Johnson Controls KT-MUL-MT-KP Assembly instructions

Smart card readers / Lecteurs de cartes à puce
Mullion / Meneau de porte
Technical Specifications
Mullion Single Gang
Model KT-MUL-MT-KP KT-MUL-MT KT-MUL-SC KT-SG-MT-KP KT-SG-MT KT-SG-SC
RF technologies 13.56 MHz
125 kHz
13.56 MHz
125 kHz 13.56 MHz 13.56 MHz
125 kHz
13.56 MHz
125 kHz 13.56 MHz
Power consumption (mA) @ 12
VDC Peak / AVG 200 mA / 80 mA 120 mA / 70 mA 120 mA / 70 mA 200 mA / 80 mA 120 mA / 70 mA 120 mA / 70 mA
Weight 110 g (0.24 lb) 110 g (0.24 lb) 105 g (0.23 lb) 175 g (0.4 lb) 170 g (0.37 lb) 165 g (0.36 lb)
Capacitive Touch Keypad with
backlighting Yes No No Yes No No
Typical read range 125 kHz
ioProx ID-1 credentials (Cards) Up to 5.1 cm (2 in.) -- Up to 6.8 cm (2.7 in.) --
Typical read range 13.56 MHz
MIFARE Plus EV1, encrypted
sector, ID-1 credentials (Cards)
Up to 3.8 cm (1.5 in.) Up to 4.3 cm (1.7 in.)
Mounting Mullion Single Gang, North America / Europe
Dimension
(H x W x D) 115.8 x44.6 x24.7 mm (4.56 x 1.75 x 0.97 in.) 115.8 x71.5 x24.7 (4.56 x 2.81 x 0.97 in.)
Supported credentials 125 kHz ioProx and HID® -- ioProx and HID® --
Supported credentials 13.56 MHz MIFARE Plus EV1, iClass CSN, and ISO/IEC 14443A/14443B/15693 CSN
Supported credentials BLE
(Bluetooth low energy) 2.4 GHz
ioSmart mobile credentials and smart keys
Wiring terminal 6 screwless poles
Tamper Optical
Wiegand communication formats Kantech SSF, Kantech XSF, 26-bit, 34-bit, HID Prox
Sounder Integrated
Security: AES-128 bit encryption From the ioSmartcard to the reader.From the reader to the access controlunit over RS-485.
Security: AES-256 bit encryption From the ioSmartmobile credential to the reader. Not verified by UL.
Output RS-485 or BLE panel-less: 1 supervised open-drain, up to 750 mA
Operating temperature - 40°C to +70°C (- 40°F to +158°F). - 35°C to +66°C (- 31°F to +151°F) for UL listed product.
Operating humidity 0 to 95% non-condensing. UL verified at 85% Rh.
LED indicator Multi-color bar: Red, green, yellow, blue. Configurable.
Inputs in Wiegand mode LED and buzzer
Inputs in RS-485 2 to 4, configurable
Inputs in BLE panel-less 2 configurable
Input voltage 8.5 VDC to 16 VDC (provided by UL 294 or UL 603 listed, power limited power source).
Housing Polycarbonate, smoked black
Flammability rating UL94 V-2
Firmware Fully upgradable using RS-485
Ingress protection rating IP55 (not verified by UL)
Communication Wiegand, RS-485 (AES-128), OSDP (AES-128 using RS-485), or BLE (AES-128, or AES-256, not veri-
fied by UL)
Cabling 3 twisted pairs AWG 22 unshielded or CAT5, up to 150 m (500 ft)
Warranty Limited lifetime
Certifications FCC, IC, CE, UL 294, UL 1076, UL 2610, FIPS 197, RoHS, WEEE.
For RS-485, NIST CAVP validation number AES 3667, key length 128.
Note: For more information about wiring distances, refer to the ioSmart Card Reader Installation Guide.

Smart card readers / Lecteurs de cartes à puce
Single Gang / Boîte électrique simple
Spécifications techniques
Meneau de porte Boîte électrique simple
Modèle KT-MUL-MT-
KP KT-MUL-MT KT-MUL-SC KT-SG-MT-KP KT-SG-MT KT-SG-SC
Fréquences de transmission 13,56MHz
125kHz
13,56MHz
125kHz 13,56MHz 13,56MHz
125kHz
13,56MHz
125kHz 13,56MHz
Consommation (mA) à 12Vc.c.
(pointes / moyenne) 200mA / 80 mA 120mA / 70 mA 120mA / 70 mA 200mA / 80
mA 120mA / 70 mA 120mA / 70 mA
Poids 110g (0,24lb) 110g (0,24lb) 105g (0,23lb) 175g (0,4lb) 170g (0,37lb) 165g (0,36lb)
Clavier tactile capacitif avec
rétroéclairage Oui Non Non Oui Non Non
Distance de lecture moyenne à
25kHz ioProx, carte type ID-1 Jusqu'à 5.1cm (2") -- Jusqu'à 6.8cm (2,7") --
Distance de lecture moyenne à
13,56MHz
Mifare Plus EV1, secteur crypté,
carte type ID-1
Jusqu'à 3.8cm (1,5") Jusqu'à 4.3cm (1,7")
Compatibilité d'installation Meneau de porte Boîte électrique simple pour l'Amérique du Nord /
Europe
Dimension en millimètres (en
pouces) (H x L x P) 115,8 x44,6 x24,7 mm (4,56 x1,75 x0,97") 115,8 x71,5 x24,7 mm (4,56 x2,81 x0,97")
Format de cartes supporté
125MHz ioProxet HID® -- ioProxetHID® --
Format de cartes supporté
13,56MHz
MIFARE Plus EV1, iClass CSN, et ISO/IEC 14443A/14443B/15693 CSN
Format de cartes supporté BLE
2.4 GHz
Identifiants mobiles et clés intelligentes ioSmart
Bornes de câblage 6pôles sansvis
Anti-sabotage Optique
Formats de Communication
Wiegand
Kantech SSF / Kantech XSF / 26bits / 34bits / HID Prox
Avertisseur sonore Intégré
Sécurité, cryptage AES-128 À partir de la carte ioSmart jusqu'au lecteur. À partir du lecteur jusqu'au contrôleurd'accès en mode
RS-485.
Sécurité, cryptage AES-256 Entre l'application mobile et le lecteur. Non vérifié par UL.
Sortie RS-485: 1supervisée drain ouvert, jusqu'à 750 mA
Température de fonctionnement - 40°C à +70°C (- 40°F à +158°F). - 35°C à +66°C (- 31°F à +151°F) pour les produits UL listed.
Taux d'humidité 0 à 95% sanscondensation. 85% sans condensation pour les produit ULlisted.
Voyant DEL Barre multicolore: Rouge, verte, jaune, bleue et couleurs obtenuespar configuration
Entrées en mode Wiegand DEL et avertisseursonore
Entrées en mode RS-485 2 à 4, configurable
Entrées en mode BLE panel-less 2 configurable
Alimentation 8,5Vc.c. à 16Vc.c. (fournie par une source d'alimentation à puissance limitée, référencée UL 294 ou
UL 603).
Boîtier Polycarbonate, noir fumé
Indice d'inflammabilité UL94 V-2
Micrologiciel Facilement mis-à-jour via le bus RS-485.
Indice de protection IP55 (non vérifié par UL).
Communication Wiegand, RS-485 (AES-128), OSDP (AES-128 via RS-485), ou BLE (AES-128, ou AES-256, non vérifié
par UL).
Câblage 3paires torsadées, 22AWG, non blindé ou CAT5, jusqu'à150m (500pi) de long.
Garantie Àvie limitée
Certifications FCC/IC, CE, UL 294, UL 1076, UL 2610, FIPS 197, RoHSet WEEE.
Pour RS-485, NIST CAVP numéro de validation AES 3667, longueur de clé 128.
Remarque: Reportez-vous au manuel d'installation pour plusde détails sur lesdistancesde câblage.

Smart card readers / Lecteurs de cartes à puce
Mounting instructions
To install the reader, complete the following steps:
1. Pull the cable from the wall through the hole of the mounting plate.
2. Attach the mounting plate to the wall.
3. For tamper detection, cut the plastic tab from the mounting plate.
4. Fasten the white reflector tab back on the wall.
5. After installing the wiring using the wiring diagrams, insert the hook at the top of the cover
into the mounting plate tab and press the bottom of the cover until the bottom hook snaps
into place.
6. Use the provided Phillip's head screw to secure the bottom of the reader.
Note: If using CAT5 cable, use two wires for GND, and two wires for PWR.
Instructions pour montage
Pour installer le lecteur:
1. Tirez le câble du mur et le passer à travers la plaque de montage.
2. Fixez la plaque de montage au mur.
3. Pour une détection d'anti-sabotage, coupez la languette en plastique à partir de la plaque de
montage.
4. Refixez la languette blanche du réflecteur sur le mur.
5. Après l'installation du câblage conformément aux schémas de câblage, insérez le crochet en
haut du couvercle dans la languette de la plaque de montage et appuyez sur le bas du
couvercle jusqu'à ce que le crochet inférieur s'enclenche.
6. Utilisez la vis à tête Phillips pour fixer la partie inférieure du lecteur.
Note: Si vous utilisez un câble CAT5, utilisez deux fils pour GND et deux fils pour PWR.
FCC COMPLIANCE STATEMENT
CAUTION: Changes or modifications not expressly approved by KANTECH could void your authority to use this equipment.
Thisequipment, Smart card readers, has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turn-
ing the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
lReorient or relocate the receiving antenna.
lIncrease the separation between the equipment and receiver.
lConnect the equipment into an outlet on a circuit different from that to which the receiver is connected.
lConsult the dealer or an experienced radio/TV technician for help.
The user may find the following booklet prepared by the FCC useful: “How to Identify and Resolve Radio/Television Interference Problems”. This booklet is available
from the U.S. Government Printing Office, Washington D.C. 20402, Stock # 004-000-00345-4.
RF Exposure Statement
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This transmitter must not be co-located or operating in conjunction
with any other antenna or transmitter. In order to avoid the possibility of exceeding the FCC radio frequency exposure limits, thisequipment should be installed and oper-
ated with minimum distance 20 cm (7.8 inches) between the antenna and your body during normal operation. Users must follow the specificoperating instructions for sat-
isfying RF exposure compliance.
ISED CANADA STATEMENT
Thisdevice contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and EconomicDevelopment Canada’s licence-exempt RSS(s). Oper-
ation issubject to the following two conditions: (1) thisdevice maynot cause interference, and (2) thisdevice must accept anyinterference, including interference that
may cause undesired operation of the device.
L’émetteur/récepteur exempt de licence contenu dansle présent appareilest conforme aux CNR d’Innovation, Scienceset Développement économique Canada applic-
ables aux appareils radio exempts de licence. L'exploitation est autorisée auxdeuxconditionssuivantes: (1) l 'appareilne doit pasproduire de brouillage, et (2) l
'utilisateurde l 'appareildoit acceptertout brouillage radioélectrique subi, même sile brouillage est susceptible d 'en compromettre le fonctionnement.
CAN ICES-3 (B) / NMB-3 (B).
RF Exposure Statement (ISED)
This equipment complies with ISED RSS-102 radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with
minimum distance 20 cm (7.6 inches) between the radiator and any part of your body. This transmitter must not be co-located or operating in conjunction with any other
antenna or transmitter.
Pour se conformer aux exigences de conformité ISED RSS-102 RF exposition, une distance de séparation d'au moins 20 cm doit être maintenue entre l'antenne de cet
appareil et toutesles personnes. Lanceurs ou ne peuvent pas coexister cette antenne ou capteurs avec d’autres.
Mullion MT Mullion SC Single Gang MT Single Gang SC
FCC ID: V8515KTMULMTKP
ISED: 5690B-KTMULMTKP
FCC ID: V8515KTMULSCKP
ISED: 5690B-KTMULSCKP
FCC ID: V8515KTSGMTKP
ISED: 5690B-KTSGMTKP
FCCID:V8515KTSGSCKP
ISED: 5690B-KTSGSCKP
UL294 Performance Levels and Requirements:
Destructive Attack:LevelI(no attack test)
Line Security: LevelIII via RS-485 communication and EntraPassreader template having Buzzer enabled for Comm fail alarm; Level 1 via Wiegand com-
munication.
Endurance: LevelIV (100,000 cycles)
Standby Power: LevelI(no integralstandbypower)
Installation location and wiring methodsshallbe in accordance with the NationalElectricalCode, ANSI/NFPA 70. There isno maintenance required and there are no
replacement partsrequired for these devices.
UL 2610 Requirements:
lFor alarm signals, the end-of-line resistor shall be UL listed 5.6Kohm, 5%, 1/2 W with 18 AWG wire leads six (6) inches minimum. It shall be
securely fastened with no means to open circuit, short to an adjacent circuit node, or cause a risk of electrical shock.
lioSmart readers that are wired to controller’s Wiegand interface and used for arming and disarming shall be configured to mode 8 to enable
Wiegand mode tamper reporting.
For BLE mobile credential installations, BLE v4.2 or higher, Android OS 9.0 or higher, Apple iOS 9 or higher, and EntraPassgo Pass2.00.xx or higher are supported.

Smart card readers / Lecteurs de cartes à puce
Wiegand wiring diagram / Schéma de câblage Wiegand
The following diagram shows how to connect the reader to the host controller using Wiegand wiring. / Le schéma suivant démontre comment
connecter le lecteur au contrôleur hôte à l'aide du câblage Wiegand.
Note:If using CAT5 cable, use two wires for GND, and two wires for PWR. / Si vous utilisez un câble CAT5, utilisez deux fils pour GND et deux fils pour PWR.
RS-485 wiring diagram / Schéma de câblage RS-485
The following diagram shows how to connect the reader to the host controller using RS-485 wiring. / Le schéma suivant démontre comment
connecter le lecteur au contrôleur hôte à l'aide du câblage RS-485.
Note: If using CAT5 cable, use two wires for GND, and two wires for PWR. / Si vous utilisez un câble CAT5, utilisez deux fils pour GND et deux fils pour PWR.
The RS-485 mode is supported by two accesscontrollers, the KT-400 and the KT-1 (COM2). / Le mode RS-485 est supporté par deux contrôleurs d'accès, le KT-400 et
le KT-1 (COM2).
Optional input wiring connections RS-485 only / Schéma de câblage des entrées facultatives en RS-485 seulement
The following diagram shows how to connect the reader for optional input connections. This wiring is in addition to connecting to the host con-
troller. This is not currently available in EntraPass when using OSDP. / Le schéma suivant démontre comment connecter le lecteur pour les
connexions d'entrées facultatives. Ce câblage s'ajoute à la connexion au contrôleur hôte. Ceci n’est pas disponible dans EntraPass quand le
lecteur est configurer en mode OSDP.
BLE lock output wiring diagram / Schéma de câblage du verrou en BLE
The following diagram shows how to connect the BUZ input to a lock output in BLE panel-less mode, with optional input contact. / Le schéma
de câblage suivant démontre comment connecter l'entrée BUZ comme une sortie de verrouillage en mode BLE sans panneau,
avec contacts d'entrée en option.
© 2022 Johnson Controls. All rights reserved. JOHNSONCONTROLS
and KANTECH are trademarks of Johnson Controls. Specifications
may change without notice. Telephone: 1-888-222-1560 or 1-800-507-
6268. www.kantech.com
