Jonsered BV32 Guide

SERVICE
Spare parts
Ersatzteile
Pièces détachées
Reserve onderdelen
Repuestos
Reservdelar
I0200082
IPL, BV32, 2002-08, 106 29 58-61
BV32
106 29 58-61

PARTS LIST NO.
PAGE NO. REPLACES PARTS LIST MODEL:
BV32
530068885 -- 8/07/02
Note: Illustrations may differ from actual models due to design changes
1530068885--9/13/01
26
1
23 316
24 25
80
88
98 99
13
4
All repairs, adjustments
andmaintenance notde-
scribedintheOperator’s
Manual must be per-
formed by qualified
service personnel.
WARNING
4
32
40
106 22
711
5
41 42 43 44
47 48 49 50 51
87
46
14
19
45
93
9
10
8
18
17 21
20
30
12
29
27
32
54
28 26
68
71
31
40
33
69
34
35
37 36
55
67
39
66
38
60
58 59
52 53 56 57
63
6162 6465
91
96
100 101
103
109
97
94 110
70
92
102
95
72
Operator’s
Manual Engine
Gasket
Kit
Spark
Arrestor
107 108 104
Kit
73
74
75 76 77
78 81
84 85
86
82
83
45
79
105
102
90
89
75
111
112
113
114
TYPE 1

PARTS LIST NO.
PAGE NO. REPLACES PARTS LIST MODEL:
BV32
530068885 -- 8/07/02
Note: Illustrations may differ from actual models due to design changes
2530068885--9/13/01
64 530019158 Crankshaft Seal
65 530032102 Outer Bearing
66 530015789 Retaining Ring
67 530014016 Crankcase Assy.
68 530039189 Flywheel Assy.
69 530347987 Washer
70 530023817 Starter Dog Spring
71 LSpacer--See Service Ref. 3
72 530014156 Crankcase/Crankshaft Assy.
73 530016080 Screw
74 530015496 Screw
75 530027523 Retainer
76 LStarter Pulley (Incl.73)
-- See Service Ref. 1
77 530042085 Starter Spring
78 530069714 Fan Housing Kit (Incl. 71, 73--77, 79,
82--84, 86 & 105)
79 530027569 Starter Handle
80 530029117 Throttle Lock Button
81 530015769 Screw
82 LBearing--See Service Ref. 3
83 LSpacer--See Service Ref. 3
84 LScrew--See Service Ref. 3
85 530019167 ”O” Ring
86 530029182 Eyelet
87 530029227 Spark Arrestor Screen
88 530015702 “C” Clip
89 530029119 Rope Retainer Tube (Roll Pin)
90 530094710 Blower Housing (Upper)
91 530029173 Band
92 530047077 Impeller (Includes Hub)
93 530014339 Deflector & Clamp Ass’y.
94 530015818 Washer -- Impeller
95 530015441 Washer
96 530001733 Nut
97 530047736 Blower Housing (Lower)
(Incl. 100--103 & door)
98 530024772 Spring -- Throttle
99 530027597 Spring -- Lever Return
100 530015667 Spring -- Torsion (right)
101 530015647 Pin -- Pivot
102 530015815 Screw
103 530015672 Spring -- Torsion (left)
104 530069348 Spark Arrestor Kit
105 530069232 Rope Kit
106 530069247 Kit -- Line Carb./Purge
107 Operator’s Manual
530083432 Scandinavian
530083433 European
108 530069294 Gasket Kit (Incl. 35, 49, 50 & 54)
109 530015814 Screw
110 LInlet Door--See Service Ref. 4
111 530049185 Air Dam Sponge
112 530053346 Heat Shield / Air Dam
113 530019168 Grommet--Carb. Box
114 530019253 Seal Foam
530047885 Decal--Door Instruction
Description
Key
No. Part
No. Description
Key
No. Part No.
1 530094712 Handle
2 530026994 Front Isolator
3 530029111 Spacer -- Isolator
4 530015635 Screw
5 530029130 Rear Isolator
6 530015813 Screw
7 530029072 Trigger
8 530037595 Assist Handle Ass’y
9 530029228 Spark Arrestor Clamp
10 530029988 Exhaust Deflector Ass’y.
11 530015840 Pin -- Handle
12 534790500 Nut
13 530037864 Shroud--Right
14 530037934 Shroud--Left
16 530069572 Switch Kit
17 530029129 Isolator -- Engine Mount
18 530029295 Isolator -- Tank
19 530015814 Screw
20 530014162 Fuel Tank Ass’y. (Incl. #21,
22 & 106)
21 530014347 Fuel Cap (w/ retainer)
22 530095646 Fuel Pick--up Ass’y.
23 530014160 Handle Cover Assy.
24 530037865 Filter Cover
25 530029112 Air Filter
26 530029404 Air Baffle
27 530069293 Muffler Kit
28 530029116 Muffler Spring
29 952030201 Spark Plug (RCJ--8Y)
30 530001624 Screw
31 530069628 Cylinder Kit
32 530029145 Lead Wire Assy.
33 530039137 Ignition Module
34 530015816 Screw
35 530019178 Cylinder Gasket
36 530025875 Piston Ring
37 530069277 Piston Kit (Incl. #36,38, & Pin)
38 530015162 Wrist Pin Retainer
39 530015306 Screw
40 530029144 Ground Wire Assy.
41 530015849 Screw
42 530015254 Wave Washer
43 530015852 Choke Spacer
44 530029114 Choke Shutter
45 530015775 Screw
46 530037492 Cable Assembly
47 530029115 Air Filter Plate
48 530069644 Carburetor Kit (WT 141A w/ Limiter Cap)
49 530019164 Carb. Gasket
50 530019165 Foam Seal
51 530015771 Screw
52 530029113 Ground Wire
53 530047696 Reed Block / Heat Shield
54 530019166 Gasket
55 530027593 Reed Valve
56 530027594 Reed Stop
57 530016064 Screw
58 530014033 Crankshaft--See Service Ref. 2
59 530015126 Flywheel Key
60 530010960 Connecting Rod Ass’y.
61 LSpacer--See Service Ref. 2
62 530032103 Inner Bearing
63 530015787 Retaining Ring
n=PART NUMBER CHANGE L=REFER TO THE SERVICE REFERENCE INDICATED FOR MORE INFORMATION.(LOCATED AT END OF IPL)
n
n
Not Shown
n
n
n
TYPE 1 TYPE 1

PARTS LIST NO.
PAGE NO. REPLACES PARTS LIST MODEL:
BV32
530068885 -- 8/07/02
Note: Illustrations may differ from actual models due to design changes
3530068885--9/13/01
26
4
12
10
9123 38
7115
16
17
18
20
22
24 25
27
28
29
30
31
3240
32
33 34
35
37 36
38
60
4142 43 44 47 48 49
50 51 52 53 54 55 56 57
62 6364 65 66 67
68
69
71
39
58 59
73
74 75 76 77
78
79
81
85
86
87
89 90 91
61
15
46
13
14
19
Engine
Gasket
Kit
Spark
Arrestor
103 84
4
80
45
72
All repairs, adjustments
andmaintenance notde-
scribed in the Operator’s
Manual must be per-
formed by qualified ser-
vice personnel.
WARNING
26
98
93
88
92
94
95
96
97
82
83
19
45
7582
Kit
21
40 70
99
100
101
102
TYPE 2

PARTS LIST NO.
PAGE NO. REPLACES PARTS LIST MODEL:
BV32
530068885 -- 8/07/02
Note: Illustrations may differ from actual models due to design changes
4530068885--9/13/01
60 530010960 Assy--Connecting Rod
61 530069232 Kit--Rope
62 530032103 Inner Bearing
63 530015787 Ring--Retaining (Crankcase)
64 530019158 Seal--Crankshaft
65 530032102 Outer Bearing
66 530015789 Ring--Retaining (Crankshaft)
67 530014016 Assy--Crankcase
68 530039189 Assy--Flywheel
(Incl. #70)
69 530347987 Washer
70 530023817 Spring--Starter Dog
71 530038386 Spacer--Flywheel
72 530014156 Assy--Crankcase/Crankshaft
(Incl. #58 & 62--67)
73 530016080 Screw
74 530015496 Screw
75 530027523 Retainer
76 530069486 Kit--Starter Pulley (Incl. #73)
77 530042085 Spring--Starter
78 530069714 Kit--Fan Housing
(Incl. #61, 71, 73--77, 79 & 86)
79 530027569 Handle--Starter
80 530069247 Kit--Line
81 530015769 Screw
82 530015815 Screw
83 530015672 Spring--Torsion (Left)
84 530069348 Kit--Spark Arrestor
85 530019167 ”O” Ring--Seal
86 530029182 Eyelet--Flange
87 530015647 Pin--Pivot
88 530049185 Sponge--Air Dam
89 530029119 Tube--Rope Retainer
90 530094710 Blower Housing (Upper)
91 530029173 Band--Blower Hsg.
92 530014157 Assy--Impeller (Incl. Hub)
93 530015667 Spring--Torsion (Right)
94 530047700 Inlet Door
95 530015441 Washer--Conical
96 530016320 Nut
97 530047736 Blower Housing (Lower)
(Incl. #82, 83, 87, 93 & 94)
98 530069692 Kit--Muffler Guard
99 530038508 Assy--Nozzle & Tube
100 530015818 Washer--Impeller
101 530019253 Seal Foam
102 530019168 Grommet
103 530069294 Kit--Gasket (Incl. #35, 49, 50 & 54)
-------- Operator’s Manual
530088113 (Scan)
530088114 (Euro)
530047885 Decal--Door Instruction
Description
Key
No. Part
No. Description
Key
No. Part No.
1 530069863 Kit--Handle
2 530026994 Isolator
3 530029111 Spacer--Isolator
4 530015635 Screw
5 530029130 Isolator--Handle (Rear)
6 530015813 Screw
7 530029072 Trigger
8 530027597 Spring--Lever Return
9 530015702 ”C” Clip--Throttle Lock
10 530029117 Throttle Lock Button
11 530015840 Pin--Handle
12 530024772 Spring--Throttle
13 530056005 Shroud--Left
14 530056006 Shroud--Right
15 530053346 Heat Shield--Air Dam
16 530069572 Kit--Switch
17 530029129 Isolator--Engine Mount
18 530029295 Isolator Tank
19 530015814 Screw
20 530014162 Assy--Fuel Tank
(Incl. #21, 22 & 80)
21 530014347 Assy--Fuel Cap w/retainer
22 530095646 Assy--Fuel Pick--up
23 530014160 Assy--Handle Cover
(Incl. #9, 10 & 12)
24 530054877 Cover--Filter
25 530029112 Filter--Air (Foam)
26 530029404 Baffle--Air
27 530069293 Kit--Muffler
28 530029116 Spring--Muffler
29 952030201 Spark Plug (RCJ--8Y)
30 530001624 Screw
31 530071581 Kit--Cylinder
32 530029425 Wire--Lead (Switch)
33 530039137 Ignition Module
34 530016357 Screw
35 530019178 Gasket--Cylinder
36 530025875 Ring--Piston
37 530069277 Kit--Piston (Incl. #36,38,& Pin)
38 530015162 Retainer
39 530015306 Screw
40 530029426 Wire--Ground (Switch)
41 530015849 Screw
42 530015254 Washer
43 530015852 Spacer--Choke
44 530029114 Choke Shutter
45 530015775 Screw
46 530037492 Assy--Cable
47 530029115 Plate--Air Filter Mtg.
48 530069644 Kit--Carburetor Ass’y.
(WT 141A w/ Limiter Cap)
49 530019164 Gasket--Carb
50 530019165 Seal--Foam/Reed Block
51 530015771 Screw
52 530029113 Ground Wire (Static)
53 530047696 Reed Block/Heat Shield
54 530019166 Gasket--Reed Block/C’case
55 530027593 Reed Valve
56 530027594 Reed Stop
57 530016064 Screw
58 530014033 Assy--Crankshaft
59 530015126 Key--Flywheel
Not Shown
L= REFER TO THE SERVICE REFERENCE INDICATED FOR MORE INFORMATION.(LOCATED AT END OF IPL)
=NEW PART NUMBER FOR THIS IPL
n
TYPE 2 TYPE 2
n
nn
n
n
n

PARTS LIST NO.
PAGE NO. REPLACES PARTS LIST MODEL:
BV32
530068885 -- 8/07/02
Note: Illustrations may differ from actual models due to design changes
5530068885--9/13/01
KEY NO. PART NO.
530095116
530095117
530069270
530038508
DESCRIPTION
1
2
4
3
1
2
3
4
Collection Bag W/Strap
Collection Bag Elbow Tube
Vacuum Tube Ass’y
Tube and Nozzle Ass’y
1. 530035264 Kit---Carburetor Repair
( KIT= Indicates Contents)
2. 530038403 Limiter Cap
3. 530069844 Kit---Gasket/Diaphragm
Key No. Part No. Description
530035014
530035151
530035016
530035268
530035293
530035166
530035164
530035203
530035121
530035028
530035031
530035188
530035106
530035178
530035264
530069844
Metering Diaphragm
Metering Diaphragm Gasket
Metering Lever Pin Screw
Mixture Needle
Mixture Needle Spring
Fuel Pump Diaphragm
Fuel Pump Gasket
Idle Speed Screw
Idle Speed Spring
Metering Lever Pin
Metering Lever
Metering Lever Spring
Inlet Needle Valve
Fuel Inlet Screen
Carb. Kwik Repair Kit
(*Indicates Contents)
Carb. Gasket/Diaphragm Kit
(+Indicates Contents)
*+
*+
*
1
2
3
4
5
8
9
10
11
12
13
14
15
16
17
18
*+
*
*
*
*
*
*+
24
5
16
Carb.
Repair
Kit
Carb.
Gasket
Kit
17 18
12 13 14 15
91011
3
19
1
Ref. Part No. Description
1
Carb.
Repair
Kit
Carburetor Assembly
WT---141A #530069644W T --- 1 4 1
8
2
KIT
KIT
KIT
KIT
KIT
KIT
KIT
KIT
KIT KIT
KIT
n=PART NUMBER CHANGE L=REFER TO THE SERVICE REFERENCE INDICATED FOR MORE INFORMATION.(LOCATED AT END OF IPL)
n
3
Gasket/
Dia.
Kit

PARTS LIST NO.
PAGE NO. REPLACES PARTS LIST MODEL:
BV32
530068885 -- 8/07/02
Note: Illustrations may differ from actual models due to design changes
6530068885--9/13/01
LSERVICE REFERENCE
530069291 530069486
9/16” or
14.3mm 3/8”or
9.5mm
1. Starter Pulley -- When ordering a new starter pulley for your unit, please measure your existing
pulley as shown by the dimensions in the illustrations below and order accordingly.
2. Crankshaft Spacer -- Earlier models equipped with the laminated crankshaft (shown on the left)
requires Spacer 530015788. Later models equipped with a step on the crankshaft (shown on the
right), do not require the spacer.
Spacer Required Spacer Not Required
Step
3. Fan Housing Kit, Spacers, Bearing and Screws -- The earlier fan housing was equipped with
bearing (530032108), screws (530015805) and required two spacers (530029176 and 530029110) as
shown below. The new fan housing does not require a bearing and uses one long spacer
(530038386). Both sets of parts are included in the new fan housing kit 530069714.
Bearing and Two Spacers Required One Long Spacer Required
530029176 530038386
530015805
530032108
4. Inlet Door -- The latch on the lower blower housing and door has changed. The new style can be
identified by the tab found at the top of the latch on the door and the latch prongs on the housing as
shown below. To replace the old door, order Lower Blower Fan Housing 530047736. To replace the
door equipped on the new style housing, order 530047700.
New Style
Latch
Prongs Tab
No
Prongs No Tab
Old Style
NewStyle Old Style
530029110
