Congratulations on choosing our products! Please carefully read this instruction manual in its
entirety and keep it well for using reference. This manual contained about the installation and
the relative using information of this products. Plese refere this manual's relative instruction
when using this equipment.

2.Safety instructions
1.Open-Package guidelines
１.１Package
Unpacking the fixture
1.Open the flight case cover
2.With one person on each side, lift the fixture out of the flight case.
3.Unlock pan and tilt before operating fixture.
Packing the fixture
1.Disconnect the fixture from power and allow it to cool.
2.lock arms and h as figure. (
3.Place the fix ture in the bottom of the flight case, and cover the case without forcing.
- Fig.1
ead - Fig.2 PAN Mechanism Lock and Release (every 45°)
- Fig.2-1)(Tilt Mechanism Lock and Release (every 45°) - Fig.2-2)
This equipment is made of new style,high intensity plastic.It fully shows the modem times light charac
teristic with beauty struture. And it is made accord to CE standard. Fully agree with the internation
512 agreement.
teris-
tic with
standard of DMX
1.Signal cable-1PC 2.Safty cable-1PC
3.User Manval-1PC 4.Omega holder-2PCS
5.Power cable-1PC 5.Service card-1PC
When receive the product,please be careful to take and put,check if the product has damage or not be-
cause of transportation, and check the following parts:
This device has been shipped with our premises in absolutely perfect condition.In order to maintain this co-
ndition and toensure a safe operation,it is absolutely necessary for the user to follow the safety instructions
and warning notes written in this manual.
Important:
The manufacturer will not accept liability for any resulting damages caused by the nonobservance of this
manual or any unauthorized modification to the device.
Please consider that damages caused by manual modifications to the device are not subject to warranty.
Every person involvd with installation and maintenance of this device to:
-Be qualilfied
-Follow the instructions of this manual.
Aviation box Fig.1
- 1 -
Arm lock
LOCKED UNLOCKED
Fig.2- 2
Level vertical transportation lock Fig.2
PAN Mechanism Lock Tilt Mechanism Lock
Fig.2-1
Head lock
45°
45°
45°
45°
45°
45°
45°
45°
45°
45°
45°
45°

- 2 -
Never let the power-cord come into contact with other cables! Handle the power cord and all connections
with particular caution!
Make sure that the available voltage is not higher than stated on the rearpanel.
Always plug in the power plug least. Make suer that the power-switch is set to off-position before you con
ections with themains with particular caution!
Make sure that the power-cord is never crimped or damaged by sharp edges.Check the decice and the p-
ower-cord from time to time.
Always disconnect from the mains, when the device is not in use or before cleaning it.
Only handle the power-cord by the plug,Never pull out the plug by tugging the powercord.
This device falls under protection class I.Therefore it is essential to connect the yellow/green conductor
to earth.
The electric connection,repairs and servicing must be carried out by a qualified employee.
Do not connect this device to a dimmer pack.
Do not switch the fixture on and off in short intervals as this would reduce the lamp’s life.
Do not touch the device’s housing bare hands during its operation(housing becomes hot)!
For replacement use lamps and fuses of same type and rating only.
t 80
c°C
IP20
t 40
a°C
Eye damage!
Avoid looking directly into the light source(meant especially for epileptics)!
Minimum distance of illuminated objects
5 metres from the lens of the projector.
Maximum ambient temperature
Do not operate the fixture if the ambient temperatuer(Ta) exceeds 40°C (104°F).
Temperature of the external surface
The maximum temperature that can be reached on the external surface of the fitting,in a ther-
mally steadystate,is 80°C (176°F).
IP20 protection rating
The fitting is protected against penetration by solid of over 12mm (0.47”) in diameter (first
digit 2), but not against dripping water,rain,splashes or jets of water (second digit 0).
Indoor use only
Not suitable for household illumination
Photobiological Safety
CAUTION. Do not look directly at the light source.Do not look at the light beam with optical de-
vices or any other tool that could cause light convergence.
The fixture must be positioned so that the minimum distance between the front lens and human
eye is at least 3metres to prevent personal photobiological risks.
Mounting surfaces
It is permissible to mount the fitting on normally flammable surfaces.
The products to which this manual refers comply with the European Directives purs-
uant to:
•2006/95/EC - Safety of electrical equipment supplied at low voltage (LVD)
•2004/108/EC - Electromagnetic Compatibility (EMC)
•2011/65/EU - Restriction of the use of certain hazardous substances (RoHS)
•2009/125/EC - EcoDesign requirements for Energy-related Products (ErP)
Protection against electrical shock
Connection must be made to a power supply system fitted with efficient earthing (Class I app-
liance according to standard EN 60598-1) .It is, moreover, recommended to protect the supply
The projector needs to be positioned so that the objects hit by the beam of light are at least
F
Risk Gr oup 1
Accor ding to
En624 71
5

Disposing
This product is supplied in compliance with European Directive 2012/19/EU-Waste Electrical and
Electronic Equipment (WEEE) . To preserve the environment please dispose/recycde this product at
the end of its life according to the local regulation.
Battery
This product contains a rechargeable lead-acid or lithium iron tetraphosphate battery.To preserve the
environment,please dispose the battery at the end of its life according to the regulation in force.
Lamp
The fitting mounts a high-pressure lamp that needs an external igniter. This igniter is fitted onto the
apparatus. -Carefully read the "operating instructions" provided by the lamp manufacturer.
-Immediately replace the lamp if damaged or deformed by heat.
Maintenance
Before starting any maintenance work or cleaning the projector,cut off power from the mains supply.
After switching off, do not remove any parts of the fitting for at least 10 minutes. After this time the like
lihood of the lamp exploding is virtually small.If it is necessary to replace the lamp,wait for another 15
minutes to avoid getting burnt.The fitting is designed to hold in any splinters produced by a lamp expl-
oding.
This device is a moving-head for creating decorative effects and was designed for indoor use only.
If the device ha been exposed to drastic temperature fluctuation(e.g.after transportation).do not weitch it on imm-
ediately.The arising condensation water might damage your device,Leave the device switched off until it has rea-
ched room temperature.
Never run the device without lamp!
Do not shake the device,Avoid brute force when installing or operating the device.
Never life the fixture by holding it at the projectorhead, as the mechanics may be damaged. Always hold the fixtu-
re at the transport handles.
When choosing the installation-spot,please make sure that the device is not exposed to heat,moisture or dust.Th-
ere should not be any cables lying around.You endanger your own and the safety of others!
The minimum distance between light output and the illuminated surface must be more than 0.2 meters.
Make sure that the area below the installation place is blocked when rigging,derigging or servicing the fixture.
Always fix the fixture with an appropriate safety rope, Fix the safety rope at the correct holes only.
Operate the fixture after having checked that the housing is firmly closed and all screws are tightly fastend.
The lamp must never be ignited if the objective-lens or any housing-cover is open, as discharge lamps may ex-
plose and emit a hign ultraviolet radiat, which may cause burns.
The maximum ambient temperature 40°C must never be exceeded.
Operate the device only after having familiarized with its functions. Do not permit operation by persons not qua-
lified for operating the device. Most damages are the result of unprofessional operation!
Please use the original packaging if the device is to be transported.
Please consider that unauthorized modifications on the device are forbidden due to safety reasonsl.
If this device will be operated in any way different to the one described in this manual, the product may suffer
damages and the guarantee becomes void.Furthermore, any other operation may lead to dangers like short-circ-
uit,burns, electric shict,burns due to ultraviolet radiation,lamp explosion,crash etc.
3.Operating determinations
lines of the projectors from indirect contact and/orshorting to earth by using appropriately sized
residual current devices.
E
!
- 3 -

4.1 Mounting
For the various mounting positions of the FIXTURE(standing on the floor, sideways or hanging different
accessories kits are available.
Through this a safe and firm installation is assured.
You’ll find special connectors on the bottom side of the system which are put to use here.
4.2 Installing the Clamps
Please consider the respective national norm s during the Installation!The installation must only be car-
ried out by an authorized dealer!
The installation of the projector has to be built and constructed in a way that it can hold 10 times the wei-
ght for 1 hour without any harming deformation.
The installation must always be secured with a secondary safety attachment, e.g.an appropriate catch
net.This secondary safety attachment must be constructed in a way that no part of the installation can
fall if the main attachment fails.
When servicing the fixture staying in the area below the installation place,on bridges,under high working
places and other endangered areas is forbidden.
The operator has to make sure that safety-relating and machine-technical installations are approved by
an expert before taking into operation for the first time and after changes before taking into operation an-
other time.
The operator has to make sure that safety-relating and machine-technical installations are approved by
an expert after every four year in the course of an acceptance test.
The operator has to make sure that safety-relating and machine-technical installations are approved by
a skilled person once a year.
The projector should be installed outside areas where persons m ay walk by or be seated.
Important!Overhead rigging requires extensive expering CE,including (but not limited to)calculating
working load limits, installation material being used, and periodic safety inspection of all installation ma-
terial and the projector. If you lack these qualifications, do not attempt the installation yourself, but inste-
ad use a professional structural rigger. Improper installation can result in bodilyinjury and or damage to
property.
The projector has to be installed out of the reach of people.
If the projector shall be lowered from the ceiling or high joists, professional trussing system s have
to be used. The projector must never be fixed swinging freely in the room .
Caution Projectors may cause severe injuries when crashing down! If you have doubts concerning the
safety of a possible installation, do not install the projector!
Before rigging make sure that the installation area can hold a minim um point load of 10 times the
projector s weight.
4.Rigging the fixture
Pay attention to the regulations of CE.
Installation by qualified staff to complete.
- 4 -

The projector can be placed directly on the stage floor or rigged in any orientation on atruss without alte-
ring its operation characteristics.
For overhead use,always install a safety-rope that can hold at least 10 times the weight of the fixture.You
must only use safety-ropes with screw on carabines.Pull the safety-rope through the two apertures on the
bottom of the base and over the trussing system etc.
1
2
3
4
mounting plate
secure chain
omega holder
Lock catch
- 5 -
Warning: it is necessary to make sure that
the installation location is perfectly appropriate,
and the installation location is safe and reliable.
1
23
4
According to the four screws broke open the back cover, back cover marked as shown direction turn to
change the bulb to corresponding card slot can be removed. According to the chart Three screws rotating
back cover,can adjust the bulb location. As shown in figure;

12
3
1
2
4.3 Power supply connection and cut off
Connect the light source to the main power source with the plug of the power cord, or cut off the power
supply:
Connection: according to procedures, the power
plug and socket is inserted into the groove one one
alignment,rotation.
Cut off:according to procedures,press the button
on the rotating plug,pull out.
- 6 -
4.5 DMX-512 connection/connection between fixtures
Only use stereo shieded cable and 3-pin XLR-plugs and connectors in order to connect.
4.4 Power Connection
mains with the enclosed power cable and plug.
If you wish to change the power supply settings, see the chapter appendix Connect the fixture to the
L
N
CABLE(EU) CABLE(US) Pin
Brown Black Live
Yellow/Green Green Earth
Light blue White Neutral
INTERNATIONAL
Warning: please verify the power of the power
supply equipment prior to the connection! Earth wire
must be grounded!
DMX512
2 1
3
2 1
3
5 1
4 2
3
5 1
4 2
3
5 1
4 2
3
1:Ground
2:Signal(-)
3:Signal(+)
1:Ground
2:Signal(-)
3:Signal(+)
4:N.A.
5:N.A.
2 1
3
5 1
4 2
3
Caution
At the last fixture,the DMX-cable has to be terminated with a terminatou. solder a 120 resistor between
signal(-) and Signal (+) into a 3-pin XLR-plug and plug it in the DMX-output of the last fixture.
DMX iutput
3-pin XLR socket
DMX iutput
5-pin XLR socket
DMX output
3-pin XLR socket
DMX output
5-pin XLR socket

5.Description of the device
DMX Terminator Diagram
-For installations where the DMX cable has to run a long distance or
is In an electrically noisy environment it is recommended to use a
DMX terminator. This help in preventing corruption of the signal by
electrical noise. The DMX terminato r is simply an XLR plug witha
120 resistor connected between pins 2 and pins3, which is then
plugged into a the output XLR socket of the last ifxture in the chain.
Ω
1
2
3
120Ω
PIN2 PIN3
- 7 -
11
14 12
13
155
Display panel
4.
5.
6.
7.
8.
9.
10.
5-pin XLR female
Network interface
Power switch
Power-in
Main Fuse
5-pin XLR male
Display
11.Small
12.WDMX wire
13. Knob
14. USB interface
15.
button
Status indicator lamp
10
4
89
6
7
8
3. Base
Head
Tilt °,
270 Fixture could auto
reset.
Arm
Pan °,630 Fixture could auto
reset.
2.
1.

6.Dimension
- 8 -

- 9 -
7.Display control
7.1 Navigation in the Menu
7.2 Display Operation
Using the buttons or touch screen, and this can be simply and easily set the address code and
code.
functions
If you view or modify the lighting feature set, then press ENTER button, the display will enter the menu
interface. Both there is sub menu corresponding to the functional operation of the main menu. Each of the
menus is representative of the specific features of the lamp. The specific contents shows as the table
menu below.
Set or browse lighting function, press UP or DOWN button.
Press ENTER to save your changes or enter the submenu.Press the UP or DOWN can change the nume-
rical (increase or decrease in value).
Press the MODE button to return to menu. Set a time 0 to 10 minutes automatically exit menu interface
and close the screen.
Put through power supply, open the power switch of lamps and lanterns, display show the company
website. According to the main interface, as shown in figure:
In the main interface, press "MODE" button to view the software version, press the "UP" "DOWN" can m-
odify the DMX address.
If the screen " " icon is green,said DMX signal connection is normal, this state can be used to check th-
elamps and lanterns and connection between the control table is normal.
LOGO
This lamp can be set to turn off the automatic flip screen function, touch this " “ icon can be manually
flip screen.
menu interface
E12:BusErr1 01
E15:Ballast Err o r 0 7
E17:BD1 BUS E r r o r 9 9
E18:BD2 BUS E r r o r 9 9
E19:BD3 BUS E r r o r 9 9
Mode EnterUp Down
001
1
001-026
Sett ings
1
Dmx Input
Wired Input
Wireless Input
Wireless In/
XLR out
Dmx Input
Mode EnterUp Down
Dmx Address
0 10
Mode EnterUp Down
Set Up
Inforamtion
Personality
Manual Control
Advanced
Mode EnterUp Down
Fixture ID
00 10
Lamp Control
ON
OFF
Confirm
Channel Mode
Mode1 1-26
Mode2 1-26
Mode3 1-34
Mode EnterUp Down Mode EnterUp DownMode EnterUp Down
Press this area for 2 seconds
to modif y the DMX address.
Main interface
Can vi ew the company LOGO ,web
site , hardware, softw are version, date.
CH-001: 000.0% 000
CH-002:PAN Fine 000.0% 000
CH-003:Tilt 000.0% 000
CH-004:Tilt Fine 000.0% 000
CH-005:P/T Speed,Time 000.0% 000
CH-006:Colour Wheel 000.0% 000
CH-007:Col.W.Fine 000.0% 000
PAN
Mode EnterUp Down

Click on the main interface of the icon, numerical to view view Settings related information of lamps and
lanterns.Symbols such as the main interface appear “ “,the following error message indicates that there
might be a lamps and lanterns,can click to view and control information content to modify the lamps and
lanterns.
- 10 -
CODE ERROR MESSAGE MEANS
E001 SpiFlashError
E002 Program Err 1
E003 Program Err 2
E004 MBDInit Error Change the main control chip or replace the display board
E005 BD1Init Error Look for virtual communication signal lines,communication chip welding or short circuit
E006 BD2Init Error
E007 BD3Init Error
E008 BD4Init Error
E012 BusErr1
E013 BusErr2
E014 SPDError
E016 MFpga Error
E017 BD1 BUS Error
E018 BD2 BUS Error
E019 BD3 BUS Error
E020 BD4 BUS Error
E021 Pan FB. Err Check the horizontal and vertical feedback line connection good or feedback IC do you have
any empty welding, short circuit
E022 Pan Zero Err Check the horizontal and vertical origin line connection good or magnetic susceptibility do you
have any empty welding, short circuit
E023 Tilt FB. Err Check the horizontal and vertical feedback line connection good or feedback IC do you have
any empty welding, short circuit
E024 Tilt Zero Err Check the horizontal and vertical origin line connection good or magnetic susceptibility do you
have any empty welding, short circuit
E025 Prism Err1
E026 Prism Err2
E027 R.Gobo1 Err1
E028 R.Gobo1 Err2
E029 R.Gobo2 Err1
E030 R.Gobo2 Err2
E031 Zoom Err
E032 Focus Err
E033 St.Gobo Err
E034 ColourW. Err
E035 Iris Error
E036 Cyan Err
E037 Magenta Err
E038 Yellow Err
E039 Cto Err
E040 Frost2 Err
E042 B.Fan1Error
E044 B.Fan2Error
E046 B.Fan3Error
E048 H.Fan1Error
E050 H.Fan2Error
E052 A.Fan1Error
E054 L.Fan1Error
E058 L.Fan3Error
Check the fan cables, signal lines, fan
Look for virtual communication signal lines or the main chip welding or short circuit
Check whether the communication line is connected well or dial the code is wrong
Check line magnetic susceptibility,magnets and magnetic susceptibility of distance and
location, have the magnet.

7.3 Menu Maps
- 11 -
Dmx Address 001~xxx Dmx Address
Mode1 1-26
Mode2 1-26
Mode3 1-34
Fixture Id 0001-xxxx Lamps address
Fixture Times xxxxxh xxm Total working hours
Lamp Times Xxxxh xxm Lamp On working hours
Error List Exx xxxxxx Error details
Diagnosis BOARD x: xx.xx%
Fans Monitor HfanxSpd: x (r/m) Fans Monitor
Dmx Value CHxx: xx xxx DMX Values
Power On Light Power On Light
Light By Dmx Light By Dmx (default ON)
Lamp On Delay Lamp ON Delay(xxm)
Pan Reverse Pan Reverse
Tilt Reverse Tilt Reverse
Feedback Feedback ON/OFF
Wired Input Wired Input（defaul）
Wiredless Input Wireless Input
Wireless In/XLR out Wireless In/XLR out
P/T Moving
Colour Moving
Gobo Moving
Brightness
Screen Time
Touch Close
Auto Screen Auto Screen
Lamp ON/OFF Lamp Control
Reset All
Reset Pan/Tilt
Reset Colour
Reset Gobo
Reset Other
Channel CHxx: xx xxx Chanel Testing
Calibration Input Password Chanel Adgusting
Factory Default Reset to orignal parameters
Touch Calibration Touch screen adjusting
Manual
Control Reset
Advanced
Personality
Lamp
Pan/Tilt
Dmx Input
BlackOut
Screen
Setup Channel Mode Default Mode1
Information

8.DMX protocol
- 12 -
Mode1 Mode2 Mode3 Function DMX Value
1 22 25
2 23 26
3 24 27
4 25 28
Open 0
Open→Slot1 1-14
Slot1 15
Slot1→Slot2 16-29
Slot2 30
Slot2→Slot3 31-44
Slot3 45
Slot3→Slot4 46-59
Slot4 60
Slot4→Slot5 61-74
Slot5 75
Slot5→Slot6 76-89
Slot6 90
Slot6→Slot7 91-104
Slot7 105
Slot7→Slot8 106-119
Slot8 120
Slot8→Open 121-127
Open 128-140
Slot1 141-145
Slot2 146-150
Slot3 151-155
Slot4 156-160
Slot5 161-165
Slot6 166-170
Slot7 171-175
Slot8 176-180
Open 181-185
CW，Fast→Slow CW 186-211
Stop(This will stop the color wheel wherever it is at the time) 212-217
CCW,Slow→Fast CCW 218-243
Fast 244-247
Medium 248-251
Slow 252-255
White→full cyan 0-255
White→full magenta 0-255
White→full yellow 0-255
Open(6000 K)→warm (3200 K) 0-255
Open 0-9
Gobo 1 10-14
Gobo 2 15-19
Gobo 3 20-24
Gobo 4 25-29
Gobo 5 30-34
Gobo 1 35-39
10 8 9
875
Continuous Rotation
Random color
7 4 5
43
5 6
9 6
6
8Yellow
Cyan
7CTO
Stepped Scroll(snap to full color pisitions)
Pan,16-bit (MSB and LSB)
Left → right (32768 = neutral)
Tilt,16-bit (MSB and LSB)
Up → down (32768 = neutral)
Colour Wheel
Continuous Scroll
0-65535
0-65536
Magenta
Breakup wheel (wheel 1)
Continuous gobo rotation:set gobo rotation speed on channels 11/12(Mode 1),9/10 (Mode 2)
or 10/11 (Mode 3)

- 13 -
Mode1 Mode2 Mode3 Function DMX Value
Gobo 2 40-44
Gobo 3 45-49
Gobo 4 50-54
Gobo 5 55-59
Gobo 1, 360° slow →10° fast 60-89
Gobo 2, 360° slow →10° fast 90-119
Gobo 3, 360° slow →10° fast 120-149
Gobo 4, 360° slow →10° fast 150-179
Gobo 5, 360° slow →10° fast 180-209
CW gobo wheel scroll, fast → slow CW 210-232
CCW gobo wheel scroll, slow → fast CCW 233-255
11 9 10
12 10 11
Open 0-9
Gobo 1 10-14
Gobo 2 15-19
Gobo 3 20-24
Gobo 4 25-29
Gobo 5 30-34
Gobo 1 35-39
Gobo 2 40-44
Gobo 3 45-49
Gobo 4 50-54
Gobo 5 55-59
Gobo 1, 360° slow →10° fast 60-89
Gobo 2, 360° slow →10° fast 90-119
Gobo 3, 360° slow →10° fast 120-149
Gobo 4, 360° slow →10° fast 150-179
Gobo 5, 360° slow →10° fast 180-209
CW gobo wheel scroll, fast → slow 210-232
CCW gobo wheel scroll, slow → fast 233-255
14 12 13
15 13 14
16 14 15
10 8 9
FX wheel (wheel 3) static gobos and animation effect selection.rotation, animation movement
type
Continuous FX wheel scrolling
Aerial wheel(wheel 2): gobo indexing, rotation (16-bit fine, MSB and LSB)
If indexed gobo is selected on channel 10(Mode1) or 8 (Mode2),9(Mode3)
Gobo indexing, 0°→360°
If continuous gobo rotation is selected on channel 10 (Mode1) or 8 (Mode2) ,
9(Mode3)
No gobo rotation, gobo indexed at 0°
CW, fast→slow
No gobo rotation, gobo stops at current position
CCW, slow→fast
No gobo rotation, gobo indexed at 90°
0-65536
0-600
601-32130
32131-32895
32136-64515
64516-65535
Continuous gobo wheel scroll with continuous gobo rotation: set gobo rotation speed on
channels 11/12(Mode1)or 9/10(Mode2),10/11(Mode3)
Continuous gobo rotation:set gobo rotation speed on channels 11/12(Mode1) or 9/10
(Mode2),10/11 (Mode3)
Gobo shake
13 11 12
Aerial wheel (wheel 2)
Breakup wheel(wheel 1): gobo indexing, rotation (16-bit fine, MSB and LSB)
If indexed gobo is selected on channel 10 (Mode1) or 8 (Mode2),9(Mode3)
Gobo indexing, 0°→360°
If continuous gobo rotation is selected on channel 10 (Mode1) or
8(Mode2),9(Mode3)
No gobo rotation, gobo indexed at 0°
CW, fast→slow
No gobo rotation, gobo stops at current position
CCW, slow→fast
No gobo rotation, gobo indexed at 90°
0-65536
0-600
601-32130
32131-32895
32136-64515
64516-65535
Gobo shake
Continuous gobo wheel scroll with continuous gobo rotation:set gobo rotation speed on
channels 11/12(Mode1) or 9/10 (Mode2),10/11(Mode3)

- 14 -
Mode1 Mode2 Mode3 Function DMX Value
Open 0
Open → Gobo 1 1-9
Gobo 1 10
Gobo 1 → Gobo 2 11-19
Gobo 2 20
Gobo 2 → Gobo 3 21-29
Gobo 3 30
Gobo 3 → Gobo 4 31-39
Gobo 4 40
Gobo 4 → Position 5 41-49
Position 5 50
Position 5 → Position 6 51-59
Position 6 60
Position 6 → Position 7 61-69
Position 7 70
Position 7 → Position 8 71-79
Position 8 80
Position 8 → Position 9 81-89
Position 9 90
Position 9 → Open 91-99
Open 100-110
Gobo 1 111-115
Gobo 2 116-120
Gobo 3 121-125
Gobo 4 126-130
Position 5 131-135
Position 6 136-140
Position 7 141-145
Position 8 146-150
Position 9 151-155
Open 156-160
CW FX wheel rotation, fast → slow 161-189
FX wheel stops at its current position 190
CCW FX wheel rotation, slow → fast 191-219
No function 220-226
Smooth 227-229
Organic 230-232
Metronome 233-235
Run forwards, fast rewind 236-238
Run backwards, fast rewind 239-241
Random animation range position 242-249
Random gobo position 250-252
Random FX wheel position 253-255
Stop 0-10
Animation speed slow → fast 11-255
Prism off 0-10
Prism indexing: set angle on ch. 17(Mode2) or 18 (Mode1 or Mode3) 11-138
Prism rotation: set direction and speed on channel. 18(Mode2) or 18 (Mode1 or
Mode3) 139-255
Indexed angle 0°- maximum 0-255
Prism stop,indexed at 0° 0-2
CW rotation, fast→slow 3-126
Prism stop at its current position 127-129
16 14 15
18 17
19 18 19
Prism indexing angle, rotation speed and direction
If prism rotation is selected on channel17(MODE2)or18(MODE1&MODE3)
Continuous FX wheel rotation: set rotation speed on channel 17 (Mode1)or
15(Mode2),16(Mode3)
17 15 16
FX wheel animation speed
Stepped FX wheel scrolling
Animation movement functions: set speed on channel 17 (Mode1)or 15(Mode2),16(Mode3)
18
Prism
Random gobo function;set time on channel 17(Mode1)or15(Mode2),16(Mode3)
If prism indexing is selected on channel17(MODE2)or18(MODE1&MODE3)

- 15 -
Mode1 Mode2 Mode3 Function DMX Value
CCW rotation, slow→fast 130-253
Prism stop, indexed at 45° 254-255
No frost → full fros 0-255
Close 252-255
Fast open,fast close -fast open,fast close 172-211
Slow open,slow close- fast open,fast close 212-251
Slow pulsation fast pulsation 132-171
Open →closed 0-131
21
22
23
24
Shutter closed (Lamp switches to 800 watt mode after shutter is closed for 3
seconds) 0-19
Shutter open 20-49
Strobe, slow →fast 50-200
Shutter open 201-210
Random strobe, slow → fast 211-255
2 Dimmer fade(MSB) Closed → open 0-255
3 Dimmer fade,fine(LSB) 0-255
No function 0-9
Reset entire fixture -3 sec. 10-14
Reset dimmer and shutter only -3 sec. 15-19
Reset CMY, CTO and color wheel only -3 sec. 20-24
Reset effects(breakup, aerial and FX wheels, iris, prism, frost, zoom, focus) only
-3 sec. 25-29
Reset pan and tilt only -3 sec. 30-34
No function 35-39
Lamp on -3 sec. 40-44
Lamp off -3 sec. 45-49
No function 50-104
Disable zoom/focuslinking -1 sec. 105-109
Enable zoom/focus linking,near distance(5 meters) -1 sec. 110-114
Enable zoom/focus linking,mediumdistance(8 meters) (default setting)-1 sec. 115-119
Enable zoom/focus linking, far distance(12 meters) -1 sec. 120-124
Ballast output full, set to 100% (default setting) 125-126
Ballast output reduced to 90% 127-128
Ballast output reduced to 80% 129-130
Ballast output reduced to 70% 131-132
Ballast output reduced to 60% 133-134
Beam smoothing=ON -1sec. 135-139
Beam smoothing=OFF -1sec. (default setting) 140-144
Pan/Tilt Moving blackout=ON -1sec. 145-149
Pan/Tilt Moving blackout=OFF-1sec.(default setting) 150-154
Colour Moving blackout=ON -1sec. 155-159
Colour Moving blackout=OFF -1sec.(default setting) 160-164
Gobo Moving blackout=ON -1sec. 165-169
Gobo Moving blackout=OFF -1sec.(default setting) 170-174
No function 175-224
autofocus priority rotation gobo1 225-229
autofocus priority rotation gobo 230-234
autofocus priority FX wheel 235-239
autofocus priority Iris 240-244
No function 245-255
30 Reserved 0-255
31 Reserved 0-255
32 Reserved 0-255
33 Reserved 0-255
34 Reserved 0-255
26 26 29
25 2
24 1 1
Strobe/shutter
23 21 Focus, 16-bit (MSB and LSB)
Infinity →near 0-65535
22 20 Zoom,16-bit(MSB and LSB)
Flood→spot 0-65535
21 19 20
Iris
20 16 17 Frost
191819

- 16 -
9.Maintance and cleaning
It is absolutely essential that the fixture is kept clean and that dust,dirt and smoke fluid residues must not
buildup on or within the fixture. Otherwise, the fixtures light-output will be significantly reduced. Regular
cleaning will not only ensure the maximum light-output, but will also allow the fixture to function reliably
through out its life. A soft lint-free cloth moistened with any good glass cleaning fluid is recommended,
under no circum stances should alcohol or solvents be used!
The front objective lens will require weekly cleaning as smoke-fluid tends to building up residues,reduc-
ing the light-output very quickly.The cooling-fans should be cleaned monthly.
The gobos may be cleaned with a soft brush,The interior of the fixture should be cleaned at least annua-
lly usinga vacuum-cleaner or an air-jet.
There are no serviceable parts inside the device except for the lamp and the fuse.
Replacing the fuse: If the lamp burns out,the fine-wire fuse of the device might fuse,too.Only replace the
fuse by a fuse of same type and rating.Before replacing the fuse,unplug mains lead.
Maintenance and maintenance of the operation, please contact the manufacturer or distributor.
DANGER:Disconnect from the mains before starting any maintenance work.
10.Electric equipment specification
10.1 Electrical paramters
SOURCE:
POWER:1203
VOLTAGE:
OSRAM 1000W/PS Lok-it! /PHILIPS MSR GOLD 1000 MiniFastfit
W
AC120-240V 50/60HZ
Color temperature：6000K
10.2 Weight and dimensions
Dimensions：
NET WEIGHT:42Kg
Dimensions
WEIGHT
Dimensions
NET WEIGHT/WEIGHT
600X470X610
Carton package
Carton package
mm
( ):51.5Kg
（Air boxes -1 lights):690X530X855mm
(Air boxes -1 lights) :38.75Kg/82.75Kg
（ ）:746X596X751mm
10.3 Channel Characteristics
2．Scan: Pa n630°,Tilt270°,Fixture could auto reset.
3．Colour wh eel:On e open+8colors.
4.RGo bo wheel 2 :one open+5 gobos.
5.GoboR wh eel: one open + 4 gobos
6.Frost: linear frost
7.Focus: linear focus.
8.Shutter: electronic shutter, random strobe.
9.Demme r: lime ar dimme r.
10.Prism system: prism effect, with rotating.
11.Zoom: linear amp lifier.
1．Channel:26、26、34DMX -512.
+FX
