OWNER'S MANUAL
ELLIPTICAL E8000
Oct 12, 07’
SAP#0000082793, v2.0

TABLE OF CONTENTS
INSTRUCTION
IMPORTANT SAFETY INSTRUCTIONS
SETUP THE ELLIPTICAL
• Getting Started
• Making A Choice Of Site
• Stabilizing The Johnson Elliptical Trainer
• Unpacking The Total Body Elliptical Trainer
ASSEMBLY
• Fasteners & Assembly Tools
• Assembly Instructions
SERIAL NUMBER LOCATION
USING THE WORKOUTS
• Display Console
• Workout Parameter Prompts
• Workout Overviews
• Workout Tips
• Workout Setup Steps
• Using Fitness Networking
MANAGER'S CUSTOM MODE
• The List Of Manager's Custom Mode
MAINTENANCE
• Daily Inspection
• Daily Maintenance
• Monthly Maintenance
• Recycling the Battery
PRODUCT SPECIFICATIONS
02
03
04
06
13
14
23
25
26
01
JOHNSON ELLIPTICAL E8000

This Owner’s Manual describes the functions of the following product:
Johnson Total Body Elliptical Trainer E8000.
See "Product Specifications”(Page 26) in this manual for product specific features.
The Johnson Total Body Elliptical Trainer E8000 is intended for commercial use.
It is recommended that all users of Johnson Fitness exercise equipment should be
informed of the following information prior to its use.
When using the Johnson Total Body Elliptical Trainer, always follow basic precautions:
• To ensure your safety and to protect the unit, read all the instructions before assembling
and using the Total Body Elliptical Trainer.
• To ensure the proper use and safety of the Total Body Elliptical Trainer, make sure that
all users read this manual. Please make this manual a part of your facility’s training
program. Remind the users that before undertaking any fitness programme, they should
obtain complete physical examinations from their physicians. If, at any time while
exercising, the user experiences dizziness, pain, or shortness of breath, nausea or
feels faint, he or she must stop immediately.
SAVE THIS OWNER’S MANUAL FOR FUTURE REFERENCE.
INSTRUCTION
READ AND SAVE ALL INSTRUCTIONS before assembling or using the Johnson
Elliptical Trainer. It is strongly recommended to take the following safety instructions.
• Do not use this product outdoors, near swimming pools or in areas of high humidity.
• Do not allow children or those unfamiliar with its operation on or near the Johnson
Total Body Elliptical Trainer. Do not leave children unsupervised around the unit.
• Never drop or insert objects into any opening. Keep hands away from moving parts.
If the item cannot be reached, contact the Johnson authorized dealer for assistance.
• Do not wear any clothing that might catch on any moving parts of the Total Body
Elliptical Trainer.
• Do not turn pedals by hand, and do not use this product in bare feet.
• Do not dismount the Total Body Elliptical Trainer until the pedals are a complete stop.
• When mounting or dismounting the Johnson Total Body Elliptical Trainer, use the
stationary handlebar whenever additional stability is required. While exercising, hold
onto the moving arms.
• Never use on the Johnson Total Body Elliptical Trainer while facing backwards.
• Keep the area around the Johnson Elliptical Trainer clear of any obstructions, including
walls and furniture. Ensure that there are a few feet of clearance in front of the Total
Body Elliptical Trainer.
• Assemble and operate the Johnson Total Body Elliptical Trainer on a solid, level surface.
• If you plan to move the unit, obtain help and use a hand truck. Do not grasp any plastic
parts while lifting or moving the unit. The unit is too heavy and the plastic parts will
break.
• Never operate the unit if it is damaged, not working properly, when it has been dropped,
or has been dropped in water.
• Do not step on or set any object on the top of the pedal lever covers or the rear
platform.
• CAUTION! If you experience chest pains, nausea, dizziness or shortness of breath,
stop exercising immediately and consult your physician before continuing.
• CAUTION! Any changes or modifications to this equipment could void the product
warranty.
IMPORTANT SAFETY INSTRUCTIONS
0302
JOHNSON ELLIPTICAL E8000JOHNSON ELLIPTICAL E8000

GETTING STARTED
Read the Owner's Manual before setting up the Johnson Elliptical Trainer. Place the
unit where it will be used before beginning the setup procedure.
MAKING A CHOICE OF SITE
The site should be well-lit and well-ventilated. Locate the E8000 on a structurally solid
and flat surface a few feet from the wall or any equipment. If the site has a heavy
plush carpet, to protect the carpeting and machinery, you should place a rigid plastic
base under the unit.
Please do not place the Total Body Elliptical Trainer in an area of high humidity, such
as the vicinity of a steam room, indoor pool, or sauna. Exposure to intensive water
vapour or chlorine could adversely affect the electronics, as well as other parts of the
machine. To make exercise a desirable daily activity for you, the Total Body Elliptical
Trainer should be in an attractive setting.
STABILIZING THE JOHNSON ELLIPTICAL TRAINER
After placing the unit where it will be used, check its stability. If the Elliptical E8000 is
placed on a slightly, uneven surface, adjusting the adjustable levelers located
underneath the base frame can help, but will not compensate for extremely uneven
surfaces. To adjust, loosen the nut, and turn the leveler until the rocking motion
ceases, and both levelers rest firmly on the floor. Retighten the nut.
SETUP THE ELLIPTICAL
UNPACKING THE TOTAL BODY ELLIPTICAL TRAINER
The Elliptical Trainer is carefully inspected before shipment so it should arrive in good
operating condition. Johnson Fitness ships the unit in the following pieces:
NOTE: If these parts are missing from the package, please contact Johnson Fitness or
the local authorised dealers at once.
0504
JOHNSON ELLIPTICAL E8000JOHNSON ELLIPTICAL E8000
Hardware Kit
(A)
(B)
(D)
(H)
(I)
(J)
(G)
(C)
(E)
(F)
Main Frame Assembly
Console Mast
Console Mast Boot
Dual-Action Handrails
Pedal Arms
Front Foot
Handlebar Set
Console
Accessory Tray
Hareware Kit
A
B
C
D
E
F
G
H
I
J
)
)
)
)
)
)
)
)
)
)

ASSEMBLY
PARTS NO. DESCRIPTION QUANTITY
Z10
Z03
Z04
Z07
Z05
Z06
Z07
Z18
Z01
Z02
Z22
Z24
Z25
Z08
Z14
Z20
Z19
Z17
Socket Buttonhead Screw (M8 X 1.25p X 20mm)
Socket Buttonhead Screw (M8 X 1.25p X 80mm)
Flat Washer (Ø8.2)
Nylon Nut (M8 X 1.25p)
Bushing
Buttonhead Bolt (M8 X 1.25p X 35mm)
Nylon Nut (M8 X 1.25p)
Buttonhead Screw (M6 X 1.0p X 20mm)
Buttonhead Screw (M8 X 1.25p X 16mm)
Spring Washer (Ø8.2)
Cross Head Screw (M5 X 0.8p X 25mm)
Spring Washer (Ø8.2)
Socket Head Screw (M8 X 1.25p X 25mm)
Link Arm Cap
#5 L-type Wrench (120L)
#6 T-type Wrench (167L)
Phillips Screwdriver
Wrench (#13)
2
2
4
2
4
2
2
8
8
8
2
4
4
4
1
1
1
1
0706
JOHNSON ELLIPTICAL E8000JOHNSON ELLIPTICAL E8000
SKETCH
ASSEMBLY EXPLODED DIAGRAM
FASTENERS & ASSEMBLY TOOLS
COLOR
OF BAG
Yellow
Red
Black
Pink
Z10
N22
Z05
Z07
Z08
Z06
Z18

0908
JOHNSON ELLIPTICAL E8000JOHNSON ELLIPTICAL E8000
STEP 1 STEP 2
• Console Mast
• Console
1). Lift up the Main Body at the front end. Ask your assistant to insert the wooden or
hard box underneath the Main Body while you lift up the Main Body.
2). Fasten the Front Foot to the Main Body by using two screws (Z10).
1). Thread the Console Mast through the Console Mast Boot.
2). Feed the cable through the Console Mast. Tape the cable to the top of the Console
Mast to secure it temporarily.
3).
Attach the Console Mast to the Base Frame using two screws (Z03), four washers
(Z04) and two nylon nuts (Z07). Ask your assistant to hold the Console Mast while
tighten screws.
4). To fix the water-holder bracket to the console mast by hanging it onto the 2
bolts and then use #5 L-type wrench to tighten the screws.
Z10
1). Connect the cable inside the Console, and unscrew the screws attached the back
of the Console.
2). Attach the Console to the top of the Console Mast using the same screws attached
the back of the Console.
Z07
Z04 Z03
Z04
N22
Water-holder Bracket

• HR Handgirps
1). Plug in the heart rate wires to the wires from the Console Mast.
2). Attach the heart rate handgrips to the Console Mast by using four screws (Z25) and
washers (Z24).
• Accessory Tray
Attach the Accessory Tray to the positioned base of the accessory tray by using two
screws (Z22).
1110
JOHNSON ELLIPTICAL E8000JOHNSON ELLIPTICAL E8000
STEP 3 STEP 4
1). Attach the Dual-Action handrail (R) and (L) to the Console Mast using screws (Z18),
and place the handlebar caps around the handlebars.
2). Fasten the link arm(R) and (L) to the pedal arms using screws (Z01) and washers
(Z02).
3). Attach the Dual-Action handrails to the link arms using bolts (Z06), bushings (Z05),
and nylon nuts (Z07).
4). Align the cut-out inside the link arm caps (Z08) with the link arm mounting hole.
Apply pressure to the cap until it snaps into place.
Z22
Z25
Z24
Z18
Z18
G24
Z06
Z08
Z05
Z05 Z07
Z08
Z01
Z02
Z01
Z02
Z05
Z07
Z08
Z08
Z06
Z05

SERIAL NUMBER LOCATION
1312
JOHNSON ELLIPTICAL E8000JOHNSON ELLIPTICAL E8000
FINAL ASSEMBLY
OPTIONAL ENTERTAINMENT SHOWN
SERIAL # PLACEMENT

1514
JOHNSON ELLIPTICAL E8000JOHNSON ELLIPTICAL E8000
USING THE WORKOUTS
DISPLAY CONSOLE
A. WORKOUT PROFILE WINDOW:
During a workout, this window displays shapes, made of triangle columns of lights, which represent
the levels of intensity in a workout-in-progress. The height of the furthest column is proportional
to the current level of the intensity.
B. INSTURCTION CENTER:
This window displays step-by-step instructions for setting up a workout.
C. INFORMATIONAL DISPLAY:
During a workout, three sets of numbers, including Speed, Time and Distance, display statistics
about the progress of the workout.
D. PROGRAM PLUS™ KEYS
Press the key to select one of the workouts. The program key with a symbol of plus “œ” represents
this key including additional workout options. Press this key repeatedly for similar workout options.
E. LEVEL ARROW KEYS
During a workout, pressing the UP or DOWN arrow can adjust intensity levels.
F. RIGHT / LEFT ARROW KEYS
A pair of RIGHT and LEFT arrows is located on the side of SELECT. Use arrows, when setting up a
workout, to change workout parameters displayed on the LCD console, such as length of workout,
weight, age, heart rate, and intensity level. In addition, the pair of RIGHT and LEFT arrows is
corresponding to the arrows in the LCD display.
G. QUICK START
Press QUICK START to begin your workout immediately, without having to select a workout program.
H. PAUSE / RESET
PAUSE: If you need to PAUSE your program during a workout, pressing the PAUSE key will PAUSE
your program for 30 seconds. Pressing START will return you to your workout.
RESET: If you need to RESET the console during your workout, you can do so by holding down
the PAUSE/RESET button for three seconds, or until the display resets.
A
B
C
E
F
G
H
D
NOTE: Pause time is only capable of existing for the bike equipped with the battery.
PROMPT DEFAULT MINIMUM MAXIMUM UNIT
TIME
LEVEL
WEIGHT
AGE
DISTANCE
CALORIES
WATTS
Heart Rate
GENDER
20
1
68 / 150
30
5 / 3
500
150
n/a
MALE
5
1
34 / 75
10
1 / 1
50
50
52
MALE
99
20
182 / 400
99
80 / 50
5000
350
200
FEMALE
minute
kg / lbs
years old
km / mile
cal.
watt
beat
NOTE: The workout time is a “countdown” display according to the default time or the maximum
time that a user inputs. When the workout time is inputted as “0”, the time will count up from a
zero to the maximum time.
WORKOUT PARAMETER PROMPTS
This section lists the default value and value range of workout parameters appeared in the
PROMPT AREA, located in the bottom of WORKOUT PROFILE WINDOW. Before an exercise session,
each parameter prompt will appear here depending on different programs.

1716
JOHNSON ELLIPTICAL E8000JOHNSON ELLIPTICAL E8000
PROGRAM
NAME
DEFAULT
TIME
PROMPT
INPUT
DESCRIPTION
QUICK START
WARM UP
COOL DOWN
MANUAL
HILL
INTERVAL
RANDOM
HILL
INTERVAL+
MULTI FX+
N/A
N/A
N/A
20 min
20 min
20 min
20 min
20 min
N/A
Time
Time
Time,
Weight
Level,
Time,
Weight
Time,
Weight
Watts,
Time,
Weight
Level,
Time,
Weight
WORKOUT OVERVIEWS
This chart lists the Johnson elliptical trainer’s pre-programmed workouts.
Quick Start is the fastest way to begin exercising
and bypasses the setup prompts. After pressing
the QUICK START key, a constant-level workout
begins.
Warm-up is a low-intensity phase that brings the
heart rate into the lower end of the target zone
and increases respiration and blood flow to
working muscles.
Cool-down is a low-intensity phase that allows
the body to begin removing lactic acid, and
other exercise by-products, which build up in
muscles and contribute to soreness.
Manual is a constant intensity level unless it is
manually changed.
Hill Interval is an efficient workout by alternating
work intervals and recovery intervals.
Random Hill is an interval training workout that
occurs in no regular pattern or progression.
CONSTANT
WATTS
RANDOM
Constant Watts is designed to maintain your
watts expenditure at a constant level by
controlling pedaling resistance and prompting
you to pedal at a specified RPM. Watts level
may vary above and below your target watts
level during this program.
Random is a workout of constantly changing
intensity levels that occur in no regular pattern
or progression.
PROGRAM
NAME
DEFAULT
TIME
PROMPT
INPUT
DESCRIPTION
GOAL+
TIME
GOAL
DISTANCE
GOAL
CALORIES
GOAL
TARGET
HR
WEIGHT
LOSS
HEART
RATE+
FIT TEST
20 min
N/A
N/A
20 min
20 min
12 min
Time,
Weight
Distance,
Weight
Calories,
Weight
Age,
HR,
Time,
Weight
Age,
HR,
Time,
Weight
Gender,
Age,
Level,
Weight
Time Goal sets exercise duration as the workout
goal. Once the objective is met, the workout
automatically goes into a cool-down phase and
ends afterward.
Distance Goal is designed to build endurance in
a certain distance. Once the objective is met,
the workout automatically goes into a cool-down
phase, and ends afterward.
Calories Goal is designed to burn a certain
number of selected calories. Once the objective
is met, the workout automatically goes into a
cool-down phase and ends afterward.
Target HR is a higher intensity workout for
maintaining a heart rate to achieve maximum
exercise results. The user must wear a heart
rate chest strip, or keep hands on contact heart
rate grips continuously. The program adjusts
the intensity level, based on the actual heart
rate, to maintain the rate at 80 percent of the
theoretical maximum.
Weight Loss is a low-intensity workout for
burning the body’s fat reserves. The user must
wear a heart rate chest strip, or keep hands on
contact heart rate grips continuously. The
program adjusts the intensity level, based on
the actual heart rate, to maintain the rate at 65
percent of the theoretical maximum.
Fit Test measures cardiovascular fitness and
can be used to monitor improvements in your
endurance.

QUICK START
Press the "QUICK START" key and the WORKOUT PROFILE WINDOW will display "3, 2, 1,
GO!” The workout begins at the default intensity level, and the workout time counts up
from “0” to the maximum workout time.
WARM UP
1) Press the “WARM-UP” key to enter the program.
2) “SELECT TIME” using the RIGHT / LEFT ARROW keys, and then press SELECT.
3) Press START to begin a warm-up.
COOL DOWN
1) Press the “COOL-DOWN” key to enter the program.
2) “SELECT TIME” using the RIGHT / LEFT ARROW keys, and then press SELECT.
3) Press START to begin a cool-down.
MANUAL
1) Press the “MANUAL” key to enter the program.
2) “SELECT TIME” using the RIGHT / LEFT ARROW keys, and then press SELECT.
3) “SELECT WEIGHT” using the RIGHT / LEFT ARROW keys, and then press SELECT.
4) Press START to begin the workout.
INTERVAL+
ëHILL INTERVAL
1) Repeatedly Press the “INTERVAL+” key to select “HILL INTERVAL”, and then press SELECT.
2) “SELECT LEVEL” using the RIGHT / LEFT ARROW keys, and then press SELECT.
3) “SELECT TIME” using the RIGHT / LEFT ARROW keys, and then press SELECT.
4) “SELECT WEIGHT” using the RIGHT / LEFT ARROW keys, and then press SELECT.
5) Press START to begin the workout.
ëRANDOM HILL
1) Repeatedly Press the “INTERVAL+” key to select “RANDOM HILL”, and then press SELECT.
2) “SELECT TIME” using the RIGHT / LEFT ARROW keys, and then press SELECT.
3) “SELECT WEIGHT” using the RIGHT / LEFT ARROW keys, and then press SELECT.
4) Press START to begin the workout.
MULTI FX+
ëCONSTANT WATTS
1) Repeatedly Press the “MULTI FX+” key to select “CONSTANT WATTS”, and then press SELECT.
2) “SELECT WATTS” using the RIGHT / LEFT ARROW keys, and then press SELECT.
3) “SELECT TIME” using the RIGHT / LEFT ARROW keys, and then press SELECT.
4) “SELECT WEIGHT” using the RIGHT / LEFT ARROW keys, and then press SELECT.
5) Press START to begin the workout.
1918
JOHNSON ELLIPTICAL E8000JOHNSON ELLIPTICAL E8000
WORKOUT TIPS
1. Johnson Fitness strongly recommends seeing your physician for a complete physical
examination before beginning any fitness program. Know your physician-recommended
heart rate target zone. If, at any time while exercising, you experiences faintness,
dizziness, pain, or shortness of breathe, you must stop immediately.
2. To mount the elliptical trainer, grasp the front stationary handlebars and place your feet
on the pedals. When you are comfortably situated, begin pedaling. To dismount the
elliptical trainer, stop pedaling, grasp the front stationary handlebars and get off the unit.
3. It is highly recommended that you always incorporate the warm-up and cool-down
period into your workout. Warm-up brings the heart rate into the lower end of the
target zone and increases respiration and blood flow to working muscles. Cool-down
takes time for a user’s heart rate to return to a resting state after vigorous exercise
and reduces the amount of lactic acid in muscle tissue.
WORKOUT SETUP STEPS
Different elliptical trainer workouts require different setup procedure. This section
provides details for setting up any workout program.
1. Begin to pedal the elliptical trainer.
2. Use the PROGRAM PLUS™ KEYS to enter the program, or use RIGHT / LEFT ARROW keys
to scroll to desired program. The program name is displayed in the PROMPT AREA.
3. Use the RIGHT / LEFT ARROW keys to scroll to desired parameter values displayed in the
PROMPT AREA.
4. Press the SELECT key to confirm each selection. Follow the steps to set up each workout.
Note: The PROGRAM PLUS™ KEYS with a symbol of plus “Ŕ” have couple of similar
workout options included. Press the key repeatedly to select the desired program.
Or, press the program key once and use RIGHT / LEFT ARROW keys to scroll to the
desired program.

2120
JOHNSON ELLIPTICAL E8000JOHNSON ELLIPTICAL E8000
GOAL+
ëTIME GOAL
1) Repeatedly Press the “GOAL+” key to select “TIME GOAL”, and then press SELECT.
2) “SELECT TIME” using the RIGHT / LEFT ARROW keys, and then press SELECT.
3) “SELECT WEIGHT” using the RIGHT / LEFT ARROW keys, and then press SELECT.
4) Press START to begin the workout.
ëDISTANCE GOAL
1) Repeatedly Press the “GOAL+” key to select “DISTANCE GOAL”, and then press SELECT.
2) “SELECT DISTANCE” using the RIGHT / LEFT ARROW keys, and then press SELECT.
3) “SELECT WEIGHT” using the RIGHT / LEFT ARROW keys, and then press SELECT.
4) Press START to begin the workout.
ëCALORIES GOAL
1) Repeatedly Press the “GOAL+” key to select “CALORIES GOAL”, and then press SELECT.
2) “SELECT CALORIES” using the RIGHT / LEFT ARROW keys, and then press SELECT.
3) “SELECT WEIGHT” using the RIGHT / LEFT ARROW keys, and then press SELECT.
4) Press START to begin the workout.
HEART RATE+
ëTARGET HR / WEIGHT LOSS
1) Repeatedly Press the “HEART RATE+” key to select “TARGET HR” or “WEIGHT LOSS”, and
then press SELECT
2) “SELECT AGE” using the RIGHT / LEFT ARROW keys, and then press SELECT.
3) “SELECT HR” using the RIGHT / LEFT ARROW keys, and then press SELECT.
4) “SELECT TIME” using the RIGHT / LEFT ARROW keys, and then press SELECT.
5) “SELECT WEIGHT” using the RIGHT / LEFT ARROW keys, and then press SELECT.
6) Press START to begin the workout.
ëRANDOM
1) Repeatedly Press the “MULTI FX+” key to select “RANDOM ”, and then press SELECT.
2) “SELECT LEVEL” using the RIGHT / LEFT ARROW keys, and then press SELECT.
3) “SELECT TIME” using the RIGHT / LEFT ARROW keys, and then press SELECT.
4) “SELECT WEIGHT” using the RIGHT / LEFT ARROW keys, and then press SELECT.
5) Press START to begin the workout.
FIT TEST’S RESULT FOR MALE
Male
Rating
Age
Estimated VO2 Max (ml/kg/min) Per Age Category
Very Poor Poor Fair Good Excellent Superior
15 – 19
20 – 29
30 – 39
40 – 49
50 – 59
60 +
< 35.0
< 33.0
< 31.5
< 30.2
< 26.1
< 20.5
35.0 – 38.3
33.0 – 36.4
31.5 – 35.4
30.2 – 33.5
26.1 – 30.9
20.5 – 26.0
38.4 – 45.1
36.5 – 42.4
35.5 – 40.9
33.6 – 38.9
31.0 – 35.7
26.1 – 32.2
45.2 – 50.9
42.5 – 46.4
41.0 – 44.9
39.0 – 43.7
35.8 – 40.9
32.3 – 36.4
51.0 – 55.9
46.5 – 52.4
45.0 – 49.4
43.8 – 48.0
41.0 – 45.3
36.5 – 44.2
> 55.9
> 52.4
> 49.4
> 48.0
> 45.3
> 44.2
Female
Rating
Age
Estimated VO2 Max (ml/kg/min) Per Age Category
Very Poor Poor Fair Good Excellent Superior
15 – 19
20 – 29
30 – 39
40 – 49
50 – 59
60 +
<25.0
<23.6
<22.8
<21.0
<20.2
<17.5
25.0 – 30.9
23.6 – 28.9
22.8 – 26.9
21.0 – 24.4
20.2 – 22.7
17.5 – 20.1
31.0 – 34.9
29.0 – 32.9
27.0 – 31.4
24.5 – 28.9
22.8 – 26.9
20.2 – 24.4
35.0 – 38.9
33.0 – 36.9
31.5 – 35.6
29.0 – 32.8
27.0 – 31.4
24.5 - 30.2
39.0 - 41.9
37.0 - 41.0
35.7 - 40.0
32.9 - 36.9
31.5 - 35.7
30.3 - 31.4
>41.9
>41.0
>40.0
>36.9
>35.7
>31.4
FIT TEST’S RESULT FOR FEMALE
FIT TEST
1) “SELECT GENDER” using the RIGHT / LEFT ARROW keys, and then press SELECT.
2) “SELECT AGE” using the RIGHT / LEFT ARROW keys, and then press SELECT.
3) “SELECT LEVEL” using the RIGHT / LEFT ARROW keys, and then press SELECT.
4) “SELECT WEIGHT” using the RIGHT / LEFT ARROW keys, and then press SELECT.
5) Press START to begin the workout.
The tables below list fit test results.

USING FITNESS NETWORKING
The two RJ45 networking ports are equipped in Johnson Elliptical Trainer E8000. These ports
allow the bike to be connected to a fitness entertainment system and/or a fitness network,
such as FitLinxx®.
C-SAFE / CARDIO PORT
The ports are located on the back of the console. The C-SAFE port enables the bike to upload
user workout statistics to a fitness network database. The CARDIO port is compatible to
entertainment protocol such as Cardio Theater® or BroadcastVision™.
2322
JOHNSON ELLIPTICAL E8000JOHNSON ELLIPTICAL E8000
C-SAFE
CARDIO
C-SAFE
CARDIO
MANAGER’s CUSTOM MODE
The Manager’s Custom Mode allow the club owner to customize the elliptical trainer for the
club.
To enter the Manager’s Custom Mode, press and hold down the "LEVEL ARROW keys
“ . Continue to hold down these two keys until the INSTRUCTION CENTER displays
“MANAGER MENU”.
1. To scroll through the list of Manager’s Custom Mode, use the “LEFT / RIGHT ARROW
keys”, or "LEVEL ARROW keys". The INSTRUCTION CENTER will display, in turn, each of
custom settings.
2. To select a custom mode, press the SELECT key to enter.
3. To change the value of the setting, use the “LEFT / RIGHT ARROW keys”, or "LEVEL
ARROW keys".
4. To confirm and save the value of the setting, press the QUICK START key. “SETTING
SAVED” will appear in the INSTRUCTION CENTER. To exit the setting without saving, press
the RESET key within 5 seconds, or if there is no key pressed, the system will resume
automatically.
THE LIST OF MANAGER'S CUSTOM MODES
P0
P1
P2
P3
P4
P5
P6
99 min
20 min
1
68kg /
150lbs
N/A
20 min
5 min
1
34kg /
75lbs
0
99 min minute
max.
time
10
182kg /
400lbs
104,000
km /
65,000
mile
MAXIMUM
TIME
DEFAULT
TIME
DEFAULT
LEVEL
MAXIMUM
LEVEL
DEFAULT
WEIGHT
DEFAULT
AGE
ACCUMU-
LATED
DISTANCE
CUSTOM
SETTING DEFAULT MINIMUM MAXIMUM UNIT STEP DESCRIPTION
Control the default program time.
Control the starting resistance level for
all programs.
Control the default weight used in calorie
calculations. Set to default unit change
(kilograms or pounds). Displayed in native
units.
Enable fitness club managers to set the
program maximum workout duration
limits during peak and non-peak hours of
club traffic. Active variable displayed in
the TIME display after change.
Enable to set maximum resistance level
for all programs.
Control the default users age used in
target heart rate calculations.
1
minute 1
1
1
n/a
20 1 20
n/a
30 10 99
age
kg/lbs
1
1
N/A
km /
mile
Accumulated distance is not editable, but
only for display. Displayed in native units
(miles or kilometers). Holding the Left and
Right Arrow keys simultaneously to reset
the accumulated distance. After the
equipment reaches the maximum
distance, it will reset to "0" automatically.

25
JOHNSON FITNESS TREADMILL T8000/T8000 PRO
24
JOHNSON ELLIPTICAL E8000 JOHNSON ELLIPTICAL E8000
P7
P8
N/A 0 65,000 hrs N/Ahour
30 sec 30 sec 180 sec 1second
ACCUMU-
LATED
TIME
PAUSE
TIME
CUSTOM
SETTING DEFAULT MINIMUM MAXIMUM UNIT STEP DESCRIPTION
Accumulated time is not editable, but
only for display. Holding the Left and
Right Arrow keys simultaneously to reset
the accumulated time. After the machine
reaches the maximum time, it will reset
to "0" automatically.
This is the maximum time during which a
workout can remain in pause mode.
Restrictions exist for the machine not
equipped with a battery.
P9
P10
P11
P12
P13
P14
P15
EL N/A N/A N/A
MODEL
SOFTWARE
VERSION
ERROR
LOG
METS
LANGUAGE
CB - Upright Bike
RB - Recumbent Bike
EL – Elliptical Trainer
ST - Stepper
Software version is not editable, but only
for display.
If this option is "ON", the METs prompt
becomes an individual display in PROMPT
AREA. If "OFF", there will be an alternate
prompt in RPM and METs at the lower-
right corner of the WORKOUT PROFILE
WINDOW.
The function would clear all custom
settings had stored on the unit and all
settings return to manufacturer default
value. Holding the Left and Right Arrow
keys simultaneously to clear all custom
settings values.
N/A
English N/A N/A N/A N/A
N/A N/A N/A N/A N/A
UNITS The measurement unit prompts for weight,
distance, and speed.
Metric Metric English N/A N/A
N/A N/A N/A N/A N/A
OFF ON OFF N/A N/A
RESET
ALL
N/A N/A N/A N/A N/A
The native language prompts in the
INSTRUCTION CENTER.
Error log is not editable, but only for display.
Holding the Left and Right Arrow keys
simultaneously to erase the error log.
MAINTENANCE
Johnson Elliptical Trainer E8000 is built for commercial environment 12 hours a day and seven
days a week. However, as a club manager or owner, you are responsible for cleaning and
maintaining the unit’s integrity. If you fail to maintain the elliptical trainer as described below,
it could affect or void the Johnson limited warranty.
NOTE: Safety of the equipment can be maintained only if the equipment is examined regularly
for damage or wear. Keep the equipment out of use until defective parts are repaired or
replaced. Pay special attention to parts that are subject to wear, such as display console,
console mounting screws, handrails, link arms, pedal arms and pedals.
DAILY INSPECTION
Look and listen for loose fasteners, unusual noises, and any other indications that the
equipment may be in need of service. If you notice any of these, obtain service.
DAILY MAINTENANCE
Johnson Fitness recommends the E8000 be cleaned before and after each workout. The
following daily maintenance tips will keep your unit operating at peak performance:
1) Use a damp, soft cloth with water or mild liquid detergent to clean all exposed surfaces.
DO NOT use ammonia, chlorine, or acid-based cleaners.
2) Keep the display console free of fingerprints and salt build-up caused by sweat.
3) Frequently vacuum the floor underneath the unit to prevent the accumulation of dust and
dirt, which can affect the smooth operation of the unit.
MONTHLY MAINTENANCE
Perform the following services each month, or as needed:
1) Check that the console, handrails, link arms, pedal arms and pedals.
RECYCLING THE BATTERY
When the Johnson elliptical trainer is about to be discarded at the end of its useful life, the
rechargeable battery must first be removed and recycled. If the elliptical trainer is being
equipped with the battery. To access the battery, unscrew the cover on the back of the
console. To remove the battery, disconnect the cable.

*Product specifications are subject to change without notice.
PRODUCT SPECIFICATIONS
26
JOHNSON ELLIPTICAL E8000
CONSOLE
Display Screen
Display Readout
Programs
On-the-fly Program Change
Telemetric Receiver
Contact HR Sensors
Program Quick Keys
One-Touch Quick Start
Pause Time
Language Options
TECHNICAL DATA
Resistance Technology
Resistance Levels
Drive System
Stride Drive System
Stride Length
Dimensions (L×W×H)
Product Weight
Max User Weight
Power Requirement
SPECIAL FEATURES
Handlebar Design
Remote Operation Keys
Pedals
Integrated Reading Rack
Accessory Tray
ENTERTAINMENT SOLUTIONS
JOHNSON® LCD TV Mount
Networking Capabilities
Workout Profile Window – 7” blue backlit graphic LCD display
Instruction Center – 14-character red LED alphanumeric display
Informational Display – 3 numeric 7-segment display (3 sets)
Time, Distance, Calories, Speed, Level, Watts, METS, Heart Rate, Profile
Manual, Interval+(Hill Interval, Random Interval), Goal+(Time Goal, Distance
Goal, Calories Goal), Multi FX+(Constant Watts, Random), Heart Rate+(Target
HR, Weight Loss), Fit Test, Warm Up, Cool Down
Yes
Yes
Yes
Yes
Yes
30 seconds
English, Italian, German, Spanish, French, Dutch, Portuguese, Japanese
JID™ generator
20
Two stage belt-driven
Forward and reverse
48 cm / 19”
211 × 79 × 170 cm / 83” × 31” × 52”
168 kg / 370 lbs
182 kg / 400 lbs
Self-powered
Multi-position dual action arms
Yes, equipped in the dual action arms
Auto-positioning pedals with front safety fences
Yes
Yes
Yes
CSAFE-Ready, Finlinxx™ certified
E8000
