baud init, 10.4 kbaud)
ISO 14230-4 KWP (fast init, 10.4 kbaud)
ISO 15765-4 CAN (11 bit ID, 250 kbaud)
ISO 15765-4 CAN (11 bit ID, 500 kbaud)
ISO 15765-4 CAN (29 bit ID, 250 kbaud)
ISO 15765-4 CAN (29 bit ID, 500 kbaud)
SAE J1939 CAN (29 bit ID, 250 kbaud)
SAE J1939 CAN (29 bit ID, 500 kbaud)

Connection OBD II socket
GNSS antenna Internal High Gain
USB 2.0 Micro-USB
LED indication 3 status LED lights
SIM Nano-SIM
Data storage 4+4MB


Making connections simpler
08
Dimensions 65(L)*50(W)*25(H) mm
Weight 65 g
󽗉
Operating temperature -20 ℃ to 70 ℃
Operating humidity 5%~95%, non-condensing

Sensors Accelerometer
BLE Support BLE 4.0 protocol
Ignition detection External Power Voltage,
Accelerometer Engine RPM
Scenarios
Vehicle movement alert, Over-
speed alert Geo-fence, Vehicle
battery detection, Power supply
disconnection
Driving behavior analysis Harsh acceleration, Harsh braking
Harsh cornering, Collision
SMS Con󽗉guration, Events, Debug
Fuel monitoring OBD II


09
Precautions About Battery
Please use batteries that are speci󽗉ed by the manufacturer of the device.
The manufacturer will assume no repair liabilities for damages resulting
from the use of non-original accessories.
・Avoid metal objects as they may cause short circuits on battery contacts.
・Do not bend or forcibly open the battery.
・Do not soak the battery in water or expose it to 󽗉re.
・It is forbidden to use batteries that are deformed, discolored, spilled, or
package-damaged.
・It is forbidden to disassemble or modify the battery.

Making connections simpler
10
Warranty Instructions and Servic

・No prior notice will be given if the product is upgraded due to
technological reasons.
・The appearance or color of the product is subject to the actual.
・The warranty card applies to the services of repair, replacement and
refund of the product with the following IMEI.
・Please keep this warranty card and the original purchase receipt
together in a safe place, as these will be needed at time of services.

・For damages not caused by human factors, this warranty lasts for one
year starting from the date of purchase.
・You can choose to pay for the repair services in any of the following
cases:
① The warranty card expires;
② No warranty card or valid proof of purchase;
③ The product, including its accessories, is not in the warranty
period;
④ Quality issues resulted from unauthorized repair, crash, liquid
spillage, accident, modi󽗉cation, or incorrect voltage input; or the
label, IMEI, or counterfeit mark of the device is broken or scribbled;
⑤ Damage caused by installing or using the device without
following the instructions in this User Manual;
⑥ The warranty does not cover damages resulted from soaking in
liquid;
⑦ The product model is inconsistent with that on the warranty card
or the warranty card was altered;
⑧ Damage caused by force majeure such as 󽗉re, 󽗊ood, or lightning.

11

・For vehicle trackers
As of January 1, 2016, the warranty lasts for 1 (one) year from the date
of purchase.
・The speci󽗉c terms are
1. A full replacement, including accessories, if the product is found
defective during the unpacking check (that is, the device has neither
been installed nor used);
2. If a defect occurs within one year after installation, then:
① ©Replace only the mainboard if the housing is intact and doesn't
a󽗈ect normal use; or
② @Replace the housing and the mainboard if the housing is
defective and a󽗈ects normal use (Please be noted that man-made
damages will void the replacement service for the housing).
3. Free repair services will be given to the product if a defect is found
during the 󽗉rst year under proper use.

Making connections simpler
12
Troubleshooting
When an issue arises with the device, you can troubleshoot it by the
following solution. If the issue persists, please don't hesitate to contact
your dealer or service provider.
Common Issues Possible Causes Solutions
Poor signal
The device is used in an area
where radio waves cannot
reach, such as near high-rise
buildings or in a basement.
Try it in a place where
satellite signals can
be well received.
Power-on failure
No SIM Insert a SIM.
The battery is exhausted. Charge the device.
Failed to access
the network
The SIM card may be attached
improperly. Check the SIM.
The metal side of the SIM card
is stained.
Clean it with an
eraser.
The SIM card is invalid.
Please contact your
network service
provider.
The device is out of cellular
service areas. Try it in a service area.
The signal is extremely weak. Try it in an area with
strong signals.
Failed to query a
location
The device keeps replying
with "No data found, please
try again".
Please contact your
dealer.

13
Customer Information
󽗉

Customer Name IMEI No.
Mailing Address
Product Model Phone
Date of Purchase Invoice No.
Purchased From
Address
Phone
Maintenance Record
Important
Please keep this warranty card in a safe place, as it is the proof for one-year
free warranty services. If this card is lost, the Company will determine the
date of purchase to be the thirtieth (30th) day after the date of production.
Service
Start Date
Problem and
Solution
Service End
Date
Customer
Signature
Warranty Card
Making connections simpler

ＦＣＣ Ｗａｒｎｉｎｇ： ＮＯＴＥ： Ｔｈｉｓ ｅｑｕｉｐｍｅｎｔ ｈａｓ ｂｅｅｎ ｔｅｓｔｅｄ ａｎｄ ｆｏｕｎｄ ｔｏ
ｃｏｍｐｌｙ ｗｉｔｈ ｔｈｅ ｌｉｍｉｔｓ ｆｏｒ ａ Ｃｌａｓｓ Ｂ ｄｉｇｉｔａｌ ｄｅｖｉｃｅ， ｐｕｒｓｕａｎｔ ｔｏ ｐａｒｔ １５
ｏｆ ｔｈｅ ＦＣＣ Ｒｕｌｅｓ．
Ｔｈｅｓｅ ｌｉｍｉｔｓ ａｒｅ ｄｅｓｉｇｎｅｄ ｔｏ ｐｒｏｖｉｄｅ ｒｅａｓｏｎａｂｌｅ ｐｒｏｔｅｃｔｉｏｎ ａｇａｉｎｓｔ
ｈａｒｍｆｕｌ ｉｎｔｅｒｆｅｒｅｎｃｅ ｉｎ ａ ｒｅｓｉｄｅｎｔｉａｌ ｉｎｓｔａｌｌａｔｉｏｎ．
Ｔｈｉｓ ｅｑｕｉｐｍｅｎｔ ｇｅｎｅｒａｔｅｓ ｕｓｅｓ ａｎｄ ｃａｎ ｒａｄｉａｔｅ ｒａｄｉｏ ｆｒｅｑｕｅｎｃｙ
ｅｎｅｒｇｙ ａｎｄ， ｉｆ ｎｏｔ ｉｎｓｔａｌｌｅｄ ａｎｄ ｕｓｅｄ ｉｎ ａｃｃｏｒｄａｎｃｅ ｗｉｔｈ ｔｈｅ
ｉｎｓｔｒｕｃｔｉｏｎｓ， ｍａｙ ｃａｕｓｅ ｈａｒｍｆｕｌ ｉｎｔｅｒｆｅｒｅｎｃｅ ｔｏ ｒａｄｉｏ ｃｏｍｍｕｎｉｃａｔｉｏｎｓ．
Ｈｏｗｅｖｅｒ， ｔｈｅｒｅ ｉｓ ｎｏ ｇｕａｒａｎｔｅｅ ｔｈａｔ ｉｎｔｅｒｆｅｒｅｎｃｅ ｗｉｌｌ ｎｏｔ ｏｃｃｕｒ ｉｎ ａ
ｐａｒｔｉｃｕｌａｒ ｉｎｓｔａｌｌａｔｉｏｎ． Ｉｆ ｔｈｉｓ ｅｑｕｉｐｍｅｎｔ ｄｏｅｓ ｃａｕｓｅ ｈａｒｍｆｕｌ
ｉｎｔｅｒｆｅｒｅｎｃｅ ｔｏ ｒａｄｉｏ ｏｒ ｔｅｌｅｖｉｓｉｏｎ ｒｅｃｅｐｔｉｏｎ， ｗｈｉｃｈ ｃａｎ ｂｅ ｄｅｔｅｒｍｉｎｅｄ
ｂｙ ｔｕｒｎｉｎｇ ｔｈｅ ｅｑｕｉｐｍｅｎｔ ｏｆｆ ａｎｄ ｏｎ， ｔｈｅ ｕｓｅｒ ｉｓ ｅｎｃｏｕｒａｇｅｄ ｔｏ ｔｒｙ ｔｏ
ｃｏｒｒｅｃｔ ｔｈｅ ｉｎｔｅｒｆｅｒｅｎｃｅ ｂｙ ｏｎｅ ｏｒ ｍｏｒｅ ｏｆ ｔｈｅ ｆｏｌｌｏｗｉｎｇ ｍｅａｓｕｒｅｓ：
－ Ｒｅｏｒｉｅｎｔ ｏｒ ｒｅｌｏｃａｔｅ ｔｈｅ ｒｅｃｅｉｖｉｎｇ ａｎｔｅｎｎａ．
－ Ｉｎｃｒｅａｓｅ ｔｈｅ ｓｅｐａｒａｔｉｏｎ ｂｅｔｗｅｅｎ ｔｈｅ ｅｑｕｉｐｍｅｎｔ ａｎｄ ｒｅｃｅｉｖｅｒ．
－Ｃｏｎｎｅｃｔ ｔｈｅ ｅｑｕｉｐｍｅｎｔ ｉｎｔｏ ａｎ ｏｕｔｌｅｔ ｏｎ ａ ｃｉｒｃｕｉｔ ｄｉｆｆｅｒｅｎｔ ｆｒｏｍ ｔｈａｔ
ｔｏ ｗｈｉｃｈ ｔｈｅ ｒｅｃｅｉｖｅｒ ｉｓ ｃｏｎｎｅｃｔｅｄ．
－Ｃｏｎｓｕｌｔ ｔｈｅ ｄｅａｌｅｒ ｏｒ ａｎ ｅｘｐｅｒｉｅｎｃｅｄ ｒａｄｉｏ／ＴＶ ｔｅｃｈｎｉｃｉａｎ ｆｏｒ ｈｅｌｐ
－ Ｔｈｉｓ ｄｅｖｉｃｅ ａｎｄ ｉｔｓ ａｎｔｅｎｎａ（ｓ） ｍｕｓｔ ｎｏｔ ｂｅ ｃｏ－ｌｏｃａｔｅｄ ｏｒ ｏｐｅｒａｔｉｎｇ ｉｎ
ｃｏｎｊｕｎｃｔｉｏｎ ｗｉｔｈ ａｎｙ ｏｔｈｅｒ ａｎｔｅｎｎａ ｏｒ ｔｒａｎｓｍｉｔｔｅｒ．
Ｔｈｉｓ ｅｑｕｉｐｍｅｎｔ ｃｏｍｐｌｉｅｓ ｗｉｔｈ ＦＣＣ ｒａｄｉａｔｉｏｎ ｅｘｐｏｓｕｒｅ ｌｉｍｉｔｓ ｓｅｔ ｆｏｒｔｈ
ｆｏｒ ａｎ ｕｎｃｏｎｔｒｏｌｌｅｄ ｅｎｖｉｒｏｎｍｅｎｔ．
Ｔｈｉｓ ｅｑｕｉｐｍｅｎｔ ｓｈｏｕｌｄ ｂｅ ｉｎｓｔａｌｌｅｄ ａｎｄ ｏｐｅｒａｔｅｄ ｗｉｔｈ ｍｉｎｉｍｕｍ
ｄｉｓｔａｎｃｅ ｏｆ ２０ ｃｍ ｂｅｔｗｅｅｎ ｔｈｅ ｒａｄｉａｔｏｒ ａｎｄ ｙｏｕｒ ｂｏｄｙ
