Jimi JM01 User manual

JM01 Motorcycle GPS Tracker
www.jimilab.com
User Manual
Version: J1409-1.0

Please read this manual carefully before attempting installation and online
activation. Pictures are for indication and illustration purposes only.
1 Accessories
Pictures are for indication and illustration purposes only.
NOTE: After opening the packing box, please check if the accessories are
complete. If there is anything missing, please contact your distributor.
Cable User Manual (Optional) Relay (Optional)

GSM indicator SIM card slot
Power indicator
GPS indicator
2 Interface descriptions

3 LED status indicator and wiring
3.1 Red LED (power/working status indicator)
Status Meaning
Quick ashing Low battery
Slow ashing Fully charged
Continuously in bright Charging
Continuously in dark No battery/troubleshoot
3.2 Blue LED (GPS signal indicator)
Status Meaning
Quick ashing Searching GPS signal
Slow ashing GPS signal has successfully
Continuously in dark GPS stops working
3.3 Green LED (GSM signal indicator)
Status Meaning
Quick ashing GSM initialization
Slow ashing GPRS online
Continuously in dark No GSM signal or no SIM card installed

3.4 Armed
When red/green/blue 3 LED lights are ashing twice in cycle, it means the terminal
is armed.
3.5 Function of the wires
V+
V-
ACC
Relay
TX
RX
GND
No. Function Color Function Illustration
1 V+ Red Positive pole
2V- Black Negative pole
3 ACC Orange ACC on
4 Relay Yellow Relay controlled wire
5 TX Green Send data / for backup
6 RX Blue Receive data / for backup
7 GND Purple Ground wire

4 Installation
4.1 Placement
The terminal should be placed under cover. It is recommended to ask
professionals to install the terminal for you.
NOTE:
(1) The terminal should be placed under cover;
(2) protect it from water;
(3) Use bandage or foam tape to keep the terminal stable;
(4) Please make sure that the front side of the terminal should be facing up
without any metal cover.
1. Best place to install
Inside the
taillight cover
or the plastic
component
Inside the
headlight cover
around the
speedometer
Under the back seat

2. Best place to install
NOTE: The GPS signal will be weaken if the device is installed under the driver seat.
4.2 Wiring
Inside the
taillight cover
Inside the
front cover
Under
the pedal
Red Black Orange Yellow
Green Blue Purple
1
5 7
2 3 4
6

Yellow
Orange
Ignition lock
Red
Black
Fuse 2A
Pump
Battery
9-28VDC
86 30 87a 85
OFF ON(ACC)
Power/ACC
interface
Software
update
interface
1234 5
6
7

(1) Use multimeter to nd out the negative pole of the battery.
(2) Use multimeter to nd out the ACC wire. Method: Use the red pen to connect
with the ACC wire while the black pen connects with the ground wire. In this
condition, when the ignition lock is off, the voltage is 0; when the ignition lock
is turned on, the multimeter will show the voltage.
(3) The red line (positive pole) of the terminal cable should be connected to the
positive pole of the battery.
(4) Follow the picture above to connect the wires.
(5) When the terminal is connected to external power, insert the SIM and the red
indicator (power indicator) should be normally on. When the ignition lock is
turned off, the red indicator should be ashing slowly.
(6) The yellow wire of the relay control line should be connected to 86 as the
picture shows.
5 Power ON/OFF
5.1 Power ON
The terminal will be automatically on when you insert the SIM card. The battery
will connect the internal wires together in the terminal and the external power
supply will start providing power to the device and also charging the battery.

5.2 GSM&GPS signal searching
After the power is on, it will start searching the GSM and GPS signal. During this period,
the green indicator (GSM indicator) will be ashing while the blue indicator will be
ashing quickly. When the blue indicator is ashing slowly, it means GPS has located.
5.3 Power OFF
Pull out the SIM card, the terminal will be off.
6 Parameters setting
6.1 Set APN
Please send SMS command to the number of terminal so as to set up the APN
parameter. The terminal will reply “OK” automatically after setting successfully.
Send SMS command: APN,APN’s name#
e.g: APN,internet#
NOTE: The APN of some countries have user name and password, you may
need to send SMS command as follows:
Send SMS command: APN,APN’s name,user name,password#
e.g: APN,internet,CLIENTE,AMENA#

6.2 Set DNS
Please send SMS command to the number of terminal so as to set up the DNS
parameter. The terminal will reply “OK” automatically after setting successfully.
Send SMS command: SERVER,1,DNS,Port,0#
e.g. SERVER,1,JM01.szdatasource.com,8841,0#
6.3 Set SOS Number
(1) Add SOS number Via SMS command
Send SMS command: SOS, A,number1,number2,number3 # (A means add number).
You can set 3 SOS numbers in maximum. If set successfully, the terminal will
reply “ok”.
e.g. SOS,A, 13510****60,135116****6,136126****8# (set all 3 SOS numbers)
SOS,A, 13510****60# (set the rst SOS number)
SOS,A, ,135116****6# (set the second SOS number)
SOS,A, , ,136126****8# (set the third SOS number)
(2) Delete SOS Numbers
Send SMS command: SOS, D,1,2,3# (D means delete SOS number)
e.g. SOS, D,1# means delete the rst number
SOS, D,3# means delete the third number

If you do not know the sequence number, you can also delete the number by SMS
command like this: SOS, D,number#
e.g. SOS, D, 135278****0# means delete this SOS number directly.
It will reply “OK” if the number is deleted successfully.
(3) Add SOS numbers via platform
You can set SOS number via the platform after activating the terminal.
6.4 Set Center Number
Send SMS command from the SOS number to set the Center Number.
(1) Add Center Number:
Send SMS command: CENTER,A,number#
e.g. CENTER,A, 135278****0#
(2) Delete Center Number
Send SMS command:CENTER,D,number#
e.g. CENTER,D, 135278****0#
NOTE: Center Number can be set ONLY by SOS numbers.
6.5 Check current parameters

Send SMS command: PARAM#
The terminal will reply messages including: IMEI number, GPRS upload interval,
time interval that GPS is activated when ACC is off, SOS numbers, center number,
sensor alarm interval, defense time and time zone.
6.6 Set GPS data upload interval
(1) Upload by interval
The default upload interval is 20 seconds, which means every 20 seconds the
terminal will upload its location data to the platform. The interval can be set by
sending SMS command: TIMER,T1,T2# (5≤T≤18000 seconds)
e.g. TIMER,20,30#
It means when ACC is on, GPS data upload interval is 20 seconds; when ACC is
off, GPS data upload interval is 30 seconds.
(2) Upload by distance
Send SMS command: DISTANCE,D# (100≤D≤10000 meters)
e.g. DISTANCE,300#
It means for every 300 meters, the terminal will upload GPS data to platform.
NOTE: if the upload interval is short, the GPRS current will add up. Please set
the suitable upload interval.

6.7 Corners upload (ON as default)
The terminal will upload GPS data to the platform when the vehicle is turning (the
turning angle reaches the pre-set value).
NOTE: if the speed is too low during turning, the GPS data will be not able to
upload to the platform.
Send SMS command: ANGLEREP,OFF# to turn it off.
6.8 Arm time interval
When the vehicle is turned off (ACC low) and stays off in 3 minutes(pre-set), the
terminal will enter arm status. During this status, if the terminal detects 6 vibrations
(default) and the vehicle still stays off (ACC off) in 30 seconds, it will activate
vibration alarm.
Send SMS command: DEFENSE,T# (1≤T≤60 minutes)
e.g. DEFENSE,15#
It means after 15 minutes the vehicle is turned off, the terminal will enter defense mode.
6.9 Reboot the terminal
Send SMS command: RESET#
When the terminal receives the command, it will reboot in 20 seconds.

7 Operation
7.1 Check location
(1) Ask for coordinates
Send SMS command from SOS number to the terminal: WHERE#
Only SOS number can apply for replying longitude and latitude from the terminal.
If GPS is located, it will reply latest longitude and latitude information.
e.g. Lat:N22.571285,Lon:E113.877115,Course:42.20,Speed:0.0740,DateTi
me:10-11-23 22:28
If GPS is not located at all, the terminal will reply: “NO DATA!”
(2)Ask for Google link
Send SMS command from SOS number to the terminal: URL#
If GPS is located, it will reply google link of latest longitude and latitude.
e.g. Google link reply
<DateTime:10-11-23 23:42:51> http://maps. google.com/
maps?q=N22.571490,E113.877103
(3) Check platform
The terminal will send position information to the platform server timely. Users can
check the position on the platform.

The platform website: www.jimishare.com
Please contact your supplier for the login methods and operations.
7.2 Vibration Alarm (ON as default)
When the vehicle is turned off (ACC low) and stays off for 3 minutes (pre-set),
the terminal will enter arm status. During this time, if the terminal detects 6 times
vibrations (default) and the vehicle still stays off (ACC off) in 30 seconds, it will
activate vibration alarm. The terminal will upload longitude and latitude data to the
platform. Then the platform will send the google link to SOS number.
e.g. GPS information link:
“vibration alarm: <DateTime:10-11-23 23:42:51> http://maps. google.com/
maps?q=N22.571490,E113.877103”
If you do not want to receive vibration alarm messages, send SMS command:
SENALM,OFF# to turn it off.
7.3 Cable cut-off Alarm (ON as default)
When the terminal cable is cut off, the cable cut-off alarm will be activated. The
terminal will send the alarm to the platform and upload longitude and latitude data.
And the platform will send google link to SOS number.
e.g. GPS information link:

“Cut Power! <DateTime:10-11-23 23:42:51> http://maps. google.com/
maps?q=N22.571490,E113.877103”
Send SMS command: POWERALM,OFF# to turn it off.
7.4 Low Battery Alarm (ON as default)
When the battery is low, the terminal will send SMS to SOS numbers and upload alarm
information to platform. Send SMS command: BATALM,OFF# to turn off the alarm.
7.5 Moving alarm (OFF as default)
Send SMS command: MOVING,ON,R# (100≤R≤1000 meters, 300 is recommended)
In the situation where ACC becomes low, if the vehicle is moved over 300 meters
(pre-set) from the latest location, the terminal will send moving alarm to the
platform. SOS number will receive moving alarm message.
e.g.
Attention! The vehicle is moved. <DateTime:10-11-2323:42:51>http://maps.google.
com/maps?q=N22.571490,E113.877103
Send SMS command: MOVING,OFF# to turn off the alarm
7.6 Petrol cut-off
(1) Cut-off petrol

When the vehicle was stolen, you can cut off the petrol on the platform in the
situation where the speed is under 20km/h. Platform password is needed. Or you
can send SMS command to the device.
Send SMS command: RELAY,1# to cut off petrol.
(2) Restore petrol
You can restore petrol on the platform. Platform password is needed.
Send SMS command: RELAY,0# to restore petrol.
NOTE: Petrol cut-off and restore commands can be executed by the center
number ONLY.
8 Trouble shooting
If there is any problem while operating the terminal, please refer to the following
table, or contact your supplier.
Common problems Causes Solution
Bad reception Near the tall building or in the
basement
Change to a place with good
signal
The terminal cannot be The fuse blows Replace the fuse

Cannot connect to the
network
SIM card is not inserted
correctly Check the SIM card
The sheet mental of SIM
card isdusty Wipe it clean
Invalid SIM card Contact your SIM card
operator
Out of GSM service area Move back to the GSM
service covered area.
Weak signal Try again in a strong signal
area
Cannot charge
Voltage is out of charging
range of the charger Change to the proper voltage
Poor contact Check if the plug is in
Cannot check
address information
GPRS function is not
activated
Please contact the SIM card
operator to activate GPRS
Cannot get the position data ①restart the terminal
②contact with your supplier
It is not a SOS number set SOS number
