Model: FC-25PFC
25-Gallon Fuel Cart
(UN/DOT Approved)
Operator’s Manual
REV 8/23/17
OPERATOR’S MANUAL FC-25PFC FUEL CART
Item Description Qty Part No.
1 ank - 25 Gallon 1 N/A
2 Adapter O-Ring Groove 1 14GC-05
3 O-Ring 1 9464K39
4 1/2” NP Swivel 90° Elbow 1 1501-8-8
5 1/2” NP M x F Ball Valve 1 BV-1/2NP MF
6 Dispensing Hose 1 80-593-14
7 Dispensing Nozzle 1 JL-5116-1
8Wheels 10.0 x 3.0 Pneumatic with 5/8”
Bearing 2 P1030-20S-R
9 Flat Washer 5/8” ID Zinc Plated 4 FRWSAW062
10 Axle Caps 5/8” ID Zinc Plated 1 14174
11 Fill Cap 1 201594
™
151 Snyder Ave.
Barberton, OH 44203
www.johndow.com
[e-mail]
4.
7
6
To load for transportation
1. Load the fuel cart onto a trailer or truck bed and place in horizontal position ONL (valve and cap up). DO NOT place inside a
vehicle trunk or inside the passenger compartment.
2. Secure the container with proper restraining devices to prevent movement in all directions. Proper restraining devices include
tie-down straps, cables or chains that are in good condition and strong enough to withstand the forces that may be
encountered during transportation. There should not be any sharp edges in contact with the plastic tank. The restraining devices
may be wrapped around the tank body in the grooved ribs, around the molded handle, or around the axle. DO NOT attach
restraining devices to the ball valve, hose fittings, or fill cap.
3. It is the vehicle operator’s responsibility to comply with all federal, state, and local regulations for the transportation of fuel,
and including the use of placards where required.
Storage
Once the container has been first used, all statements below apply, whether the container is empty, full or partially full.
1. It is the user’s responsibility to review and comply with all local and state building and fire codes regarding allowed quantity of
fuel that may be stored and the approved storage locations.
2. Keep out of reach of children.
3. Store in well-ventilated area.
4. Keep away from flame, pilot lights, stoves, heaters, electric motors and other sources of ignition.
5. DO NOT store inside a residence, living space or basement.
6. DO NOT store in an attached garage that is connected to residence or dwelling.
7. DO NOT store in vehicle passenger compartment or vehicle trunk.
8. DO NOT store in direct sunlight.

OPERATOR’S MANUAL FC-25PFC FUEL CART OPERATOR’S MANUAL FC-25PFC FUEL CART
Assembly Instructions
1. Assemble the 1/2 inch threaded end of the hose (A) into the valve as shown. DO NOT
use any pipe sealant or tape on this connection. The rotating nut on the 90° elbow will
pull the valve against a metal cone seat to creating the seal. Tighten.
2 Wrap the ¾ inch pipe fitting end of hose (B) with PTFE tape or apply pipe sealant.
Assemble into the dispensing nozzle and tighten.
3. The tires are not inflated prior to shipment. Inflate both tires to 15 psi (1.0 bar) before
using.
To fill container
1. Confirm the filling location is safe and away from all sources of ignition, sparks, and
flames.
2. Place the fuel cart container on the ground in horizontal position (valve and fill cap up)
away from vehicle before filling. Placing the container on the ground allows a path for stat-
ic charge to dissipate.
3. Dissipate any static electricity by touching a metal surface away from the nozzle prior to
removing nozzle from dispensing pump
4. Remove filler neck cap and insert service station dispensing nozzle into the filler neck
opening.
5. Keep the service station dispensing nozzle in contact with the container opening while fill-
ing. DO NOT use nozzle lock-open device. DO NOT re-enter vehicle while filling your gas
caddy or while refueling your vehicle. Re-entry could cause a static build up.
6. Fill slowly to prevent the build up of static charges. Stop immediately if you sense the
build up of static charges (sensation of hair raising or tingling of parts of body).
DO NOT resume filling until static charges dissipate.
7. Closely monitor flow to prevent spills and overfilling the container.
8. Do not fill above the bottom of the threaded filler neck.
9. Reinstall the filler neck cap and tighten by turning the fill cap in direction as shown
until ratchet “CLICK” is heard. The ratchet indicates that the cap is tight and fully closed.
10.Wipe any residual fuel from outside of tank or allow to evaporate.
To dispense from container
1. Position tank in upright vertical position.
2. Slowly crack open fill cap to vent any internal pressure.
3. Retighten fill cap. (Note: Cap will self vent while dispensing).
4. Open foot valve by turning the ball valve handle clockwise as shown to be inline with the
flow in the hose.
5. Place tip of nozzle into container that is being filled. The nozzle must remain inside the
container while dispensing.
6. Fuel is gravity dispensed through nozzle. Squeeze handle to begin flow, release to stop.
7. onitor flow and liquid level to prevent spills.
8. When finished drain remaining fuel back into the tank per the instructions below.
To drain fuel from hose back into the container
1. Lay fuel cart in horizontal position (valve and fill cap up).
2. Elevate the nozzle above the hose, and slope the hose back to the valve to
provide a clear path for fluid to drain.
3. With the nozzle above the hose, squeeze the handle of the nozzle to allow hose to vent
and fuel to drain back into the tank.
4. Close the ball valve.
To close for transportation or storage
Return all fuel from hose back into tank per above instructions.
1 Close the tank
a.. Close ball valve by turning the handle until it stops in 90° position as shown.
This indicates that the ball valve is in the closed position.
b. Turn fill cap in direction as shown until the cap seats on tank, then turn an
additional 1/8 turn.
c. Turn manual vent in direction as shown until closed, then turn an additional 1/8 turn.
2. 3.
Capacity and Dimensions:
Fill capacity vertical: 25.0 gal. (94,6 liter)*
Fill capacity horizontal: 22.5 gal. (85,1 liter)*
aximum volume of tank: 29.5 gal. (112,1 liter)
*when filled to just below the bottom of filler neck
Tare Weight: 32.0 lbs (14,55 kg)
Gross Weight (25 gal of fuel): 192.0 lbs (87,1 kg)*
Dimensions (horizontal): 43 (L) x 23 (W) x 18 (H)
INSTRUCTIONS PERTAINING TO THE RISK OR INJUR TO PERSONS.
IMPORTANT SAFET INSTRUCTIONS. SAVE THESE INSTRUCTIONS.
READ THIS MANUAL CAREFULL BEFORE INSTALLING,
OPERATING OR SERVICING THIS EQUIPMENT
It is the responsibility of the employer to place this information in the
hands of the operator. Keep for future reference.
1. Gasoline and other fuels are extremely flammable. Keep away from heat sparks and open flames as an explosion will result in
severe personal injury.
2. Gasoline vapors can explode. Avoid breathing fuel vapors.
3. DO NOT siphon by mouth. Harmful or fatal if swallowed; if swallowed, DO NOT induce vomiting. Call a physician immediately.
4. Ground ALL containers for extra safety by connecting the containers to a metal pipe or rod that is buried underground.
5. DO NOT modify this tank or its componenets. All components and design features have been tested and approved for use for
handling flammable fuel.
6. DO NOT get back in vehicle whicle refueling re-entry could cause a static build up.
7. Avoid excessive atitation, shaking, splashing or high flow rates as these can increase the risks of static charge build up.
8. DO NOT use electronics or mobile communication devices such as mobile phones while dispensing or handling fuel.
9. DO NOT smoke near or while using this gas caddy.
10.Secure or strap container to trailer or truck bed. DO NOT store inside vehicle, living space or direct sunlight. Store and use in a
well ventilated area.
11.Keep container closed when not in use.
12.Keep nozzle in contact with the container while filling. DO NOT use nozzle lock-open device.
1. Obtain aterial Safety Data Sheets on fuels being handled. Always wear required proper personal protection equipment
and clothing.
2. Place container in horizontal position on ground when filling.
3. When using this product basic precautions should always be followed, including the following:
a. Read ALL instructions before using this product.
b. To reduce the risk of injury, close supervision is necessary.
c. Keep out of reach of children.
d. DO NOT put fingers or hands into openings or into the pump.
4. Ensure that all fittings and threaded hose and pipe connections are tightened and leak free.
5. If fire starts, DO NOT remove nozzle. Back away immediately.
1. Be certain all operators of the equipment have been trained for safe working practices and understand its limitations.
2. Use Caddy for “one type of fuel only” to avoid possible damage to vehicle.
3. Use care when maneuvering to prevent injury or loss of control. Seek assistance to avoid strain or injury when required.
4. onitor flow rate and fill levels to prevent overflows and spills. DO NOT overfill containers, drums or tanks.
5. Perform the entire closure procedure before using the fuel cart to transport fuel.
6. Regulations for the transportation of gasoline vary from state to state, even locally. It is the vehicle operator’s responsibility to
review and comply with all federal, state and local regulations.
7. Review and comply with all building and fire codes concerning proper storage of fuel. It is the owner’s/user’s responsibility to
comply with all building and fire codes.
DANGER
WARNING
CAUTION
Indicates an imminently hazardous situation which, if not avoided, will result in death or
serious injury.
Indicates a potentially hazardous situation which, if not avoided, mayh result in death or
serious injury.
Indicates a potentially hazardous situation which if not, avoided, may result in minor or
moderate personal injury. It may also warn of unsafe practices.
