Joemeek JM47 TrakPak Q User manual

JM47 Tr a k Pa k Q
Quick start users guide
Congratulations on purchasing the all in one recording solution from JOEMEEK, the JM47
TrakPak. This quick start guide is designed to help you get good recordings and sounds
with as little hassle as possible.
Please check the contents of your TrakPak, and try a recording,
connecting your TrakPak contents as follows.
JM47 Meekrophone
VC3Q Pro Channel
& 5m Mic cable (underneath)
VC3Q Power supply
JM47 shockmount
Mic In
Line InInsert
Out 1Out 2
Phantom
Mix In
Power 12V AC
Only use power
supply provided
WARNING! Removal of cover
may expose dangerous voltages
No user serviceable parts inside
VC3Q Pro Channel rear panel view
To recorder
To monitors
(optional)
Power
Supply
* Phantom power button must be
pressed in for JM47 to function
Instrument source
NOTE : connection will disable
the mic input on VC3.
JM47 Meekrophone
The cardioid symbol shows the front of the Meekrophone.

Once you have set up your TrakPak, try out some of these settings. Remember that different sounds
require different use of a microphone and pre amplifier, so these settings should only be used as a
starting point. The best way to get good sounds is to use you ears! The output gain setting is not
shown as it's setting depends on connected equipment.
Comp On
Comp On
A blacked out button indicates that it is pushed in.
Setting hints from the designer...
Input Gain : Always try to run the input gain high, i.e. just lighting all the
lights on the Pro Channel with the compressor switched out. Use this to
get your setting, then add compression as needed. The level on the meter
will drop, but the input amp will be working at the same level.
Compression release : Compression is more noticeable on the slow attack
setting and short release settings.
Enhancer : Take care not to over use the enhancer, you can always add
enhancement later in the mix, but you cannot take it off!
Output gain : The output gain is always the last control to set. It is the
only control that will not alter the sound of the Pro Channel in any way.
30cm approx, near edge of one cone
Miking cabinets
For electric bass and guitar,
better results can be
achieved (than a direct
recording) by using the
JM47 Meekrophone to mic
a cabinet when played
LOUD. Use similar settings
as shown but with much
less input gain. The JM47
may also be used with the
10dB pad to reduce output
level if necessary.
JM47 TrakPak
Quick start users guide
Manufactured by: FLETCHER Electroacoustics Ltd.
St Mary’s, Barton Road, Torquay, Devon. TQ1 4DP. ENGLAND.
Tel: [phone]
Fax: [phone]
e-mail: [email protected]
Input Gain Comp On
Compression Attack Release Low (80Hz) Mid (1.8kHz) Out VolHigh (8kHz) On Phantom O/L
EQ In
Mic Gain
0
10
20
35
60
111
3
2
4
567
0
0
15 25
5
MIC PRE - OPTO COMPRESSOR - MEEQUALIZER VC3Q
JOEMEEK
1ms 125ms -16 -16 -1611ms 1.5s +16 +16 +16 +6
+4
+2
700ms 0 0 0
800ms
1s -6
-10
+3 +3 +3 -10 -3 -3 -3
6ms 7ms
5ms
dB Input Meter
-12 -6 0 +8
Q
- RECORDING VOCALS
Medium compression, slow attack, medium release, brightening eq but
keep subtle for this program material.
- Mike'd acoustic guitar
Heavy compression, slow attack, medium release, aggressive eq
- BASS/Drums
Heavy Heavy compression, slow attack, fast release, plenty of bass
boost, and mid range cut - (especially good with slap styles)
Input Gain Comp On
Compression Attack Release Low (80Hz) Mid (1.8kHz) Out VolHigh (8kHz) On Phantom O/L
EQ In
Mic Gain
0
10
20
35
60
111
3
2
4
567
0
0
15 25
5
MIC PRE - OPTO COMPRESSOR - MEEQUALIZER VC3Q
JOEMEEK
1ms 125ms -16 -16 -1611ms 1.5s +16 +16 +16 +6
+4
+2
700ms 0 0 0
800ms
1s -6
-10
+3 +3 +3 -10 -3 -3 -3
6ms 7ms
5ms
dB Input Meter
-12 -6 0 +8
Q
Input Gain Comp On
Compression Attack Release Low (80Hz) Mid (1.8kHz) Out VolHigh (8kHz) On Phantom O/L
EQ In
Mic Gain
0
10
20
35
60
111
3
2
4
567
0
0
15 25
5
MIC PRE - OPTO COMPRESSOR - MEEQUALIZER VC3Q
JOEMEEK
1ms 125ms -16 -16 -1611ms 1.5s +16 +16 +16 +6
+4
+2
700ms 0 0 0
800ms
1s -6
-10
+3 +3 +3 -10 -3 -3 -3
6ms 7ms
5ms
dB Input Meter
-12 -6 0 +8
Q
Caution!
