JOBO Spectator GSP040 User manual

Owner’s Manual

2

   
   
  




















3
GB
Content
General remarks 4
1. First use 6
1.1. Introduction 6
1.2. Safety instructions 6
1.3. Scope of delivery 7
1.4. Charging the battery 7
1.5. Switching on / off 8
2. How SPECTATOR functions 9
2.1. Product Function Diagram 9
2.2. OPERATION 10
3. Connect to the PC 20
3.1. Minimum systems requirements 20
3.2. Driver Windows 98/ME/XP/VISTA, Linux 2.4.x, MacOS 10.2.x 20
3.3. Log off SPECTATOR under Windows 20
3.4. SPECTATOR format for hard disks 20
3.6 Connect to PC 23
4. Warranty and Service 24
4.1. Warranty conditions 24
4.2. Contact/Service 25
4.3. STATEMENT & CAUTIONS 25
4.4. Technical specifications 26

4
General remarks
1. Liability
The manufacturer only guarantees suitability for the original purpose of this
product. Furthermore the manufacturer cannot be held responsible for the damage
of data. This also includes the loss of data as well as any consequential damage re-
sulting from the use of this product. The manufacturer reserves the right to further
develop the product continuously. Any such changes can be made without being
directly described in this manual. Thus, information contained in this manual must
not necessarily reflect the state of technical execution. For information on updates
please go to our Internet page under www.jobo.com.
2. Safety instructions
- Work on the product must only be carried out by appropriately qualified staff of
JOBO AG.
- Please, read this manual carefully and observe the appropriate instructions
when installing the device.
- Do not open the product or try to make changes to it. Never insert metallic
objects into the product as this may cause an electric shock, fire, a short circuit
or hazardous emissions. The components cannot be serviced by the user. If the
device does not function properly it must be examined by a qualified staff mem-
ber of the JOBO Technical Service. In this context please observe the warranty
conditions listed in Chapter 4.
- Never expose the device to rain and keep it away from water and moisture.
Never place liquid-filled containers on the device as its contents might penet-
rate into the opening of the drive as a result of which the danger of an electric
shock, a short circuit, a fire or an injury would be increased.
3. Instructions for use
- Never expose the device to temperatures outside the range of between 5° C
and 40° C (41 F and 104 F). This could result in damage to the drive or other
electronic components. Do not place the device in the proximity of heat sources
and do not expose it to direct sun light (also not through a window). Excessi-
vely cold or damp environments may also cause damage to the drive.
- Always pull the mains cable from the socket when there is the danger of
lightning or when the drive is not being used for an extended period of time

5
GB
because otherwise the danger of electrical shocks, of fire or of short circuits will
increase.
- Do not place the drive next to other electrical devices like television sets, ra-
dios or loudspeakers as this may impair the functioning of these other devices.
- Do not place the drive next to sources of magnetic interferences like computer
screens, television sets or loudspeakers. Magnetic interferences may impair the
operation and the stability of the drive. Do not place any heavy objects on the
drive and do not exert any excessive force or pressure on the device.
- During use or storage keep the device as free of dust as possible. Dust may
accumulate on the inside of the device and thus increase the danger of damage
or dysfunction.
- Never clean the surface of the device with solvents, paint thinners, cleaning
agents or any other chemical products. Instead clean the device by wiping it
down with a soft, dry cloth.
- In security checks at airports, customs stations etc. the device should be
treated like a laptop and not be put through X-ray machines or other control
systems.
- Do not switch on SPECTATOR above an altitude of 3,000 m above sea level. The
hard disk could be damaged by this and as a result data could be lost.
Attention!
If the above instructions for use are not observed the warranty for this device may
lapse.
4. Waste disposal of batteries
Batteries do not belong into household waste. As a consumer you are legally
obliged to return spent batteries to the point of purchase. Under no circumstances
must batteries be disposed of in an open fire, in a trash can, in a recycling
container unsuitable for batteries or in any other way that might constitute an
environmental hazard.

6
1. First use
1.1. Introduction
Many thanks for choosing the JOBO SPECTATOR. The SPECTATOR is the perfect
solution if you want more than just storing your data! With the new SPECTATOR
you can already view your pictures in superb quality while you are still traveling,
no matter where you are – and you can do so without a PC!
On the large 2.5“ high brilliance TFT color LCD you can look at your most beautiful
photos in breathtaking quality and you can even zoom in and out. The high reso-
lution display with 16 million colors makes it possible to view images accurately
no matter where you happen to be. The SPECTATOR supports all the conventional
memory cards and also boasts a USB port as well as a TV OUT connection. The
small memory miracle which is available with a 40, 80 or 120 GB hard disk starts
the data transfer with an automatic „Verify“ process so that you can be certain
that the transfer of you valuable pictures to the device has been successfully com-
pleted. The integrated Li-Ion battery makes the SPECTATOR your ideal companion
with which you can store, view and show your photos wherever you are.
For more information on all JOBO premium class storage products please go to
www.jobo.com
1.2. Safety instructions
The hard disk of the SPECTATOR is factory-formatted.
In order to prevent short circuits and electrical discharges you must avoid expo-
sing this product under all circumstances to water, rain or moisture. Please, also
observe the warranty provisions in Chapter 4.
In security checks at airports, customs stations etc. the device should be treated
like a laptop and not made to go through an X-ray machine or other control
systems.
Do not switch on SPECTATOR above an altitude of 3,000 m above sea level. The
hard disk could be damaged by this and as a result data could be lost.

7
GB
1.3. Scope of delivery
The package contains the following parts:
- JOBO SPECTATOR
- integrated battery
- integrated hard disk
- mains adapter
- driver CD including software
- USB cable
- video cable
- manual
1.4. Charging the battery
The device has an integrated Li-Ion battery with 2000 mAh. Please, charge the
battery once completely for 12 hours before the first use by way of the mains
adapter supplied with SPECTATOR. Only use the original mains adapter that comes
with the device for charging. The internal battery will then be charged via the
mains adapter. If the SPECTATOR is connected to a computer the charging is effec-
ted via the USB cable as long as the computer is switched on. Since the battery is
a Li-Ion battery the so-called memory effect is eliminated, which means you can
recharge the battery to be on the safe side when it is still half full. The charging
level of the battery is indicated by the battery symbol in the display.
The battery must not be exchanged by anyone other than the manufacturer.

8
1.5. Switching on / off
1.5.1. Switching on SPECTATOR
On the right-hand side there is the „ON / OFF” sliding switch by which to switch
on SPECTATOR. In order to avoid switching on the device by mistake the switch
needs to be held in the “ON” position for 2 seconds to activate the device. Make
sure that the battery is sufficiently charged.
1.5.2. Switching off SPECTATOR
In order to switch off the device you again operate the “ON / OFF” sliding switch
on the right-hand side for about 2 seconds. The display will confirm that the
device has been switched off.
The device has an energy saving function that you can activate in the systems
menu or by way of a timing function. With this function the display is switched
off after a pre-selected time. This measure relieves the internal battery and thus
saves energy. In order to use the device again press the “ON/OFF“ sliding switch.

9
GB
2. How SPECTATOR functions
2.1. Product Function Diagram
In order to familiarize you with SPECTATOR all keys and their functions are explai-
ned in the following diagram:
1. RESET : Restart the machine
2. Power : Pull 3 seconds to turn on or turn off
3. Hold : Lock the current status (except On/Off button)
4. TV Out : Connect to TV
5. : USB port
6. DC-5V : Input 5V
7. LED Power : Light on or off for power on or off
8. LED Battery Charging : Light on while charging battery
9. LED Battery Full : Light off when battery is full
10. LCD : 2.5TFT LCD Display
11. : Enter or confirm, view file
12. : Select Up file, or pan the picture up
13. : Select Down file, or pan the picture down
14. : Back to previous menu or file, pan the picture left
15. : Next menu or file, pan the picture right
16. + : Zoom out
17. - : Zoom in
18. : View slideshow/image, edit or copy file
19. : Back to the Start Up Menu, Thumbnail Menu or Exit
Battery Status:
When battery is full, battery status will show full green
When battery is low, battery status will show red meaning you need to recharge
the battery in time.

10
2.2. OPERATION
2.2.1. COPYING FILES to Hard Disk
After power on, the start up screen will give you three modes to choose from. The
device is also immediately in standby mode to copy files from memory cards to
internal Hard Disk. If you insert a card then press the file will be copied to
Hard Disk automatically. The card type is detected as well.
During the copying process the data is automatically verified. Thus you have the
safety to have same data on your memory card and on the hard disk after the
copying process is finished.
After the files are copied you are asked if you want to view the copied files or not.
Press if you do not wish to view the files, or press for “yes” to take a look.

11
GB
Important:
Under no circumstances should you remove the memory card during the copying
process. This may lead to the complete freezing of the SPECTATOR which can only
be released by a Reset.
For a copying process involving a large data volume it is recommended to check
the battery capacity by observing the battery symbol on the display. If the capaci-
ty is low you should first recharge the battery or connect the mains adaptor to the
device during copying.
If the device cuts out during copying the battery must be recharged and the
copying process repeated.
2.2.2. FILE MODE
The file mode gives you the opportunity to browse through the whole HDD, as
well as the inserted memory cards. In this mode you can copy, paste and delete
files and folders. This gives you the opportunity to move data from the HDD to
the memory card and vice versa as well. In this mode you can see the whole HDD
structure with all files, not just image files.
2.2.2.1 Select FILE mode
On the start up screen, you can use the buttons or to select one of the
three modes; FILE, IMAGE or SYSTEM mode. To confirm press the button. The
selected mode is highlight ed in red.

12
2.2.2.2. Functions of buttons in FILE mode
In the FILE mode the buttons have the following functions:
a.) down to next folder in folder structure
b.) pan after zoom to right side
a.) up to previous folder in folder structure
b.) pan after zoom to left side
a.) Select a file or folder in folder structure
b.) confirm to display an image
c.) confirm “copy, paste or delete”
d.) zoom back to full screen size, when image is displayed
a.) moving up in folder structure
b.) pan after zoom to the top
a.) moving down in folders
b.) pan after zoom to the bottom
activates the menu “copy paste delete”
takes you back to previous menu
+ Zoom in while image is displayed
- Zoom out while image is displayed
2.2.2.3. COPY – PASTE – DELETE
Being in the FILE menu and pressing the button activates the menu “copy
paste delete” on the right-hand side of the screen. You can either select a whole
folder or just one file, with this feature you can move the data everywhere you
want – even back to memory card.
First of all you have to choose the location in which you want to activate the
menu “copy paste delete”. To do so you either select the Hard Disk or one of the
memory slots. To confirm just press the button.

13
GB
The red highlighted button for example “copy” can be confirmed by pressing the
button. After doing so the menu disappears, this is also the confirmation
that the process has worked.
If you choose the “delete” button, there is a security step added. Once you con-
firmed “delete” with the button an extra window appears asking if you really
want to delete the file.

14
Press:
to finally delete the file or folder
to go back to previous menu.
2.2.3. IMAGE MODE
The image mode gives you all the possibilities to view your images: You can
preview the images, there is a thumbnail view, slideshow mode, zoom function and
you can use the “TV out” to present your pictures on TV. In the IMAGE mode all
files except images are hidden.
2.2.3.1 Select IMAGE mode
On the start up screen, you can use the buttons or to select one of the
three modes; FILE, IMAGE or SYSTEM mode. To confirm press the button. The
selected mode is highlighted in red.

15
GB
2.2.3.2 Functions of buttons in IMAGE mode
In the IMAGE mode the buttons have the following functions:
a.) next picture
b.) down to next folder in folder structure
c.) pan after zoom to right side
a.) previous picture
b.) up to previous folder in folder structure
c.) pan after zoom to left side
a.) Select a file or folder in folder structure
b.) confirm to display an image
c.) zoom back to full screen size when image is displayed
a.) moving up in folder structure
b.) pan after zoom to the top
a.) moving down in folders
b.) pan after zoom to the bottom
a.) activates “Thumbnail view”
b.) in “Thumbnail view” it activates the “slideshow” mode
a.) takes you back to previous menu
b.) takes you back from “Slideshow” mode to “Thumbnail view”
+ Zoom in while image is displayed
- Zoom out while image is displayed
2.2.3.3 Preview Image
When in the IMAGE mode select a folder containing images. The images in the
folder are displayed as preview pictures on the right-hand side of the screen. In
addition the size of the picture is shown underneath the image. If you scroll up
or down the corresponding picture will be shown.

16
2.2.3.4 Thumbnail view / Slideshow mode
When you have selected a folder, press button for thumbnail view. Then 8
pictures are displayed on the screen. You can move through the whole folder by
using the buttons: , , and .
To start the slideshow press button again and the slideshow will start auto-
matically. The pictures change automatically as well.
To get back to the “Thumbnail view” just press again button.
2.2.4. SYSTEM MODE
The SYSTEM mode allows you to adjust the SPECTAOR perfectly to your requirements,
such as on screen menu language, brightness and contrast of the display etc.

17
GB
2.2.4.1 Select SYSTEM mode
On the start up screen you can use the buttons or to select one of the
three modes; FILE, IMAGE or SYSTEM mode. To confirm press the button. The
selected mode is highlighted in red.
2.2.4.2 Functions of buttons in SYSTEM mode
In the SYSTEM mode the buttons have the following functions:
and change options
and selecting functions
takes you back to main menu
2.2.4.3 Settings in the SYSTEM menu

18
You have the following options to adjust:
1. Language of the on-screen menu
a. English
b. German
c. French
d. Spanish
e. Dutch
f. Swedish
g. Italian
2. Brightness
Range from 5 to 55
3. Contrast
Range from 5 to 55
4. TV
You can choose between:
S-PAL
C-Pal
C-NTSC
S-NTSC
5. LCD Off
This is a power saving function you, can choose to turn off the display after 5sec,
15sec, 30sec or never.
6. Update
You can update the firmware if there is a new release with new functions.
Warnings: If you wish to update the firmware to a new version, please download a
correct updated firmware from JOBO first and store it on a memory card; insert the
memory card in the slot, and press button to update the system. At the same
time, the screen will turn black but it still works (LED power light on). Please DO
NOT shut off power or pull out the memory card!
When finished, the power indicator light will turn off. Restart the machine. A new
version has been updated.

19
GB
2.2.5. SPECTATOR as external HDD or USB card reader
Connect the SPECTATOR to your computer with the USB cable. Then you can select
that the device will be identified as an HDD or CARD REARDER. Press button
to confirm your choice.
After confirming your choice the device will power off automatically and the
screen will turn black
Your computer will now automatically recognize the connected device. The hard
disk of the SPECTATOR will now be available to you as a new letter code drive. You
can new copy, move or delete all types of files in the Windows Explorer by `Drag
and Drop`.
2.2.6. Connect SPECTATOR to TV
In order to use the SPECTAOR with a TV you have to connect the yellow plug of the
video cable on one side to the TV OUT on the SPECTATOR, and another side to TV
related ports (red/white/yellow).The screen is now shown on the TV as well.
Make sure that you have selected the right TV format in the system mode (NTSC, PAL).

20
3. Connect to the PC
3.1. Minimum systems requirements
- Microsoft Windows TM 98/ Me/ 2000/ XP, MacOS 10.2 or higher, Linux 2.4.x or
higher
- CD-ROM drive
- Pentium2, 400 MHz
- RAM 32MB (Windows ME, 2000) – 64MB (Windows XP)
- 20MB hard disk memory
- USB interface
3.2. Driver Windows 98/ME/XP/VISTA, Linux 2.4.x,
MacOS 10.2.x
For these operating systems no drivers are required. Please, make sure that you
have installed the most recent Service Packs of the operating systems in question.
3.3. Log off SPECTATOR under Windows
Windows 2000/ME/XP users click on the ‚Remove or eject hardware’ symbol in the
bottom right-hand corner of the systems tray (next to the clock). Now select ‚USB
mass memory’ and click on the ‚End’ button.
Windows 98 users must use the ‚Device Manager’ to log off SPECTATOR. Find the
SPECTATOR in the ‘Device Manager` and click on the name with the right-hand
mouse key. After having selected ‚Remove’ you can disconnect SPECTATOR from
your PC.
3.4. SPECTATOR format for hard disks
The hard disk of SPECTATOR is factory-formatted.
SPECTATOR is a hard-disk based product. In the event of malfunctions the internal
hard disk can be reformatted.
It is imperative that this is done in the FAT32 format.
For Windows XP you need the program „Swissknife“ or „FAT32API.exe“ in order
to do the formatting. You will find the „FAT32API.exe“ program under www.jobo.
com (SPECTATOR formatting program) and „Swissknife“ on the enclosed driver CD.
