Joy-it LINKERKIT OLED User manual

LINKERKIT OLED
for Raspberry Pi and Arduino
1. GENERAL INFORMATION
Dear customer,
thank you for choosing our product. In the following, we will show you how
to use your product.
Should you encounter any unexpected problems during use, please do not
hesitate to contact us.

2. CONNECTION TO RASPBERRY PI
If you want to connect the display directly with your device, the table shows
you the pin assignment.
1. connect the display
Use our LinkerKit sytem so that you can plug in the LinkerKit cable into the
I2C port like in the following picture.
pin name display pin name Raspberry Pi pin number Raspberry Pi
GND
VCC
SDA
SCL
GND
3V3
GPIO 02 / SDA1
GPIO 03 / SCL1
06
01
03
05
2. Activation of the I2C interface
To follow the following installation instructions without any deviations, we
recommend the operating system Raspbian (Buster) to use as an image.
First you have to edit the data le “cong.txt“. The following line must be
added at the end of the le.
dtparam=i2x_arm=on
conguration of the hardware initialization in the cong.txt

You can edit the le directly on the Raspberry with the following command:
sudo nano/boot/cong.txt
cong.txt can be edited directly on the Raspberry
With the key combination „Strg“ + „X“ and a following „Y“ and „Enter“ as a
conrmation, changes will be saved.
3.Installation of the Adafruit SSD1306 library
The developers of adafruit oer a library to control OLED displays with a
SSD1306 chipset. To use this library you must give the following commands
to install further but necessary modules:
(every command must be conrmed with “Enter“):
sudo apt-get update
sudo apt-get install build essential python-dev python-pip-y
sudo pip install RPi.GPIO
sudo apt-get install python-imaging python-smbus-y
If all modules are installed, the “Adafruit_Python_SSD1306“ library can be
installed with the following commands:
sudo apt-get install git
git clone https://github.com/adafruit/Adafruit_Python_SSD1306.git
cd Adafruit_Python_SSD1306
sudo python setup.py install

4. Application of code examples
In the adafruit library are some code examples. To invoke them, you rst
must switch to the example le with the following command.
cd examples
From there you can invoke the following commands:
show ticker
sudo python animate.py
show a little picture
sudo python image.py happycat_oled_64.ppm
show dierent shapes
sudo python shapes.py
3. CONNECTION TO ARDUINO
1. Connect the display
Use our LinkerKit sytem so that you can plug in the LinkerKit cable into the
I2C port like in the following picture.

If you want to connect the display directly with your device, the table shows
you the pin assignment.
pin name display pin name Arduino
GND
VCC
SDA
SCL
GND
5V
SDA
SCL
2.Installation of adafruit libraries
The developers of adafruit oer a library to control OLED displays with a
SSD1306 chipset.
Both libraries “Adafruit_SSD1306“ and “Adafruit-GFX-Library“ must be
downloaded, installed and edited.
Download:
Download the libraries with the following link as a Zip le:
Adafruit_SSD1306
https://github.com/adafruit/Adafruit_SSD1306
Adafruit-GFX-Library
https://github.com/adafruit/Adafruit-GFX-Library
Unzip:
The libraries must be unzipped in the Arduino library folder aer the
download. This folder can be usually found here:
C:\Benutzer\<BENUTZERNAME>\Dokumente\Arduino\libraries\
The path can change depending on the used Arduino installation.
Adjust:
Two les must be edited that the library can be used with the LinkerKit
OLED display. In...
...\libraries\Adafruit_SSD1306-master\Adafruit_SSD1306.h
must be the following lines:
61 --------------------------------------------------
62 // #dene SSD1306_128_64
63 #dene SSD1306_128_32
64 // #dene SSD1306_128_16
65 /* ===============================================

These must be changed like that:
61 --------------------------------------------------
62 #dene SSD1306_128_64
63 // #dene SSD1306_128_32
64 // #dene SSD1306_128_16
65 /* ===============================================
In
...\libraries\Adafruit_SSD1306-master\examples\ssd1306_128x64_i2c.ino
must be the following lines:
60 //by default, we‘ll generate the high voltage from the 3.3v line
internally! (neat!)
61 display.begin(SSD1306_SWITCHCAPVCC, 0x3D;
// initialize with the I2C addr 0x3D (for the 128x64)
62 // init done
These must be changed like that:
60 //by default, we‘ll generate the high voltage from the 3.3v line
internally! (neat!)
61 display.begin(SSD1306_SWITCHCAPVCC, 0x3C;
// initialize with the I2C addr 0x3D (for the 128x64)
62 // init done
3. Application of code examples
Now in the library contained code examples can be used . For that the
example program can be chosen directly in the Arduino program...

... and can be directly compiled and loaded on the Arduino.

5. SUPPORT
If any questions remain open or problems arise aer your purchase, we are
available by email, telephone and ticket support system to answer these.
E-Mail: [e-mail]
Ticket-System: http://support.joy-it.net
Telephone: [phone] – 66 (10 - 17 o‘clock)
For more information visit our website:
www.joy-it.net
www.joy-it.net
Simac Electronics Handel GmbH
Pascalstr. 8 47506 Neukirchen-Vluyn
Published: 31.07.2019
