JONATHAN Y JYL9718A User manual

JYL9718 CH
JONATHAN Y
ITEM#:JYL9718A/B/C/D
SIZE:φ52"X H14"-19"

5.2kgs
(11.44lbs)
6.24kgs
(13.728lbs)3.01cu.ft
60.406 29 180 5438
52

4
lamp shade
Lamp pan

1. Notice the half ball on the end of the support rod is grooved down one side. This key way fits
over the small keyway pin on the inside of the mounting bracket and keeps the ceiling fan from
spinning on the mounting bracket.
2. Carefully push the canopy to the bottom of the mounting bracket, make two sliding holes
aligned to the two prominent screws on the mounting bracket, and then turn clockwise until tight.
3. Push the canopy ring to the bottom of the canopy, slide the inner holes aligned to the two
prominent screws on the mounting bracket again, and turn the canopy ring clockwise until tight.
7

Yellow
Green
White
Black
16
GG

1.Fastening the blade to the motor
1. Remove the 12 blade screws from the top and bottom
of the fan motor.
2. Then place the blade in the corresponding position,
lock two screws on the upper and lower parts of the blade,
and preinstall the screws.
3. Put the remaining blades together and lock the screws.
1. Install the light panel
1. As shown in the picture, remove the 3 screws
on the motor, install the lamp plate on the motor,
and lock the screws.

2. Connecting lamp wire and Install the lamp cover
1. Connect the light kit with motor,
put the light kit in the light kit fitter.
10

Fan Shutdown
Rotation Direction
LightON/LightOFF
Natural Wind
11
Height with 5" rod: 14"
Height with 10" rod: 19"

Pairing JONATHAN Y Mobile APP
Scan the QR code to download the "JONATHAN Y " APP
a. Download and Open "JONATHAN Y" Mobile App.
b. Turn on the electric power.
c. The app pairing: please long press the key immediately till you hear the
long “beep” sound, And then, entre the wifi_pair status(Intellectual product).
d. Press the + button in the top right corner of the mobile App.
e. Under "Add Manually" select Home Appliances.
f. Select Fan.
g. Click "Confirm indicator rapidly blink" and type in your Wi-Fi name &
password then proceed to click "OK".
h. After the loading screen go back to homepage and you should be able to
find your device there.
Q : If you cannot pair the JONATHAN Y APP
A : 1 . Please check whether the WI-FI network is 2.4g.
2. Turn off the power and turn on the power again, wait for 10 seconds, then press
and hold " " at the same time until the receiver emits a prolonged
beep sound three times.
3. Pairing JONATHAN Y Mobile APP again.
Q : If you remote cannot control the receiver.
A : 1. Please turn off the power.
2. Turn on the power again.
3. Press and hold " " at the same time. Until the receiver emits "beep" three times.
12
Use of intelligent remote control

13
In addition to the included control , you can operate your fan with the JONATHAN Y app.
Upgradeable with Smart Features
Scan the code to the right with your phone to find out how you can enable smart
features through the JONATHAN Y app and integrate with your smart home ecosystem.
NOTE : Press light toggle and season toggle and hold for 4 second if you prefer not
using the app or broadcasting Wi-Fi.
1. To use the JONATHAN Y app , download it from the App Store or Google Play.
2. Open the app to create your account . You can also log in using your Facebook or Google account.
3.To set up a Wi-Fi connection you will need the SSID and Wi-Fi password for the network you
wish to connect to.
4. You will rceive a prompt to name your fan device and upload an optional picture of it if you choose.
Intelligent function

The fan is noisy.
