JONATHAN Y Aldrin JYL9715A User manual

50-INCH CEILING FAN
50-INCH CEILING FAN
JYL9715 CH
JONATHAN Y
ITEM#:JYL9715A/B/C/D/ESIZE
:φ50"X H6.25"-11.25"-16.25"

3.8kgs
(8.36lbs)
4.56kgs
(10.03lbs)2.37cu.ft
60.261 18 187 4125
50

4
Blades Decorative Cover

7

Yellow
Green
White
Black
16
GG

1.Remove the fan motor housing
2.Fastening the blade to the motor
10
1. Remove the six screws on the shell of the fan
motor to separate the shell from the motor.
1. Insert the positioning column into the slot above
the motor and tighten the preinstalled blade screws
to secure the blade to the fan motor assembly.
2. Repeat this step for other blade components.

11
1. After installing the fan blades, lock the six screws
removed from the motor shell with the shell and motor.
Install the trim cover
3.Install the fan motor housing

12
Fan Shutdown
Rotation Direction
NaturalWind
Height for Ceiling Mounted:
Height with 5" rod:
Height with 10" rod:
6.25"
11.25"
16.25"

13
Use of intelligent remote control
Pairing JONATHAN Y Mobile APP
Scan the QR code to download the "JONATHAN Y " APP
a. Download and Open "JONATHAN Y" Mobile App.
b. Turn on the electric power.
c. The app pairing: please long press the key immediately till you hear the
long “beep” sound, And then, entre the wifi_pair status(Intellectual product).
d. Press the + button in the top right corner of the mobile App.
e. Under "Add Manually" select Home Appliances.
f. Select Fan.
g. Click "Confirm indicator rapidly blink" and type in your Wi-Fi name &
password then proceed to click "OK".
h. After the loading screen go back to homepage and you should be able to
find your device there.
Q : If you cannot pair the JONATHAN Y APP
A : 1 . Please check whether the WI-FI network is 2.4g.
2. Turn off the power and turn on the power again, wait for 10 seconds, then press
and hold " " at the same time until the receiver emits a prolonged
beep sound three times.
3. Pairing JONATHAN Y Mobile APP again.
Q : If you remote cannot control the receiver.
A : 1. Please turn off the power.
2. Turn on the power again.
3. Press and hold " " at the same time. Until the receiver emits "beep" three times.

In addition to the included control , you can operate your fan with the JONATHAN Y app.
Upgradeable with Smart Features
Scan the code to the right with your phone to find out how you can enable smart
features through the JONATHAN Y app and integrate with your smart home ecosystem.
NOTE : Press light toggle and season toggle and hold for 4 second if you prefer not
using the app or broadcasting Wi-Fi.
1. To use the JONATHAN Y app , download it from the App Store or Google Play.
2. Open the app to create your account . You can also log in using your Facebook or Google account.
3.To set up a Wi-Fi connection you will need the SSID and Wi-Fi password for the network you
wish to connect to.
4. You will rceive a prompt to name your fan device and upload an optional picture of it if you choose.
Intelligent function
14

The fan is noisy.
15
