INSTALLATION GUIDE
for the
SB-F-ESCP/10W1v3
SKU#94440
2001-2011 Ford Escape, Mazda Tribute
2005-2011 Mercury Mariner
Thank you for choosing a JL Audio Stealthbox®for your automotive sound system. With proper installation, your new
vehicle-specific enclosed subwoofer system will deliver years of listening pleasure.
We strongly recommend that you have your new Stealthbox®installed by your authorized JL Audio dealer. The
installation professionals employed by your dealer have the necessary tools and experience to disassemble and
reassemble your vehicle properly. Also, keep in mind that your warranty coverage extends to 2 years if your system is
installed or approved by your authorized JL Audio dealer. If you prefer to perform your own installation, please read
this installation guide completely
before beginning the process.
If you choose to perform the installation yourself, it is absolutely vital that
the Stealthbox®be properly mounted to the vehicle according to these
instructions. Failure to mount the enclosure properly presents two problems:
1) The sub-bass performance will suffer due to the movement of the enclosure
caused by the force exerted by the woofer(s).
2) A loose enclosure presents a serious safety hazard in the event of a collision
or sudden deceleration.
STEP 1
Remove the cover in front of the pocket as shown.
Continued on Next Page
STEP 2
This is how it looks after removing the cover.
STEP 3
Remove the woofer from the Stealthbox®. Hold the
enclosure in place and use a marker to mark the interior
panel through the hole in the back of the Stealthbox®
SB-F-ESCP/10W1V3 INSTR_SKU# 011286
INSTALLATION
DIFFICULTY:
35
OUT
OF
ESTIMATED TIME:
23 HOURS

Continued on Next Page
SB-F-ESCP/10W1V3 INSTR_SKU# 011286
STEP 6
Remove bottom plastic trim piece from rear left door
opening.
STEP 4
Drill a 1” hole in the interior panel where marked as STEP 3
as shown.
Note: Before drilling, make sure that you are not
going to be drilling into any gas lines, brake lines,
transmission lines, electrical wiring, transfer case (4x4
vehicles) or anything else that might cause a reduc-
tion in your weekly pay. Always wear eye protection
when drilling!
Page 2 • JL Audio, Inc 2016
STEP 9
This shows the holes where the bracket mounts.
STEP 10 DETAIL 1
The bracket will be mounted as shown at left in the older
model vehicles.
STEP 10
Mount the bracket.
The bracket will be oriented as shown with all three bolts in a
straight line in the newer vehicles.
For the older models, the bracket will be mounted upside
down to the photo at left with the stud threaded into the
“triangular” hole and, above the two mounting bolts as
shown below
Please refer to the detail pictures for
further clarification.
STEP 8
The interior with the side panel removed. Note where the
bracket had been previously installed
STEP 5
Remove bottom trunk plastic trim panel as
shown.
STEP 7
Remove side panel as shown.

SB-F-ESCP/10W1V3 INSTR_SKU# 011286
Page 5• JL Audio, Inc 2016
All specifications are subject to change without notice. “JL Audio®” and the JL Audio logo, “Stealthbox” and the Stealthbox logo are registered
trademarks of JL Audio, Inc.“Ahead of the Curve” and its respective logo is a trademark of JL Audio, Inc.
JLA-SKU# 011286 09.20.2016 • Printed in USA • ©2016 JL Audio, Inc.
For more detailed information please visit us online at www.jlaudio.com.
[phone]
www.jlaudio.com
10369 NORTH COMMERCE PARKWAY • MIRAMAR, FLORIDA • 33025 • USA
INCLUDED HARDWARE
2) 1/4-20 x 1 1/4” Hex Head Bolt 2) 1/4-20 Hex Head Nut
2) 1/4” Split Lock Washer 2) 1/4” Flat Washer
1) 3/8” Split Lock Washer 1) 3/8” Flat Washer
1) 3/8-16 x 2 1/4” Allen Head Stud 1) 1” Spacer
1) Custom Mount bracket
SPECIFICATIONS
Enclosure Type: Acoustic Suspension (sealed)
Driver Type: 10W1v3-2
Nominal Impedance: 2 ohms
Continuous Power Handling: 300watts
POWER RECOMMENDATION
JL Audio recommends using a high quality amplifier such as the JL Audio XD300/1v2. The diagram below shows
the recommended crossover settings for the XD300/1v2 when being used to power your Stealthbox®.
The JL Audio XD300/1v2is a very versatile audio component. Please consult the owner’s manual for even more
detailed information about installing and tuning this amplifier.
MID/HIGH FREQUENCY DRIVER FITMENT
A variety of JL Audio coaxial and component systems will fit in the factory speaker locations of you vehicle.
Front Speaker Size / Location: 5”x 7” / 6”x 8”- Front Doors
Fits JL Audio Models: TR570-CXi, C5-570, C5-570x & ZR570-CSi
Rear Speaker Size / Location: 5”x 7” / 6”x 8”- Rear Door
Fits JL Audio Models: TR570-CXi, C5-570x
STEP 11
Expand the round hole in the interior panel from STEP 4 as
shown, re-install all of the interior panels that were removed
earlier, place the 1” Spacer (included) over the Stud as shown.
STEP 13
Mount woofer to the box . place grill over the speaker, secure
the woofer and you are done.
CONGRATULATIONS!
You have completed the installation for this model!
Enjoy your new Stealthbox®!
Please refer to the Power Recommendation section for an
amplifier recommendation and basic set-up help.
STEP 10 DETAIL 2
This is how the hardware should be configured for the
bracket and, the Stealthbox®.
STEP 12
Put the box in the panel and line it up with the bolt. Make
sure to run speaker wire from the enclosure to the location of
the amp before securing it to the vehicle.
