FCP-PA-701-NF
FCP Programmable Fan Coil or PTAC Thermostat without Fan
LIT-12013797
September 2021
Quick Start Guide
Parts included
• One FCP thermostat
• Four mounting screws
• One lock screw
• Trim plate
• Four pre-installed terminal wires
• One wire label
• One coin cell battery
Applications
The FCP-PA-701-NF programmable, non-connected, stand-alone fan coil unit (FCU) or package terminal air conditioning (PTAC)
thermostat is compatible with most 24 VAC FCU or PTAC equipment.
The following list shows the compatible congurations of the equipment:
• 2-pipe without fan
• 4-pipe without fan
• Conventional PTAC without fan
• Radiant oor heating application
Note: An optional remote sensor is compatable with all congurations.
North American emissions compliance
United States
Canada
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and
can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment o󰀨 and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit di󰀨erent from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Warning: Changes or modications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to
operate the equipment.
CAN ICES-3(B)/NMB-3(B). This Class (B) digital apparatus meets all the requirements of the Canadian Interference-Causing Equipment Regulations.
Cet appareil numérique de la Classe (B) respecte toutes les exigences du Règlement sur le matériel brouilleur du Canada.
Number Description
1 Schedule
2 Time
3 Room temperature
4 Temperature setpoint
5 Back
6 Up
7 Down
8 Mode
9 Cool or heat status
10 Day
Figure 1: FCP dimensions, in. (mm) and UI layout Table 1: UI layout

FCP-PA-701-NF
LIT-12013797
2
Mounting
You can mount the FCP thermostat directly on the wall or to a junction box.
To mount the thermostat directly on the wall, complete the following steps:
1. To mark the screw holes, hold the back housing of the thermostat against the wall and use a pencil to lightly mark the holes. Ensure
the opening in the center of the back housing aligns with the wires in the wall. Figure 2 shows the back housing.
2. Drill the holes.
3. Optional: Insert drywall anchors into the holes.
4. Use the mounting screws to attach the back housing to the wall. See Figure 2.
5. Connect the wires to the front of the thermostat according to your equipment. See Wiring for diagrams.
6. Attach the front of the thermostat to the back housing. See Figure 3.
7. Optional: Insert the lock screw. See Figure 3.
To mount the thermostat to a junction box, complete the following steps:
1. Pull the wires through the hole in the junction box.
2. Insert the mounting screw in the top screw hole of the junction box. Drive the screw partially in, leaving it protrude 0.07 in. to 0.12 in.
(2 mm to 3 mm).
3. Place the top screw hole of the trim plate over the partly inserted screw in the junction box, then pull the wires through the trim plate
opening.
4. Slide the trim plate down to hook the plate onto the screw. See Figure 4.
5. Place the back housing in the trim plate opening.
6. Use the included screws to attach the back housing to the trim plate. The bottom screw joins with the junction box. See Figure 5.
7. Connect the wires to the front of the thermostat according to your equipment. See Wiring for diagrams.
8. Attach the front of the thermostat to the trim plate. See Figure 6.
9. Optional: Insert the lock screw.
Risk of Electric Shock
Disconnect the power supply before making electrical connections. Contact with components carrying hazardous
voltage can cause electric shock and may result in severe personal injury or death.
Risque de décharge électrique
Débrancher l’alimentation avant de réaliser tout branchement électrique. Tout contact avec des composants
conducteurs de tensions dangereuses risque d’entraîner une décharge électrique et de provoquer des blessures
graves, voire mortelles.
Figure 2: Mounting the back housing to the wall Figure 3: Attaching the front housing to the back housing

FCP-PA-701-NF
LIT-12013797
3
Wiring
Figure 5: Attaching the back housing to the
trim plate
Figure 4: Attaching the trim plate to the
junction box
Figure 7: 2-pipe fan coil unit
Figure 8: 4-Pipe fan coil unit
Figure 6: Attaching the front housing to the
back housing

FCP-PA-701-NF
LIT-12013797
4
Preset conguration proles
The FCP thermostat includes 20 preset conguration proles. You can use these proles to quickly congure essential settings, such as
system type, remote sensor, and pipe sensor.
The thermostat screen shows the preset conguration menu on the rst power up or after a factory reset. To select a conguration
prole, use the Up or Down buttons to scroll through the conguration proles, then press Mode to conrm your selection. The following
table lists the preset conguration proles.
Setup and adjustments
Figure 9: Conventional PTAC
Prole # Remote
sensor
Pipe
sensor
System
type
2-pipe
FCU with
aux heat
Available modes:
1: Heat only
2: Cool only
3: Heat and cool with auto
4: Heat and cool without auto
Pipe state
- calendar
Pipe state:
0: Heat
1: Cool
Purge
frequency:
0: Never
1: 2 hours
2: 24 hours
1Yes Yes 2-pipe FCU Yes 3O󰀨 - 1
2Yes Yes 2-pipe FCU Yes 3O󰀨 - 0
3Yes Yes 2-pipe FCU No 4 O󰀨 - 1
4Yes Yes 2-pipe FCU No 4 O󰀨 - 0
5Yes No 2-pipe FCU Yes 3O󰀨 0 -
6Yes No 2-pipe FCU Yes 3 On - -
7Yes No 2-pipe FCU No 4 O󰀨 0 -
8Yes No 2-pipe FCU No 4 On - -
9 No Ye s 2-pipe FCU No 4 O󰀨 - 1
10 No Yes 2-pipe FCU No 4 O󰀨 - 0
11 No No 2-pipe FCU No 4 O󰀨 0 -
12 No No 2-pipe FCU No 4 On - -
13 No No 2-pipe FCU Yes 3O󰀨 0 -
14 No No 2-pipe FCU Yes 3 On - -
15 Yes No 4-pipe FCU - 3 - - -
Table 2: Preset conguration proles (part 1 of 2)

FCP-PA-701-NF
LIT-12013797
5
Prole # Remote
sensor
Pipe
sensor
System
type
2-pipe
FCU with
aux heat
Available modes:
1: heat only
2: cool only
3: heat and cool with Auto
4: heat and cool without Auto
Pipe state
- calendar
Pipe state:
0: heat
1: cool
Purge
frequency:
0: Never
1: 2 hours
2: 24 hours
16 Yes No 4-pipe FCU - 4 - - -
17 No No 4-pipe FCU - 3 - - -
18 No No H-C - 1 - - -
19 Yes No H-C - 1 - - -
20 No No H-C - 3 - - -
Button combinations
The following table describes the button combinations that you can use to access menus or functions. The table also indicates the
modes in which these button combinations are applicable.
Menu or function Applicable in mode Button combination
Advance Settings menu OFF mode Mode + Back for 5 seconds
Access Programming menu OFF mode, when programming
is enabled in Advanced Settings
Mode + Up for 5 seconds
Pipe State (Heat/Cool) Selection OFF mode and system type =
2-pipe FCU
Back + Up for 5 seconds
Ex-Factory Reset OFF mode Mode + Back + Up for 5 seconds
Toggle Keypad lock/unlock HEAT and COOL mode Mode + Up + Down for 10 seconds
Enable/Disable unoccupied mode manually HEAT and COOL mode Mode for 5 seconds
Table 3: Button combinations
Table 2: Preset conguration proles (part 2 of 2)
Control mode
FCP has four control modes: OFF, HEAT, COOL, AUTO. The available control modes depend on the selected system type and available
mode in the advanced menu setting, see Table 6.
System type Control modes when thermostat operates
2-pipe
FCU with
aux heat
Fan
control
Pipe
sensor
installed
Pipe sensor state Heat only Cool only O󰀨 Auto
2-pipe FCU No
No
No Heat, manual
selection
Yes No
Yes
No
2-pipe FCU No No Cool, manual
selection
No Yes No
2-pipe FCU Yes No Heat, manual
selection
Yes No No
2-pipe FCU Yes No Cool, manual
selection
Yes Yes Yes
2-pipe FCU No Yes Heat, auto selection Yes No No
2-pipe FCU No Yes Cool, auto selection No Yes No
2-pipe FCU Yes Yes Heat, auto selection Yes No No
2-pipe FCU Yes Yes Cool, auto selection Ye s Ye s Ye s
4-pipe FCU n/a n/a n/a Yes Yes Yes
PTAC conventional n/a n/a n/a Ye s Ye s Ye s
Press Mode to access the control mode menu. Press Mode again to select the required control mode, OFF, HEAT, COOL, or AUTO. Do
not press any button for 2 seconds to conrm a change.
Note: AUTO mode is only available when both heating and cooling are available.
Table 4: FCP available modes

FCP-PA-701-NF
LIT-12013797
6
Run mode
Depending on your conguration, the thermostat runs in one of the following modes:
• Hold: the thermostat runs in hold mode if you do not enable the schedule.
• Schedule: the thermostat runs in schedule mode if you enable the schedule.
• Unoccupied: the thermostat runs in setpoint change or o󰀨 mode, depending on the unoccupied action that you set.
Setting the temperature
To change the temperature when the thermostat is in hold mode, press the Up or Down button to adjust the temperature setpoint. You
can also override the temperature when the thermostat is in schedule mode. To override the temperature, press the Up or Down button
to adjust the temperature setpoint. The thermostat runs in the new setpoint until the next scheduled period.
Advanced settings
You can edit user preference settings (UP), system conguration settings (SS), and installer conguration settings (IS) through the
advanced settings menu.
To access the advanced settings menu, complete the following steps:
1. Press Mode to set the thermostat to OFF mode.
2. Press and hold Mode and Back for 5 seconds.
The rst screen of the advanced settings menu shows your system conguration summary. Use the Up and Down buttons to scroll
through the advanced settings menu and press Mode to enter a submenu. Press Back to return to the previous menu.
Navigating the user preference settings, system conguration settings, and installer conguration settings
• Press Mode to scroll through the menu and press Up or Down to change options.
• Press Mode to conrm a change.
• Press Back to move backward in the menu, or press Mode at the end of the menu to return to the advanced settings menu.
The following tables list the user preference settings and system conguration settings. For an overview of the installer conguration
setting items, see FCP Programmable and Non-programmable Fan Coil or PTAC Thermostat User Guide, LIT-2013635.
Menu item Description Setting options Default
01 Temperature scale F: Fahrenheit
C: Celsius
F
02 User temperature calibration Temperature with calibration value. O󰀨set: +/- 5.4°F (+/-
3.0°C)
0.0°F (0.0°C)
03 Temperature calibration – remote
sensor
Temperature with calibration value. O󰀨set: +/- 5.4°F (+/-
3.0°C)
0.0°F (0.0°C)
04 Temperature calibration – pipe
sensor
Temperature with calibration value. O󰀨set: +/- 5.4°F (+/-
3.0°C)
0.0°F (0.0°C)
05 Backlight on duration 10 seconds, 30 seconds, always ON 10 seconds
06 Backlight brightness level 20, 40, 60, 80, 100 80
07 Display content 0: Ambient temperature + set temperature
1: Set temperature only
2: Ambient temperature only
0
08 Clock format 12: 12 hour
24: 24 hour
12
09 Auto Daylight Savings ON: Auto DST on
OFF: Auto DST o󰀨
ON
10 Programming mode ON: programmable
OFF: manual
ON
11 Periods per day 1, 2, 3, 4, 5, 6 2
12 Use default temperatures after
mode change
ON: Uses default temperatures
OFF: Uses last temperature for each mode
ON
13 Default heat mode set temperature 60°F (15.5°C) - Max Heat Set Temp 70°F (21°C)
14 Default cool mode set temperature Min Cool Set Temp - 80°F (27°C) 74°F (23.5°C)
Table 5: User preference settings

FCP-PA-701-NF
LIT-12013797
7
Menu item Description Setting options Default
21 System type 2FCU: 2-pipe fan coil unit without fan
4FCU: 4-pipe fan coil unit without fan
H-C: conventional without fan
4FCU
22 2-pipe FCU with aux heat available
(available only if system type = 2FCU)
Yes
No
No
23 Available modes 2FCU without aux heat:
04: Heat and cool without auto
2FCU without aux: 04
2FCU with aux: 03
4FCU, HP, or H-C: 03
2FCU with aux heat:
03: Heat and cool with auto
04: Heat and cool without auto
4FCU or H-C:
01: Heat only
02: Cool only
03: Heat and cool with auto
04 : Heat and cool without auto
25 Remote sensor location 0: in room
1: in duct
0
26 Remote sensor type 0: type II
1: type III
0
27 Pipe sensor type 0: type II
1: type III
0
28 Pipe state – calendar ON
OFF
OFF
29 Heat to cool day
(unavailable if pipe state – calendar = OFF)
1-Mar to 31-May 15-Apr
30 Cool to heat day
(unavailable if pipe state – calendar = OFF)
1-Sep to 30-Nov 15-Oct
31 Pipe state
(unavailable if system type ≠ 2FCU or if pipe
sensor = true or if pipe state – calendar = ON)
0: Heat
1: Cool
0
32 Heat to cool threshold
(unavailable if system type ≠ 2FCU or if pipe
sensor = false)
50°F - 72°F (10°C - 22°C) 60°F (16°C)
33 Cool to heat threshold
(unavailable if system type ≠ 2FC or if pipe sensor
= false)
55°F - 90°F (13°C - 32°C) 80°F (27°C)
34 Purge frequency
(unavailable if system type ≠ 2FC or if pipe sensor
= false)
0: Never
1: 2 hours
2: 24 hours
0
Table 6: System conguration settings

FCP-PA-701-NF
LIT-12013797
8
Programmable mode
In the programmable mode menu you can adjust time of day, date, schedule for heat, and schedule for cool.
To enable the programmable mode, complete the following steps:
1. Press Mode to set the thermostat to OFF mode.
2. Press and hold Mode and Back for 5 seconds to access the Advanced Settings menu.
3. Press Up to navigate to User Preference Settings, then press Mode to enter the menu.
4. Press Mode to navigate to 10.
5. Use the Up and Down buttons to set the programmable mode to ON and press Mode to conrm the change.
To access the programmable mode, press Mode to set the thermostat to OFF mode, then press and hold Mode and Up for 5 seconds.
Setting the time and date
1. In the programmable mode, press Mode to access the Set Time menu.
2. In the Set Time menu, press Mode to scroll through the menu and press Up or Down to change the options.
3. After each change, press Mode to conrm the change.
4. After you set all the options in the Set Clock menu, press Mode to continue to set the schedule, or press Back to exit the menu and
return to the home screen.
Setting the heat and cool schedule
You can program a schedule for up to seven consecutive days. Each day can consist of a maximum of six periods. You can change the
start times for each period by increments of 15 minutes.
1. In the programmable mode, press Up or Down to navigate to the heat icon, then press Mode to access the menu.
2. Press Up or Down to select the day of the week you want to schedule, then press Mode to conrm the selection.
3. Press Mode to navigate to the next setting and press Up or Down to set the required period and temperature. Repeat this step until
you set all the schedule settings.
4. Press Mode to save the settings and return to Set Sche menu.
5. Press Up or Down to navigate to the cool icon and press Mode to access the menu.
6. Repeat Step 3 and Step 4 until you set all the schedule settings.
Remote sensor
The system conguration summary indicates if a remote sensor is installed. Access the advanced settings menu to see your system
conguration summary.
You can adjust the values of the temperature o󰀨set to calibrate the remote sensor temperature.
To calibrate the remote sensor, complete the following steps:
1. Press Mode to set the thermostat to OFF mode.
2. Press and hold Mode and Back for 5 seconds to access the Advanced Settings menu.
3. Press Up to navigate to User Preference Settings, then press Mode to enter the menu.
4. Press Mode to navigate to 03.
5. Use the Up and Down buttons to change the option, then press Mode to conrm the change.
6. Press Mode at the end of the advanced settings menu to return to the home screen.
Pipe sensor
The system conguration summary indicates if a pipe sensor is installed. Access the advanced settings menu to see your system
conguration summary.
You can adjust the values of the temperature o󰀨set to calibrate the pipe sensor temperature.
To calibrate the pipe sensor, complete the following steps:
1. Press Mode to set the thermostat to OFF mode.
2. Press and hold Mode and Back for 5 seconds to access the advanced settings menu.
3. Press Up to navigate to User Preference Settings, then press Mode to enter the menu.
4. Press Mode to navigate to 04.
5. Use the Up and Down buttons to change the option, then press Mode to conrm the change.
6. Press Mode at the end of the advanced settings menu to return to the home screen.

FCP-PA-701-NF
LIT-12013797
9
Troubleshooting
The following table lists common errors and their solutions.
Error code Description Solution
ER:01 ERROR_AIR_
SENSOR_OPEN
• Check if the built-in temperature sensor is disconnected from the thermostat circuit board or
damaged.
• Contact technical support.
ER:02 ERROR_AIR_
SENSOR_SHORT
• Check if the built-in temperature sensor is short circuited or damaged.
• Contact technical support.
ER:03 ERROR_AIR_
SENSOR_HI
Built-in temperature sensor detected a temperature that is too high.
• Verify that the thermostat wiring is connected correctly to the FCU or PTAC.
• Contact technical support.
ER:04 ERROR_AIR_
SENSOR_LO
Built-in temperature sensor detected a temperature that is too low.
• Verify that the thermostat wiring is connected correctly to the FCU or PTAC.
• Contact technical support.
ER:05 ERROR_REMOTE_
SENSOR_OPEN
• Check if the remote temperature sensor is disconnected from the thermostat terminals RS
and SC. If it is, rewire the remote sensor correctly and then power cycle the thermostat.
• Check if the remote sensor has malfunctioned or is damaged.
• Contact technical support.
ER:06 ERROR_REMOTE_
SENSOR_SHORT
• Check the remote temperature sensor wiring and check if thermostat terminals RS and
SC are shorted. If they are, rewire the remote sensor correctly and then power cycle the
thermostat.
• Check if the remote sensor is malfunctioned or damaged.
• Contact technical support.
ER:07 ERROR_REMOTE_
SENSOR_HI
Remote sensor detected a temperature that is too high.
• Verify that the thermostat wiring is connected correctly to the FCU or PTAC.
• Verify that the remote sensor is installed correctly in the room or duct.
• Contact technical support.
ER:08 ERROR_REMOTE_
SENSOR_LO
Remote sensor detected a temperature that is too low.
• Verify that the thermostat wiring is connected correctly to the FCU or PTAC.
• Verify that the remote sensor is installed correctly in the room or duct.
• Contact technical support.
ER:09 ERROR_PIPE_
SENSOR_OPEN
• Check if the pipe temperature sensor wiring is disconnected from thermostat terminals PS
and SC. If yes, re-wire the pipe sensor correctly and then power cycle the thermostat.
• Check if the pipe sensor is malfunctioned or damaged.
• Contact technical support.
ER:10 ERROR_PIPE_
SENSOR_SHORT
• Check the pipe temperature sensor wiring and check if thermostat terminals PS and SC are
shorted. If it is, rewire the pipe sensor correctly and then power cycle the thermostat.
• Check if the pipe sensor has malfunctioned or is damaged.
• Contact technical support.
ER:11 ERROR_PIPE_
SENSOR_HI
Pipe sensor detected a temperature that is too high.
• Verify that the pipe sensor is installed correctly in the pipe.
• Contact technical support.
ER:12 ERROR_PIPE_
SENSOR_LO
Pipe sensor detected a temperature that is too low.
• Verify that the pipe sensor is installed correctly in the pipe.
• Contact technical support.
Table 7: Common errors

FCP-PA-701-NF
www.johnsoncontrols.com
Building Technologies & Solutions
Headquarters: Milwaukee, Wisconsin, USA
Branch Offices: Principal Cities World-wide
© Copyright 2021 Johnson Controls.
All specifications and other information shown were current as of document revision and are subject to change without notice.
This product is covered by a limited warranty, details of which can be found at
www.johnsoncontrols.com/buildingswarranty.
Product warranty
Contact information
Contact your local branch o󰀩ce: www.johnsoncontrols.com/locations
Contact Johnson Controls: www.johnsoncontrols.com/contact-us
Technical specications
Specication Description
Model FCP-PA-701-NF
Power requirements 20 VAC to 30 VAC, 60 Hz, max. 3 A (3 VA at 24 V nominal)
Output rating Valve outputs 1 A maximum per each relay channel
(Max. relays ON combination: 1 relay), 20 VAC to 30 VAC
Analog inputs Remote sensor 10K ohm at 77°F (25°C) NTC sensor
Pipe sensor 10K ohm at 77°F (25°C) NTC sensor
Binary input Set back NC/NO dry contact switch
Local temperature sensor type NTC temperature sensor, accurate to ±1°F (±0.6°C) at 77°F (25°C)
Remote temperature sensor type NTC temperature sensor, accurate to ±2°F (±1.2°C) at 70°F (21°C)
Wire size 18 AWG (100 ft [30.5 m] maximum) to 24 AWG (36 ft [11 m] maximum)
Temperature adjustment range Heat mode 45°F to 90°F (7°C to 32°C)
Cool mode 60°F to 95°F (15°C to 35°C)
Accuracy Local temperature
sensor
±1°F (+/-0.6°C)
Remote temperature
sensor
±2°F (±1.2°C) at 70°F (21°C)
Remote pipe sensor ±5°F (±3.0°C)
Deadband 2°F to 5°F (1°C to 3°C)
Ambient conditions Operating 14°F to 122°F (-10°C to 50°C); 5% RH to 90% RH, noncondensing
Storage -4°F to 140°F (-20°C to 60°C); 5% RH to 90% RH, noncondensing
Disconnection means Type 1B
Pollution degree 2
Rated impulse voltage 330 V
Automatic action 100,000 cycles
Ratings for supply and loading 20 VAC to 30 VAC
Dimensions H x W x D 3.27 in. x 3.94 in. x 0.98 in. (83 mm x 100 mm x 25 mm)
Shipping weight Product with packing and accessories: 10.1 oz (285 g)
Thermostat only: 4.9 oz (138 g)
Trim plate: 1.2 oz (33 g)
Compliance CONFORMS TO UL STD. 60730-1 & 60730-2-9
CERTIFIED TO CSA STD. E60730-1 & E60730-2-9
Table 8: FCP technical specications
5013346
