jotron TR-7750C User manual

Jotron AS| TR7750C: Operators Manual Introduction
Page ii
P/N: 84748 (G)
Approvals
The equipment is designed to meet the essential requirements of European Directives 1999/5/EC,
89/336EEC as amended by Directive 93/68/EEC and 72/23/EEC
Standards
The following standards are applied:
EMC: EN301843-1 and EN301843-2
FCC part 80
Health and Safety: EN60950
Radio specifications: EN301929-1 and EN301929-2
For an updated list of approvals and statements of conformity, these are available on:
www.jotron.com

Jotron AS| TR7750C: Operators Manual Introduction
Page iii
P/N: 84748 (G)
List of abbreviations and definitions
BITE
Built In Test Equipment
bps
Bits Per Second.
DSP
Digital Signal Processor
ETSI
European Telecommunication Standardisation Institute
ICAO
International Civil Aviation Organization
IEC
International Electro-technical Commission.
LAN
Local Area Network
PA
Power Amplifier
PSU
Power Supply Unit. Separate unit to power the equipment.
PTT
Push To Talk
RF
Radio Frequency
S/N
SIGNAL- TO-NOISE RATIO
SNMP
Simple Network Management Protocol, a network protocol used to control the radio equipment.
This equipment is defined as an AGENT in a SNMP system.
VSWR
Voltage Standing Wave Ratio

Jotron AS| TR7750C: Operators Manual Introduction
Page iv
P/N: 84748 (G)
Amendment Record
NO
INIT
DATE
CHAPTERS
VERSION
REASONFOR CHANGE
1
ES
13.08.08
All
84748_O
perators
_TR7000
C_A
New product
2
OH
11.11.08
3.2.5, 3.2.6, 3.2.7,
3.4.4, 3.4.5, 3.4.6
B
Information regarding Frequency stability,
Hardware Key and protection of I/O lines added.
3
ES
29.06.09
3-5
C
Information regarding type of LAN cable
4
OH
10.11.09
3.4.5, 1.1
D
Pin 8 Aux 2 is N/C, Output power configuration
range in radio model table.
5
BA
05.04.13
3.2.7, 3.2.8, 3.4.6,
4.6.1
E
Fixed RS485 polarity error.
6
BR
28.04.14
4.4
F
FCC and IC approval
7
BA
04.06.14
Page vi
G
Added warning statement, modification warning
statement and digital device statement.
8
9
10
11
12
13
14
15
16
17
18
19
20
The information in this book has been carefully checked and is believed to be accurate. However, no
responsibility is assumed for inaccuracies.
Jotron AS reserves the right to make changes without further notice to any products or modules
described herein to improve reliability, function or design. Jotron AS does not assume any liability
arising out of the application or use of the described product.

Jotron AS| TR7750C: Operators Manual Introduction
Page v
P/N: 84748 (G)
SAFETY INSTRUCTIONS
CAUTION!
This equipment contains CMOS integrated circuits. Observe handling precautions to avoid static
discharges which may damage these devices.
WARNING!
Some RF semiconductor devices used in this equipment may contain Beryllium Oxide. If inhaled, dust
from this oxide can be toxic. No danger will arise from normal handling but no attempt should be
made to tamper with these devices. On no account must these transistors be destroyed or discarded
with industrial or domestic waste, but should be returned to the manufacturers for subsequent
disposal.

Jotron AS| TR7750C: Operators Manual Introduction
Page vi
P/N: 84748 (G)
WARNING STATEMENT
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.
MODIFICATION WARNING STATEMENT
Changes or modifications not expressly approved by the party responsible for compliance could void
the user's authority to operate the equipment.
DIGITAL DEVICE STATEMENT
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
--Reorient or relocate the receiving antenna.
--Increase the separation between the equipment and transceiver.
--Connect the equipment into an outlet on a circuit different from that
to which the transceiver is connected.
--Consult the dealer or an experienced radio/TV technician for help.

Jotron AS| TR7750C: Operators Manual Introduction
Page viii
P/N: 84748 (G)
TABLE OF CONTENTS
1INTRODUCTION.......................................................................................................................1-1
1.1 MODELS COVERED BY THIS MANUAL.....................................................................................1-1
1.2 LAYOUT OF THE TRANSCEIVER ..............................................................................................1-1
1.3 APPLICATIONS........................................................................................................................1-2
2TECHNICAL SPECIFICATIONS............................................................................................2-1
2.1 GENERAL SPECIFICATION,TRANSCEIVER UNITS,TR-7750C................................................2-1
2.2 TRANSMITTER UNITS,TA-7650C..........................................................................................2-1
2.3 RECEIVER UNIT,RA-7203C...................................................................................................2-2
2.4 POWER SUPPLY UNIT,PSU-7002...........................................................................................2-2
3FUNCTIONAL DESCRIPTION...............................................................................................3-1
3.1 FRONT PANEL CONTROLS,TRANSMITTER UNIT ....................................................................3-1
3.1.1 Display............................................................................................................................3-1
3.1.2 Scroll/Select switch and Navigation buttons A, B and C................................................3-1
3.1.3 PTT button......................................................................................................................3-1
3.1.4 ON/OFF button...............................................................................................................3-1
3.1.5 LED Indicators ...............................................................................................................3-2
3.1.6 Mic/Headset connector...................................................................................................3-2
3.2 TRANSMITTER,REAR CONNECTIONS......................................................................................3-4
3.2.1 Antenna connector (50 ohm N).......................................................................................3-4
3.2.2 Receiver ant. Connector (50 ohm BNC).........................................................................3-4
3.2.3 DC input connector (Amphenol MS 3106A 10SL4S)(Jotron P/N: 96715) .....................3-4
3.2.4 LAN connector (RJ45)....................................................................................................3-5
3.2.5 AUX1 CONNECTOR (RJ45)..........................................................................................3-5
3.2.6 AUX2 connector (RJ45)..................................................................................................3-6
3.2.7 REM connector (RJ45)...................................................................................................3-6
3.2.8 Rx connector (RJ45).......................................................................................................3-7
3.3 FRONT PANEL CONTROLS,RECEIVER UNIT ...........................................................................3-8
3.3.1 Display............................................................................................................................3-8
3.3.2 Scroll/Select switch and Navigation buttons A, B and C................................................3-8
3.3.3 ON/OFF button...............................................................................................................3-8
3.3.4 LED Indicators ...............................................................................................................3-8
3.3.5 Headset connector..........................................................................................................3-9
3.4 RECEIVER,REAR CONNECTIONS...........................................................................................3-10
3.4.1 Antenna connector (50 ohm N).....................................................................................3-10
3.4.2 DC input connector (Amphenol MS 3106A 10SL4S)(Jotron P/N: 96715) ...................3-10
3.4.3 LAN connector (RJ45)..................................................................................................3-11
3.4.4 AUX1 CONNECTOR (RJ45)........................................................................................3-11
3.4.5 AUX2 connector (RJ45)................................................................................................3-12
3.4.6 REM connector (RJ45).................................................................................................3-12
3.5 PSU-7002, POWER SUPPLY UNIT,FRONTVIEW....................................................................3-13
3.5.1 LED Indicators .............................................................................................................3-13
3.6 POWER SUPPLY UNIT REAR CONNECTORS...........................................................................3-14
3.6.1 DC input connector (Amphenol MS 3106A 10SL4S)(Jotron P/N: 96715) ...................3-14
3.6.2 DC Output Connector(Amphenol MS 3106A 12S3P)(Jotron P/N: 93697) ..................3-14
3.6.3 AC Input connector.......................................................................................................3-15
4INSTALLATION........................................................................................................................4-1
4.1 INTRODUCTION.......................................................................................................................4-1

Jotron AS| TR7750C: Operators Manual Introduction
Page ix
P/N: 84748 (G)
4.2 INITIAL INSPECTION ...............................................................................................................4-1
4.3 INSTALLATION INTO EQUIPMENT CABINET ............................................................................4-2
4.4 ANTENNA CONNECTORS.........................................................................................................4-2
4.5 AC AND DC CONNECTORS .....................................................................................................4-2
4.6 REMOTE SIGNALS...................................................................................................................4-2
4.6.1 REM connector (receiver) and RX connector (transmitter)...........................................4-3
4.6.2 Audio in/out and Line loop keying..................................................................................4-6
4.6.3 Other key signals ............................................................................................................4-9
4.6.4 Squelch and AGC signals, receiver unit.......................................................................4-11
4.6.5 Alarm and Select signals transmitter and receiver.......................................................4-12
4.6.6 Miscellaneous signals, transmitter...............................................................................4-14
4.7 APPLICATIONS......................................................................................................................4-15
4.7.1 Transceiver, local configuration...................................................................................4-15
4.7.2 Transceiver, remote configuration ...............................................................................4-18
4.7.3 Transmitter, main / backup configuration....................................................................4-20
4.7.4 Receiver, main / backup configuration.........................................................................4-22
5OPERATING INSTRUCTIONS...............................................................................................5-1
5.1 INTRODUCTION.......................................................................................................................5-1
5.2 USER MENU –TRANSMITTER (RESTRICTED ACCESS LEVEL)..................................................5-2
5.3 USER MENU –TRANSMITTER (DEFAULT ACCESS LEVEL).......................................................5-3
5.4 SETTING,INFORMATION AND CONFIGURATION MENUS –TRANSMITTER...............................5-4
5.4.1 Radio control group........................................................................................................5-5
5.4.2 TX config group..............................................................................................................5-5
5.4.3 Interface config group ....................................................................................................5-6
5.4.4 Bite system group............................................................................................................5-7
5.4.5 System info group ...........................................................................................................5-7
5.5 PARAMETER DETAILS –TRANSMITTER ..................................................................................5-8
5.5.1 Radio control group........................................................................................................5-8
5.5.2 TX config group..............................................................................................................5-8
5.5.3 Interface config group ..................................................................................................5-11
5.5.4 Bite system group..........................................................................................................5-14
5.6 USER MENU –RECEIVER (RESTRICTED ACCESS LEVEL).......................................................5-15
5.7 USER MENU –RECEIVER (DEFAULT ACCESS LEVEL)............................................................5-16
5.8 SETTING,INFORMATION AND CONFIGURATION MENUS –RECEIVER....................................5-17
5.8.1 Radio control group......................................................................................................5-18
5.8.2 RX config group............................................................................................................5-18
5.8.3 Interface config group ..................................................................................................5-19
5.8.4 Bite system group..........................................................................................................5-20
5.8.5 System info group .........................................................................................................5-20
5.9 PARAMETER DETAILS –RECEIVER .......................................................................................5-21
5.9.1 Radio control group......................................................................................................5-21
5.9.2 RX config group............................................................................................................5-22
5.9.3 Interface config group ..................................................................................................5-23
5.9.4 Bite system group..........................................................................................................5-26
6ERROR CONDITIONS AND CORRECTIVE ACTIONS.....................................................6-1
6.1 TRANSMITTER ERROR CONDITIONS........................................................................................6-1
6.2 RECEIVER ERROR CONDITIONS...............................................................................................6-5
7LIST OF TABLES AND FIGURES..........................................................................................7-1
APPENDIX A. LIST OF MARITIME CHANNELS AND FREQUENCIES............................7-1

Jotron AS| TR7750C: Operators Manual Introduction
Page 1-1
P/N: 84748 (G)
1Introduction
1.1 Models covered by this manual
The following models / variants are covered by this operator’s manual
Model
P/N
Contain units
Output
Frequency
range
Modes
TR-7750C, Transceiver
X-84610
RA-7203C, TA-7650C,
PSU-7002
10 - 50 Watts
156-162 MHz
FM, (G3E)
TA-7650C, Transmitter
X-84555
TA-7650C,
PSU-7002
10 - 50 Watts
156-162 MHz
FM, (G3E)
RA-7203C, Receiver
X-84550
RA-7203C
N/A
156-162 MHz
FM, (G3E)
Table 1.1-1, Radio models
Throughout this manual the term transmitter unit, TX, TA-7650C refers to the transmitter unit.
The term transceiver, TR, TR-7750C refers to any variant of the transceiver unless specifically noted
in the text and the term receiver, RX and RA-7203C is used for the receiver unit.
1.2 Layout of the transceiver
The receiver unit, RA-7203C operates as an independent receiver. The transmitter unit TA-7650C
operates as an independent transmitter, but requires the power supply unit, PSU-7002 for operation
on AC power. The receiver and transmitter units may be placed in entirely different locations or
together when configured as a transceiver.
Figure 1.1, Complete Transceiver, RA-7203C, TA-7650C and PSU-7002
